SGWIPS2007SSPMParking Meter with Data Collection

IPS Use Versi S Single er’s Ma on 1.0 I All inform e-Space anual IPS GROUP, Inc mation contained e Parki c. – M5 Manual ( d herein is consid ng Met (Ver. 1.0) dered confidentia ter M5: 560 1 E-mail: s Web: htt al IPS 1 Oberlin Dri San Die g Phone: (85 upport@ipsg p://www.ipsg S Group, Inc ive, Suite 10 go, CA 9212 58) 404-060 groupinc.com groupinc.com 1 c. 00 21 07 m m INFORMATION TO USER This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures. • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment IPS GROUP, Inc. – M5 Manual (Ver. 1.0) All information contained herein is considered confidential 2 TABLE OF CONTENTS INTRODUCTION ............................................................................................................... 4 BASIC METER OPERATION ............................................................................................ 5 Turning the Meter On and Off ..................................................................................... 5 Coins ........................................................................................................................... 5 Credit Cards ................................................................................................................ 5 Smart Cards ................................................................................................................ 6 PARKING METER FEATURES ........................................................................................ 7 Display ........................................................................................................................ 8 Idle/Expired ........................................................................................................ 9 Paid .................................................................................................................... 9 Faulty ................................................................................................................ 10 Prepay .............................................................................................................. 11 Payment Not Accepted ..................................................................................... 11 LEDs ......................................................................................................................... 11 No Parking/After Hours .................................................................................... 11 Idle/Expired ...................................................................................................... 11 Paid .................................................................................................................. 12 Out of Order ..................................................................................................... 12 Keypad ...................................................................................................................... 12 Diagnostics Button .................................................................................................... 13 Card Entry Slot / Card Payment ................................................................................ 13 Coin Entry Slot .......................................................................................................... 13 Payment Method Decal ............................................................................................. 14 Solar Panel ................................................................................................................ 14 Coin Validator ............................................................................................................ 14 RFID .......................................................................................................................... 14 Main Screen .............................................................................................................. 16 Faults ........................................................................................................................ 16 Coin Test ................................................................................................................... 17 Card Test .................................................................................................................. 17 Communications Test (Comms Test) ........................................................................ 18 Fault Logging ............................................................................................................ 19 Meter Swap ............................................................................................................... 19 Voltages ..........................................................................................................…

Text truncated - open the document above for the full version.

03/12/2013 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification FCC ID: SGWIPS2007SSPM Authority to Act as Agent On our behalf, I appoint Alan Laudani of Nemko USA Inc., 2210 Faraday Ave, STE 150, Carlsbad, CA, USA to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in Federal Communication Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc., still resides with 5601 Oberlin Drive San Diego,CA 92121 This appointment is in effect until July 1, 2013. Sincerely Gary J. Thomas Sr. RF Design Engineer IPS Group Inc.

03/11/2013 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Re: Request of Confidentiality for FCC ID#: SGWIPS2007SSPM Pursuant to Sections 0.457(d)(I)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below: Schematics, Parts List, Operating Description, Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(I)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Gary J. Thomas Sr. RF Design Engineer

03/15/2013 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Our communications 400MHz radios that are in our parking metering system do not co-transmit with our cellular radio. Our secure data is only transmitted after transactions have been made and uploaded after normal parking metered monitoring times of day. The main board 400MHz communication radio that resides in our upper head assembly within the parking meter housing and serves as our receiver and the cash canister which is located below this housed assembly functions as a transmitter. Sincerely, Gary J. Thomas Sr. RF Design Engineer

Card Reader Card reader Coin validator card Coin validator card Coin Validator assy LCD display Display board Expiry board Keypad NFS antenna RFID antenna Solar panel controller Validator Connector board

