SRS-RV-M5-UCRF Data Modem

FireLine Data Radio Modem Technical Manual Version B7 November 2005 Raveon Technologies Corporation 2722 Loker Avenue West, Suite D Carlsbad, CA 92010 www.raveontech.com Table Of Contents Safety / Warning Information ................................................................................3 Overview...............................................................................................................4 FCC Safety Compliance Statement......................................................................4 Features................................................................................................................5 Specifications........................................................................................................6 General...................................................................................................................................................... 6 Transmitter................................................................................................................................................. 6 Receiver..................................................................................................................................................... 6 User Input and Output Signals................................................................................................................... 6 Front Panel...........................................................................................................7 LEDs.......................................................................................................................................................... 7 DC Power................................................................................................................................................... 7 User I/O Connector.................................................................................................................................... 8 Using the FireLine Modem....................................................................................9 Setup.......................................................................................................................................................... 9 Addressing................................................................................................................................................. 9 The Address Mask................................................................................................................................... 10 Examples:................................................................................................................................................11 Installation...........................................................................................................12 Serial Port Data and Handshaking......................................................................12 User Serial Port Commands...............................................................................16 Overview.................................................................................................................................................. 16 Command Mode....................................................................................................................................... 16 Setting a Parameter................................................................................................................................. 16 Reading a Parameter............................................................................................................................... 17 CONFIG Button........................................................................................................................................ 17 Command Mode Commands................................................................................................................... 18 Default Frequencies................................................................................................................................. 20 Channel 5 451.800000 Itinerant Business Debug Related Commands......................................... 21 Debug Related Commands...................................................................................................................... 21 Tune-up and Alignment.......................................................................................22 Center Frequency.................................................................................................................................... 22 TX Deviation.............................................................................................................................................22 TX Modulation Balance............................................................................................................................ 23 RX DC Offset Verification......................................................................................................................... 23 RX Carrier Detect..................................................................................................................................... 23 SkyLine Compatibility Mode................................................................................25 Antenna Information............................................................................................27 Internal Radio Connection ..................................................................................28 Appendix A. Null Modem Cables......................................................................29 Troubleshooting..................................................................................................31 Mechanical..........................................................................................................33 Limited One Year Warranty ......................................................................…

Text truncated - open the document above for the full version.

Raveon Technologies Corporation www.raveontech.com S.N. 2650-01 2650-01B0D3 Model: RV-M5-UC FCCID: SRS-RV-M5-UC This device complies with Part 15, 22 and 90 of FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.

M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0034 Date of Report: November 17, 2005 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: Raveon Technologies Corporation Equipment: RF Data Modem FCC ID: SRS-RV-M5-UC FCC Rules: Radiofrequency Radiation Exposure Limits 47 CFR 1.1310 MPE - Mobiles X Fixed Based Station X Gentlemen: On behalf of the Applicant, enclosed please find the Supplemental Test Data Report, the whole for Environmental Assessment (MPE) of the referenced equipment as shown. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, David E. Lee, Quality Assurance Manager enclosure(s) cc: Applicant DEL/del M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0034 Environmental Assessment for Mobiles/Fixed Base Station for FCC ID: SRS-RV-M5-UC Model: RV-M5-UC to Federal Communications Commission 47 CFR 1.1310 (MPE) Radiofrequency Radiation Exposure Limits Date Of Report: November 17, 2005 On the Behalf of the Applicant: Raveon Technologies Corporation At the Request of: P.O. Deposit check #5265 Raveon Technologies Corporation 1750 Bella Laguna Court Encinitas, CA 92024 Attention of: John Sonnenberg 760-931-8001; fax: 760-931-8004 Email: [email protected] Supervised By: David E. Lee, Quality Assurance Manager M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 1 of 4 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0034 Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report (Supplemental) b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d05b0034 d) Client: Raveon Technologies Corporation 1750 Bella Laguna Court Encinitas, CA 92024 e) Identification: FCC ID: SRS-RV-M5-UC Model: RV-M5-UC Description: RF Data Modem f) EUT Condition: Not required unless specified in individual tests. g) Report Date: November 17, 2005 EUT Received: October 28, 2005 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: David E. Lee, Quality Assurance Manager n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 2 of 4 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0034 Identification of the Equipment Under Test (EUT) Name and Address of Applicant: Raveon Technologies Corporation 1750 Bella Laguna Court Encinitas, CA 92024 Manufacturer: Raveon Technologies Corporation 1750 Bella Laguna Court Encinitas, CA 92024 FCC ID: SRS-RV-M5-UC Model Number: RV-M5-UC Description: RF Data Modem Type of Emission: 11K0F1D Frequency Range, MHz: 450 - 480 Power Rating, Watts: 2.0 Switchable X Variable N/A Modulation: AMPS TDMA CDMA X OTHER Antenna: Helical Monopole X Whip (Mobile Use) X Other (Base Station) Note: For RF Safety test antenna gain taken at the upper range of expected gain (i.e. 0 dBd) for mobile use and RF Power set to highest nominal power across all channels. M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 3 of 4 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0034 Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.4-1992/2003, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104 °F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Prior to testing, the EUT was tuned up in accordance with the manufacturer's alignment procedures. All external gain controls were maintained at the position of maximum and/or optimum gain throughout the testing. Measurement results, unless otherwise noted, are worst-case measurements. A2LA “A2LA has accredited M. Flom Associates, Inc. Chandler, AZ for technical competence in the field of Electrical Testing. The accreditation covers the specific tests and types of tests listed on the agreed scope of accreditation. This laboratory meets the requirements of ISO/IEC 17025 – 1999 ‘General Requirements for the Competence of Testing and Calibration Laboratories’ and any additional program requirements in the identified field of testing.” Certificate Number: 2152-01 M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 4 of 4 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0034 Name of Test: R.F. Radiation Exposure The following calculation is provided; MPE Calculated based on Uncontrolled Exposure 100% Duty Cycle, 0dBi Antenna Frequency, MHZ 470.000 Limit =f/1500 =0.31mW/cm² Minimum Safe Distance = [1.85 x 2.00/(12.56 x 3.10)] 1/2 = 30.8 cm M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0034 (The following will be placed in the Instruction Manual) Mandatory Safety Instructions to Installers & Users Antenna Minimum Safe Distance for M…

