SMQIT30Shenzhen CTL Testing Technology Co., Ltd.

Page 3 of 90 Report No.: AiTSZ-251208040FW1 ※ ※ Revision History ※ ※ REV.DESCRIPTIONISSUED DATEREMARK Rev.1.0Initial Test Report ReleaseDec. 18, 2025Jack Li Page 4 of 90 Report No.: AiTSZ-251208040FW1 TABLE OF CONTENTS 1.General Information............................................................................................6 1.1.RF exposure limits....................................................................................6 1.2.Statement of Compliance........................................................................7 1.3.EUT Description.......................................................................................8 1.4.Test specification(s)..................................................................................9 1.5.Ambient Condition...................................................................................9 1.6.Test Facility..............................................................................................9 2.SAR Measurement System.................................................................................10 2.1.SATIMO SAR Measurement Set-up Diagram.........................................10 2.2.Robot.....................................................................................................11 2.3.Probe......................................................................................................12 2.3.1.E-Field Probe Calibration.................................................................12 2.4.Phantoms...............................................................................................13 2.5.Technical Data........................................................................................14 2.6.Device Holder.........................................................................................15 2.7.Test Equipment List................................................................................16 3.SAR Measurement Procedures..........................................................................19 3.1.Power Reference....................................................................................19 3.2.Area scan & Zoom scan..........................................................................19 3.3.Description of interpolation/extrapolation scheme..............................21 3.4.Volumetric Scan.....................................................................................21 3.5.Power Drift.............................................................................................21 4.System Verification Procedure...........................................................................22 4.1.Tissue Verification..................................................................................22 4.1.1.Tissue Dielectric Parameter Check Results......................................23 4.2.System Verification Procedure..............................................................24 4.2.1.System Verification Results.............................................................25 5.SAR measurement variabilit...............................................................................26 6.SAR Measurement Uncertainty.........................................................................27 7.RF Exposure Positions........................................................................................28 7.1.Generic device.......................................................................................28 8.RF Output Power................................................................................................29 8.1.Wi-Fi & BT Output Power.......................................................................29 8.2.NFC.........................................................................................................31 9.Antenna Location...............................................................................................32 10.Stand-alone SAR test exclusion.......................................................................33 11.SAR Measurement Results..............................................................................34 12.Simultaneous Transmission Analysis..............................................................36 Appendix A. Photo documentation..........................................................................37 Appendix B. System Check Plots..............................................................................38 Page 5 of 90 Report No.: AiTSZ-251208040FW1 Appendix C. SAR Test Plots.......................................................................................49 Appendix D. Calibration Certificate..........................................................................60 Appendix E. Justification of the extended calibration..............................................89 Page 6 of 90 Report No.: AiTSZ-251208040FW1 1.General Information 1.1.RF exposure limits (A).Limits for Occupational/Controlled Exposure (W/kg) Whole-BodyPartial-BodyHands, Wrists, Feet and Ankles 0.48.020.0 (B).Limits for General Population/Uncontrolled Exposure (W/kg) Whole-BodyPartial-BodyHands, Wrists, Feet and Ankles 0.081.64.0 NOTE: Whole-Body SAR is averaged over the entire body, partial-body SAR is averaged over any 1 gram of tissue defined as a tissue volume in the shape of a cube. SAR for hands, wrists, feet and ankles is averaged over any 10 grams of tissue defined as a tissue volume in the shape of a cube. Occupational/Controlled Environments: Are defined as locations where there is exposure that may be incurred by people who are aware of the potential for exposure, (i.e. as a result of employment or occupation). General Population/Uncontrolled Environments: Are defined as locations where there is the exposure of individuals who have no knowledge or control of their exposure. NOTE TRUNK LIMIT 1.6 W/kg APPLIED TO THIS EUT Page 7 of 90 Report No.: AiTSZ-251208040FW1 1.2.Statement of Compliance The maximum results of Specific Abso…

Text truncated - open the document above for the full version.

