SMUKT6898YDWIRELESS DOOR CHIME

USE MANUAL Brief Account THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATIONIS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. The Device Data Product: Wireless Door Chime Frequency: 433.768MHz Power: A23, 12V Use Description The ultra-distance remote control (30metres long) meets the need of various buildings. And the doorbell must match the device to use. Part Description 1. Pushbutton 2. Pilot Lamp 3. Battery Press the key “1”, the doorbell will make the combination of the quadric-partial tone. When the key “1” is pressed, the pilot lamp will light and it will go out as soon as the key is released. Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Be sure not to let it close to any metal object or expose it to rains. Description of the circuits Schematic Operation specification for remote controller 2262 is a coding integration element, it’s pins No. 1-8 are used for users, so the code can be coded discretionally by dip switches (but it should be consist with the mainframe code). When user operates the remote controller, press the switch, then power supply is gotten, and circuit works. 2262 sends code from pin 17 to shooting module with impulse form. According to the signal, H 10 at shooting module works. Then the signal is sent over. This is so-called coding.

button electrify the circuit 2262 code output signal sound surface filter H 10 working pilot lamp coruscates INPUT: 120V 60Hz FUNDAMENTAL OPERATION FREQUENCY IS 433.768 MHz

F IGURE 1 W IRELESS D OOR C HIME (M/N: KT6898Y-D) G ENERAL A PPEARANCE (F RONT V IEW ) F IGURE 2 W IRELESS D OOR C HIME (M/N: KT6898Y-D) G ENERAL A PPEARANCE (R EAR V IEW )

Label Location Information Refer to the below red arrow: (For example)

Kangtai Product: Wireless Door Chime Model: KT6898Y-D Frequency: 433.768MHz FCC ID: SMUKT6898YD

F IGURE 1 W IRELESS D OOR C HIME (M/N: KT6898Y-D) C OVER R EMOVED F IGURE 2 W IRELESS D OOR C HIME (M/N: KT6898Y-D) M AIN B OARD (C OMPONENT S IDE ) F IGURE 3 W IRELESS D OOR C HIME (M/N: KT6898Y-D) M AIN B OARD (S OLDERED S IDE )

Operational description for KT6898Y-D Wireless Door Chime 1. What the KT6898Y-D does? KT6898Y-D is a portable wireless remote control. It can control the receiver, which is away from the remote controller 30meters long. The receiver can make the combination of the quadric-partial tone. 2. Block Diagram Step: 1) Push the button and it will make the IC (HX 2262) and Triode work. At the same time, the LED lights. 2) The IC modulates the carrier. The signal generated by oscillator (The oscillator generates carrier in 433.768 MHz.) and the code generated by the IC is sent from pin 17 to the base of the Triode. 3) The Triode magnifies the signal comes from IC to the inbuilt antenna. 4) The inbuilt antenna generates RF signal. 3. Specification: 1) Type of modulation: Pulse 2) Pulse cycle: 56.40ms 3) Duty cycle: 9.54dB 4) Antenna: Amplify RF signal. 5) Ground: The negative pole of battery is grounding. Button Oscillator IC (HX 2262) Triode (2) Antenna Triode Dip Switches

