SIO-NIAS10NIA.S10 (naviPlay iPod Adapter)

naviPlay™ Bluetooth ® Stereo Kit for iPod ® naviPlay Bluetooth iPod Adapter NIA.S10 naviPlay Bluetooth Stereo Remote NSR.H100 User’s Guide NaviPlay User’s Guide 2 of 27 Contents Introduction5 About Bluetooth5 Product Requirements5 Getting Started With the naviPlay iPod Adapter6 Getting Started With the naviPlay Stereo Remote8 Listening to Music With the naviPlay Bluetooth Stereo Kit9 Setting Up the naviPlay Bluetooth Stereo Kit9 Listening to Music Wirelessly10 Turning Off the naviPlay iPod Adapter and Remote11 Battery Charging12 Charging the naviPlay Stereo Remote12 Charging the naviPlay iPod Adapter12 Using the naviPlay iPod Adapter With Other Bluetooth Devices14 Using the naviPlay Stereo Remote With Other Bluetooth Music Devices15 Using the naviPlay iPod Adapter as a Dock for the IPod16 Upgrading Firmware17 Upgrading Firmware from a Bluetooth-Enabled Windows Computer17 Upgrading Firmware from a Bluetooth-Enabled Macintosh Computer17 Troubleshooting19 Appendix: Technical Specifications21 naviPlay Bluetooth iPod Adapter Model: NIA.S1021 naviPLay Bluetooth Stereo Remote Model: NSR.H10022 AC/DC Power Adapter23 Important Safety Information24 NaviPlay User’s Guide 3 of 27 AC/DC Adapter Power Supply24 Lithium Battery Safety Precautions25 Exposure to Radio Frequency Radiation25 FCC Part 15 Radio Frequency Interference Statement26 Industry Canada ICES-003 Emission Compliance Statement26 European Radio Approval Information26 CE Declaration of Conformity27 NaviPlay User’s Guide 4 of 27 © Copyright 2004 TEN Technology, Inc. All rights reserved. TEN Technology word mark, TEN Technology logo, naviPlay, and naviPod are trademarks of TEN Technology, Inc., registered in the US and other countries. Apple, the Apple logo, and iPod are trademarks of Apple Computer, Inc., registered in the US and other countries. Bluetooth is a trademark owned by Bluetooth SIG, Inc. USA, and licensed to TEN Technology, Inc. All other products or name brands are trademarks of their respective holders. Portions copyright © 2003-2004 Bluetooth Stereo headphone (iWISH) and adapter (iWISA) reference design licensed from Impulsesoft Pvt. Ltd. iWISH and iWISA are trademarks of Impulsesoft Pvt. Ltd. naviPlay Bluetooth Stereo Kit for iPod: User Guide 5 of 27 Introduction Congratulations on acquiring the TEN Technology naviPlay Bluetooth Stereo Kit for iPod – the first wireless Bluetooth product made specifically for the Apple iPod and iPod mini. The naviPlay iPod adapter and the naviPlay stereo remote together let you listen to music on your iPod wirelessly using Bluetooth at near-CD audio quality. In addition to supporting stereo audio, the naviPlay Remote provides wireless control of the iPod, including play/pause, next track and previous track, and volume. The naviPlay iPod adapter and the naviPlay Remote in the same naviPlay Kit are pre- paired at the factory to connect to each other automatically. Bluetooth The TEN Technology naviPlay Bluetooth iPod Adapter uses Bluetooth technology to provide near-CD- Audio quality (44.1 and 48 KHz, 16-bit) stereo audio streaming wirelessly from the Apple iPod to the naviPlay Remote. Bluetooth is a radio technology for short-range wireless mobility, eliminating cables, wires, or cords between enabled devices, such as mobile phones and headphones, and works over a range of 10 to 100 meters. Bluetooth facilitates fast, secure transmissions of both audio and data, even when the devices are not in line of sight of each other. The naviPlay devices are Bluetooth version 1.2 compliant, and support the Advanced Audio Distribution profile (A2DP) and Audio Video Remote Control profile (AVRCP). Requirements The naviPlay iPod Adapter requires an Apple iPod equipped with a Dock Connector – 3 rd generation iPod, 4 th generation Click Wheel iPod, or iPod mini models. There is no additional software or drivers to install. The naviPlay remote can be connected to standard stereo headphones, powered speakers, or stereo systems with a 3.5mm audio plug. naviPlay Bluetooth Stereo Kit for iPod: User Guide 6 of 27 Getting Started With the naviPlay iPod Adapter Figure 1: TEN naviPlay iPod adapter Recommendation: Please charge the naviPlay iPod Adapter for at least 1 hour before first using. Charging: Connect the Firewire iPod cable (included with the Apple iPod) to the dock connector on the back of the naviPlay iPod Adapter. Connect the Firewire plug to the included AC power supply, and connect the AC power supply to a standard electrical outlet. The Charge LED will glow constant red when charging and turn off once the battery is fully charged. Set Up: Select the appropriate clip for your iPod model. The clips are marked on the back to identify which iPod model it is made for. Attach clip to naviPlay iPod Adapter. Attach iPod: Slide your iPod into the clip. Before seating your iPod to the dock connector, adjust the battery pack position to align the dock connector – you may have to push the battery pack backwards or forwards relative to the base of the naviPlay iPod Adapter. Power on: Push the On/Off button once to turn on the naviPlay iPod Adapter. You should see the Status LED blink. Clip to secure iPod On/Off button Status LED Charge LED iPod dock connector naviPlay Bluetooth Stereo Kit for iPod: User Guide 7 of 27 naviPlay Bluetooth Stereo Kit for iPod: User Guide 8 of 27 Getting Started With the naviPlay Remote Figure 2: TEN naviPlay Remote Recommendation: Please charge the naviPlay Remote for at least 1 hour before first using. Charging: Connect the DC plug cable (attached to the included AC Power Supply) to the naviPlay Remote’s DC jack (opposite end from headphone jack). Connect the AC power supply to a standard electrical outlet. The Charge LED around the DC jack will glow constant red when charging and turn off once the battery is fully charged. Attach Headphones or speakers: Connect your headphones, powered speakers or stereo system to naviPlay Remote’s headphone jack. Power on: Push the On/Off button once…

