SMQUWM2WIFI module

EDAN INSTRUMENTS, INC.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 02, 2025
Application Purpose: Original Equipment
Equipment Note: WIFI module
Frequency Range: 2412.00000000 - 2462.00000000
Company: EDAN INSTRUMENTS, INC.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1/13 UWM2 PHYEvaluationTestUtility UserGuide TableofContents 1.Introduction ........................................................................................................................................ 2 2.TestSetupDetails ............................................................................................................................ 2 3.ApplicationUsage ........................................................................................................................... 3 3.1WiFiTxApplicationUsage ................................................................................................ 4 3.2WiFiRXApplicationUsage ............................................................................................... 9 FCCDeclaration .................................................................................................................................... 10 2/13 1.Introduction Thepurposeofthisdocumentistoprovidetheusageoftheapplicationsfortransmitand receiveteststoevaluatetheRFperformanceoftheUWM2usingatestdriverin windowsenvironment.Theevaluationboardprovidesthenecessaryconnectorssothat youcanmeasuretransmitandreceiveperformanceofthePHY,usingSpectrum AnalyzerandSignalGeneratorineither2.4GHz,5GHz. Ingeneral,transmitperformanceofaradiocanbeanalyzedinthreesteps. Maximumpower:TheusercanobservetheRFoutputpowerforagivenmaximumgain supportedbytheRF. EVM:TheusercanobservetheEVMforagivenratedRFpowerassupportedbytheRF transceiver. SpectralMask:TheusercanverifywhethertheUWM2modulemeetsthespectral maskrequirementsdefinedbyIEEEstandardforagivenmaximumRFoutputpower, inaparticularmodeofoperationlike11a,11b,11g,11acand11ax. ThereceiveperformanceofthePHYcanbeanalyzedusingPacketErrorRatio (PER)test. TheRxperformanceisanalyzedbythesensitivitiesatdifferentdatarates.In general,thesensitivityisobservedas10%PacketErrorRatio(PER)pointin 11a,11g,11acand11axand8%PERpointin11b. Thedocumentcontainsthreemajorsections. Section3.1describestheusageofthe‘WiFitransmit’utility,whichprovidesthe optionsforsettingvariousparameterstocarryouttransmittestsontheUWM2 device. Section3.2describestheusageofthe‘WiFireceive’utility,whichenablesthe usertoperformreceivetestsontheUWM2device. 2.TestSetupDetails Thediagramshownbelow,illustratesthetestsetupforevaluatingreceiveand transmitperformanceofUWM2WLANmodule. Asshowninthetestsetup,theUWM2evaluationboard(EVB)isconnecttopc viaUART.TheboardisconnectedtoaWLANsignalanalyzerthrougha microwavecoaxialcabletotesttheTxorRxperforman 3/13 Figure1:BasedRFEvaluationSetupInterface Followingdiagramillustratesvarioussoftwarecomponentsinvolvedinperforming TxandRxtestsusingspectrumanalyzerandsignalgeneratorrespectively. The‘transmit’utilityisacommandlineapplicationtoperformTxtests.Before runningtheTxtests,theuserisexpectedtoconnectUWM2moudletoasignal analyzerusingtheRFcable. The‘receive’utilityisalsoaseparatecommandlineapplicationthatcanbeused fordisplayingstatisticsonthereceivedpacketswhilecarryingoutthereceive sensitivitytests. 