APPENDIX F ORM OF C OMPONENTS

Zhejiang Kangtai Electric Co., Ltd. FCC ID: SMUKT6898YD Page 1 of 23 Audix Technology (Shanghai) Co., Ltd. Report No.ACI-F04090 Prepared For : Zhejiang Kangtai Electric Co., Ltd. No.5 Kangtai Road Huanghua Industrial District, Yueqing, Zhejiang, China Prepared By : Audix Technology (Shanghai) Co., Ltd. 3 F 34 Bldg 680 Guiping Rd., Caohejing Hi-Tech Park, Shanghai, China 200233 Tel : +86-21-64955500 Fax : +86-21-64955491 Report No. : ACI-F04090 Date of Test : Oct 10-Oct 18, 2004 Date of Report : Oct 20, 2004 Application for FCC Certification On behalf of Zhejiang Kangtai Electric Co., Ltd. Wireless Door Chime Model No.: KT6898Y-D Serial No.: F04091002 FCC ID : SMUKT6898YD Zhejiang Kangtai Electric Co., Ltd. FCC ID: SMUKT6898YD Page 2 of 23 Audix Technology (Shanghai) Co., Ltd. Report No.ACI-F04090 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 4 1.3 Measurement Uncertainty .......................................................................................................... 4 2 RADIATED EMISSION TEST....................................................................................................... 5 2.1 Test Equipment........................................................................................................................... 5 2.2 Block Diagram of Test Setup ..................................................................................................... 5 2.3 Radiated Emission Limit ............................................................................................................ 6 2.4 Test Configuration...................................................................................................................... 6 2.5 Operating Condition of EUT ...................................................................................................... 6 2.6 Test Procedures .......................................................................................................................... 6 2.7 Test Results ................................................................................................................................ 7 3 FUNDAMENTAL AND SPURIOUS EMISSIONS TEST ......................................................... 11 3.1 Test Equipment......................................................................................................................... 11 3.2 Block Diagram of Test Setup ................................................................................................... 11 3.3 Fundamental and Spurious Emission Limit ............................................................................. 11 3.4 Test Configuration.................................................................................................................... 12 3.5 Operating Condition of EUT .................................................................................................... 12 3.6 Test Procedures ........................................................................................................................ 12 3.7 Test Results .............................................................................................................................. 13 4 BANDWIDTH MEASUREMENT................................................................................................ 17 4.1 Test Equipment......................................................................................................................... 17 4.2 Bandwidth Limit....................................................................................................................... 17 4.3 Test Results .............................................................................................................................. 17 5 OPERATION DESCRIPTION ..................................................................................................... 17 APPENDIX I Plot of the Pulse Train........................................................................................... 18 APPENDIX II Plot of the Occupied Bandwidth......................................................................... 21 Zhejiang Kangtai Electric Co., Ltd. FCC ID: SMUKT6898YD Page 3 of 23 Audix Technology (Shanghai) Co., Ltd. Report No.ACI-F04090 TEST REPORT FOR FCC CERTIFICATION Applicant : Zhejiang Kangtai Electric Co., Ltd. Manufacturer : Zhejiang Kangtai Electric Co., Ltd. EUT Description : Wireless Door Chime (A) Model No. : KT6898Y-D (B) Serial No. : F04091002 (C) Power Supply : 12V DC (D) Crystal Frequency : 433.768MHz Test Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART C JULY 2003 AND ANSI C63.4:2001 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C limits radiated emission. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT (M/N: KT6898Y-D; S/N: F04091002), which was tested in 3m anechoic chamber on Oct 10-Oct 18, 2004 to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report contains data that are not covered by the NVLAP accreditation. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal gove…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Radiated Emission Test F RONT V IEW OF T EST B ACK V IEW OF T EST S ETUP WITH M AXIMUM D ETECTED E MISSION AT H ORIZONTAL P OLARIZATION S ETUP WITH M AXIMUM D ETECTED E MISSION AT V ERTICAL P OLARIZATION 2. Fundamental And Spurious Emissions Test L OW F REQUENCY AT H ORIZONTAL P OLARIZATION (L YING D IRECTION ) L OW F REQUENCY AT V ERTICAL P OLARIZATION (L YING D IRECTION ) L OW F REQUENCY AT H ORIZONTAL P OLARIZATION (S IDE D IRECTION ) L OW F REQUENCY AT V ERTICAL P OLARIZATION (S IDE D IRECTION ) L OW F REQUENCY AT H ORIZONTAL P OLARIZATION (S TAND D IRECTION ) L OW F REQUENCY AT V ERTICAL P OLARIZATION (S TAND D IRECTION ) H IGH F REQUENCY AT H ORIZONTAL P OLARIZATION (L YING D IRECTION ) H IGH F REQUENCY AT V ERTICAL P OLARIZATION (L YING D IRECTION ) H IGH F REQUENCY AT H ORIZONTAL P OLARIZATION (S IDE D IRECTION ) H IGH F REQUENCY AT V ERTICAL P OLARIZATION (S IDE D IRECTION ) H IGH F REQUENCY AT H ORIZONTAL P OLARIZATION (S TAND D IRECTION ) H IGH F REQUENCY AT V ERTICAL P OLARIZATION (S TAND D IRECTION )
