SGFJS109WR1RF Wireless Game Bike Controller

A C Installing the Wireless controller 000000000 1Copyright© 2004 CATEYE Co., Ltd. CCBT-041126 #704-1300 Package Contents Check that the following items are included in the package. Mounting Batteries Loosen the four M5 screws and two M3 screws on the back of the wireless controller to remove the battery cover. Insert the 3 AAA batteries, being careful to orient the batteries correctly. Replace the battery cover and the M3 screws. Replace also the bracket and the M5 screws. GB-200 / GB-300 ReceiverController bracketWireless controller Battery cover M3 screw Controller bracket M5 screw Installing the handlebar and wireless controller Secure the handlebar, installation bracket and controller with the four cap bolts supplied. Handlebar unit Handlebar Handlebar installation bracket Connecting the wireless controller Insert the speed sensor cable plug (light blue) which extends from the handlebar post into the “S” jack on the wireless controller. Install the brake button onto the handlebar grip. Insert the cable plug (yellow) into the “B” jack on the wireless controller. Insert the connection cable plug into the “H” jack on the wireless controller. Insert the straight plug on the other end of the cable into the jack on the bottom of the handlebar unit. CautionDo not insert or remove the wireless control- ler connection plugs while the “Playstation2” power is on. Doing so may cause problems with the “Playstation2.” Brake button cable Cable from handlebar post Connection cable Connection cable Handlebar unit ENG See also “GAMEBIKE FITNESS” or “GAMEBIKE FITNESS PRO” instruction manual. Remove the controller Unplug the three plugs from the controller. CautionWhen unplugging the connectors, make sure that the “PlayStation2” is off. If the controller is held in place with a plastic bracket: Remove the existing bracket from the handlebar. Remove the cap bolts securing the handlebar installation bracket to the handlebar unit. Important: Use only the new cap bolts and controller bracket. If the controller is held in place with an L-shaped metal bracket: Loosen the four M6 cap bolts which fix the controller to the handlebar unit then remove the controller. Reference:Use only a new controller. Use only either a “PlayStation” or “PlayStation2” controller. Handlebar unit Handlebar Handlebar installation bracket M6 cap bolts Controller coverLR03 (AAA) battery x 3M6 x 30 cap bolts x 4 M6 x 30 cap bolts Installing the wireless controller ANALOG SELECTSTART STEERING LEVELSPEED LEVEL RL AC AC Steering sensitivity level control GAMEBIKE FITNESS PRO Wireless controller Cautions•Certain software packages whose packaging or documentation provides no indication of analog compliance or com- patibility will not work in analog mode. •Certain software packages will not switch mode even if the analog mode switch is pressed. In the case of certain software packages, the mode switches automatically. Important:Depending on the software, bike main unit controls sometimes take precedence on the gameplay screen and prevent operation of the wireless controller. Reference:This wireless controller can be used as a controller for “Playstation2”. In this case the sensitivity adjustment level con- trols will not be activated. L2 button L1 button SELECT button Direction key Signal from controller: When analog mode is OFF. Left-hand stick/L3 button Signal from controller: When analog mode is ON. Acceleration sensitivity level control R2 button R1 button START button Green button Pink button Brake signal Red button Blue button Right-hand stick/R3 button Analog mode switch AC button Power switch Green LED Mounting batteries in the wireless controller If the batteries are low, communication between the wireless controller and receiver cannot be carried out. Remove the wireless controller from the controller bracket, open the battery cover, and then place the 3 LR03 (AAA) batteries in position, being careful to orient the batteries correctly. CautionsDo no mix old and new batteries, or different types of batteries. Controller bracket Battery cover Wireless controller M5 screw M3 screw Controller Cover Care While using GAMEBIKE FITNESS PRO, the user may perspire/sweat while training. To prevent sweat from getting into the wireless controller, please use the controller cover provided. Please wash and dry after use. Controller cover Wireless controller Connecting the device to Playstation2 This controller is only used for “PlayStation 2”. Insert the receiver into the controller terminal on the front of the “PlayStation 2” main unit. For further information, also see the instruction manual of the “PlayStation 2”. A maximum of 16 wireless controllers can be used simultaneously. Important:If more than 2 wireless controllers are used simultaneously, the wireless controllers and receivers automatically specify their channels. If channel repetitions or interferences occur, it is necessary to reset the channels. CautionMake sure to insert or remove the receiver when the power to the “PlayStation 2” main unit has been turned off. Reference:It is possible for two players to play simultaneously by connecting two GAMEBIKE FITNESS PROs or connecting to a general controller. A C “Playstation2” unit Receiver 1P side 2P side AC button Resetting channels •If more than 2 wireless controllers are used, follow the steps below. 1.Turn off the power to all wireless controllers. 2.Turn on the power to one of the wireless controllers and press the AC button of the receiver. The green LEDs of the wireless controller and re ceiver light. 3.Repeat the same steps for the remaining wireless control- lers so that each receiver is set to the rel evant receiver. Checking the connecting condition between the wireless controller and receiver The connecting condition can be checked with the green LED of the wireless controller: If the green LED of the wireless controller or receiver lights, the condition is OK. If the green LED of the wireless controller or receiver blinks …

