SRVLMT-3000SWireless POS Terminal

LMT-3000S Installation Guide 2004-12-02 page. 1/1 LMT-3000S Installation Guide LMT-3000S Installation Guide 2004-12-02 page. 2/2 Revision History 2002. 12.24 Revision 1.0 is created. 2004. 10.12 Revision 1.1 is updated 2004. 12.01 Revision 1.2 is updated (Product specification is added.) Document Title: LMT-3000S Installation Guide, Revision 1.2 Copyright © 2003 Linudix, Co. Ltd. All rights reserved. No part of this publication may be copied, distributed, stored in a retrieval system, translated into any human or computer language, transmitted, in any form or by any means, without the prior written consent of Linudix. Comments or suggestions on how to improve this document can be sent to [email protected] . LMT-3000S Installation Guide 2004-12-02 page. 3/3 FCC WARNING Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications, However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Caution: To comply with the limits for an FCC Class B computing device, always use the shielded signal cord supplied with this unit. The Federal Communications Commission warns that changes or modifications of the unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC RF EXPOSURE COMPLIANCE This device has been tested for FCC RF exposure and SAR compliance in the host hand-held, hand-operated electronic organizer/PC. To maintain FCC RF exposure compliance, a 1.5 cm of separation distance must be maintained between the front and back of the device and the user’s or any bystander’s body (excluding hands, wrist, feet and ankles). LMT-3000S Installation Guide 2004-12-02 page. 4/4 Table of Contents GENERAL WARNING MATTER 5 A POWER RELATED WARNING MATTER 5 INSTALL THE LMT-3000S 6 STEP 1: UNPACK AND CONFIRM COMPONENT 6 STEP 2: INSTALL A PAPER ROLL IN THE PRINTER 6 STEP 3: INSTALL/REPLACE SIM CARDS 7 STEP 4: USE THE PRIMARY SMART CARD READER 8 STEP 5: USE THE MAGNETIC CARD READER 9 CLEAN THE TERMINAL AND PRINTER 10 TERMINAL 10 SMART CARD READER 10 PRINTER 10 TROUBLESHOOTING 11 PRODUCT SPECIFICATIONS 12 DESCRIPTION AND MODEL NAME 12 MAIN CONTROLLER SPECIFICATION 12 PERIPHERAL SPECIFICATION 12 CHARGER 13 SDK SPECIFICATION 13 OVERALL SPECIFICATION 14 APPEARANCE 14 LINUDIX SERVICE AND SUPPORT 15 LMT-3000S Installation Guide 2004-12-02 page. 5/5 General Warning Matter 9 When you use this product after purchase for the first time, let charge to the full a battery and use it. The battery is not charged to the full, when the product is shipment. 9 You are careful not to be wet to moisture this product. Fatal damage can occur in it. 9 Please do not use this in high temperature and moisture environment. 9 Please do not use this in an explosive or a combustibility gas. 9 Please do not wipe the main body with gasoline or thinner and the same chemical solution. 9 Please do not remodel or disassembles this product voluntarily. 9 Please do not keep a battery to firearms adjacency. A Power Related Warning Matter 9 Please do not use damaged power cord, plug, and socket. 9 Please do not touch a power plug in a wet hand. 9 Please do a warning so that a power cord is not pressed by a heavy thing or not stooped forcibly. 9 Please certainly use only a designated battery. 9 Please be careful so that it is not connected each other directly monads in the outside of a battery or a battery charger. 9 Please do not give a severe shock to a battery charger or a battery, and do not drop them. LMT-3000S Installation Guide 2004-12-02 page. 6/6 Install the LMT-3000S Step 1: Unpack and Confirm Component 9 Open the shipping carton and carefully inspect its contents for possible tampering or shipping damage. If a component appears damaged, please immediately notify the shipping company and your Linudix distributor or service provider. 9 Please confirm whether there are the product main body and a component like the following picture. Battery Power adapter Printer Paper Main body Headset Figure 1. LMT-3000S Product Component Step 2: Install a Paper Roll in the Printer 9 A printer paper is provided with a cylindricality of a diameter of 3cm. 9 If you above raise an opening thing button located in the top of the terminal main body, a printer cover opens. LMT-3000S Installation Guide 2004-12-02 page. 7/7 9 Please turn over one side of a paper mounting part in state above to have completely opened a printer cover a little, and please insert a paper. 9 Please be closed till sound passes a printer cover in state to have pulled an edge of a paper a little. 9 When print cuts a finished later printer paper, if you take a paper as a hand and pull bottom course, you can cut a paper soft. Step 3: Install/Replace SIM Cards 9 To unlock a cardholder, slide its locking plate to the unlocked position, shown by the OPEN arrow. 9 Open the cardholder by pivoting the cover from its connector base. 9 Remove any previously-installed MSAM card by sliding the card from the cover. 9 Install an MSAM card by aligning the card and carefully sliding it within th…

