SQG-MT3202230WiFi 6 + Bluetooth 5.4 Module

Laird Connectivity LLC
WiFi 6 + Bluetooth 5.4 Module - FCC ID SQG-MT3202230 - Laird Connectivity LLC
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Apr 16, 2024
Application Purpose
Original Equipment
Date of Application
Apr 15, 2024
Equipment Note
WiFi 6 + Bluetooth 5.4 Module
Frequency Range
2402.00000000 - 2480.00000000
Company
Laird Connectivity LLC
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗
↗
↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Datasheet Sona™ MT320 Version 0.2 https://www.ezurio.com/ 2 © Copyright 2024 Ezurio All Rights Reserved Americas: +1-800-492-2320 Europe: +44-1628-858-940 Hong Kong: +852-2762-4823 Sona MT320 Datasheet Revision History Version Date Notes Contributors Approver 0.1 22 Sept. 2023 Initial version Various Andy Ross 0.2 5 Feb 2024 Update BT standard to 5.4 Andrew Chen Andy Ross https://www.ezurio.com/ 3 © Copyright 2024 Ezurio All Rights Reserved Americas: +1-800-492-2320 Europe: +44-1628-858-940 Hong Kong: +852-2762-4823 Sona MT320 Datasheet Contents 1 Scope .............................................................................................................................................................................. 4 2 Introduction ...................................................................................................................................................................... 4 2.1 General Description ................................................................................................................................................ 4 2.2 Sona MT320 Series Features Summary ................................................................................................................ 6 2.3 Specifications .......................................................................................................................................................... 7 3 WLAN Functional Description ....................................................................................................................................... 14 3.1 Overview ............................................................................................................................................................... 14 4 Bluetooth Functional Description .................................................................................................................................. 15 5 Block Diagrams ............................................................................................................................................................. 17 5.1 M.2 1420 ............................................................................................................................................................... 17 5.2 M.2 2230 E-Key .................................................................................................................................................... 17 6 Electrical Characteristics ............................................................................................................................................... 18 6.1 Absolute Maximum Ratings .................................................................................................................................. 18 6.2 Recommended Operating Conditions .................................................................................................................. 18 6.3 DC Electrical Characteristics ................................................................................................................................ 18 6.4 WLAN Radio Receiver Characteristics ................................................................................................................. 18 6.5 WLAN Transmitter Characteristics ....................................................................................................................... 21 7 Bluetooth Radio Characteristics .................................................................................................................................... 23 8 Power-Up Sequence and Timing .................................................................................................................................. 28 8.1 Power On Sequence ............................................................................................................................................. 28 8.2 Global Cold Reset ................................................................................................................................................. 28 9 Pin Definitions ............................................................................................................................................................... 29 9.1 M.2 1420 Solder-down .......................................................................................................................................... 29 9.2 M.2 2230 E-Key .................................................................................................................................................... 32 10 Mechanical Specifications ............................................................................................................................................. 35 10.1 M.2 1420 ............................................................................................................................................................... 35 11 Sona MT320 Mechanical Dimension ............................................................................................................................ 37 11.1 M.2 2230 E-Key .................................................................................................................................................... 38 11.2 M.2 2230 E-Key Mounting .................................................................................................................................... 38 12 RF Layout Design Guidelines ....................................................................................................................................... 40 13 Application Notes .......................................................................................................................................................... 41 13.1 Introduction ........................................................................................................................................................…

Text truncated - open the document above for the full version.

Attestation Statements

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Ezurio LLC and SQG Attestation Statement Reference: a) FCC CFR section 2.911(d)(5)(i) b) FCC Section 2.911(d)(5)(ii) c) FCC Section 2.911(d)(7) a) [Ezurio LLC] certifies that the equipment [FCC ID: SQG-MT3202230] for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules; b) [Ezurio LLC] certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment; c) [Ezurio LLC] as required by section 2.911(d)(7), will also serve as the agent for service of process for the above referenced FCC Grantee Code. The service of process includes, but is not limited to, delivery of any correspondence, notices, orders, decisions, and requirements of administrative, legal, or judicial process related to Commission proceedings. The applicant acknowledges that they will maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges their responsibility to inform the FCC whenever the following agent information changes. Designated Agent Company name:Ezurio LLC Grantee Code: SQG Contact Name: Brian Petted, Technology Leader Street Address: W66 N220 Commerce Court City/Province/Zip: Cedarburg, Wisconsin, 53012 Telephone No: (262)-421-4974 Email: [email protected] FRN: 0022590616 Sincerely yours, Signed by the Applicant Name: Brian Petted Title: Technology Leader Date:2024-04-01

