SO7-208B0001Pella Insynctive Bridge

Bridge Integrated Entry Door Sensor Integrated Patio Door Sensor Integrated Window Sensor Universal Window and Door Sensor Garage Door Sensor Pella ® Insynctive ® Product Guide Sensor Details and Setup Insynctive ® Product Guide | 2 3 General and Safety Information • Need Help? • Home Automation • Warnings 4 Product Specifications 6 Bridge • Detailed Instructions • Additional Instructions • Troubleshooting 9 Integrated Entry Door Sensor • Detailed Instructions • Additional Instructions • Troubleshooting 16 Integrated Patio Door Sensor • Detailed Instructions • Additional Instructions • Troubleshooting 21 Integrated Window Sensor • Detailed Instructions • Additional Instructions • Troubleshooting 25 Universal Window and Door Sensor • Detailed Instructions • Additional Instructions • Troubleshooting 29 Garage Door Sensor • Detailed Instructions • Additional Instructions • Troubleshooting 33 FCC Compliance and Industry Canada 33 Limited Warranty 33 Software License Agreement and Privacy Policy Table of Contents Insynctive ® Product Guide | 3 Need Help? For instant access to warranties, troubleshooting information and videos, visit Pella.CustHelp.com or call 855-473-5524. Pella Insynctive products can be used with the free Pella Insynctive App or with a compatible home automation system. Home Automation Compatibility. To view a list of compatible systems and find instructions on how to pair Pella ® Insynctive ® products, visit ConnectPella.com or call 855-473-5524. Failure to adhere to the warnings below may result in death, serious injury and/or loss of valuables. Pella Insynctive products are not 100% reliable for a variety of reasons. For example, products: — communicate data wirelessly, and wireless data is susceptible to interference or failure. — require proper installation. — may be damaged after installation. — require a battery with an adequate charge. — require proper pairing. — may indicate a closed or locked status when a window or door is not completely closed. Therefore, Pella Insynctive products should not be relied upon in situations where life, safety and/or protection of valuables are solely dependent on their function. Test each product at least once per year to help ensure proper operation. • Use caution when windows are open and when removing a transmitter to avoid a fall out of a window. Keep children and pets away from open windows. • BRIDGE may be connected to a non-Pella product such as a compatible home automation system. All systems are subject to compromise or failure to warn for a variety of reasons. Review and comply with the information for the system that is connected with BRIDGE. • Pella Insynctive products are not a substitute for careful adult supervision of children. • Keep battery and other small parts out of the reach of children. If small parts are swallowed, immediately seek medical help. • Use only Pella-provided power supply and cord for BRIDGE. Failure to do so may result in damage to BRIDGE that would not be covered by the warranty. • Batteries carry the risk of fire, explosion and burns. Do not recharge, disassemble or incinerate. • SENSORS may indicate a window or door is closed, but water intrusion may occur during rain. Windows and doors should be closed and locked for optimal performance in rain. General and Safety Information Insynctive ® Product Guide | 4 Bridge Frequency: 433.92MHz (Insynctive ® ) Operating Temperature: 32° to 120°F (0°to 49°C) Operating Humidity: 5% to 95% RH noncondensing Enrollment Capacity: 128 devices Power Supply and Cord: 5VDC, 1A — only use provided power supply Indoor Use Only FCC ID: SO7-208B0000 IC ID: 11009A-208B0000 Integrated Entry Door Sensor Frequency: 433.92MHz (Insynctive) Operating Temperature: -22° to 140°F (-30° to 60°C) Operating Humidity: 5% to 95% RH noncondensing Lock Sensor Battery: 3V lithium CR2032 Open/Close Sensor Battery: 3V lithium CR2 Typical Battery Life: 10 years (based on operating temperatures of 32° to 120°F [0°to 49°C], may vary by use) Lock Sensor for Entry Door with Deadbolt Lock FCC ID: SO7-205Y0000 IC ID: 11009A-205Y0000 Lock Sensor for Entry Door with Multipoint Lock FCC ID: SO7-13N80000 IC ID: 110009A-13N80000 Entry Door Open/Close Sensor FCC ID: SO7-205Z0000 IC ID: 11009A-205Z0000 Integrated Patio Door Sensor Frequency: 433.92MHz (Insynctive) Operating Temperature: -22° to 140°F (-30° to 60°C) Operating Humidity: 5% to 95% RH noncondensing Lock Sensor Battery: 3V lithium CR2032 Open/Close Sensor Battery: 3V lithium CR2 Typical Battery Life: 10 years (based on operating temperatures of 32° to 120°F [0°to 49°C], may vary by use) Lock Sensor FCC ID: SO7-13N80000 IC ID: 110009A-13N80000 Hinged Patio Door Open/Close Sensor FCC ID: SO7-13N90000 IC ID: 110009A-13N90000 Sliding Patio Door Open/Close Sensor FCC ID: SO7-205Z0000 IC ID: 11009A-205Z0000 Integrated Window Sensor Frequency: 433.92MHz (Insynctive) Operating Temperature: -22° to 140°F (-30° to 60°C) Operating Humidity: 5% to 95% RH noncondensing Battery: 3V lithium CR2032 Typical Battery Life: 10 years (based on operating temperatures of 32° to 120°F [0°to 49°C], may vary by use) Open/Close Sensor FCC ID: SO7-13N80000 IC ID: 110009A-13N80000 Double-Hung Open/Close Sensor FCC ID: SO7-13P20000 IC ID: 11009A-13P20000 Product Specifications Insynctive ® Product Guide | 5 Universal Window and Door Sensor Frequency: 433.92MHz (Insynctive ® ) Operating Temperature: 32° to 120°F (0° to 49°C) Operating Humidity: 5% to 95% RH noncondensing Battery: 3V lithium CR2032 Typical Battery Life: 5 years (may vary by use) Magnet Gap: 1/2" max FCC ID: SO7-205T0000 IC ID: 11009A-205T0000 Garage Door Sensor Frequency: 433.92MHz (Insynctive) Operating Temperature: 32° to 120°F (0° to 49°C) Operating Humidity: 5% to 95% RH noncondensing Battery: 3V lithium CR123A Typical Battery Life: 5 years (may vary by use) FCC ID: SO7-206F0000 IC ID: 11009A-206F0000 Product Specifications (continued) Insynctive ® Product Guide | 6 BRIDGE is the wireless communicat…