3.ApplicationUsage Ingeneral,beforeperforminganytestsconfigurethePHYtooperateinthe appropriateband.Thetransmittestscanbeperformedthroughautilitycalled ‘bcmdhd_active.sh’whichisfoundunder‘wifi’directory. Configurethefollowingparametersthroughthisapplicationbeforerunningthetests. Transmitpower Transmitdatarate Transmitmode Channelnumber 4/13 3.1WiFiTxApplicationUsage Theapplicationcanbestartedinthefollowingsteps: pluguartEVBintothedeviceandlabtop,checkthelabtop’sUARTnumberandsetSetup theserialporttoolPortland,sendthecommandviauarttools. 1、InstallPython3.9.10andupdatelibrary pipinstallpyserial pipinstallxmodem pipinstalltqdm pipinstallpyyaml 2、Downloadthetestfirmware. 3、SetUARTtool A、selectthecorrectnumber B、setthebaudrateto2000000 C、ClickOKenterthetestprogram. 4、Enterthe‘dstart15’ontoolintoRFtest. Txcommand 2.4GCH611B1Mtestcommand: set_chan600 5/13 set_rate012020 tx_mpdu020000x10000 x//xmeansstoptheTX 2.4GCH611B11Mtestcommand: set_chan600 set_rate0112020 tx_mpdu020000x10000 2.4GCH611G6Mtestcommand: set_chan600 set_rate062020 tx_mpdu020000x10000 2.4GCH611G54Mtestcommand: set_chan600 set_rate0542020 tx_mpdu020000x10000 2.4GCH611NHT20MCS0testcommand: set_chan600 set_rate202000 tx_mpdu020000x10000 2.4GCH611NHT20MCS7testcommand: set_chan600 set_rate272000 tx_mpdu020000x10000 2.4GCH611NHT40MCS0testcommand: set_chan610 set_rate204000 tx_mpdu020000x10000 2.4GCH611NHT40MCS7testcommand: set_chan610 set_rate274000 6/13 tx_mpdu020000x10000 2.4GCH611AXHE20MCS0testcommand: set_chan600 set_rate502000 tx_mpdu020000x10000 2.4GCH611AXHE20MCS11testcommand: set_chan600 set_rate5112000 tx_mpdu020000x10000 2.4GCH611AXHE40MCS0testcommand: set_chan600 set_rate504000 tx_mpdu020000x10000 2.4GCH611AXHE40MCS11testcommand: set_chan600 set_rate5114000 tx_mpdu020000x10000 5GCH3611A6Mtestcommand: set_chan3600 set_rate062020 tx_mpdu020000x10000 5GCH3611A54Mtestcommand: set_chan3600 set_rate0542020 tx_mpdu020000x10000 5GCH3611NHT20MCS0testcommand: set_chan3600 set_rate202020 7/13 tx_mpdu020000x10000 5GCH3611NHT20MCS7testcommand: set_chan3600 set_rate272020 tx_mpdu020000x10000 5GCH3811NHT40MCS0testcommand: set_chan3800 set_rate204020 tx_mpdu020000x10000 5GCH3811NHT40MCS7testcommand: set_chan3800 set_rate274020 tx_mpdu020000x10000 5GCH3611ACVHT20MCS0testcommand: set_chan3600 set_rate402000 tx_mpdu020000x10000 5GCH3611ACVHT20MCS7testcommand: set_chan3600 set_rate472000 tx_mpdu020000x10000 5GCH3811ACVHT40MCS0testcommand: set_chan3810 set_rate404000 tx_mpdu020000x10000 5GCH3811ACVHT40MCS7testcommand: set_chan3800 set_rate474020 tx_mpdu020000x10000 5GCH4211ACVHT80MCS0testcommand: 8/13 set_chan3210 set_rate408000 tx_mpdu020000x10000 5GCH4211ACVHT80MCS7testcommand: set_chan4200 set_rate478020 tx_mpdu020000x10000 5GCH3611AXHE20MCS0testcommand: set_chan3600 set_rate502000 tx_mpdu020000x10000 5GCH4211AXHE20MCS11testcommand: set_chan3600 set_rate5112000 tx_mpdu020000x10000 5GCH3811AXHE40MCS0testcommand: set_chan3810 set_rate504000 tx_mpdu020000x10000 5GCH4211AXHE40MCS11testcommand: set_c…

