SIP-0455-W27 MHz Transmitter

The applicant confirmed that confidentiality is not required for any exhibits. The Amendment report downloaded to web site.

The Label Location: 44mm 21mm 30mm 4mm

CIRCUIT DESCRIPTION Item no.: 0455 Moon Buggy Transmit Mode: When TX. Unit switch “on” Q2 and the crystal produce a transmit frequency. Press one of the key “F” “B” “L” “R’. The TX – IC give the encoded signal out and modulation to Q1. After amplifier the signal transmit out from antenna. Receiver Mode: The signal received from the antenna and pass to “Band pass filter”. After local oscillation and deflection, it detects the signal from Q1. The signal go to encoder the signal can control motor “Forward” “Backward” “Left” and “Right” “Q2 Q4 Q5” control forward. “Q3 Q6 Q7” control forward “Q8 Q10 Q11” control left “Q9 Q12 Q13” control right.

Report No.: SZEMO060100050RFF Page: 1 of 10 FCC ID: SIP-0455-W Authorized Signature: Robinson Lo Laboratory Manager This report refers to the General Conditions for Inspection and Testing Services, printed overleaf This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. Member of the SGS Group (SGS SA) SGS-CSTC Standards Technical Services Ltd. No.198 Kezhu Road, Science Town Economic& Technology Development District Guangzhou, China 510663 Telephone: +86 (0) 20 8215 5555 Fax: +86 (0) 20 8207 5059 Email: [email protected] FEDERAL COMMUNICATIONS COMMISSION Registration number: 282399 TEST REPORT Application No. : SZEMO060100050RF(SGS SZ NO.: SZTYR060100022/EL) Applicant: MEGAGAIN INTERNATIONAL LTD. FCC ID: SIP-0455-W Fundamental Frequency : 27.145MHz Equipment Under Test (EUT): Name: MOON BUGGY Model No.: Labelled Age Grading: Country of Origin: Country of Destination: 0455-W 3 + YEARS CHINA USA Standards: FCC PART 15, SUBPART C : 2004 Section 15.227 Date of Receipt: 10 January 2006 Date of Test: 11 January to 17 March 2006 Date of Issue: 21 March 2006 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. FCC ID: SIP-0455-W Report No.: SZEMO060100050RFF Page: 2 of 10 SGS-CSTC Standards Technical Services Ltd. 2 Test Summary Test Test Requirement Stanadard Paragraph Result Radiated Emission (30MHz to 1000MHz) FCC PART 15 :2004 Section 15.227 PASS Occupied Bandwidth FCC PART 15 :2004 Section 15.215 PASS Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radiated Frequency. The EUT passed the RE test after modifications specified below. 1, Changed L1 from 30pF to 10pF. 2, Added a 180pF capacitance Ca and a 680pF capacitance Cb detailed in the picture above. FCC ID: SIP-0455-W Report No.: SZEMO060100050RFF Page: 3 of 10 SGS-CSTC Standards Technical Services Ltd. 3 Contents Page 1 COVER PAGE ...........................................................................................................................................1 2 TEST SUMMARY....................................................................................................................................................2 3 CONTENTS..............................................................................................................................................................3 4 GENERAL INFORMATION...................................................................................................................................4 4.1 CLIENT INFORMATION.......................................................................................................................................4 4.2 DETAILS OF E.U.T............................................................................................................................................4 4.3 DESCRIPTION OF SUPPORT UNITS...................................................................................................................4 4.4 TEST LOCATION................................................................................................................................................4 4.5 OTHER INFORMATION REQUESTED BY THE CUSTOMER..................................................................................4 4.6 TEST FACILITY...................................................................................................................................................5 5 TEST RESULTS......................................................................................................................................................6 5.1 TEST INSTRUMENTS..........................................................................................................................................6 5.2 E.U.T. OPERATION...........................................................................................................................................6 5.3 TEST PROCEDURE & MEASUREMENT DATA.....................................................................................................6 5.3.1 Radiated Emissions...................................................................................................................................6 5.3.2 Occupied Bandwidth..............................................................................................................................8-9 FCC ID: SIP-0455-W Report No.: SZEMO060100050RFF Page: 4 of 10 SGS-CSTC Standards Technical Services Ltd. 4 General Information 4.1 Client Information Applicant Name: MEGAGAIN INTERNATIONAL LTD. Applicant Address: RM1908, GREENFIELD TOWER, CONCORDIA, PLAZA, 1, SCIENCE MUSEUM ROAD, T.S.T. EAST. KLN. 4.2 Details of E.U.T. EUT Name: MOON BUGGY Item No.: 0455-W Power Supply: 9.0V DC (1*9.0V ‘6F22’ Size Battery) for Tx. Power Cord: N/A- 4.3 Description of Support Units The EUT was tested as an independent unit: 27MHz radio transmitt…