Text truncated - open the document above for the full version.

Product Specification Product Specification Rufa 2.4 GHz SMD Antenna Rev : AE020157-D / Aug 18 2003 Rufa 2.4 GHz SMD Antenna 2 (10)Subject to changes without prior notice 1. FEATURES - Designed for 2.4 GHz (Bluetooth TM , WLAN 802.11b, Home RF) - Intended for SMD mounting - Supplied in tape on reel 2. DESCRIPTION - Mobile phones - PDA’s - Headsets - Laptops - PC- Cards - CF- Cards 3. APPLICATION The Rufa antenna is intended for use with all 2.4 GHz applications. The antenna requires a groundplane, i.e your device acts as an active part of the antenna and thus demand careful consideration concerning its placement TABLE OF CONTENT 1. Features ......................................................................................................................................................................... 2 2. Description ..................................................................................................................................................................... 2 3. Application ...................................................................................................................................................................... 2 4. Model names .................................................................................................................................................................. 3 5. General data ................................................................................................................................................................... 3 6. Electrical characteristics ................................................................................................................................................. 3 7. Electrical performance .................................................................................................................................................... 4 7.1 Voltage Standing Wave Ratio ............................................................................................................................... 4 7.2 3D-Radiation ........................................................................................................................................................ 4 7.3 Radiation patterns ................................................................................................................................................ 4 8. Antenna Dimensions ....................................................................................................................................................... 5 9. Antenna Foot print .......................................................................................................................................................... 5 10. Electrical interface ........................................................................................................................................................ 6 10.1 Transmission line and matching ......................................................................................................................... 6 10.2 Test board dimensions ....................................................................................................................................... 6 10.3 Test board matching ........................................................................................................................................... 6 11. Soldering ....................................................................................................................................................................... 6 11.1 Recomended soldering conditions ..................................................................................................................... 6 12. Reliability ...................................................................................................................................................................... 7 12.1 Temperature and Humidity ................................................................................................................................. 7 12.2 Mechanical ......................................................................................................................................................... 7 12.3 Miscellaneous .................................................................................................................................................... 7 12.4 Judgement standard .......................................................................................................................................... 7 13. Hazardous Material Reguration Conformance .............................................................................................................. 7 14. Application example ...................................................................................................................................................... 8 15. Packaging ..................................................................................................................................................................... 9 15.1 Shelf storage recommendation .......................................................................................................................... 9 15.2 Tape characteristics ........................................................................................................................................... 9 15.3 Reel dimension .................................................................................................................................................. 9 15.4 Box dimensions ................................................................................................................................................. 9 15.5 Bag properties ................................................................................................................................................... 9 15.6 Reel label i…