Cover Letter(s)

Date: 2024/4/1 Federal Communications Commission 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: SQG-MT3202230 Product name: WiFi 6 + Bluetooth 5.4 Module To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model Sona MT320 2230 to the FCC Rules and Regulations. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Dist., TaoYuan City 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e- mail : [email protected] Webs We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 862. This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Brian Petted Technology Leader Ezurio LLC [email protected] Tel: 262-421 -4974

Cover Letter(s)

Confidentiality Request Letter Date: 2024/4/1 Federal Communications Commission Authorization and Evaluation Division FCC ID:SQG-MT3202230 Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Brian Petted Technology Leader Ezurio LLC [email protected] Tel: 262-421 -4974

Cover Letter(s)

Date: April 1, 2024 Subject: Ad Hoc Mode Function Declaration FCC ID: SQG-MT3202230 IC ID: 3147A-MT3202230 To Whom it may concern, We, Ezurio LLC declare that the device does not support any non-US channels, country code selection and Channel 12 and 13 in 2.4 GHz band in all the operational mode(s). Also, the client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master and the device without support DFS detection capability. This includes restriction on transmissions for beacons and support for ad-hoc peer-to-peer modes. Regards, Brian Petted Technology Leader Ezurio LLC [email protected] Tel: 262-421 -4974

Cover Letter(s)

Modular Approval Request FCC (KDB 996369 D01 & Part 15.212) FCC ID: SQG-MT3202230 Items to be covered by Single modular transmitters. Answer from applicant 1. The modular transmitter must have its own RF shielding. The device complies with this requirement. Please refer to RF exposure report. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The module contains a MT7921LSN transceiver which controls the physical data rates and modulation parameters. 3. The modular transmitter must have its own power supply regulation. The module contains a MT7921LSNtransceiver that has an integrated power management system, including internal voltage regulation. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(b)(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). Antenna Connectors is RPSMA/ I-PEX MHF4L. And no external amplifier will be used with this modular. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. This modular is tested under stand-alone configuration. Please refer to Test setup photo. 6. The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number in accordance with 15.212 (a)(1)(vi)(A) / (B). The modular transmitter is labeled with its own FCC ID number. Please refer to label sample and label location. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. The modular complies with this requirement. Please refer to user manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 1.1310, 2.1091, 2.1093, and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance. Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. The device complies with this requirement. Please refer to RF exposure report. Brian Petted Technology Leader Ezurio LLC [email protected] Tel: 262-421 -4974

External Photos

Project No.: EP420801 Page No. : 1 of 10 Photographs of EUT Project No.: EP420801 Page No. : 2 of 10 Project No.: EP420801 Page No. : 3 of 10 Project No.: EP420801 Page No. : 4 of 10

ID Label/Location Info

THIRD ANGLE PROJECTION 20.00 20.00 Notes: 1.Material: Polyimide, White 2.Font: Arial 3.Logo Size: Height 3mm Label info: 1.Model Name 2.Part Number: Refer to the part number on the PO 3.FCC ID approval 4.IC approval 5.Date Code: SSYYWWD SS: manufacturer number YY: last two numbers of the year WW: Week number of the year D: Sun=1,Mon=2,Tue=3,Wed=4,Thu=5, Fri=6,Sat=7 6.Wi-Fi MAC 7.CE logo 8.2D Barcode Barcode type: Data Matrix ECC200 Barcode content:Wi-Fi MAC 9.Rev X: X=The major revision of the ordering part number which can be found on the PO 10.UKCA logo REVISIONS REV.DESCRIPTIONDATEAPPROVED 1.0Initial releaseAug 18, 2023AC - - - - SHEET 1 OF 1 UNLESS OTHERWISE SPECIFIED: SCALE: 7:1 REVDWG. NO.SIZE TITLE: DATE INTERPRET GEOMETRIC TOLERANCING PER: ASME 14.5M DIMENSIONS ARE IN MILLIMETERS TOLERANCES: ANGULAR: X.X X.XX 5 4 32 1 6 7 8 A B C D E F 8 7 6 5 4 32 1 F E D C B A B Sona MT921 M.2 Product label CAD FILE: Sona MT320 M.2 Product label ± .5 ± .2 ± .1 UNLESS OTHERWISE NOTED, THIS DOCUMENT CONTAINS LAIRD CONNECTIVITY INFORMATION. REPRODUCTION, USE, DISCLOSURE OR TRANSMITTAL OF ALL OR ANY PART OF THIS DOCUMENT IS PROHIBITED EXCEPT TO THE EXTENT APPROVED IN WRITING BY AN AUTHORIZED REPRESENTATIVE OF LAIRD CONNECTIVITY. LAIRD CONNECTIVITY RESERVES ALL RIGHTS UNDER PATENTS, TRADEMARKS, COPY RIGHTS AND TRADE SECRETS. COPYRIGHT, LAIRD CONNECTIVITY 2020, ALL RIGHTS RESERVED. Aug 18, 2023 UNIT: mm