Text truncated - open the document above for the full version.

External Photos

FCCID:SMQUWM2Page 1 of 3 ReportNo.:CTL2506266011-WF ExternalPhotosofEUT FCCID:SMQUWM2Page 2 of 3 ReportNo.:CTL2506266011-WF FCCID:SMQUWM2Page 3 of 3 ReportNo.:CTL2506266011-WF WIFIAntenna

ID Label/Location Info

FCCID:SMQUWM2Page1of1ReportNo.:CTL2506266011-WF Size:L0.5cm*W0.5cm FCCID:SMQUWM2

Internal Photos

FCCID:SMQUWM2Page 1 of 2 ReportNo.:CTL2506266011-WF InternalPhotosofEUT FCCID:SMQUWM2Page 2 of 2 ReportNo.:CTL2506266011-WF

RF Exposure Info

ShenzhenCTLTestingTechnologyCo.,Ltd. Tel:+86-755-89486194E-mail:[email protected] RFExposureevaluation ReportReferenceNo.:CTL2506266011-WFH Compiledby: (position+printedname+signature) HappyGuo (Fileadministrators) Testedby: (position+printedname+signature) LydiaOu (TestEngineer) Approvedby: (position+printedname+signature) IvanXie (Manager) ProductName ................................. : WIFImodule Model/Typereference .................... :UWM2 ListModel(s)....................................:N/A TradeMark ....................................... : Medtronic FCCID...............................................: SMQUWM2 Applicant’sname...........................: EDANINSTRUMENTS,INC. Addressofapplicant ..................... : #15JinhuiRoad,JinshaCommunity,KengziSub-District, PingshanDistrict,518122ShenzhenP.R.China TestFirm...........................................: ShenzhenCTLTestingTechnologyCo.,Ltd. AddressofTestFirm.....................: Floor1-A,BaishaTechnologyPark,No.3011,ShahexiRoad, NanshanDistrict,Shenzhen,China518055 Testspecification...........................: Standard ............................................ : 47CFR§1.1310 47CFR§2.1093 KDB447498D01GeneralRFExposureGuidancev06 TRFOriginator..................................: ShenzhenCTLTestingTechnologyCo.,Ltd. MasterTRF ....................................... :Dated2011-01 Dateofreceiptoftestitem..........: Sept.04,2024 DateofTestDate............................: Sept.04,2024-Nov.03,2024 DateofIssue .................................... : Nov.04,2024 Result................................................: Pass ShenzhenCTLTestingTechnologyCo.,Ltd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe ShenzhenCTLTestingTechnologyCo.,Ltd.isacknowledgedascopyrightownerandsourceofthe material.ShenzhenCTLTestingTechnologyCo.,Ltd.takesnoresponsibilityforandwillnotassume liabilityfordamagesresultingfromthereader'sinterpretationofthereproducedmaterialduetoits placementandcontext. V1.0Page2of12ReportNo.:CTL2506266011-WFH RFExposureevaluationREPORT TestReportNo.:CTL2506266011-WFH Nov.04,2024 Dateofissue EquipmentunderTest: WIFImodule SampleNo:CTL250626601001 CTL250626601006 Model/Type:UWM2 ListedModels:N/A Applicant: EDANINSTRUMENTS,INC. Address: #15JinhuiRoad,JinshaCommunity,KengziSub-District, PingshanDistrict,518122ShenzhenP.R.China Manufacturer: EDANINSTRUMENTS,INC. Address: #15JinhuiRoad,JinshaCommunity,KengziSub-District, PingshanDistrict,518122ShenzhenP.R.China Thetestresultspresentedinthisreportrelateonlytotheobjecttested. Thisreportshallnotbereproduced,exceptinfull,withoutthewrittenapprovaloftheissuingtesting laboratory. V1.0Page3of12ReportNo.:CTL2506266011-WFH **ModifiedHistory** RevisionsDescriptionIssuedDataReportNo.Remark