Text truncated - open the document above for the full version.

Corporate Headquarters: P.O.Box 1757,Fremont,CA 94538,USA •Tel:(510)623-1231 •Fax:(510)623-1434 •Email:[email protected] Asia/Pacific: Plot 18,Lrg Jelawat 4,Kawasan Perindustrian Seberang Jaya 13700,Prai,Penang,Malaysia •Tel:+604-3992909 •Fax:+604-3992903 Attn. Certification Manager NORTHWEST EMC 22975 Evergreen Pkwy, Suite 400 97124 Hillsboro, Oregon December 9, 2004 I would like to apply for an original FCC certification of the following product on behalf of TEN Technology, Inc.: Product name: Bluetooth naviPlay iPod Adapter Model number: NIA.S10 FCC ID : SIO-NIAS10 FRN number: 0011002722 The radio section of the Bluetooth naviPlay iPod Adapter, model NIA.S10 consists of a Power Class 2 (2.5 mW max.) Bluetooth radio with an internal antenna. It is fully compliant with the FCC Part 15 standard and Bluetooth 1.2 specifications. The following documents in PDF format (version 5.0) are included: NIA.S10.NorthwestEMC.FCC.cover.letter.doc” (this letter with hyperlinks to documents) TCB415 Contract TCB415 Schedules A and B TCB410 Application for Certification Agent Authorization Confidentiality Request FCC ID Label and Location External and Internal Photos EUT Information Operational Description Block Diagram Schematic Motherboard ASY90203 Schematic Control Board ASY90188 Antenna Info GigaRufa 3030A5839-01 User Guide - Draft RF Exposure Calculations FCC Test Report Please do contact me should you have any questions or need additional documentation. Best regards, Lubos Honzik Regulatory Compliance Engineer SMART Modular Technologies, Inc. 130 Katherine Court #4 San Antonio, TX 78209, USA Tel: (210) 824-4873 Email: [email protected]