Text truncated - open the document above for the full version.

DATE: October 14, 2004 Federal Communications Commission Equipment Authorization branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality Gentlemen: In reference to the application under FCC ID: SRVLMT-3000S, and pursuant to Sections 0.457(d)(l)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Schematics Block Diagrams Theory of Operation . These documents contain detailed system and equipment description and related information about the product that LINUDIX considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LINUDIX considers that this information would be of benefit to its competitors, and that disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Yu-Chul Kim Associate Research Engineer Linudix Co., Ltd

1 Mike Kuo From: Claire Hoque Sent: December102004Friday 1:56 PM To: Mike Kuo Cc: Kathy Yao; Thu Chan Subject: RE: Linudix Co. Ltd., FCC ID: SRVLMT-3000S, Assessment NO.: AN04T4393, Notice#1 FCC PART 22 & 24 Report(revise... Hi Mike, Here is the answer. Question #1: As indicated in the filing, the radio module contains in this device is identical to the one certified under FCC ID:PY76220511. By reviewing the FCC ID:PY76220511 on file with FCC, this module is certified with max. conducted output of 1.38 W @ 850MHz band and 0.6W @ 1900MHz band. In the ERP/EIRP test report, there is no information provided on the conducted output power setting during fundamental ERP/EIRP tests. Please provide it. If the conducted output power was used is higher than +/-0.5dB of certified modular conducted output power, then all tests required under Part 22/24 need to be performed and can not associate with FCC ID:PY76220511 . <answer>pls see revised test report. Thanks, Claire

PROPOSED FCC ID LABEL AND LOCATION Linudix Co. Ltd. This device complies with Part 22 and Part 24 of the FCC Rules. FCC ID: SRVLMT-3000S FCC ID LABEL LOCATION

LMT-3000S GSM850/1900 Antenna Specification Frequency Range 824~849MHz / 1850~1920MHz (Dual Band) VSWR Less than 1.5:1 Gain 1.0 dBi Impedance 50 Ohm Polarization Vertical Radiation Pattern Omni-directional