Text truncated - open the document above for the full version.

SN8P1707Q NRF2401 PS console 8MHz 16MHz Indicators

Test Setup FCC ID : SGFJS109WR1 External Photo - Front External Photo - Rear

2.4GHz Wireless Bicycle Receiver Module This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Model No: JS109WR1 506-109W0101B0 FCC ID: SGFJS109WR1 IC: 5297A-JS109WR1 2.4GHz Wireless Bicycle Receiver Module This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Model No: JS109WR1 506-109W0101B0 FCC ID: SGFJS109WR1 IC: 5297A-JS109WR1 44mm x 19mm 28mm x 20mm 2.4GHz Wireless Bicycle Controller Model No: JS109WT1 506-109W0101A0 FCC ID: SGFJS109WT1 IC: 5297A-JS109WT1 Battery: 3 x 1.5V AAA (LR03) 2.4GHz Wireless Bicycle Controller Model No: JS109WT1 506-109W0101A0 FCC ID: SGFJS109WT1 IC: 5297A-JS109WT1 Battery: 3 x 1.5V AAA (LR03)

Test Setup FCC ID : SGFJS109WR1 Internal Photo - 1 Internal Photo - 2 Test Setup FCC ID : SGFJS109WR1 Internal Photo - 3 Internal Photo - 4 Test Setup FCC ID : SGFJS109WR1 Internal Photo - 5

