SOP422261AWireless headphones
Roland Corporation
Click to zoom
Application Details
- Equipment Class
- DSS - Part 15 Spread Spectrum Transmitter
- Date of Grant
- Jun 19, 2022
- Application Purpose
- Original Equipment
- Date of Application
- Jun 19, 2022
- Equipment Note
- Wireless headphones
- Frequency Range
- 2402.00000000 - 2480.00000000
- Company
- Roland Corporation
- Country
- Japan
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
IMPORTANT NOTES USING THE UNIT SAFELY WARNING Do not disassemble or modify by yourself Do not carry out anything unless you are instructed to do so in the owner’s manual. Otherwise, you risk causing malfunction. Do not repair or replace parts by yourself Be sure to contact your dealer, a Roland service center, or an o cial Roland dealer. For a list of Roland service centers and o cial Roland dealers, refer to the Roland website. Do not use or store in the following types of locations • Subject to temperature extremes (e.g., direct sunlight in an enclosed vehicle, near a heating duct, on top of heat-generating equipment); or are • Damp (e.g., baths, washrooms, on wet oors); or are • Exposed to steam or smoke; or are • Subject to salt exposure; or are • Exposed to rain; or are • Dusty or sandy; or are • Subject to high levels of vibration and shakiness; or are • Placed in a poorly ventilated location Avoid extended use at high volume Use of the unit at high volume for extended periods of time may cause hearing loss. If you ever experience any hearing loss or ringing in the ears, you should immediately stop using the unit and consult a specialized physician. Do not allow foreign objects or liquids to enter unit; never place containers with liquid on unit Do not place containers containing liquid (e.g., ower vases) on this product. Never allow foreign objects (e.g., ammable objects, coins, wires) or liquids (e.g., water or juice) to enter this product. Doing so may cause short circuits, faulty operation, or other malfunctions. Turn o the unit if an abnormality or malfunction occurs In the following cases, immediately turn o the power and contact your dealer, a Roland service center, or an o cial Roland dealer for service. • If smoke or unusual odor occurs; or • Objects have fallen into, or liquid has been spilled onto the unit; or • The unit has been exposed to rain (or otherwise has become wet); or • The unit does not appear to operate normally or exhibits a marked change in performance. For a list of Roland service centers and o cial Roland dealers, refer to the Roland website. Be cautious to protect children from injury Always make sure that an adult is on hand to provide supervision and guidance when using the unit in places where children are present, or when a child will be using the unit. Do not drop or subject to strong impact Otherwise, you risk causing damage or malfunction. Handling units that contain a lithium-ion battery Do not use, recharge, or leave the unit in a location that is subject to low or high temperature • In direct sunlight • Near a re • Inside a vehicle on a hot day, etc. • Ambient temperature range during using: 5–40 °C (41–104 °F) • Ambient temperature range during charging: 5–35 °C (41–95 °F) • Ambient temperature range during storing: 0–40 °C (32–104 °F) • Do not leave the unit recharging for an extended time When recharging is completed, disconnect the power supply used for recharging; do not leave the power supply connected for an extended time. CAUTION Avoid climbing on top of the unit, or placing heavy objects on it Otherwise, you risk injury as the result of the unit toppling over or dropping down. Disconnect all cords/cables before moving the unit Damage or malfunction may result if you fail to disconnect all cables before moving the unit. Take care so as not to get ngers pinched Take care not to pinch your ngers when opening or closing the headphones. Whenever there is a threat of lightning, disconnect the power plug from the outlet If the power plug is not removed from the outlet, you risk receiving an electric shock. Keep small items out of the reach of children To prevent accidental ingestion of the parts listed below, always keep them out of the reach of small children. • Adaptor plug • Plug cap • Screws (when in use) Precautions if liquid leaks from the product If liquid leaks from the internal lithium-ion battery, observe the following precautions. • Do not touch the liquid with your bare hands. • If any of the leaking fluid gets into your eyes, the loss of vision may result. Do not rub your eyes; use clean water to flush them thoroughly. Then, promptly see a doctor. • Burning of the skin or dermatitis may result if uid has gotten onto your skin or clothing. Use clean water to ush a ected areas thoroughly; then, promptly see a doctor. About WARNING and CAUTION Notices About the Symbols ALWAYS OBSERVE THE FOLLOWING INSTRUCTIONS FOR THE PREVENTION OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS WARNING Used for instructions intended to alert the user to the risk of death or severe injury should the unit be used improperly. CAUTION Used for instructions intended to alert the user to the risk of injury or material damage should the unit be used improperly. * Material damage refers to damage or other adverse e ects caused with respect to the home and all its furnishings, as well to domestic animals or pets. The symbol alerts the user to important instructions or warnings. The speci c meaning of the symbol is determined by the design contained within the triangle. In the case of the symbol at left, it is used for general cautions, warnings, or alerts to danger. The symbol alerts the user to items that must never be carried out (are forbidden). The speci c thing that must not be done is indicated by the design contained within the circle. In the case of the symbol at left, it means that the unit must never be disassembled. The symbol alerts the user to things that must be carried out. The speci c thing that must be done is indicated by the design contained within the circle. In the case of the symbol at left, it means that the power- cord plug must be unplugged from the outlet. Read Me First English Power Supply: Use of Batteries • This product is equipped with a lithium-ion battery. • Even if you do not use this product for an extended period of time, you should charge it once every three months to prevent the internal lithium-io…
Text truncated - open the document above for the full version.