19 LZT 123 7589 R1A 5. System Connector Interface 5.1 Overview Electrical connections to the radio device (except the antenna), are made through the System Connector Interface. The system connector is a 60-pin, standard 0.05 in (1.27 mm) pitch device. The system connector allows both board-to-board and board-to-cable connections to be made. Use a board-board connector to connect the radio device directly to a PCB, and a board-cable connector to connect the radio device via a cable. Figure 5.1 below shows the numbering of the connector pins. A ground connection is provided at the mounting hole next to the RF connector on the radio device as shown below. Connect this ground point to the DGND pins of the radio device by the shortest, low-impedance path possible. The purpose of this connection is to allow any antenna ESD strikes to bypass the radio device’s internal ground path. Figure 5.1 Radio Device, viewed from underneath The following table gives the pin assignments for the system connector interface and a short description for each signal. Pin 59Pin 1 Pin 60Pin 2 Ground connection 5. SYSTEM CONNECTOR INTERFACE 20 LZT 123 7589 R1A I‚‡rUnder the heading “Dir” in the table, radio device input and output signals are indicated by the letters I and O respectively. PinSignal NameDirSignal TypeDescription 1VCC-SupplyPower supply 2DGND--Digital ground 3VCC-SupplyPower supply 4DGND--Digital ground 5VCC-SupplyPower supply 6DGND--Digital ground 7VCC-SupplyPower supply 8DGND--Digital ground 9VCC-SupplyPower supply 10DGND--Digital ground 11CHG_IN-Battery charge power Battery charging 12DGND--Digital ground 13IO5 ADC4 I/0 I Digital 2.75V Analogue General purpose input/output 5 Analogue to digital converter 4 14ON/OFFIInternal pull up, open drain Turns the radio device on and off. 15SIMVCC-Digital 3 V/5 VSIM card power supply. Power output from radio device for SIM Card 16SIMPRESENCEIInternal pull up, open drain SIM Presence A “1” indicates that the SIM is missing; a “0” that it is inserted 17SIMRSTODigital 3 V/5 VSIM card reset 18SIMDATAI/ODigital 3 V/5 VSIM card data 19SIMCLKODigital 3 V/5 VSIM card clock 20DACOAnalogueDigital to analogue converter 21IO1 KEYROW2 I/O I Digital 2.75VGeneral purpose input/output 1 Keyboard row 2 22IO2 ADC5 I/O I Digital 2.75V Analogue General purpose input/output 2 Analogue to digital converter 5 23IO3 KEYROW3 I/O I Digital 2.75VGeneral purpose input/output 3 Keyboard row 3 24IO4 KEYROW4 I/O I Digital 2.75VGeneral purpose input/output 4 Keyboard row 4 25VRTCISupply 1.8VSupply for real time clock 26ADC1IAnalogueAnalogue to digital converter 1 27ADC2IAnalogueAnalogue to digital converter 2 5. SYSTEM CONNECTOR INTERFACE 21 LZT 123 7589 R1A 28ADC3IAnalogueAnalogue to digital converter 3 29SDAI/O2.75V, internal pull up I 2 C data 30SCLO2.75V, internal pull up I 2 C clock 31BUZZERODigital 2.75VBuzzer output from radio device 32OUT3 KEYCOL3 DSR O O O Digital 2.75VGeneral purpose output 3 Keyboard column 3 Data set ready (UART1) 33LED IO6 O I/O Digital 2.75VFlashing LED General purpose I/O 6 34VIOOPower Out 2.75 V Radio device power indication. VIO is a 2.75 V at 75 mA output supply that can be used to power external circuitry that interfaces to the radio device 35TX_ONODigital 2.75VThis output indicates when the GSM radio device is going to transmit the burst 36RI KEYCOL2 O2 O O O Digital 2.75VRing Indicator (UART1) Keyboard column 2 General purpose output 2 37DTR KEYROW1 IN1 I I I Digital 2.75VData Terminal Ready (UART1) Keyboard row 1 General purpose input 1 38DCD KEYCOL1 O1 O O O Digital 2.75VData Carrier Detect (UART1) Keyboard column 1 General purpose output 1 39RTS IO9 I I/O Digital 2.75VRequest To Send (UART1) General purpose I/O 9 40CTS KEYCOL4 O4 O O O Digital 2.75VClear To Send (UART1) Keyboard column 4 General purpose output 4 41TDIDigital 2.75VTransmitted Data (UART1). Data from DTE (host) to DCE (radio device). 42RDODigital 2.75VReceived Data (UART1). Data from DCE (radio device) to DTE (host). 43TD3 I/O7 I I/O Digital 2.75VTransmitted data (UART3) General purpose I/O 7 44RD3 I/O8 O I/O Digital 2.75VReceived data (UART3) General purpose I/O 8 45TD2IDigital 2.75VTransmitted data (UART2). Used for flashing the memory. 46RD2ODigital 2.75VReceived data (UART2). Used for flashing the memory. 47PCMULDIDigital 2.75VDSP PCM digital audio input 48PCMDLDODigital 2.75VDSP PCM digital audio output PinSignal NameDirSignal TypeDescription 5. SYSTEM CONNECTOR INTERFACE 22 LZT 123 7589 R1A 5.2 General Electrical and Logical Characteristics Many of the signals, as indicated in the table above, are high-speed CMOS logic inputs or outputs powered from a 2.75 V ± 5 % internal voltage regulator, and are defined as Digital 2.75 V. Whenever a signal is defined as Digital 2.75 V, the following electrical characteristics apply. I‚‡rUnused pins can be left floating. 5.2.1 General Protection Requirements • All 2.75 V digital inputs will continuously withstand and suffer no damage in the power-on or power-off condition when subjected to any voltage from - 0.5 V to 3.47 V (3.3 V + 5 %). • All 2.75 V digital outputs will continuously withstand a short circuit to any other voltage within the range 0 V to 3 V. • All analogue outputs will continuously withstand a short circuit to any voltage within the range 0 V to 3 V. 49PCMOODigital 2.75VCodec PCM digital audio output 50PCMIIDigital 2.75VCodec PCM digital audio input 51PCMSYNCODigital 2.75VDSP PCM frame sync 52PCMCLKODigital 2.75VDSP PCM clock output 53MICPIAnalogueMicrophone Input positive 54MICNIAnalogueMicrophone Input negative 55BEARPOAnalogueSpeaker output positive 56BEARNOAnalogueSpeaker output negative 57AFMSOAnalogueAudio output from radio device 58SERVICEI2.7VFlash programming voltage for the MS. Enable logger information if not flashing. 59ATMSIAnalogueAudio input to radio device 60AGND-AnalogueAnalogue ground PinSignal NameDirSignal TypeDescription ParameterMin.Max.Units High Level Output Voltage (V OH ), I o = –2mA2.22.75V Low Le…