Northwest EMC TCB Compliance Opinion Rev. 9/15/03 Smrm0001 Information about the Applicant Company Name TEN Technology, Inc. Grantee Thomas Hsiu Address 130 Katherien Court, #4 City, State, Zip San Antonio, TX 78209 Job Number SMRM0001 Model naviPlay iPod Adapter NIA.S10 FCC ID SIO-NIAS10 Agent Smart Modular Technologies, Inc. Approval Type Original Equipment Class DTS Digital Transmission System Rule Part 15.247 BlueTooth Overview The radio section of the Bluetooth naviPlay iPod Adapter, model NIA.S10 consists of a Power Class 2 (2.5 mW max.) Bluetooth radio with an internal antenna. It is fully compliant with the FCC Part 15 standard and Bluetooth 1.2 specifications. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. Signature TCB Committee 12/20/2004 Northwest EMC TCB Compliance Opinion Rev. 9/15/03 Smrm0001 Findings Opinions Specification Requirements Description 47 Cfr 2.1033(b)(3) Installation guide, operating instructions,user manual Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference User Manual.pdf Specification Requirements Description 47 Cfr 2.1033(b)(4) Operational description Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Operational Description.pdf Specification Requirements Description 47 Cfr 2.1033(b)(5) Frequency block diagram Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Block Diagram.pdf Specification Requirements Description 47 Cfr 2.1033(b)(6) Schematic diagram Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Schematics.pdf Specification Requirements Description 47 Cfr 2.1033(b)(7) Internal and external photos Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Internal Photos.pdf, External Photos.pdf Specification Requirements Description 47 Cfr 2.1033(b)(6) Conversions showing how the test results were achieved Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Schematics.pdf Northwest EMC TCB Compliance Opinion Rev. 9/15/03 Smrm0001 Specification Requirements Description Required Exhibit Test Setup Photo Exhibit Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Specification Requirements Description 47 Cfr 1.1307(b),2.1091,2.1093 RF Exposure Hazzard Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Specification Requirements Description 47 Cfr 15.19 Labeling Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference User Manual.pdf, Label.pdf Specification Requirements Description 47 Cfr 15.21 Information for user Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference User Manual.pdf Specification Requirements Description 47 Cfr 15.27 Special accessories Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Specification Requirements Description 47 Cfr 15.33 Frequency range of tests Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Specification Requirements Description 47 Cfr 15.35 Measurement detectors Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Northwest EMC TCB Compliance Opinion Rev. 9/15/03 Smrm0001 Specification Requirements Description ANSI C63.4 EUT Ports All EUT ports populated,emissions maximized,Antenna height adjusted Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Specification Requirements Description 47 Cfr 15.203 Antenna Requirements Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Specification Requirements Description 47 Cfr 15.205 Restricted bands Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Specification Requirements Description 47 Cfr 15.207 Power line Conducted emissions Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Specification Requirements Description 47 Cfr 15.209 Spurious Emissions Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Specification Requirements Description 47 Cfr 15.247(a) Occupied Bandwidth Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Specification Requirements Description 47 Cfr 15.247(b) Output Power Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Northwest EMC TCB Compliance Opinion Rev. 9/15/03 Smrm0001 Specification Requirements Description 47 Cfr 14.247(c) Band Edge Compliance Opinion The device meets the requirements of the rule. Discussion The client has provided the necessary exhibit. Reference Technical Report_7LAY0028.pdf Specification Req…

Text truncated - open the document above for the full version.

Corporate Headquarters: P.O.Box 1757,Fremont,CA 94538,USA •Tel:(510)623-1231 •Fax:(510)623-1434 •Email:[email protected] Asia/Pacific: Plot 18,Lrg Jelawat 4,Kawasan Perindustrian Seberang Jaya 13700,Prai,Penang,Malaysia •Tel:+604-3992909 •Fax:+604-3992903 1 of 1 Attn. Certification Manager NORTHWEST EMC 22975 Evergreen Pkwy, Suite 400 97124 Hillsboro, Oregon December 7, 2004 Subject:Confidentiality Request FCC ID:SIO-NIAS10 I would like to request confidentiality for the block diagram, schematics and operational descrip- tion of the TEN Technology’s Bluetooth naviPlay iPod Adapter, model NIA.S10 . The reason is, TEN Technology, Inc. wants to protect its IP and investments in this new technol- ogy. TEN Technology, Inc. doesn’t want to make the block diagram, schematics and operational description freely available to its competitors. Thank you for your understanding. Best regards, Lubos Honzik Regulatory Compliance Engineer

Bluetooth NaviPlay iPod Adapter Model NIA.S10 December 1, 2004 technology Front View Rear View

Bluetooth NaviPlay iPod Adapter Model NIA.S10 December 1, 2004 technology Product Labeling 95 mm 85 mm 46 mm 18 mm 35 mm 47 mm XX-XXXXX-XXXXX iPod Adapter Model No: NIA.S10 Patents Pending Designed in California Assembled in China Use only with SFEC ACDL–04 AC adapter Input: DC 12V 1.0A FCC ID SIO-NIAS10 IC: 5344A-NIAS10 v1.2 TEN Technology naviPlay BT ™ Size: 35 mm x 18 mm Label: White coated ESD-rated Pre-printed text and graphics: Pantone 429 CVC Barcode & serial number: Black