External Photos
Page1of4FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity ExternalPhotosoftheEUT Fig.1 Fig.2 Page2of4FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.3 Fig.4 Page3of4FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.5 Fig.6 Page4of4FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.7
ID Label/Location Info
Page1of1FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity LABELANDLOCATION LabelLocation Enlargethepicture
Internal Photos
Page1 of 7FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add: 101,201BldgA & 301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330| E-mail:[email protected]| Web:www.lcs-cert.com Scancodeto checkauthenticity InternalPhotosof theEUT Fig. 1 Fig. 2 Page2 of 7FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add: 101,201BldgA & 301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330| E-mail:[email protected]| Web:www.lcs-cert.com Scancodeto checkauthenticity Fig. 3 Fig. 4 Page3 of 7FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add: 101,201BldgA & 301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330| E-mail:[email protected]| Web:www.lcs-cert.com Scancodeto checkauthenticity Fig. 5 Fig. 6 Page4 of 7FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add: 101,201BldgA & 301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330| E-mail:[email protected]| Web:www.lcs-cert.com Scancodeto checkauthenticity Fig. 7 Fig. 8 BTAntenna Page5 of 7FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add: 101,201BldgA & 301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330| E-mail:[email protected]| Web:www.lcs-cert.com Scancodeto checkauthenticity Fig. 9 Fig. 10 Page6 of 7FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add: 101,201BldgA & 301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330| E-mail:[email protected]| Web:www.lcs-cert.com Scancodeto checkauthenticity Fig. 11 Fig. 12 Page7 of 7FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add: 101,201BldgA & 301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330| E-mail:[email protected]| Web:www.lcs-cert.com Scancodeto checkauthenticity Fig. 13 Fig. 14
RF Exposure Info
Page1of4FCCID:SOP422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCCRFExposureEvaluation 1.ProductInformation FCCID:SOP422261A Productname:Wirelessheadphones TestModel:XFBT3 PowerSupply:Input:DC5V,400mA DC3.7VbyRechargeableLi-ionBattery,430mAh HardwareVersion:V2.0 SoftwareVersion:V0.01 FrequencyRange:2402MHz~2480MHz ChannelNumber:79channelsforBluetoothV5.1(DSS) ChannelSpacing:1MHzforBluetoothV5.1(DSS) ModulationType:GFSK,π/4-DQPSK,8-DPSKforBluetoothV5.1(DSS) BluetoothVersion:V5.1 AntennaType:InternalAntenna AntennaGain:0dBi Exposurecategory:Generalpopulation/uncontrolledenvironment EUTType:ProductionUnit DeviceType:PortableDevice Page2of4FCCID:SOP422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 2.EvaluationmethodandLimit AccordingtoKDB447498D01GeneralRFExposureGuidancev06Section4.3.1StandaloneSAR testexclusionconsiderations:“UnlessspecificallyrequiredbythepublishedRFexposureKDB procedures,standalone1-gheadorbodyand10-gextremitySARevaluationforgeneralpopulation exposureconditions,bymeasurementornumericalsimulation,isnotrequiredwhenthe correspondingSARTestExclusionThresholdcondition,listedbelow,issatisfied.Thesetest exclusionconditionsarebasedonsource-basedtime-averagedmaximumconductedoutputpower oftheRFchannelrequiringevaluation,adjustedfortune-uptolerance,andtheminimumtest separationdistancerequiredfortheexposureconditions.22Theminimumtestseparationdistance isdeterminedbythesmallestdistancefromtheantennaandradiatingstructuresoroutersurfaceof