Internal Photos

Project No.: EP420801 Page No. : 5 of 10 Project No.: EP420801 Page No. : 6 of 10 Project No.: EP420801 Page No. : 7 of 10 Project No.: EP420801 Page No. : 8 of 10 Project No.: EP420801 Page No. : 9 of 10 Project No.: EP420801 Page No. : 10 of 10

RF Exposure Info

Report No.: FA420801 Page : 1 of 7 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : SQG-MT3202230 Equipment : WiFi 6 + Bluetooth 5.4 Module Model No. : Sona MT320 2230 Brand Name : Ezurio Applicant : Ezurio LLC Address : W66N220 Commerce Court, Cedarburg, WI 53012 United States Of America Standard : 47 CFR FCC Part 2.1091 Received Date : Feb. 08, 2024 Tested Date : Dec. 19, 2023 ~ Feb. 29, 2024 We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA420801 Page : 2 of 7 Report Version: Rev. 01 Table of Contents 1 RF EXPOSURE TEST EXEMPTIONS ................................................................................................... 4 1.1 1-mW TEST EXEMPTION ..................................................................................................................... 4 1.2 SAR-BASED EXEMPTION .................................................................................................................... 4 1.3 MPE-BASED EXEMPTION .................................................................................................................... 4 1.4 REFERENCE GUIDANCE ..................................................................................................................... 5 1.5 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 5 1.6 MEASUREMENT UNCERTAINTY ......................................................................................................... 5 1.7 EXEMPTION CALCULATION ................................................................................................................ 6 2 TEST LABORATORY INFORMATION ................................................................................................. 7 Report No.: FA420801 Page : 3 of 7 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA420801 Rev. 01 Initial issue Apr. 12, 2024 Report No.: FA420801 Page : 4 of 7 Report Version: Rev. 01 1 RF Exposure Test Exemptions 1.1 1-mW TEST EXEMPTION Available maximum time-averaged power is no more than 1 mW. 1.2 SAR-BASED EXEMPTION This exemption is applicable to the frequency range between 300 MHz and 6 GHz, with test separation distances between 0.5 cm and 40 cm, and for all RF sources in fixed, mobile, and portable device exposure conditions. The maximum time-averaged power or effective radiated power (ERP), whichever is greater, ≤ Pth Pth (mW) = ERP 20cm (d/20) x d≤20cm Pth (mW) = ERP 20cm 20 cm < d ≤40cm Where = - log 10 Pth (mW) = ERP 20cm (mW) = 2040f 0.3GHz ≤ f < 1.5 GHz Pth (mW) = ERP 20cm (mW) = 3060 1.5GHz ≤ f < 6 GHz Frequency (MHz) Power Thresholds mW dBm 663 1353 31.31 699 1426 31.54 704 1436 31.57 777 1585 32.00 824 1681 32.26 902 1840 32.65 1500 ~ 6000 3060 34.86 1.3 MPE-BASED EXEMPTION For a much wider frequency range, from 300 kHz to 100 GHz, applicable for separation distances greater or equal to λ/2π, where λ is the free-space operating wavelength in meters. Radio Source Frequency Minimum Distance Threshold ERP F L MHz F H MHz λ L / 2π λ H / 2π W 0.3 - 1.34 159 m - 35.6 m 1920 R 2 1.34 - 30 35.6 m - 1.6 m 3450 R 2 /f 2 30 - 300 1.6 m - 159 mm 3.83 R 2 300 - 1500 159 mm - 31.8 mm 0.0128 R 2 f 1500 - 100000 31.8 mm - 0.5 mm 19.2 R 2 Note: R is the antenna-person separation distance. Report No.: FA420801 Page : 5 of 7 Report Version: Rev. 01 1.4 REFERENCE GUIDANCE 447498 D04 Interim General RF Exposure Guidance v01. 1.5 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 1.6 MEASUREMENT UNCERTAINTY The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)). Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FA420801 Page : 6 of 7 Report Version: Rev. 01 1.7 EXEMPTION CALCULATION Non-beamforming mode Frequency Range (MHz) Maximum Conducted Power (dBm) Maximum Tune Up Limit (dBm) Antenna Gain (dBi) EIRP (dBm) ERP (dBm) ERP (mW) SAR-Based Exemption Thresholds (mW) Ratio Pass/ Fail 2412~2462 (Wi-Fi) 21.65 22 2.6 24.6 22.45 175.79 3060 0.057 Pass 5180~5240 (Wi-Fi) 18.31 18.5 4.4 22.9 20.75 118.85 3060 0.039 Pass 5260~5320 (Wi-Fi) 18.5 19 4.4 23.4 21.25 133.35 3060 0.044 Pass 5500~5720 (Wi-Fi) 22.25 22.5 4.4 26.9 24.75 298.54 3060 0.098 Pass 5745~5820 (Wi-Fi) 22.61 23 4.4 27.4 25.25 334.97 3060 0.109 Pass 2402-2480 (BT EDR) 6.49 6.5 2.6 9.1 6.95 4.95 3060 0.002 Pass 2402-2480 (BT LE) 6.97 7 2.6 9.6 7.45 5.56 3060 0.002 Pass Beamforming mode Frequency Range (MHz) Maximum Conducted Power (dBm) Maximum Tune Up Limit (dBm) Antenna Gain (dBi) EIRP (dBm) ERP (dBm) ERP (mW) SAR-Based Exemption Thresholds (mW) Ratio Pass/ Fail 2412~2462 (Wi-Fi) 14.97 15 5.61 20.61 18.46 70.15 3060 0.023 Pass 5180~5240 (Wi-Fi) 15.17 15.5 7.41 22.91 20.76 119.12 3060 0.039 Pass 5260~5320 (Wi-Fi) 15.49 15.5 7.41 22.91 20.76 119.12 3060 0.039 Pass 5500~5720 (Wi-Fi) 19.24 19.5 7.41 26.91 24.76 299.23 3060 0.098 Pass 5745~5820 (Wi-Fi) 19.60 20 7.41 27.41 25.26 335.74 3060 0.110 Pass *Ratio =ERP / exemption thresholds. Remarks: For 2400 ~ 2483.5 MHz: Directional gain = 2.4+10* log(2/1)=5.41 dBi For 5180~5825 MHz: Directional gain = 4.4+10* log(2/1)=7.41 dBi Report No.: FA420801 Page : 7 of 7 Report Version: Rev. 01 2 Test laboratory information …