Version1.0InitialTestReportRelease2025-11-04CTL2506266011-WFHTracyQi V1.0Page4of12ReportNo.:CTL2506266011-WFH 1.GENERALINFORMATION 1.1.Environmentalconditions Duringthemeasurementtheenvironmentalconditionswerewithinthelistedranges: NormalTemperature:25°C-35°C RelativeHumidity:35%-55% AirPressure:101KPa 1.2.ProductInformation FCCID:SMQUWM2 ProductnameWIFImodule ModelnumberUWM2 PowersupplyDC5Vpowersupply ModulationType 2.4GWIFI: 802.11b:DSSS 802.11g/802.11n(H20)/802.11n(H40)/802.11ax(HEW20)/ 802.11ax(HEW40):OFDM 5GWIFI:OFDM AntennaTypeFPCAntenna AntennaGain 2.4GWIFI:3.31dBi 5GWIFI: BAND1:4.69dBi BAND2A:4.43dBi BAND2C:2.84dBi BAND3:1.37dBi HardwareversionV1.0 SoftwareversionV1.0 OperationFrequencyBand2.4GWIFI:2412-2462MHz 5GWIFI: 5180MHz-5240MHz 5260MHz-5320MHz 5500MHz-5700MHz 5745MHz-5825MHz Extremetemp.Tolerance-20°Cto+55°C Extremevol.Limits4.5VDCto5.5VDC(nominal:5.0VDC) ExposurecategoryGeneralpopulation/uncontrolledenvironment EUTTypeProductionUnit DeviceTypeMobileDevice V1.0Page5of12ReportNo.:CTL2506266011-WFH 1.3.TestFacility 1.3.1Addressofthetestlaboratory ShenzhenCTLTestingTechnologyCo.,Ltd. Floor1-A,BaishaTechnologyPark,No.3011ShahexiRoad,NanshanDistrict,Shenzhen,China 518055 Thereisone3msemi-anechoicchamberandtwolineconductedlabsforfinaltest.TheTestSitesmeet therequirementsindocumentsANSIC63.10andCISPR32/EN55032requirements. 1.3.2Laboratoryaccreditation Thetestfacilityisrecognized,certified,oraccreditedbythefollowingorganizations: A2LA-LabCert.No.4343.01 ShenzhenCTLTestingTechnologyCo.,Ltd,EMCLaboratoryhasbeenaccreditedbyA2LAfor technicalcompetenceinthefieldofelectricaltesting,andprovedtobeincompliancewithISO/IEC 17025:2017GeneralRequirementsfortheCompetenceofTestingandCalibrationLaboratoriesand anyadditionalprogramrequirementsintheidentifiedfieldoftesting. ICRegistrationNo.:9618B CABidentifier:CN0041 The3malternatetestsiteofShenzhenCTLTestingTechnologyCo.,Ltd.EMCLaboratoryhasbeen registeredbyInnovation,ScienceandEconomicDevelopmentCanadatotesttoCanadianradio equipmentrequirementswithRegistrationNo.:9618B. FCC-RegistrationNo.:399832 DesignationNo.:CN1216 ShenzhenCTLTestingTechnologyCo.,Ltd.EMCLaboratoryhasbeenregisteredandfullydescribed inareportfiledwiththe(FCC)FederalCommunicationsCommission.Theacceptanceletterfromthe FCCismaintainedinourfiles.Registration399832. 1.4.Statementofthemeasurementuncertainty Thedataandresultsreferencedinthisdocumentaretrueandaccurate.Thereaderiscautionedthat theremaybeerrorswithinthecalibrationlimitsoftheequipmentandfacilities.Themeasurement uncertaintywascalculatedforallmeasurementslistedinthistestreportacc.toCISPR16-4 “Specificationforradiodisturbanceandimmunitymeasuringapparatusandmethods–Part4: UncertaintyinEMCMeasurements“andisdocumentedintheShenzhenCTLTestingTechnologyCo., Ltd.qualitysystemacc.toDINENISO/IEC17025.Furthermore,componentandprocessvariabilityof devicessimilartothattestedmayresultinadditionaldeviation.Themanufacturerhasthesole responsibilityofcontinuedcomplianceofthedevice. HereafterthebestmeasurementcapabilityforCTLlaboratoryisreported: Test Measurement Uncertainty Notes Transmitterpowerconducted ±0.57dB (1) TransmitterpowerRadiated ±2.20dB (1) Conductedspuriousemission9KHz-40GHz ±1.60dB (1) OccupiedBan…