Text truncated - open the document above for the full version.

IN ACCORDANCE WITH THE REQUIREMENTS OF FCC REPORT AND ORDER: ET DOCKET 93-62, AND OET BULLETIN 65 SUPPLEMENT C FOR Wireless POS Terminal MODEL: LMT-3000S FCC ID: SRVLMT-3000S REPORT NUMBER: 04I3098-3 ISSUE DATE: November 19, 2004 Prepared for Linudix Co., Ltd. Anyang K-Center 6F, 1591-9, Kwanyang-Dong Dongan-Gu Anyang, Gyeonggi, 431-060, Korea Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 04I3098-3 DATE: November 19, 2004 FCC ID: SRVLMT-3000S COMPLIANCE CERTIFICATION SERVICES Page: 2 of 30 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Revisions Revised By REPORT NO: 04I3098-3 DATE: November 19, 2004 FCC ID: SRVLMT-3000S COMPLIANCE CERTIFICATION SERVICES Page: 3 of 30 This report shall not be reproduced except in full, without the written approval of CCS. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) DATES OF TEST: November 19, 2004 APPLICANT: Linudix Co., Ltd. ADDRESS: Anyang K-Center 6F, 1591-9, Kwanyang-Dong Dongan-Gu Anyang, Gyeonggi, 431-060, Korea FCC ID: SRVLMT-3000S MODEL: LMT-3000S DEVICE CATEGORY: Portable Device EXPOSURE CATEGORY: General Population/Uncontrolled Explosure Wireless POS Terminal Test Sample is a: Production unit Modulation type: GSM+GPRS FCC Rule Parts Frequency Range [MHz] The Highest SAR Values [1g_mW/g] Max. Power Output [dBm] 24E 1850.2 ~ 1909.8 Body: 0.293 30.4 22H 824.2 ~ 848.8 Body: 0.585 32.4 Note: A separation distance of 1.5 cm between the back of the device and a flat phantom This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Explosure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (Edition 01-01). Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Released For CCS By: Hsin-Fu Shih (Sunny Shih) COMPLIANCE CERTIFICATION SERVICES REPORT NO: 04I3098-3 DATE: November 19, 2004 FCC ID: SRVLMT-3000S COMPLIANCE CERTIFICATION SERVICES Page: 4 of 30 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1 EQUIPMENT UNDER TEST (EUT) DESCRIPTION............................................................................ 5 2 FACILITIES AND ACCREDITATION ................................................................................................... 5 3 SYSTEM DESCRIPTION ..................................................................................................................... 6 4 SYSTEM COMPONENTS .................................................................................................................... 7 4.1 DASY4 MEASUREMENT SERVER.............................................................................................. 7 4.2 DATA ACQUISITION ELECTRONICS (DAE)............................................................................... 7 4.3 EX3DV3 ISOTROPIC E-FIELD PROBE FOR DOSIMETRIC MEASUREMENTS ....................... 7 4.4 LIGHT BEAM UNIT ....................................................................................................................... 8 4.5 SAM PHANTOM (V4.0)................................................................................................................. 8 4.6 DEVICE HOLDER FOR SAM TWIN PHANTOM .......................................................................... 9 4.7 SYSTEM VALIDATION KITS ........................................................................................................ 9 4.8 COMPOSITION OF INGREDIENTS FOR TISSUE SIMULATING LIQUID .................................. 9 5 TEST POSITIONS FOR DEVICES OPERATING NEXT TO A PERSON’S EAR.............................. 10 5.1 CHEEK/TOUCH POSITION........................................................................................................ 11 5.2 EAR/TILT POSITION .................................................................................................................. 12 6 TEST POSITIONS FOR BODY-WORN AND OTHER SIMILAR CONFIGURATIONS ..................... 13 7 SIMULATING LIQUID PARAMETERS CHECK ................................................................................. 14 7.1 SIMULATING LIQUID PARAMETER CHECK RESULT............................................................. 15 8 SYSTEM PERFORMANCE CHECK .................................................................................................. 19 8.1 SYSTEM PERFORMANCE CHECK RESULTS ......................................................................... 20 9 SAR MEASUREMENT PROCEDURES............................................................................................. 21 10 PROCEDURES USED TO ESTABLISH TEST SIGNAL.................................................................... 23 11 SAR MEASUREMENT RESULTS .....................................................................................................24 11.1 BODY POSITION ........................................................................................................................ 24 12 EUT PHOTOS .................................................................................................................................... 25 13 MEASUREMENT UNCERTAINTY...................................................................................................…