JS109W(NORDIC) CIRCUIT DESCRIPTION A. Receiver Section 1 Signal Dispose 1.1 PS2 console send the data to U2, MCU thru J1 and process it and input to RF module for transmission. 1.2 Y1 provide 8MHz clock so that U2 procedure go on. 1.3 U3 switch will request to change other frequency without being interferred when there is other same frequency interfering during working. 1.4 D1 on circuit show LED light when controller enter analog mode oppositely will be digita1 mode. 1.5 D2 on circuit show LED flash during connection or no signal input. The LED will illuminate upon finished connection. 2. RF module circuit 2.1 MCU in the module is generating GFSK signal, CRC adjustment and identifying ID code function and the 2.4GHz RF IC provide the modulation, transmit and receive function. 2.2 Y1 on module provide 16MHz clock for U1 so that firmed on normal frequency. 2.3 Receiving and transmitting appointed RF signal by C8 coupling and C10 filtering then through PCB antenna completed. Frequency Table (Frequency in GHz) CH1 2.414 CH2 2.418 CH3 2.422 CH4 2.426 CH5 2.430 CH6 2.434 CH7 2.438 CH8 2.442 CH9 2.446 CH10 2.450 CH11 2.454 CH12 2.458 CH13 2.462 CH14 2.466 CH15 2.470 CH16 2.474 PRELIMINARY PRODUCT SPECIFICATION Q5)6LQJOH&KLS*+]5DGLR7UDQVFHLYHU Nordic VLSI ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989 Revision: 1.0Page 1 of 31December 2002 Single chip 2.4 GHz Transceiver )($785(6$33/,&$7,216 • True single chip GFSK transceiver in a small 24-pin package (QFN24 5x5mm) • Wireless mouse, keyboard, joystick • Keyless entry • Data rate 0 to1Mbps• Wireless data communication • Only 2 external components• Alarm and security systems • Multi Channel operation • 125 channels • Support frequency hopping • Channel switching time <200μs. • Home Automation • Remote control • Surveillance • Automotive • Power supply range: 1.9 to 3.6 V• Telemetry • Address and CRC computation• Intelligent sports equipment • Shock Burst™ mode for ultra-low power operation • Industrial sensors • Toys • Simultaneous dual receiver topology • Low supply current (TX), typical 8mA peak @ -5dBm output power • Data slicer / clock recovery of data • 100% RF tested • No need for external SAW filter • Low supply current (RX), typical 15mA peak in receive mode • World wide use *(1(5$/'(6&5,37,21 nRF2401 is a single-chip radio transceiver for the world wide 2.4 - 2.5 GHz ISM band. The transceiver consists of a fully integrated frequency synthesizer, a power amplifier, a crystal oscillator and a modulator. Output power and frequency channels are easily programmable by use of the 3-wire interface. Current consumption is very low, only 8mA at an output power of -5dBm and 15mA in receive mode. Built-in Power Down modes makes power saving easily realizable. 48,&.5()(5(1&('$7$ 3DUDPHWHU9DOXH8QLW Minimum supply voltage1.9V Maximum output power0dBm Maximum GFSK data rate1000kbps Supply current GFSK in transmit @ -5dBm output power8mA Supply current GFSK in receive mode15mA Temperature range-40 to +85 ° C Sensitivity-85dBm Supply current in Power Down mode<1 μΑ Table 1 nRF2401 quick reference data Q5) PRELIMINARY PRODUCT SPECIFICATION Q5)6LQJOH&KLS*+]5DGLR7UDQVFHLYHU Nordic VLSI ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989 Revision: 1.0Page 2 of 31December 2002 7\SH1XPEHU'HVFULSWLRQ9HUVLRQ NRF2401 IC24 pin QFN 5x5A NRF2401-EVKITEvaluation kit (2 test PCB, 2 configuration PCB, SW)1.0 Table 2 nRF2401 ordering information %/2&.',$*5$0 DVDD VDD=3VVDD=3V DATA CS CLK1 3-wire interface Serial Programming Interface Frequency Synthesiser PA nRF Interface LNA PWR_UP VSS=0V XC1 XC2 400Ω IREF VDD_PS=1.8V VSS_PA=0V ANT1 ANT2 CE CLK2 DOUT2 DEMOD IF BPF 22kΩ VSS=0V VSS=0V VSS=3V DR2 DR1 VSS=0VVSS=0V Figure 1 nRF2401 with external components. PRELIMINARY PRODUCT SPECIFICATION Q5)6LQJOH&KLS*+]5DGLR7UDQVFHLYHU Nordic VLSI ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989 Revision: 1.0Page 3 of 31December 2002 3,1)81&7,216 3LQ 1DPH 3LQIXQFWLRQ 'HVFULSWLRQ 1CEDigital InputChip Enable Activates RX or TX mode 2DR2Digital OutputRX Data Ready at Channel#2 3CLK2Digital I/OClock Output/Input for RX Data Channel#2 4DOUT2Digital OutputRX Data Channel 2 5CSDigital InputChip Select Activates Configuration Mode 6DR1Digital OutputRX Data Ready at Channel#1 7CLK1Digital I/OClock Input (TX) & Output/Input (RX) for Channel#1 8DATADigital I/ORX Data Channel 1/TX Data Input/ 3-wire interface 9DVDDPowerPositive Digital Supply output for decoupling purposes 10VSSPowerGround (0V) 11XC2Analog OutputCrystal Pin 2 12XC1Analog InputCrystal Pin 1 13VDD_PAPower OutputPower Supply (+1.8V) to Power Amplifier 14ANT1RFAntenna interface 1 15ANT2RFAntenna interface 2 16VSS_PAPowerGround (0V) 17VDDPowerPower Supply (+3V DC) 18VSSPowerGround (0V) 19IREFAnalog InputReference current 20VSSPowerGround (0V) 21VDDPowerPower Supply (+3V DC) 22VSSPowerGround (0V) 23PWR_UPDigital InputPower Up 24VDDPowerPower Supply (+3V DC) Table 3 nRF2401 pin function 3,1$66,*10(17 DOUT2 AVDD DATA Q5) QFN24 5x5 DVDD AVDD PWR_UP AVSS ANT2 AVSS VSS_PA CLK1 CE 2322 21 24 987 4 3 2 1 18 17 16 6 5 VDD_PA ANT1 14 IREF AVSS 2019 1112 13 15 10 CS XC2XC1 DR1 DR2 CLK2 AVDDAVSS Figure 2. nRF2401 pin assignment (top view) for a QFN24 5x5 package. PRELIMINARY PRODUCT SPECIFICATION Q5)6LQJOH&KLS*+]5DGLR7UDQVFHLYHU Nordic VLSI ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989 Revision: 1.0Page 4 of 31December 2002 (/(&75,&$/63(&,),&$7,216 Conditions: VDD = +3V, VSS = 0V, T A = - 40ºC to + 85ºC 6\PERO 3DUDPHWHU FRQGLWLRQ 1RWHV 0LQ 7\S 0D[ 8QLWV 2SHUDWLQJFRQGLWLRQV VDDSupply voltage1.93.03.6V TEMPOperating Temperature-402785ºC 'LJLWDOLQSXWSLQ V IH HIGH level input voltageVDD- 0.3VDDV V IL LOW level input voltageVss0.3V 'LJLWDORXWSXWSLQ V OH HIGH level output voltage (I OH =-0.5mA)VDD- 0.3VDDV V OL LOW level output volt…