Text truncated - open the document above for the full version.

Test Report

SPECIFICATION FOR APPROVAL Customer Name Edan Customer Product Model NO. : Specification LD 2.4/5G WIFI MPN: LBS -037A (RD version) Manufacturer Shenzhen Bogesi Communication Technology Co., Ltd Approve Date 2025/9/9 Supplier Sign and SealCustomer Sign and Seal Note: 1. After the electronic file or paper file that has been stamped by BGS and was provided to the customer,, the customer need to sign the paper or electronic file of the approval back to BGS before place the formal order to BGS. If there is no formal change or change notice, BGS acquiesce that the customer approve and accept this specification of product . 2. The relevant intellectual property rights of this product are owned by Shenzhen Bogesi Communication Technology Co., Ltd. Without the permission of our BGS, please do not apply for patent rights for this product in other names, and please do not disclose this product and related information to others or provide to third -party for viewing and use. Application： Applied on the Edan's LD project Electrical specifications： Frequency band2.4/5.8GAntenna materialFPC Impedance50 Ω Antenna connect type Connector VSWR≤3.0PolarizationLinear polarization Gain（LD） Working Temperature-40°C～+85°C Storage Temperature+19°C～+23°C 2400-2500MHz:2.6dBi≤gain≤3.31dBi 5100-5825MHz:1.23dBi≤gain≤4.69dBi TRP&TIS: Test instrumentsTest MethodTest result BLUETEST.se RTS60 Chamber CMW5000 1.Assemble the antenna inside device 2. OTA RF test in anachoic chamber 3. Measuring TRP and TIS see the test data Test conditions and instruments Test instrumentsTest MethodTest result 7× 4× 3 anechoic chamber + Aglient E5071B Network analyzer 1.Assemble the antenna inside device 2. Put the device on the fixture in the chamber, and connect with the network analyzer 3. Test the passive test data using the test software see the test data ADD:Room 308, Block B, Sibiono Gene Therapy Park, NO. 19, 1st Science 12:02echnology Middle Road, Hi -Tech Industry Park(Middle), Nanshan District, Shenzhen LD Sample picture： ADD:Room 308, Block B, Sibiono Gene Therapy Park, NO. 19, 1st Science 12:02echnology Middle Road, Hi-Tech Industry Park(Middle), Nanshan District, Shenzhen Product Materials Ingredient Declaration Form Product Name LD 2.4/5G WIFI Model NO.LBS -037ADeclaration Date2025/9/9 No.Part name Homogeneous Material Name The homogeneous material contains the value of RoHS restricted substance（ppm）均质物料内含有RoHS限制物质的量值（ppm） Certification numberTest date CdPbHgCr+6PBBPBDE 1 FPC Electrolytic flexible copper-clad foil substrate 有胶柔性覆铜板 NDNDNDNDNDNDSHAEC240288090062024/12/20 2Solder resist inkNDNDNDNDNDNDETR255013832025/5/20 33M glueNDNDNDNDNDNDSHAEC240274809012024/12/6 4GoldNDNDNDNDNDNDA2250164855101001E2025/3/18 5BracketPCNDNDNDNDNDNDEKR24C005912025/1/2 Description: Material analysis expansion table is similar to our company's machine type BOM, which describes the composition of each material provided by the supplier, and then conducts RoHS control on each component (or the supplier shall conduct RoHS compliance management on his supplier, and provide tripartite inspection certificate). A complete material analysis expansion table that includes: 1. Material expansion table: component composition decomposition 2. Third-party verification report of each component

Test Report

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 E-mail: [email protected] TEST REPORT FCC PART 15.247 Report Reference No. ................ : CTL2506266011-WF01 Compiled by: ( position+printed name+signature) Happy Guo (File administrators) Tested by: ( position+printed name+signature) Lydia Ou (Test Engineer) Approved by: ( position+printed name+signature) Ivan Xie (Manager) Product Name ............................ : WIFI module Model/Type reference ................ : UWM2 List Model(s) ............................... : N/A Trade Mark .................................. : Medtronic FCC ID ......................................... : SMQUWM2 Applicant’s name ....................... : EDAN INSTRUMENTS, INC. Address of applicant ................. : #15 Jinhui Road, Jinsha Community, Kengzi Sub-District, Pingshan District,518122 Shenzhen P.R.China Test Firm ..................................... : Shenzhen CTL Testing Technology Co., Ltd. Address of Test Firm ................. : Floor 1-A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Test specification ....................... : Standard ...................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz. TRF Originator ............................. : Shenzhen CTL Testing Technology Co., Ltd. Master TRF .................................. : Dated 2011-01 Date of receipt of test item ........ : Sept. 04, 2024 Date of Test Date ........................ : Sept. 04, 2024-Nov. 03, 2024 Date of Issue .............................. : Nov. 04, 2024 Result .......................................... : Pass Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. V1.0 Page 2 of 32 Report No.: CTL2506266011-WF01 TEST REPORT Test Report No. : CTL2506266011-WF01 Nov. 04, 2024 Date of issue Equipment under Test : WIFI module Sample No : CTL250626601001 CTL250626601006 Model /Type : UWM2 Listed Models : N/A Applicant : EDAN INSTRUMENTS, INC. Address : #15 Jinhui Road, Jinsha Community, Kengzi Sub-District, Pingshan District,518122 Shenzhen P.R.China Manufacturer : EDAN INSTRUMENTS, INC. Address : #15 Jinhui Road, Jinsha Community, Kengzi Sub-District, Pingshan District,518122 Shenzhen P.R.China Test result Pass * * In the configuration tested, the EUT complied with the standards specified page 5. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the issuing testing laboratory. V1.0 Page 3 of 32 Report No.: CTL2506266011-WF01 ** Modified History ** Revisions Description Issued Data Report No. Remark Version 1.0 Initial Test Report Release 2025-11-04 CTL2506266011-WF01 Tracy Qi V1.0 Page 4 of 32 Report No.: CTL2506266011-WF01 Table of Contents Page 1. SUMMARY .................................................................................................................................................................... 5 1.1. TEST STANDARDS ........................................................................................................................................................... 5 1.2. TEST DESCRIPTION .............................................................................................................................................................. 5 1.3. TEST FACILITY ..................................................................................................................................................................... 6 1.4. STATEMENT OF THE MEASUREMENT UNCERTAINTY ..................................................................................................................... 7 2. GENERAL INFORMATION ............................................................................................................................................... 8 2.1. ENVIRONMENTAL CONDITIONS .............................................................................................................................................. 8 2.2. GENERAL DESCRIPTION OF EUT ............................................................................................................................................ 8 2.3. DESCRIPTION OF TEST MODES AND TEST FREQUENCY ................................................................................................................ 9 2.4. EQUIPMENTS USED DURING THE TEST ................................................................................................................................... 10 2.5. RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................................................... 10 2.6. MODIFICATIONS ............................................................................................................................................................... 11 3. TEST CONDITIONS AND RESULTS ................................................................................................................................. 12 3.1. CONDUCTED EMISSIONS TEST ............................................................................................................................................. 12 3.2. RADIATED EMISSIONS AND BAND EDGE ................................................................................................................................. 13 3.3. MAXIMUM CONDUCTED OUTPUT POWER ........................................................................…