Text truncated - open the document above for the full version.

Date/Time: 11/19/04 13:54:20 Test Laboratory: Compliance Certification Services System Performance Check @ 1900MHz DUT: Dipole 1900 MHz; Type: D1900V2; Serial: D1900V2 - SN:5d043 Phantom section: Flat Section Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.43 mho/m; ε r = 41.2; ρ = 1000 kg/m 3 Measurement Standard: DASY4 (High Precision Assessment) z Room Ambient Temperature: 24.0 deg. C; Liquid Temperature: 23.0 deg. C z Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg z Probe: EX3DV3 - SN3531; ConvF(8.98, 8.98, 8.98); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 12/23/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.4 Build 3; Postprocessing SW: SEMCAD, V1.8 Build 130 d=10mm; Pin=250mW/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 13.4 mW/g d=10mm; Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 98.1 V/m; Power Drift = 0.0 dB Peak SAR (extrapolated) = 18.2 W/kg SAR(1 g) = 10 mW/g; SAR(10 g) = 5.19 mW/g 0 dB = 13.4mW/g Date/Time: 11/19/04 13:54:20 Test Laboratory: Compliance Certification Services System Performance Check @ 1900MHz DUT: Dipole 1900 MHz; Type: D1900V2; Serial: D1900V2 - SN:5d043 Phantom section: Flat Section Measurement Standard: DASY4 (High Precision Assessment) d=10mm; Pin=250mW/Z Scan (1x1x41): Measurement grid: dx=20mm, dy=20mm, dz=2.5mm Maximum value of SAR (measured) = 18.8 mW/g Date/Time: 11/19/04 16:46:40 Test Laboratory: Compliance Certification Services System Performance Check @ 835MHz DUT: Dipole 835 MHz; Type: D835V2; Serial: D835V2 - SN:4d002 Phantom section: Flat Section Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.905 mho/m; ε r = 40.5; ρ = 1000 kg/m 3 Measurement Standard: DASY4 (High Precision Assessment) z Room Ambient Temperature: 24.0 deg. C; Liquid Temperature: 23.0 deg. C z Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg z Probe: EX3DV3 - SN3531; ConvF(10.7, 10.7, 10.7); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 12/23/2003 z Phantom: SAM 1; Type: SAM 1; Serial: 1185 z Measurement SW: DASY4, V4.4 Build 3; Postprocessing SW: SEMCAD, V1.8 Build 130 d=15mm, Pin=250mW/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 3 mW/g d=15mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 58.2 V/m; Power Drift = -0.0 dB Peak SAR (extrapolated) = 3.7 W/kg SAR(1 g) = 2.45 mW/g; SAR(10 g) = 1.59 mW/g 0 dB = 3mW/g Date/Time: 11/19/04 16:46:40 Test Laboratory: Compliance Certification Services System Performance Check @ 835MHz DUT: Dipole 835 MHz; Type: D835V2; Serial: D835V2 - SN:4d002 Phantom section: Flat Section Measurement Standard: DASY4 (High Precision Assessment) d=15mm, Pin=250mW/Z Scan (1x1x41): Measurement grid: dx=20mm, dy=20mm, dz=2.5mm Maximum value of SAR (measured) = 3.98 mW/g