thedevice,accordingtothehostformfactor,exposureconditionsandplatformrequirements,toany partofthebodyorextremityofauserorbystander(see5)ofsection4.1).ToqualifyforSARtest exclusion,thetestseparationdistancesappliedmustbefullyexplainedandjustifiedbythe operatingconfigurationsandexposureconditionsofthetransmitterandapplicablehostplatform requirements,typicallyintheSARmeasurementorSARanalysisreport,accordingtotherequired publishedRFexposureKDBprocedures.WhennootherRFexposuretestingorreportingis required,astatementofjustificationandcompliancemustbeincludedintheequipmentapproval,in lieuoftheSARreport,toqualifyfortheSARtestexclusion.Whenrequired,thedevicespecific conditionsdescribedintheotherpublishedRFexposureKDBproceduresmustbesatisfiedbefore applyingtheseSARtestexclusionprovisions;forexample,handheldPTTtwo-wayradios,handsets, laptops&tabletsetc.“ [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]·[√f(GHz)]≤3.0for1-gSARand≤7.5for10-gextremitySAR,where: •f(GHz)istheRFchanneltransmitfrequencyinGHz •PoweranddistanceareroundedtothenearestmWandmmbeforecalculation •Theresultisroundedtoonedecimalplaceforcomparison •3.0and7.5arereferredtoasthenumericthresholdsinthestep2below Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis≤50mm andfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmaccordingtof)insection4.1isappliedto determineSARtestexclusion. Whenoneofthefollowingtestexclusionconditionsissatisfiedforallcombinationsof simultaneoustransmissionconfigurations,furtherequipmentapprovalisnotrequiredto incorporatetransmittermodulesinhostdevicesthatoperateinthemixedmobileandportablehost platformexposureconditions.ThegranteeisresponsiblefordocumentingthisaccordingtoClassI permissivechangerequirements.AntennasthatqualifyforstandaloneSARtestexclusionmust applytheestimatedstandaloneSARtodeterminesimultaneoustransmissiontestexclusion. a)The[∑of(thehighestmeasuredorestimatedSARforeachstandaloneantennaconfiguration, adjustedformaximumtune-uptolerance)/1.6W/kg]+[∑ofMPEratios]is≤1.0. b)TheSARtopeaklocationseparationratiosofallsimultaneouslytransmittingantennapairs operatinginportabledeviceexposureconditionsareall≤0.04,andthe[∑ofMPEratios]is≤ 1.0. 3.ReferEvaluationMethod ANSIC95.1–1999:IEEEStandardforSafetyLevelswithRespecttoHumanExposuretoRadio FrequencyElectromagneticFields,3kHzto300GHz. FCCKDBpublication447498D01GeneralRFExposureGuidancev06:MobileandPortableDevices RFExposureProceduresandEquipmentAuthorizationPolicies. FCCCFR47part11.1310:Radiofrequencyradiationexposurelimits. FCCCFR47part22.1093:Radiofrequencyradiationexposureevaluation:portabledevices Page3of4FCCID:SOP422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 4.ConductedPowerResults <BT> ModeChannelFrequency(MHz)PeakConductedOutputPower(dBm) GFSK 024021.14 3924411.59 7824801.63 π/4-DQPSK 024020.93 3924411.46 7824801.48 8-DPSK 024021.02 392441-0.77 7824800.42 5.ManufacturingTolerance <BT> GFSK(Peak) ChannelChannel0Channel39Channel78 Target(dBm)1.01.01.0 Tolerance±(dB)1.01.01.0 π/4-DQPSK(Peak) ChannelChannel0Channel39Channel78 Target(dBm)01.01.0 Tolerance±(dB)1.01.01.0 8-DPSK(Peak) ChannelChannel0Channel39Channel78 Target(dBm)1.000 Tolerance±(dB)1.01.01.0 Page4of4FCCID:SOP422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6.EvaluationResults 6.1StandaloneEvaluation Band/Mode f (GHz) Antenna Distance (mm) RFoutputpower SARTest Exclusion Threshold SARTest Exclusion dBmmW BT GFSK2.48052.01.58490.4992<3.0 Yes π/4-DQPSK2.48052.01.58490.4992<3.0 Yes 8-DPSK2.40252.01.58490.4913<3.0 Yes Remark: 1.Outputpowerincludingtuneuptolerance; 2.Whentheminimumtestseparationdistanceis<5mm,adis…
Text truncated - open the document above for the full version.