Bluetooth NaviPlay iPod Adapter Model NIA.S10 December 1, 2004 technology Open Enclosure PC80188 Rev. B0 and PC80203 Rev. A0 Printed Circuit Board Assemblies Bluetooth NaviPlay iPod Adapter Model NIA.S10 December 1, 2004 technology PC80188 Rev. B0 Assembly Top PC80188 Rev. B0 Assembly Bottom Bluetooth NaviPlay iPod Adapter Model NIA.S10 December 1, 2004 technology PC80203 Rev. A0 Assembly Top PC80203 Rev. A0 Assembly Bottom

Bluetooth naviPlay iPod Adapter Model NIA.S10 technology Estimate of RF Field Maximum Exposure OET Bulletin 65, Edition 97-1, August 1997 Calculations can be made to predict RF power density levels around typical RF sources. For example, in the case of a single radiating antenna, a prediction for power density in the far-field of the antenna can be made by use of the equation below. This equation is generally accurate in the far-field of an antenna but will over-predict power density in the near field, where it could be used for making a "worst case" or conservative prediction.: where: S = power density (in appropriate units, e.g. mW/cm 2 ) R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) EIRP = equivalent (or effective) isotropically radiated power (in appropriate units, e.g., mW) Power Density Calculations Using Maximum EIRP Value The Bluetooth naviPlay iPod Adapter, model NIA.S10, can classified as a Portable Device. As per 47 CFR §2.1091 Portable Devices have their radiating elements operating 20 cm or less from the body of the user or of a nearby person. FCC power density limit for MPE for General Population/ Uncontrolled Exposure is S max = 1.0 mW/cm 2 (OET Bulletin 65 Supplement C, Edition 97-01). The maximum EIRP of a Bluetooth Class 2 transmitter is 2.5 mW. The power density at the dis- tance of r = 2.5 cm from the antenna is: The power density of the Bluetooth naviPlay iPod Adapter transmitter at 2.5 cm distance is still 30 times less than the FCC exposure limit for General Population. The maximum power density of 1.0 mW/cm 2 would theoretically be exceeded at a distance of less than 4.5 mm: S EIRP 4πR 2 -------------- = W EIRP 4πr 2 -------------- 2.5 4π2.5 2 × ---------------------- 0.032mW cm 2 ⁄[]=== r EIRP 4πW -------------- 2.5 4π1.0× --------------------0.45cm[]===