Page 54 of 90 Report No.: AiTSZ-251208040FW1 #3 Date of measurement: 15/12/2025 A. Experimental conditions. Probe0523-EPGO-403 ConvF2.29 Area Scandx=10mm dy=10mm, Complete Zoom Scan7x7x12,dx=4mm dy=4mm dz=2.0mm,Complete PhantomValidation plane Device PositionBody BandU-NII-2c Channels/FrequencyHigh (134)/ frequency 5670.000 Mhz B. Permitivity Middle TX Frequency (MHz)5670.000 Relative permitivity (real part)35.600 Relative permitivity (imaginary part)16.200 Conductivity (S/m)5.103 C. SAR Surface and Volume SURFACE SARVOLUME SAR Maximum location: X=-21.00, Y=-2.00 ; SAR Peak: 0.95 W/kg D. SAR 1g & 10g SAR 10g (W/Kg)0.222 SAR 1g (W/Kg)0.454 Variation (%)3.660 Horizontal validation criteria: minimum distance (mm)11.313708 Vertical validation criteria: SAR ratio M2/M1 (%)69.462025 Page 55 of 90 Report No.: AiTSZ-251208040FW1 E. Z Axis Scan Z (mm)0.002.004.006.008.0010.0012.0014.0016.0018.0020.0022.00 SAR (W/Kg)0.8560.6320.4390.3710.2860.2410.2030.1870.1670.1680.1430.126 F. 3D Image 3D screen shotHot spot position Page 56 of 90 Report No.: AiTSZ-251208040FW1 #4 Date of measurement: 17/12/2025 A. Experimental conditions. Probe0523-EPGO-403 ConvF2.27 Area Scandx=10mm dy=10mm, Complete Zoom Scan7x7x12,dx=4mm dy=4mm dz=2.0mm,Complete PhantomValidation plane Device PositionBody BandU-NII-3 Channels/FrequencyLow (149)/ frequency 5745.000 Mhz B. Permitivity Middle TX Frequency (MHz)5745.000 Relative permitivity (real part)35.305 Relative permitivity (imaginary part)16.352 Conductivity (S/m)5.219 C. SAR Surface and Volume SURFACE SARVOLUME SAR Maximum location: X=-21.00, Y=-2.00 ; SAR Peak: 0.93 W/kg D. SAR 1g & 10g SAR 10g (W/Kg)0.225 SAR 1g (W/Kg)0.469 Variation (%)0.230 Horizontal validation criteria: minimum distance (mm)11.313708 Vertical validation criteria: SAR ratio M2/M1 (%)70.588235 Page 57 of 90 Report No.: AiTSZ-251208040FW1 E. Z Axis Scan Z (mm)0.002.004.006.008.0010.0012.0014.0016.0018.0020.0022.00 SAR (W/Kg)0.8980.6800.4800.4170.3140.2750.2290.2100.1740.1660.1550.135 F. 3D Image 3D screen shotHot spot position Page 58 of 90 Report No.: AiTSZ-251208040FW1 #5 Date of measurement: 8/12/2025 A. Experimental conditions. Probe0523-EPGO-403 ConvF2.38 Area Scandx=12mm dy=12mm, Complete Zoom Scan7x7x7,dx=5mm dy=5mm dz=5.0mm,Complete PhantomValidation plane Device PositionBody BandISM Channels/FrequencyHigh (11)/ frequency 2462.000 Mhz B. Permitivity Middle TX Frequency (MHz)2462.000 Relative permitivity (real part)39.214 Relative permitivity (imaginary part)13.210 Conductivity (S/m)1.807 C. SAR Surface and Volume SURFACE SARVOLUME SAR Maximum location: X=-24.00, Y=-1.00 ; SAR Peak: 1.06 W/kg D. SAR 1g & 10g SAR 10g (W/Kg)0.337 SAR 1g (W/Kg)0.647 Variation (%)0.210 Horizontal validation criteria: minimum distance (mm)10.000000 Vertical validation criteria: SAR ratio M2/M1 (%)44.884038 Page 59 of 90 Report No.: AiTSZ-251208040FW1 E. Z Axis Scan Z (mm)0.004.009.0014.0019.0024.0029.00 SAR (W/Kg)1.3640.7330.3290.2380.1250.1100.045 F. 3D Image 3D screen shotHot spot position Page 60 of 90 Report No.: AiTSZ-251208040FW1 Appendix D. Calibration Certificate Table of contents E Field Probe - EPGO0523-403 2450 MHz Dipole - SN 03/15 DIP 2G450-352 5000-6000 MHz Dipole - SN 03/14 WGA33 Page 61 of 90 Report No.: AiTSZ-251208040FW1 Page 62 of 90 Report No.: AiTSZ-251208040FW1 Page 63 of 90 Report No.: AiTSZ-251208040FW1 Page 64 of 90 Report No.: AiTSZ-251208040FW1 Page 65 of 90 Report No.: AiTSZ-251208040FW1 Page 66 of 90 Report No.: AiTSZ-251208040FW1 Page 67 of 90 Report No.: AiTSZ-251208040FW1 Page 68 of 90 Report No.: AiTSZ-251208040FW1 Page 69 of 90 Report No.: AiTSZ-251208040FW1 Page 70 of 90 Report No.: AiTSZ-251208040FW1 Page 71 of 90 Report No.: AiTSZ-251208040FW1 Page 72 of 90 Report No.: AiTSZ-251208040FW1 Page 73 of 90 Report No.: AiTSZ-251208040FW1 Page 74 of 90 Report No.: AiTSZ-251208040FW1 Page 75 of 90 Report No.: AiTSZ-251208040FW1 Page 76 of 90 Report No.: AiTSZ-251208040FW1 Page 77 of 90 Report No.: AiTSZ-251208040FW1 Page 78 of 90 Report No.: AiTSZ-251208040FW1 Page 79 of 90 Report No.: AiTSZ-251208040FW1 Page 80 of 90 Report No.: AiTSZ-251208040FW1 Page 81 of 90 Report No.: AiTSZ-251208040FW1 Page 82 of 90 Report No.: AiTSZ-251208040FW1