Text truncated - open the document above for the full version.

Test Report

Report No.: FR420801AD Page : 1 of 24 Report Version: Rev. 01 FCC Test Report FCC ID : SQG-MT3202230 Equipment : WiFi 6 + Bluetooth 5.4 Module Model No. : Sona MT320 2230 Brand Name : Ezurio Applicant : Ezurio LLC Address : W66N220 Commerce Court, Cedarburg, WI 53012 United States Of America Standard : 47 CFR FCC Part 15.247 Received Date : Feb. 08, 2024 Tested Date : Feb. 26 ~ Feb. 29, 2024 We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FR420801AD Page : 2 of 24 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 8 1.3 Test Setup Chart .................................................................................................................................... 8 1.4 The Equipment List .............................................................................................................................. 10 1.5 Test Standards ..................................................................................................................................... 11 1.6 Reference Guidance ............................................................................................................................ 11 1.7 Deviation from Test Standard and Measurement Procedure ............................................................... 11 1.8 Measurement Uncertainty .................................................................................................................... 12 2 TEST CONFIGURATION ..................................................................................................................... 13 2.1 Testing Facility...................................................................................................................................... 13 2.2 The Worst Test Modes and Channel Details ....................................................................................... 13 3 TRANSMITTER TEST RESULTS........................................................................................................ 14 3.1 Unwanted Emissions into Restricted Frequency Bands ...................................................................... 14 3.2 Unwanted Emissions into Non-Restricted Frequency Bands .............................................................. 17 3.3 Conducted Output Power ..................................................................................................................... 18 3.4 Number of Hopping Frequency ............................................................................................................ 19 3.5 20dB and Occupied Bandwidth ............................................................................................................ 20 3.6 Channel Separation .............................................................................................................................. 21 3.7 Number of Dwell Time .......................................................................................................................... 22 3.8 AC Power Line Conducted Emissions ................................................................................................. 23 4 TEST LABORATORY INFORMATION ............................................................................................... 24 Appendix A. Unwanted Emissions into Restricted Frequency Bands Appendix B. Unwanted Emissions into Non-Restricted Frequency Bands Appendix C. Conducted Output Power Appendix D. Number of Hopping Frequency Appendix E. 20dB and Occupied Bandwidth Appendix F. Channel Separation Appendix G. Number of Dwell Time Appendix H. AC Power Line Conducted Emissions Report No.: FR420801AD Page : 3 of 24 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR420801AD Rev. 01 Initial issue Apr. 12, 2024 Report No.: FR420801AD Page : 4 of 24 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 AC Power Line Conducted Emission [dBuV]: 0.393MHz 29.64 (Margin -18.35dB) - AV Pass 15.247(d) 15.209 Unwanted Emissions [dBuV/m at 3m]: 610.06MHz 35.67 (Margin -10.33dB) - PK Pass 15.247(d) Band Edge Meet the requirement of limit Pass 15.247(b)(1) Conducted Output Power Power [dBm]: 9.55 Pass 15.247(a)(1)(iii) Number of Hopping Channels Meet the requirement of limit Pass 15.247(a)(1) Hopping Channel Separation Meet the requirement of limit Pass 15.247(a)(1)(iii) Dwell Time Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FR420801AD Page : 5 of 24 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) Bluetooth Mode Ch. Frequency (MHz) Channel Number Data Rate 2400-2483.5 BR 2402-2480 0-78 [79] 1 Mbps…

Text truncated - open the document above for the full version.

Test Report

A https://www.lairdconnect.com/ 1 © Copyright 2022 Laird Connectivity All Rights Reserved Americas: +1-800-492-2320 Europe: +44-1628-858-940 Hong Kong: +852 2762 4823 In 2020 the FCC announced the allocation of a new frequency spectrum for Wi-Fi applications, extending the frequencies up to 7125 MHz. The FlexMIMO 6E two-port MIMO antenna supports this extended Wi-Fi of 2400-2500, 4900-5925, and 5925-7125 MHz. The patented FlexMIMO 6E also drastically simplifies the size, cost, and technical requirements for implementing the two antennas required for 802.11 modules that use MIMO or WiFi diversity. Designed for rapid integration into space-constrained devices and housings, the flexible, adhesive-backed antennas are available with MHF1 or MHF4L connectors, providing multiple installation solutions for IoT device manufacturers. The FlexMIMO technology provides consistent, stable performance across all three Wi-Fi bands, ensuring a solid and reliable connection at all times. ▪ Full Coverage – Operates over all three Wi-Fi bands ▪ Performance – Exceptional performance across all bands ▪ Versatile – Flexible, peel-and-stick adhesive-backed antenna for a variety of space-constrained IoT devices. ▪ Future-Proofed – Coverage for emerging Wi-Fi 6E applications. ▪ Reliable – PIFA technology is easy to integrate into IoT devices and less likely to detune in proximity of metal or a human body. ▪ Quality – Designed and built to exact specifications. ▪ US Patent # 10.763.578 ▪ Smart metering and utilities ▪ Industrial IoT ▪ Agricultural and rural (Farm sense and control) ▪ Quick service restaurants ▪ Smart lockers ▪ Medical devices Number of Ports 2 Operating Frequency (MHz) 2400-2500 4900-5925 5925-7125 VSWR – Average 1.9:1 1.8:1 1.8:1 VSWR – Maximum < 3.0:1 < 3.0:1 < 3.0:1 Minimum Isolation (dB) …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Brian Petted(Technology Leader)
[email protected]2624214974Fax: 262-375-4248

Technical Contact

International Certification Corp.Gary Chang
[email protected]+88632718628

No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Dist., · Taiwan

Non-Technical Contact

International Certification Corp.Wendy Liao
[email protected]+88632718629

Test Firm

International Certification Corp.Fu-Cheng Chuang
[email protected]886-3-271-8666Fax: 886-3-318-0155

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz9.00 mW
Modular Type
Single Modular Approval
Confidentiality
Long Term
Grant Notes
Power Output is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End users must be provided with specific operating instructions for satisfying RF exposure compliance.