Text truncated - open the document above for the full version.

SCH-109WPN010102.sch-1 - Thu Oct 28 15:17:44 2004 SCH-109HPN060102.sch-1 - Thu Oct 28 15:16:16 2004

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2371 0521 Website: www.hk.intertek-etlsemko.com Techcorp Ltd. Application For Certification (FCC ID: SGFJS109WR1) RF Wireless Game Bike Controller (Receiver) 04218072 DL/ Sandy Lee February 8, 2005 INTERTEK TESTING SERVICES FCC ID: SGFJS109WR1 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information INTERTEK TESTING SERVICES FCC ID: SGFJS109WR1 ii MEASUREMENT/TECHNICAL REPORT Techcorp Ltd. - MODEL: JOYTECH JS109WR1 FCC ID: SGFJS109WR1 February 8, 2005 This report concerns (check one:) Original Grant X Class II Change Equipment Type: Low Power Transmitter (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [12-08-03 Edition] provision. Report prepared by: Derek Leung Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, Kowloon, Hong Kong. Phone: 852-2173-8539 Fax: 852-2371-0521 INTERTEK TESTING SERVICES FCC ID: SGFJS109WR1 iii Table of Contents 1.0 General Description..............................................................................................2 1.1 Product Description ..............................................................................................2 1.2 Related Submittal(s) Grants .................................................................................2 1.3 Test Methodology.................................................................................................3 1.4 Test Facility ..........................................................................................................3 2.0 System Test Configuration ...................................................................................5 2.1 Justification ..........................................................................................................5 2.2 EUT Exercising Software .....................................................................................5 2.3 Special Accessories .............................................................................................5 2.4 Equipment Modification ........................................................................................6 2.5 Measurement Uncertainty ....................................................................................6 2.6 Support Equipment List and Description ..............................................................6 3.0 Emission Results ..................................................................................................8 3.1 Field Strength Calculation ....................................................................................9 3.2 Radiated Emission Configuration Photograph ....................................................11 3.3 Radiated Emission Data.....................................................................................12 3.4 Conducted Emission Configuration Photograph .................................................15 3.5 Conducted Emission Data.......................................................................................16 4.0 Equipment Photographs .....................................................................................18 5.0 Product Labelling ................................................................................................20 6.0 Technical Specifications ....................................................................................22 7.0 Instruction Manual ..............................................................................................24 8.0 Miscellaneous Information .................................................................................26 8.1 Bandwidth Plot ...................................................................................................27 8.2 Discussion of Pulse Desensitization ...................................................................28 8.3 Calculation of Average Factor ............................................................................29 8.4 Emissions Test Procedures................................................................................30 INTERTEK TESTING SERVICES FCC ID: SGFJS109WR1 iv List of attached file Exhibit type File Description filename Test Report Test Report report.pdf Operation Description Technical Description descri.pdf Test Setup Photo Radiated Emission radiated photos.doc Test Setup Photo Conducted Emission conducted photos.doc Test Report Conducted Emission Test Result conducted.pdf Test Report Bandwidth Plot bw.pdf External Photo External Photo external photos.doc Internal Photo Internal Photo internal photos.doc Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf Test Report Timing Diagram timing.pdf INTERTEK TESTING SERVICES FCC ID: SGFJS109WR1 1 EXHIBIT 1 GENERAL DES…