Page 83 of 90 Report No.: AiTSZ-251208040FW1 Page 84 of 90 Report No.: AiTSZ-251208040FW1 Page 85 of 90 Report No.: AiTSZ-251208040FW1 Page 86 of 90 Report No.: AiTSZ-251208040FW1 Page 87 of 90 Report No.: AiTSZ-251208040FW1 Page 88 of 90 Report No.: AiTSZ-251208040FW1 Page 89 of 90 Report No.: AiTSZ-251208040FW1 Appendix E. Justification of the extended calibration If dipoles are verified in return loss (<-20dB, within 20% of prior calibration for below 3GHz, and <-8dB, within 20% of prior calibration for 5GHz to 6GHz), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. <Head 2450MHz> Return Loss (dB) Delta (%)ImpedanceDelta(ohm) Date of Measurement -29.27-53.6-Feb. 21, 2024 -29.390.4153.7420.142Feb. 20, 2025 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Head 5200MHz> Return Loss (dB) Delta (%)ImpedanceDelta(ohm) Date of Measurement -9.64-25.80-Feb. 21, 2024 -9.18194.7525.8910.091Feb. 20, 2025 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Head 5400MHz> Return Loss (dB) Delta (%)ImpedanceDelta(ohm) Date of Measurement -14.01-51.53-Feb. 21, 2024 -14.16121.0851.8700.340Feb. 20, 2025 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Head 5600MHz> Return Loss (dB) Delta (%)ImpedanceDelta(ohm) Date of Measurement -16.83-44.12-Feb. 21, 2024 -16.98010.8944.8210.701Feb. 20, 2025 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Page 90 of 90 Report No.: AiTSZ-251208040FW1 <Head 5800MHz> Return Loss (dB) Delta (%)ImpedanceDelta(ohm) Date of Measurement -14.91-38.53-Feb. 21, 2024 -14.3493.7638.7150.185Feb. 20, 2025 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. ※※END OF THE REPORT※※