Text truncated - open the document above for the full version.

Test Report

Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page1/57 ShenzhenCTLTestingTechnologyCo.,Ltd. Floor1-A,BaishaTechnologyPark,No.3011,ShahexiRoad,NanshanDistrict,Shenzhen,China518055 Tel:+86-755-89486194E-mail:[email protected] Annexfor2.4GWi-Fi TestReportNo.:CTL2506266011-WF01 TABLEOFCONTENTS 1.Bandwidth ............................................................................................................................................................. 3 1.1TestResult..................................................................................................................................................3 1.1.1OBW ................................................................................................................................................. 3 1.1.26dBBW............................................................................................................................................3 1.2TestGraph .................................................................................................................................................. 4 1.2.1OBW.................................................................................................................................................4 1.2.26dBBW..........................................................................................................................................13 2.MaximumConductedOutputPower .............................................................................................................. 22 2.1TestResult ............................................................................................................................................... 22 2.1.1Power.............................................................................................................................................22 3.MaximumPowerSpectralDensity..................................................................................................................23 3.1TestResult ............................................................................................................................................... 23 3.1.1PSD................................................................................................................................................23 3.2TestGraph ................................................................................................................................................ 24 3.2.1PSD................................................................................................................................................24 Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page2/57 4.UnwantedEmissionsInNon-restrictedFrequencyBands.........................................................................33 4.1TestResult...............................................................................................................................................33 4.1.1Ref .................................................................................................................................................. 33 4.1.2CSE................................................................................................................................................33 4.2TestGraph ................................................................................................................................................ 34 4.2.1Ref..................................................................................................................................................34 4.2.2CSE................................................................................................................................................43 Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page3/57 1.Bandwidth 1.1TestResult 1.1.1OBW Mode TX Type Frequency (MHz) RU RU Pos ANT 99%OccupiedBandwidth(MHz) Verdict ResultLimit 802.11bSISO 2412//114.717/Pass 2437//114.907/Pass 2462//114.818/Pass 802.11gSISO 2412//117.263/Pass 2437//117.440/Pass 2462//117.344/Pass 802.11n (HT20) SISO 2412//118.077/Pass 2437//118.294/Pass 2462//118.206/Pass 802.11n (HT40) SISO 2422//136.849/Pass 2437//137.208/Pass 2452//136.842/Pass 802.11ax (HEW20) SISO 2412SU/118.830/Pass 2437SU/119.026/Pass 2462SU/118.985/Pass 802.11ax (HEW40) SISO 2422SU/137.908/Pass 2437SU/138.154/Pass 2452SU/137.893/Pass 1.1.26dBBW Mode TX Type Frequency (MHz) RU RU Pos ANT 6dBBandwidth(MHz) Verdict ResultLimit 802.11bSISO 2412//113.153>=0.5Pass 2437//113.251>=0.5Pass 2462//113.202>=0.5Pass 802.11gSISO 2412//116.731>=0.5Pass 2437//116.799>=0.5Pass 2462//116.897>=0.5Pass 802.11n (HT20) SISO 2412//117.546>=0.5Pass 2437//117.788>=0.5Pass 2462//117.559>=0.5Pass 802.11n (HT40) SISO 2422//136.652>=0.5Pass 2437//136.900>=0.5Pass 2452//136.211>=0.5Pass 802.11ax (HEW20) SISO 2412SU/118.431>=0.5Pass 2437SU/118.641>=0.5Pass 2462SU/118.603>=0.5Pass 802.11ax (HEW40) SISO 2422SU/137.567>=0.5Pass 2437SU/137.784>=0.5Pass 2452SU/137.573>=0.5Pass Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page4/57 1.2TestGraph 1.2.1OBW 802.11b_LCH_2412MHz_Ant1(SISO)_NTNV 802.11b_MCH_2437MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page5/57 802.11b_HCH_2462MHz_Ant1(SISO)_NTNV 802.11g_LCH_2412MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page6/57 802.11g_MCH_2437MHz_Ant1(SISO)_NTNV 802.11g_HCH_2462MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page7/57 802.11n(HT20)_LCH_2412MHz_Ant1(SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page8/57 802.11n(HT20)_HCH_2462MHz_Ant1(SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page9/57 802.11n(HT40)_MCH_2437MHz_Ant1(SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1(SISO)_NTNV A…

