SMUKT6898YCWIRELESS DOOR CHIME

SAFETY AND USE MANUAL Brief Account THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATIONIS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. The Device Data Product: Wireless Door Chime Frequency: 433.768MHz Power: A23, 12V Use Description The ultra-distance remote control (30metres long) meets the need of various buildings. And The doorbell must match the device to use. Part Description 1. Pushbutton 2. Pilot lamp 3. Battery Press the key “1”, the doorbell will make the combination of the quadric-partial tone. When the key “1” is pressed, the pilot lamp will light and it will go out as soon as the key is released. Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Be sure not to let it close to any metal object or expose it to rains.

button electrify the circuit 2262 code output signal sound surface filter H 10 working pilot lamp coruscates INPUT: 120V 60Hz FUNDAMENTAL OPERATION FREQUENCY IS 433.768 MHz

F IGURE 1 W IRELESS D OOR C HIME (M/N: KT6898Y-C) G ENERAL A PPEARANCE (F RONT V IEW ) F IGURE 2 W IRELESS D OOR C HIME (M/N: KT6898Y-C) G ENERAL A PPEARANCE (R EAR V IEW )

Label Location Information Refer to the below red arrow: (For example)

Kangtai Product: Wireless Door Chime Model: KT6898Y-C Frequency: 433.768MHz FCC ID: SMUKT6898YC

Operational description for KT6898Y-C Wireless Door Chime 1. What the KT6898Y-C does? KT6898Y-C is a portable wireless remote control. It can control the receiver, which is away from the remote controller 30meters long. The receiver can make the combination of the quadric-partial tone. 2. Block Diagram Step: 1) The button makes the IC and Triode work. 2) The IC (HX 2262) modulates the carrier. The triode amplifies the signal. 3) Pin 16 of the dip switches that is connected to pin 1 of the IC Board is linked the ground. It can generate the signal to let the receiver ring (The receiver can ring only when the connection method of the transmitter is same to the receiver’s and the receiver will not work if the connection method are different between the receiver and transmitter). The inbuilt antenna generates RF signal. 4) The oscillator generates carrier in 433.768MHz. 3. Specification: 1) Type of modulation: Pulse 2) Pulse cycle: 46.40ms 3) Duty cycle: 11.61dB 4) Antenna: Amplify RF signal. 5) Ground: The negative pole of battery is grounding. Button (1) Oscillator (4) IC (HX 2262) (2) Triode (2) Antenna (3) Triode (2) Dip Switches (3)

APPENDIX F ORM OF C OMPONENTS

Zhejiang Kangtai Electric Co., Ltd. FCC ID: SMUKT6898YC Page 1 of 23 Audix Technology (Shanghai) Co., Ltd. Report No.ACI-F04082 Prepared For : Zhejiang Kangtai Electric Co., Ltd. No.5 Kangtai Road Huanghua Industrial District, Yueqing, Zhejiang, China Prepared By : Audix Technology (Shanghai) Co., Ltd. 3 F 34 Bldg 680 Guiping Rd., Caohejing Hi-Tech Park, Shanghai, China 200233 Tel : +86-21-64955500 Fax : +86-21-64955491 Report No. : ACI-F04082 Date of Test : Oct 10-Nov 06, 2004 Date of Report : Nov 06, 2004 Application for FCC Certification On behalf of Zhejiang Kangtai Electric Co., Ltd. Wireless Door Chime Model No.: KT6898Y-C Serial No.: F04091001 FCC ID : SMUKT6898YC Zhejiang Kangtai Electric Co., Ltd. FCC ID: SMUKT6898YC Page 2 of 23 Audix Technology (Shanghai) Co., Ltd. Report No.ACI-F04082 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 4 1.3 Measurement Uncertainty .......................................................................................................... 4 2 RADIATED EMISSION TEST....................................................................................................... 5 2.1 Test Equipment........................................................................................................................... 5 2.2 Block Diagram of Test Setup ..................................................................................................... 5 2.3 Radiated Emission Limit ............................................................................................................ 6 2.4 Test Configuration...................................................................................................................... 6 2.5 Operating Condition of EUT ...................................................................................................... 6 2.6 Test Procedures .......................................................................................................................... 6 2.7 Test Results ................................................................................................................................ 7 3 FUNDAMENTAL AND SPURIOUS EMISSIONS TEST ......................................................... 11 3.1 Test Equipment......................................................................................................................... 11 3.2 Block Diagram of Test Setup ................................................................................................... 11 3.3 Fundamental and Spurious Emission Limit ............................................................................. 11 3.4 Test Configuration.................................................................................................................... 12 3.5 Operating Condition of EUT .................................................................................................... 12 3.6 Test Procedures ........................................................................................................................ 12 3.7 Test Results .............................................................................................................................. 13 4 BANDWIDTH MEASUREMENT................................................................................................ 17 4.1 Test Equipment......................................................................................................................... 17 4.2 Bandwidth Limit....................................................................................................................... 17 4.3 Test Results .............................................................................................................................. 17 5 OPERATION DESCRIPTION ..................................................................................................... 17 APPENDIX I Plot of the Pulse Train........................................................................................... 18 APPENDIX II Plot of the Occupied Bandwidth......................................................................... 21 Zhejiang Kangtai Electric Co., Ltd. FCC ID: SMUKT6898YC Page 3 of 23 Audix Technology (Shanghai) Co., Ltd. Report No.ACI-F04082 TEST REPORT FOR FCC CERTIFICATION Applicant : Zhejiang Kangtai Electric Co., Ltd. Manufacturer : Zhejiang Kangtai Electric Co., Ltd. EUT Description : Wireless Door Chime (A) Model No. : KT6898Y-C (B) Serial No. : F04091001 (C) Power Supply : 12V DC (D) Crystal Frequency : 433.768MHz Test Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART C JULY 2003 AND ANSI C63.4:2001 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C limits radiated emission. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT (M/N: KT6898Y-C; S/N: F04091001), which was tested in 3m anechoic chamber on Oct 10-Nov 06, 2004 to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report contains data that are not covered by the NVLAP accreditation. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal gove…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Radiated Emission Test F RONT V IEW OF T EST B ACK V IEW OF T EST S ETUP WITH M AXIMUM D ETECTED E MISSION AT H ORIZONTAL P OLARIZATION S ETUP WITH M AXIMUM D ETECTED E MISSION AT V ERTICAL P OLARIZATION 2. Fundamental And Spurious Emissions Test L OW F REQUENCY AT H ORIZONTAL P OLARIZATION (L YING D IRECTION ) L OW F REQUENCY AT V ERTICAL P OLARIZATION (L YING D IRECTION ) L OW F REQUENCY AT H ORIZONTAL P OLARIZATION (S IDE D IRECTION ) L OW F REQUENCY AT V ERTICAL P OLARIZATION (S IDE D IRECTION ) L OW F REQUENCY AT H ORIZONTAL P OLARIZATION (S TAND D IRECTION ) L OW F REQUENCY AT V ERTICAL P OLARIZATION (S TAND D IRECTION ) H IGH F REQUENCY AT H ORIZONTAL P OLARIZATION (L YING D IRECTION ) H IGH F REQUENCY AT V ERTICAL P OLARIZATION (L YING D IRECTION ) H IGH F REQUENCY AT H ORIZONTAL P OLARIZATION (S IDE D IRECTION ) H IGH F REQUENCY AT V ERTICAL P OLARIZATION (S IDE D IRECTION ) H IGH F REQUENCY AT H ORIZONTAL P OLARIZATION (S TAND D IRECTION ) H IGH F REQUENCY AT V ERTICAL P OLARIZATION (S TAND D IRECTION )