SPECIFICATION FOR APPROVAL Customer Name Edan Customer Product Model NO. : Specification iT30 2.4/5G WIFI MPN: LBS -050B (RA version) Manufacturer Shenzhen Bogesi Communication Technology Co., Ltd Approve Date 2026/1/13 Supplier Sign and SealCustomer Sign and Seal Note: 1. After the electronic file or paper file that has been stamped by BGS and was provided to the customer,, the customer need to sign the paper or electronic file of the approval back to BGS before place the formal order to BGS. If there is no formal change or change notice, BGS acquiesce that the customer approve and accept this specification of product . 2. The relevant intellectual property rights of this product are owned by Shenzhen Bogesi Communication Technology Co., Ltd. Without the permission of our BGS, please do not apply for patent rights for this product in other names, and please do not disclose this product and related information to others or provide to third -party for viewing and use. Room B308, Building B, Cybernaut GMP Factory, No. 19, Keji Zhongyi Road, Maling Community, Yuehai Street, Nanshan District, Shenzhen Application： Applied on the Edan's iT30 project Electrical specifications： Frequency band2.4/5.8GAntenna materialFPC+PET Impedance50Ω Antenna connect type Connector VSWR≤3.0PolarizationLinear polarization Gain 2400-2500MHz:4.68dBi≤gain≤5.98dBi Working Temperature-40°C～+85°C 5100-5800MHz:1.19dBi≤gain≤3.37dBi Storage Temperature+19°C～+23°C TRP&TIS: Test instrumentsTest MethodTest result BLUETEST.se RTS60 Chamber CMW5000 1.Assemble the antenna inside device 2. OTA RF test in anachoic chamber 3. Measuring TRP and TIS see the test data Test conditions and instruments Test instrumentsTest MethodTest result 7×4×3 anechoic chamber + Aglient E5071B Network analyzer 1.Assemble the antenna inside device 2. Put the device on the fixture in the chamber, and connect with the network analyzer 3. Test the passive test data using the test software see the test data Test data

ShenzhenCTLTestingTechnologyCo.,Ltd. Tel:+86-755-89486194E-mail:[email protected] TESTREPORT FCCPART15SUBPARTE15.407 ReportReferenceNo. .................... :CTL2412319011-WF03 Compiledby: (position+printedname+signature) HappyGuo (Fileadministrators) Testedby: (position+printedname+signature) LydiaOu (TestEngineer) Approvedby: (position+printedname+signature) IvanXie (Manager) ProductName.................................: TelemetryMonitor Model/Typereference .................... :iT30 ListModel(s)....................................:N/A TradeMark.......................................: EDAN FCCID ............................................... : SMQIT30 Applicant’sname...........................: EDANINSTRUMENTS,INC. Addressofapplicant ..................... : #15JinhuiRoad,JinshaCommunity,KengziSub-District, PingshanDistrict,518122ShenzhenP.R.China TestFirm...........................................: ShenzhenCTLTestingTechnologyCo.,Ltd. AddressofTestFirm.....................: Floor1-A,BaishaTechnologyPark,No.3011,ShahexiRoad, NanshanDistrict,Shenzhen,China518055 Testspecification...........................: Standard............................................: 47CFRFCCPart15SubpartE15.407 TRFOriginator..................................: ShenzhenCTLTestingTechnologyCo.,Ltd. MasterTRF ....................................... :Dated2011-01 Dateofreceiptoftestitem..........: Apr.30,2025 DateofTestDate ............................ : Apr.30,2025-Dec.04,2025 DateofIssue....................................: Dec.05,2025 Result................................................: Pass ShenzhenCTLTestingTechnologyCo.,Ltd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe ShenzhenCTLTestingTechnologyCo.,Ltd.isacknowledgedascopyrightownerandsourceofthe material.ShenzhenCTLTestingTechnologyCo.,Ltd.takesnoresponsibilityforandwillnotassume liabilityfordamagesresultingfromthereader'sinterpretationofthereproducedmaterialduetoits placementandcontext. V1.0Page2of52ReportNo.:CTL2412319011-WF03 TESTREPORT TestReportNo.:CTL2412319011-WF03 Dec.05,2025 Dateofissue EquipmentunderTest: TelemetryMonitor SampleNo:CTL2412319011 Model/Type: iT30 ListedModels : N/A Applicant:EDANINSTRUMENTS,INC. Address : #15JinhuiRoad,JinshaCommunity,Kengzi Sub-District,PingshanDistrict,518122Shenzhen P.R.China Manufacturer:EDANINSTRUMENTS,INC. Address : #15JinhuiRoad,JinshaCommunity,Kengzi Sub-District,PingshanDistrict,518122Shenzhen P.R.China TestresultPass* *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedpage5. Thetestresultspresentedinthisreportrelateonlytotheobjecttested. Thisreportshallnotbereproduced,exceptinfull,withoutthewrittenapprovaloftheissuingtesting laboratory. V1.0Page3of52ReportNo.:CTL2412319011-WF03 **ModifiedHistory** RevisionsDescriptionIssuedDataReportNo.Remark Version1.0InitialTestReportRelease2025-12-05CTL2412319011-WF03TracyQi V1.0Page4of52ReportNo.:CTL2412319011-WF03 TableofContentsPage 1.SUMMARY .............................................................................................................................................................................. 5 1.1.TESTSTANDARDS ............................................................................................................................................................ 5 1.2.TESTDESCRIPTION ............................................................................................................................................................... 5 1.3.TESTFACILITY ...................................................................................................................................................................... 6 1.4.STATEMENTOFTHEMEASUREMENTUNCERTAINTY ...................................................................................................................... 6 1.5.AUXILIARYTESTEQUIPMENTINFORMATION ............................................................................................................................... 7 2.GENERALINFORMATION ....................................................................................................................................................... 8 2.1.ENVIRONMENTALCONDITIONS ................................................................................................................................................ 8 2.2.GENERALDESCRIPTIONOFEUT ............................................................................................................................................. 8 2.3.DESCRIPTIONOFTESTMODESANDTESTFREQUENCY ................................................................................................................ 9 2.4.EQUIPMENTSUSEDDURINGTHETEST ................................................................................................................................... 10 2.5.RELATEDSUBMITTAL(S)/GRANT(S) ..................................................................................................................................... 11 2.6.MODIFICATIONS ................................................................................................................................................................. 11 3.TESTCONDITIONSANDRESULTS ......................................................................................................................................... 12 3.1.CONDUCTEDEMISSIONSTEST .............................................................................................................................................. 12 3.2.RADIATEDEMISSIONS ......................................................................................................................................................... 17 3.3.MAXIMUMCONDUCTEDAVERAGEOUTPUTPOWER ................................................................................................................ 45 3.4.POWERSPECTRALDENSITY ............................................................…