Text truncated - open the document above for the full version.

Test Report

Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page37/57 802.11n(HT20)_LCH_2412MHz_Ant1(SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page38/57 802.11n(HT20)_HCH_2462MHz_Ant1(SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page39/57 802.11n(HT40)_MCH_2437MHz_Ant1(SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page40/57 802.11ax(HEW20)_LCH_2412MHz_SU_/_Ant1(SISO)_NTNV 802.11ax(HEW20)_MCH_2437MHz_SU_/_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page41/57 802.11ax(HEW20)_HCH_2462MHz_SU_/_Ant1(SISO)_NTNV 802.11ax(HEW40)_LCH_2422MHz_SU_/_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page42/57 802.11ax(HEW40)_MCH_2437MHz_SU_/_Ant1(SISO)_NTNV 802.11ax(HEW40)_HCH_2452MHz_SU_/_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page43/57 4.2.2CSE 802.11b_LCH_2412MHz_Ant1(SISO)_NTNV 802.11b_LCH_2412MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page44/57 802.11b_MCH_2437MHz_Ant1(SISO)_NTNV 802.11b_HCH_2462MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page45/57 802.11b_HCH_2462MHz_Ant1(SISO)_NTNV 802.11g_LCH_2412MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page46/57 802.11g_LCH_2412MHz_Ant1(SISO)_NTNV 802.11g_MCH_2437MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page47/57 802.11g_HCH_2462MHz_Ant1(SISO)_NTNV 802.11g_HCH_2462MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page48/57 802.11n(HT20)_LCH_2412MHz_Ant1(SISO)_NTNV 802.11n(HT20)_LCH_2412MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page49/57 802.11n(HT20)_MCH_2437MHz_Ant1(SISO)_NTNV 802.11n(HT20)_HCH_2462MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page50/57 802.11n(HT20)_HCH_2462MHz_Ant1(SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2506266011-WF01 FCCID:SMQUWM2 Page51/57 802.11n(HT40)_LCH_2422MHz_Ant1(SISO)_NTNV 802.11n(HT…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Huanhuan Xia

[email protected]Fax: 0086 755 26882223

Test Firm

Shenzhen CTL Testing Technology Co., Ltd.Tracy Qi

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	45.90 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Single Modular Approval. Output power listed is peak conducted. Grantee is responsible for providing specific testing instructions to host manufacturers for additional testing to verify compliance as a composite system. This includes retesting of transmitter module per part 15.31(h) and (k) and verification of compliance with FCC RF Exposure requirements. This module is restricted to installation in products for use only in mobile and fixed applications. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This device supports 802.11b, 802.11g, 802.11n and 802.11ax with a 20 MHz and 40 MHz bandwidth mode.