7Layers for Smart Modular Technologies naviPlay iPod Adapter naviPlay Stereo Remote December 8, 2004 Report No. 7LAY0028 Report Prepared By www.nwemc.com 1-888-EMI-CERT © 2004 Northwest EMC, Inc 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Test Issue Date: December 8, 2004 Smart Modular Technologies Model NIA.S10 naviPlay iPod Adapter Model NSR.H100 naviPlay Stereo Remote Emissions Specification Test Method Pass Fail FCC 15.247(a) Occupied Bandwidth:2004 ANSI C63.4:2003 FCC 15.247(b) Output Power:2004 ANSI C63.4:2003 FCC 15.247(c) Band Edge Compliance:2004 ANSI C63.4:2003 FCC 15.247(c) Spurious Conducted Emissions:2004 ANSI C63.4:2003 FCC 15.247(c) Spurious Radiated Emissions:2004 ANSI C63.4:2003 FCC 15.247(d) Power Spectral Density:2004 ANSI C63.4:2003 FCC 15.207 AC Power Line Conducted Emissions:2004 ANSI C63.4:2003 Modifications made to the product See the Modifications section of this report Test Facility The measurement facilities used to collect the data is located at: Northwest EMC, Inc. 22975 NW Evergreen Parkway, Suite 400; Hillsboro, OR 97124 Phone: (503) 844-4066 Fax: 844-3826 Northwest EMC, Inc. 41 Tesla, Irvine, CA 92618 Phone: (949) 861-8918 Fax: 861-8923 The sites have been fully described in a report filed with and accepted by the FCC (Federal Communications Commission) and Industry Canada. Approved By: Don Facteau, IS Manager This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested, the specific description is noted in each of the individual sections of the test report supporting this certificate of test. Northwest EMC Revision History Revision 05/05/03 Revision Number Description Date Page Number 00 None Northwest EMC Accreditations and Authorizations Revision 04/01/04 FCC: Accredited by NVLAP for performance of FCC radio, digital, and ISM device testing. Our Open Area Test Sites, certification chambers, and conducted measurement facilities, have been fully described in reports filed with the FCC and accepted by the FCC in letters maintained in our files. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by the FCC as a Telecommunications Certification Body (TCB). This allows Northwest EMC to certify transmitters to FCC specifications in accordance with 47 CFR 2.960 and 2.962. NVLAP: Northwest EMC, Inc. is recognized under the United States Department of Commerce, National Institute of Standards and Technology, National Voluntary Laboratory Accreditation Program for satisfactory compliance with the requirements of ISO/IEC 17025 for Testing Laboratories. The NVLAP accreditation encompasses Electromagnetic Compatibility Testing in accordance with the European Union EMC Directive 89/336/EEC, ANSI C63.4, MIL-STD 461E, DO-160D and SAE J1113. Additionally, Northwest EMC is accredited by NVLAP to perform radio testing in accordance with the European Union R&TTE Directive 1999/5/EEC, the requirements of FCC, and the RSS radio standards for Industry Canada. Accreditation has been granted to Northwest EMC, Inc. under Certificate Numbers: 200629-0, 200630-0, and 200676-0. Industry Canada: Accredited by NVLAP for performance of Industry Canada RSS and ICES testing. Our Open Area Test Sites and certification chambers comply with RSS 212, Issue 1 (Provisional) and have been filed with Industry Canada and accepted. Northwest EMC has been accredited by ANSI to ISO / IEC Guide 65 as a product certifier. We have been designated by NIST and recognized by Industry Canada as a Certification Body (CB) per the APEC Mutual Recognition Arrangement (MRA). This allows Northwest EMC to certify transmitters to Industry Canada technical requirements. CAB: Designated by NIST and validated by the European Commission as a Conformity Assessment Body (CAB) to conduct tests and approve products to the EMC directive and transmitters to the R&TTE directive, as described in the U.S. - EU Mutual Recognition Agreement TÜV Product Service: Included in TUV Product Service Group's Listing of Recognized Laboratories. It qualifies in connection with the TUV Certification after Recognition of Agent's Testing Program for the product categories and/or standards shown in TUV's current Listing of CARAT Laboratories available from TUV. A certificate was issued to represent that this laboratory continues to meet TUV's CARAT Program requirements. Certificate No. USA0401C Northwest EMC Accreditations and Authorizations Revision 04/01/04 TÜV Rheinland: Authorized to carryout EMC tests by order and under supervision of TÜV Rheinland. This authorization is based on "Conditions for EMC- Subcontractors" of November 1992. NEMKO: Assessed and accredited by NEMKO (Norwegian testing and certification body) for European emissions and immunity testing. As a result of NEMKO's laboratory assessment, they will accept test results from Northwest EMC, Inc. for product certification (Authorization No. ELA 119). Technology International: Assessed in accordance with ISO Guide 25 defining the general international requirements for the competence of calibration and testing laboratories and with ITI assessment criteria LACO196. Based upon that assessment Interference Technology International, Ltd., has granted approval for specifications implementing the EU Directive on EMC (89/336/EEC and amendments). The scope of the approval was provided on a Schedule of Assessment supplied with the certificate and is available upon request. Australia/New Zealand: The National Association of Testing Authorities (NATA), Australia has been appointed by the ACA…

Text truncated - open the document above for the full version.

BLUETOOTH APPROVALS FCC Procedure Received from Joe Dichoso on 2-15-02 The following exhibit indicates the FCC Spread Spectrum requirements in Section 15.247 for devices meeting the Bluetooth Specifications in the 2.4 GHz band as of February 2001 operating in the USA. The purpose of this exhibit is to help expedite the approval process for Bluetooth devices. This exhibit provides items that vary for each device and also provides a list of items that are common to Bluetooth devices that explains the remaining requirements. The list of common items can be …

Text truncated - open the document above for the full version.