Test Report
Page 1 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity AppendixA RF Test Data for BT (ConductedMeasurement) ProductName:Wirelessheadphones Test Model:XFBT3 EnvironmentalConditions Temperature: 23.5  C RelativeHumidity:52.2% ATM Pressure:100.0 kPa Test Engineer: Bill Zhu Supervisedby: Li Huan Page 2 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity A.1 -20dBBandwidth ConditionModeFrequency(MHz)Antenna-20 dB Bandwidth(MHz)Limit -20 dB Bandwidth(MHz)Verdict NVNT1-DH52402Ant11.021N/APass NVNT1-DH52441Ant11.022N/APass NVNT1-DH52480Ant11.026N/APass NVNT2-DH52402Ant11.287N/APass NVNT2-DH52441Ant11.286N/APass NVNT2-DH52480Ant11.278N/APass NVNT3-DH52402Ant11.276N/APass NVNT3-DH52441Ant11.287N/APass NVNT3-DH52480Ant11.287N/APass Page 3 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity Test Graphs -20dBBandwidthNVNT1-DH52402MHzAnt1 -20dBBandwidthNVNT1-DH52441MHzAnt1 Page 4 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity -20dBBandwidthNVNT1-DH52480MHzAnt1 -20dBBandwidthNVNT2-DH52402MHzAnt1 Page 5 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity -20dBBandwidthNVNT2-DH52441MHzAnt1 -20dBBandwidthNVNT2-DH52480MHzAnt1 Page 6 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity -20dBBandwidthNVNT3-DH52402MHzAnt1 -20dBBandwidthNVNT3-DH52441MHzAnt1 Page 7 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity -20dBBandwidthNVNT3-DH52480MHzAnt1 Page 8 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity A.2 OccupiedChannelBandwidth ConditionModeFrequency(MHz)Antenna99% OBW (MHz) NVNT1-DH52402Ant10.896 NVNT1-DH52441Ant10.903 NVNT1-DH52480Ant10.907 NVNT2-DH52402Ant11.182 NVNT2-DH52441Ant11.188 NVNT2-DH52480Ant11.188 NVNT3-DH52402Ant11.185 NVNT3-DH52441Ant11.192 NVNT3-DH52480Ant11.182 Page 9 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity Test Graphs OBW NVNT1-DH52402MHzAnt1 OBW NVNT1-DH52441MHzAnt1 Page 10 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity OBW NVNT1-DH52480MHzAnt1 OBW NVNT2-DH52402MHzAnt1 Page 11 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity OBW NVNT2-DH52441MHzAnt1 OBW NVNT2-DH52480MHzAnt1 Page 12 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity OBW NVNT3-DH52402MHzAnt1 OBW NVNT3-DH52441MHzAnt1 Page 13 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code to check authenticity OBW NVNT3-DH52480MHzAnt1 Page 14 of 66FCC ID: SOP 422261AIC: 9569A-422261A ShenzhenLCS ComplianceTestingLaboratoryLtd. Add: 101, 201 Bldg A & 301 Bldg C, Juji IndustrialPark Yabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel: +(86) 0755-82591330| E-mail:[email protected]| Web: www.lcs-cert.com Scan code t…
Text truncated - open the document above for the full version.