Text truncated - open the document above for the full version.

M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0029 Date: November 16, 2005 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: Raveon Technologies Corporation Equipment: RF Data Modem FCC ID: SRS-RV-M5-UC FCC Rules: 22, 90, 90.210 and Confidentiality Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. Filing fees are attached. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, David E. Lee, Quality Assurance Manager enclosure(s) cc: Applicant DEL/del M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0029 Transmitter Certification of FCC ID: SRS-RV-M5-UC Model: RV-M5-UC to Federal Communications Commission Rule Part(s) 22, 90, 90.210 and Confidentiality Date of report: November 16, 2005 On the Behalf of the Applicant: Raveon Technologies Corporation At the Request of: P.O. Deposit check #5265 Raveon Technologies Corporation 1750 Bella Laguna Court Encinitas, CA 92024 Attention of: John Sonnenberg 760-931-8001; fax: 760-931-8004 Email: [email protected] Supervised by: David E. Lee, Quality Assurance Manager M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0029 The Applicant has been cautioned as to the following: 15.21 Information to the User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0029 Table of Contents Rule Description Page 2.1033(c)(14) Rule Summary 2 . Standard Test Conditions and Engineering Practices 3 2.1033(c) General Information Required 4 2.1046(a) Carrier Output Power (Conducted) 7 2.1046(a) ERP Carrier Power (Radiated) 9 2.1046(a) RF Power Output (Radiated) 11 2.1051 Unwanted Emissions (Transmitter Conducted) 12 2.1049(c)(1) Emission Masks (Occupied Bandwidth) 14 2.1055(a)(1) Frequency Stability (Temperature Variation) 20 2.1055(b)(1) Frequency Stability (Voltage Variation) 22 2.202(g) Necessary Bandwidth and Emission Bandwidth 24 M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 1 of 24 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0029 Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d05b0029 d) Client: Raveon Technologies Corporation 1750 Bella Laguna Court Encinitas, CA 92024 e) Identification: RV-M5-UC FCC ID: SRS- RV-M5-UC EUT Description: RF Data Modem f) EUT Condition: Not required unless specified in individual tests. g) Report Date: November 16, 2005 EUT Received: October-28, 2005 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: David E. Lee, Quality Assurance Manager n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. M. Flom Associates, Inc. 3356 North San Marcos Place, Suite 107 Page 2 of 24 Chandler, Arizona 85225-7176 FCC ID: SRS-RV-MS-UC (480) 926-3100 phone, (480) 926-3598 fax MFA p05a0010, d05b0029 Sub-part 2.1033(c)(14): Test and Measurement Data All tests and measurement data shown were performed in accordance with FCC Rules and Regulations, Volume II; Part 2, Sub-part J, Sections 2.947, 2.1033(c), 2.1041, 2.1046, 2.1047, 2.1079, 2.1051, 2.1053, 2.1055, 2.1057 and the following individual Parts: 21 – Domestic Public Fixed Radio Services X 22 – Public Mobile Services 22 Subpart H - Cellular Radiotelephone Service 22.901(d) - Alternative technologies a…

Text truncated - open the document above for the full version.
