SH5-CAPAccess Point With Two 802.11abg WLAN Cards

Miltope Corporation

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Oct 25, 2004
Application Purpose: Original Equipment
Date of Application: Oct 25, 2004
Equipment Note: Access Point With Two 802.11abg WLAN Cards
Frequency Range: 5745.00000000 - 5805.00000000
Company: Miltope Corporation
Country: United States