Text truncated - open the document above for the full version.

Annexfor5GWi-FiBAND1TestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30 Page1/24 ShenzhenCTLTestingTechnologyCo.,Ltd. Floor1-A,BaishaTechnologyPark,No.3011,ShahexiRoad,NanshanDistrict,Shenzhen,China518055 Tel:+86-755-89486194E-mail:[email protected] Annexfor5GWi-FiBAND1 TestReportNo.:CTL2412319011-WF03 TABLEOFCONTENTS 1.DutyCycle ............................................................................................................................................................. 3 1.1TestResult..................................................................................................................................................3 1.1.1Ant1..................................................................................................................................................3 1.2TestGraph .................................................................................................................................................. 4 1.2.1Ant1..................................................................................................................................................4 2.Bandwidth ............................................................................................................................................................. 8 2.1TestResult..................................................................................................................................................8 2.1.1OBW ................................................................................................................................................. 8 2.1.226dBBW..........................................................................................................................................8 2.2TestGraph .................................................................................................................................................. 9 2.2.1OBW.................................................................................................................................................9 2.2.226dBBW ....................................................................................................................................... 13 3.MaximumConductedOutputPower..............................................................................................................17 3.1TestResult...............................................................................................................................................17 Annexfor5GWi-FiBAND1TestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30 Page2/24 3.1.1Power.............................................................................................................................................17 4.MaximumPowerSpectralDensity..................................................................................................................18 4.1TestResult ............................................................................................................................................... 18 4.1.1PSD................................................................................................................................................18 4.2TestGraph ................................................................................................................................................ 19 4.2.1PSD................................................................................................................................................19 5.FrequencyStability............................................................................................................................................23 5.1TestResult ............................................................................................................................................... 23 5.1.1Ant1................................................................................................................................................23 Annexfor5GWi-FiBAND1TestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30 Page3/24 1.DutyCycle 1.1TestResult 1.1.1Ant1 Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) DutyCycle (%) DutyCycle CorrectionFactor(dB) Max.DC Variation(%) 802.11aSISO 51802.0642.19494.070.270.00 52002.0652.19494.120.260.07 52402.0652.19494.120.260.04 802.11n (HT20) SISO 51801.9202.04993.700.280.04 52001.9212.05093.710.280.00 52401.9222.05193.710.280.07 802.11n (HT40) SISO 51900.9451.07487.990.560.03 52300.9451.07487.990.560.03 Annexfor5GWi-FiBAND1TestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30 Page4/24 1.2TestGraph 1.2.1Ant1 802.11a_LCH_5180MHz_Ant1_NTNV 802.11a_MCH_5200MHz_Ant1_NTNV Annexfor5GWi-FiBAND1TestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30 Page5/24 802.11a_HCH_5240MHz_Ant1_NTNV 802.11n(HT20)_LCH_5180MHz_Ant1_NTNV Annexfor5GWi-FiBAND1TestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30 Page6/24 802.11n(HT20)_MCH_5200MHz_Ant1_NTNV 802.11n(HT20)_HCH_5240MHz_Ant1_NTNV Annexfor5GWi-FiBAND1TestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30 Page7/24 802.11n(HT40)_LCH_5190MHz_Ant1_NTNV 802.11n(HT40)_HCH_5230MHz_Ant1_NTNV Annexfor5GWi-FiBAND1TestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30 Page8/24 2.Bandwidth 2.1TestResult 2.1.1OBW Mode TX Type Frequency (MHz) ANT 99%OccupiedBandwidth(MHz) Verdict ResultLimit 802.11aSISO 5180117.384/Pass 5200117.295/Pass 5240117.425/Pass 802.11n (HT20) SISO 5180118.258/Pass 5200118.269/Pass 5240118.228/Pass 802.11n (HT40) SISO 5190135.922/Pass 5230135.883/Pass 2.1.226dBBW Mode TX Type Frequency (MHz) ANT 26dBBandwidth(MHz) Verdict ResultLimit 802.11aSISO 5180121.738/Pass 5200121.469/Pass 5240121.892/Pass 802.11n (HT20) SISO 5180122.112/Pass 5200122.237/Pass 5240122.944/Pass 802.11n (HT40) SISO 5190138.928/Pass 5230139.325/Pass Annexfor5GWi-FiBAND1TestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30 Page9/24 2.2TestGraph 2.2.1OBW 802.11a_LCH_5180MHz_Ant1_NTNV 802.11a_MCH_5200MHz_Ant1_NTNV Annexfor5GWi-FiBAND1TestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30…

Text truncated - open the document above for the full version.

Annexfor5GWi-FiBAND2ATestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30 Page1/24 ShenzhenCTLTestingTechnologyCo.,Ltd. Floor1-A,BaishaTechnologyPark,No.3011,ShahexiRoad,NanshanDistrict,Shenzhen,China518055 Tel:+86-755-89486194E-mail:[email protected] Annexfor5GWi-FiBAND2A TestReportNo.:CTL2412319011-WF03 TABLEOFCONTENTS 1.DutyCycle ............................................................................................................................................................. 3 1.1TestResult..................................................................................................................................................3 1.1.1Ant1..................................................................................................................................................3 1.2TestGraph .................................................................................................................................................. 4 1.2.1Ant1..................................................................................................................................................4 2.Bandwidth ............................................................................................................................................................. 8 2.1TestResult..................................................................................................................................................8 2.1.1OBW ................................................................................................................................................. 8 2.1.226dBBW..........................................................................................................................................8 2.2TestGraph .................................................................................................................................................. 9 2.2.1OBW.................................................................................................................................................9 2.2.226dBBW ....................................................................................................................................... 13 3.MaximumConductedOutputPower..............................................................................................................17 3.1TestResult...............................................................................................................................................17 Annexfor5GWi-FiBAND2ATestReportNo.:CTL2412319011-WF03 FCCID:SMQIT30 Page2/24 3.1.1Power.............................................................................................................................................17 4.MaximumPowerSpectralDensity..................................................................................................................18 4.1TestResult ............................................................................................................................................... 18 4.1.1PSD................................................................................................................................................18 4.2TestGraph ................................................................................................................................................ 19 4.2.1PSD.......................................…

Text truncated - open the document above for the full version.