Test Report
Page 1 of 36 FCCID:SOP422261AReportNo.:LCSA050222009EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCCTESTREPORT FOR RolandCorporation Wirelessheadphones TestModel:XFBT3 Preparedfor:RolandCorporation Address:1-5-3,Shinmiyakoda,ita-ku,Hamamatsu,Sizuoka,Japan Preparedby:ShenzhenLCSComplianceTestingLaboratoryLtd. Address: 101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei, ShajingStreet,BaoanDistrict,Shenzhen,518000,China Tel:(+86)755-82591330 Fax:(+86)755-82591332 Web:www.LCS-cert.com Mail:[email protected] Dateofreceiptoftestsample:May06,2022 Numberoftestedsamples:2 SampleNo.:A050222009-1,A050222009-2 Serialnumber:Prototype DateofTest:May06,2022~May11,2022 DateofReport:May13,2022 Page 2 of 36 FCCID:SOP422261AReportNo.:LCSA050222009EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCCTESTREPORT FCCCFR47PART15C(15.247) ReportReferenceNo......................:LCSA050222009EA DateofIssue.......................................:May13,2022 TestingLaboratoryName..............:ShenzhenLCSComplianceTestingLaboratoryLtd. Address................................................: 101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei, ShajingStreet,BaoanDistrict,Shenzhen,518000,China TestingLocation/Procedure............ : FullapplicationofHarmonisedstandards■PartialapplicationofHarmonisedstandards□ Otherstandardtestingmethod□ Applicant’sName.............................: RolandCorporation Address................................................: 1-5-3,Shinmiyakoda,ita-ku,Hamamatsu,Sizuoka,Japan TestSpecification Standard..............................................:FCCCFR47PART15C(15.247) TestReportFormNo.........................:LCSEMC-1.0 TRFOriginator....................................:ShenzhenLCSComplianceTestingLaboratoryLtd. MasterTRF.........................................:Dated2011-03 ShenzhenLCSComplianceTestingLaboratoryLtd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe ShenzhenLCSComplianceTestingLaboratoryLtd.isacknowledgedascopyrightownerandsourceofthe material.ShenzhenLCSComplianceTestingLaboratoryLtd.takesnoresponsibilityforandwillnot assumeliabilityfordamagesresultingfromthereader'sinterpretationofthereproducedmaterialduetoits placementandcontext. TestItemDescription.....................:Wirelessheadphones TradeMark..........................................:V-MODA TestModel...........................................:XFBT3 Ratings.................................................:Input:DC5V,400mA DC3.7VbyRechargeableLi-ionBattery,430mAh Result..................................................:Positive Compiledby:Supervisedby:Approvedby: KevinHuang/Administrator JinWang/Techniqueprincipal GavinLiang/Manager Page 3 of 36 FCCID:SOP422261AReportNo.:LCSA050222009EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCC--TESTREPORT TestResult Positive Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetestlaboratory. TestReportNo.:LCSA050222009EA May13,2022 Dateofissue TestModel.............................. : XFBT3 EUT......................................... : Wirelessheadphones Applicant...............................:RolandCorporation Address...................................:1-5-3,Shinmiyakoda,ita-ku,Hamamatsu,Sizuoka,Japan Telephone...............................: / Fax..........................................:/ Manufacturer.........................: RolandCorporation Address...................................:1-5-3,Shinmiyakoda,ita-ku,Hamamatsu,Sizuoka,Japan Telephone...............................: / Fax..........................................:/ Factory...................................: CosonicElectroacousticTechnologyCo.,Ltd. Address...................................: No.151,ShipaiSection,DongyuanAvenue,ShipaiTown, DongguanCity,GuangdongProvince,P.R.China. Telephone...............................:/ Fax..........................................:/ Page 4 of 36 FCCID:SOP422261AReportNo.:LCSA050222009EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity RevisionHistory ReportVersionIssueDateRevisionContentRevisedBy 000May13,2022InitialIssue-- Page 5 of 36 FCCID:SOP422261AReportNo.:LCSA050222009EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TABLEOFCONTENTS DescriptionPage 1.GENERALINFORMATION...........................................................................................6 1.1DescriptionofDevice(EUT)...................................................................................................6 1.2SupportequipmentList...........................................................................................................7 1.3ExternalI/OCable..................................................................................................................7 1.4DescriptionofTestFacility.....................................................................................................7 1.5StatementoftheMeasurement…
Text truncated - open the document above for the full version.
Test Setup Photos
Page1of2FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestSetupPhotosoftheEUT TestSetupPhoto(s)ofRadiatedEmissionsMeasurement Fig.1 Fig.2 Page2of2FCCID:SOP422261AIC:9569A-422261A ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestSetupPhoto(s)ofConductedEmissionsMeasurement Fig.3
Contact Information
Applicant
Hisashi Ninomiya(Assistant Manager)
Test Firm
Shenzhen LCS Compliance Testing Laboratory Ltd.Gavin Liang
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 1.50 mW |
Other Applications from Roland Corporation
SOP426571A
Sep 22, 2024GUITAR AMPLIFIER
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
SOP426421A
Aug 30, 2023KSD2853_Antenna module
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
SOP422201A
Jul 15, 2021TRUE WIRELESS EARBUDS
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
SOPFSC-BT806B
Jul 06, 2020Bluetooth Module
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
SOP411981Y
Jun 02, 2011Microphone
Equipment Class
DTS - Digital Transmission System