Nemko USA, Inc. 2210 Faraday Avenue, Suite 150 Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 FCC Part 15 Subpart C, 15.231: 29/03/2012 Certification Test Report In Accordance With: FCC Part 15 Subpart C, 15.225 Applicant: IPS Group Inc 5601 Oberlin Drive San Diego CA 92121 Equipment Under Test (EUT): Parking Meter Model: MK5 SSPM FCC ID: SGWIPS2007SSPM Tested By: Nemko USA Inc. 2210 Faraday Avenue, Suite 150 Carlsbad, CA 92008 Test Report Number: 2013 03231818 FCC2 Date: March 6, 2013 Project Number 10239592 NEX Number 231818 Total Number of Pages: 21 Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 Report Number: 2013 03231818 FCC2 FCC ID: SGWIPS2007SSPM Specification: FCC Part 15C, 15.225 Page 1 of 21 Applicant Affirmation Gary Thomas representing IPS Group Inc hereby affirms: a) That he/she has reviewed and concurs that the test shown in this report are reflective of the operational characteristics of the device for which certification is sought; b) That the devices in this test report will be representative of production units; c) That all changes (in hardware and software/firmware) to the subject device will be reviewed. d) That any changes impacting the attributes, functionality or operational characteristics documented in this report will be communicated to the body responsible for approving (certifying) the subject equipment. Gary Thomas Printed name of official Signature of official 5601 Oberlin Drive March 6, 2013 Address Date (858) 404-0607 [email protected] Telephone number Email address of official NOTE—This affirmation must be signed by the responsible party before it is submitted to a regulatory body for approval. Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 Report Number: 2013 03231818 FCC2 FCC ID: SGWIPS2007SSPM Specification: FCC Part 15C, 15.225 Page 2 of 21 Section 1. Summary of Test Results 1.1 General All measurements are traceable to national standards These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15; Subpart C. Radiated tests were conducted is accordance with ANSI C63.4-2003. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. The assessment summary is as follows: Apparatus Assessed: Parking Meter Model: MK5 SSPM Specification: FCC Part 15 Subpart C, 15.225 Date Received in Laboratory: February 25, 2013 Compliance Status: Complies Exclusions: None Non-compliances: None Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 Report Number: 2013 03231818 FCC2 FCC ID: SGWIPS2007SSPM Specification: FCC Part 15C, 15.225 Page 3 of 21 1.2 Report Release History REVISION DATE COMMENTS - January 13, 2010 Prepared By: Mark Phillips - January 13, 2010 Initial Release: Alan Laudani Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. Nemko USA Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. Mark Phillips, RF/EMC Test Engineer EMC/RF Test Engineer Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 Report Number: 2013 03231818 FCC2 FCC ID: SGWIPS2007SSPM Specification: FCC Part 15C, 15.225 Page 4 of 21 TABLE OF CONTENTS Applicant Affirmation 1 Section 1. Summary of Test Results 2 1.1 General 2 1.2 Report Release History 3 TABLE OF CONTENTS 4 Section 2: Equipment Under Test 5 2.1 Theory of Operation 5 2.2 Technical Specifications of the EUT 5 Section 3: Test Conditions 6 3.1 Specifications 6 3.2 Test Environment 6 3.3 Test Equipment 7 Section 4: Observations 7 4.1 Modifications Performed During Assessment 7 4.2 Record Of Technical Judgements 7 4.3 EUT Parameters Affecting Compliance 7 4.4 Tests Deleted 7 4.5 Additional Observations 7 4.6 Deviations From Laboratory Test Procedures 7 Section 5: Results Summary 8 5.1 Test Results 8 Appendix A: Test Results A1 Conducted Emissions A1 Occupied Bandwidth A2 Frequency Stability A4 Types of Momentary Signals AError! Bookmark not defined. Field Strength and Radiated Spurious Emissions A6 APPENDIX B B1 B. Radiated Emissions Measurement Uncertainties B1 APPENDIX C C1 C. Nemko USA, Inc. Test Equipment & Facilities Calibration Program C1 Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (760) 444-3500 Fax (760) 444-3005 Report Number: 2013 03231818 FCC2 FCC ID: SGWIPS2007SSPM Specification: FCC Part 15C, 15.225 Page 5 of 21 Section 2: Equipment Under Test 2.1 Theory of Operation firmware version 52.57.4 The MK5 SSPM is a Parking Meter. The operating frequencies are 410.610 MHz to 430.400 MHz and 13.56 MHz. The MK5 SSPM has firmware version 52.57.4. The EUT’s performance during test was evaluated against the performance criterion specified by applicable test standards. Performance results are detailed in the test results section of this report. Highest frequency generated or used: 430.4 MHz 2.2 Technical Specifications of the EUT Manufacturer: IPS Group Inc Operating Frequency: 13.56 MHz Measured Field Strength: 32.7 dBμV/m @ 10m Modulation: OOK Antenna Data: integral wire loop antenna Antenna Connector: NONE Power Source: 3.6V Internal Rechargeable Batteries Nemko USA, Inc. 2210 Faraday Avenue, Suite 150, Carlsbad, CA 92008 Phone (…

Text truncated - open the document above for the full version.

Momentary signals test, 15.231(e )