Text truncated - open the document above for the full version.

Fundament a l emission (C hannel 1) : 34.8 dB μ V/m Attenuation : 32.97 dB Emission at 2388.6 M H z : (34.8 – 32.97) or 1.83 dB μ V/ m which is be low limit of 54.0 dB μ V/ m Fundament a l emission (Channel 16) : 35.0 dB μ V/m Attenuation : 27.06 dB Emission at 2486.8 M H z : (35.0 – 27.06) or 7.94 dB μ V/ m which is be low limit of 54.0 dB μ V/ m

Nordic Wireless PS2 Bike Game-Pad Data Transfer Description : 2004/12/17 Normal Transfer: Key data no change Key data change 9.3ms 9.3ms Remote 9.3ms Key data no change 200us (Max.) Dongle Yellow: Key Data. 1byte Preamble+5 bytes Adress+19 bytes Payload+1 bytes CRC: 0.8ms Blue: Motor Data. 1byte Preamble+5 bytes Addess+3bytes Payload+1 bytes CRC: 0.32ms Bit format: RZ code. 1us 1us “1” “0” Calculation of Average Factor For dongle, duty cycle = 0.32 / 9.3 = 0.035 Average factor = 20 x log10(0.035) = -29.1 dB

Report No.: 04218072 Ctrl No.:N/A PAGE 1 Tested By:Hong, Report No.:04218072 Scan Settings (1 Range) |--------- Frequencies -----------||----------- Receiver Settings ------------| Start Stop Step IF BW Detector M-Time Atten Preamp OpRge 150k 30M 5k 10k PK+AV 10ms AUTO LN OFF 60dB Final Measurement: x QP / + AV Meas Time: 1 s Subranges: 16 Acc Margin: 20dB Transducer No. Start Stop Name 21 9k 30M EW0698 0 10 20 30 40 50 60 70 80 90 dBuV 100 0.15 MHz 30110 F15Q F15A Report No.: 04218072 Ctrl No.:N/A Tested By:Hong, Report No.:04218072 Scan Settings (1 Range) |--------- Frequencies -----------||----------- Receiver Settings ------------| Start Stop Step IF BW Detector M-Time Atten Preamp OpRge 150k 30M 5k 10k PK+AV 10ms AUTO LN OFF 60dB Final Measurement Results: Frequency QP Level QP Limit MHz dBuV dBuV 0.17000 54.8 65.0 0.21000 39.5 63.2 0.29500 34.8 60.3 15.31500 37.3 60.0 15.59500 36.3 60.0 Frequency AV Level AV Limit MHz dBuV dBuV 0.17500 52.7 54.7 0.23000 45.0 52.4 0.35000 34.2 49.0 0.46500 27.8 46.6 2.67500 28.0 46.0 15.36500 31.6 50.0 15.48000 30.7 50.0 * limit exceeded

Test Setup FCC ID : SGFJS109WR1 Radiated Photo - Front Radiated Photo - Rear RADIATED Model No.: JS109WR1 Job No.: 04218072 RADIATED Model No.: JS109WR1 Job No.: 04218072

Test Setup FCC ID : SGFJS109WR1 Conduct Photo - 1 Conduct Photo - 2 Test Setup FCC ID : SGFJS109WR1 Conduct Photo - 3