Date/Time: 11/19/04 14:56:06 Test Laboratory: Compliance Certification Services Body Position DUT: Linudix; Type: LMT-3000S; Serial: 340600885 Phantom section: Flat Section Frequency: 1850.2 MHz;Duty Cycle: 1:8 Medium parameters used (interpolated): f = 1850.2 MHz; σ = 1.5 mho/m; ε r = 54.5; ρ = 1000 kg/m 3 Measurement Standard: DASY4 (High Precision Assessment) z Room Ambient Temperature: 24.0 deg. C; Liquid Temperature: 23.0 deg. C z Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg z Probe: EX3DV3 - SN3531; ConvF(8.1, 8.1, 8.1); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 12/23/2003 z Phantom: SAM 2; Type: SAM 2; Serial: 1050 z Measurement SW: DASY4, V4.4 Build 3; Postprocessing SW: SEMCAD, V1.8 Build 130 d = 15 mm, L-ch/Area Scan (10x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.115 mW/g d = 15 mm, L-ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 4.69 V/m; Power Drift = 0.14 dB Peak SAR (extrapolated) = 0.151 W/kg SAR(1 g) = 0.104 mW/g; SAR(10 g) = 0.064 mW/g Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 0.127 mW/g d = 15 mm, L-ch/Zoom Scan (5x5x7)/Cube 1: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 4.69 V/m; Power Drift = 0.14 dB Peak SAR (extrapolated) = 0.104 W/kg SAR(1 g) = 0.068 mW/g; SAR(10 g) = 0.040 mW/g Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 0.086 mW/g 0 dB = 0.086mW/g Date/Time: 11/19/04 14:56:06 Test Laboratory: Compliance Certification Services Body Position DUT: Linudix; Type: LMT-3000S; Serial: 340600885 Phantom section: Flat Section Frequency: 1880 MHz;Duty Cycle: 1:8 Medium parameters used: f = 1880 MHz; σ = 1.52 mho/m; ε r = 54.5; ρ = 1000 kg/m 3 Measurement Standard: DASY4 (High Precision Assessment) z Room Ambient Temperature: 24.0 deg. C; Liquid Temperature: 23.0 deg. C z Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg z Probe: EX3DV3 - SN3531; ConvF(8.1, 8.1, 8.1); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 12/23/2003 z Phantom: SAM 2; Type: SAM 2; Serial: 1050 z Measurement SW: DASY4, V4.4 Build 3; Postprocessing SW: SEMCAD, V1.8 Build 130 d = 15 mm, M-ch/Area Scan (9x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.199 mW/g d = 15 mm, M-ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 6.33 V/m; Power Drift = 0.13 dB Peak SAR (extrapolated) = 0.268 W/kg SAR(1 g) = 0.184 mW/g; SAR(10 g) = 0.111 mW/g Maximum value of SAR (measured) = 0.226 mW/g d = 15 mm, M-ch/Zoom Scan (5x5x7)/Cube 1: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 6.33 V/m; Power Drift = 0.13 dB Peak SAR (extrapolated) = 0.186 W/kg SAR(1 g) = 0.123 mW/g; SAR(10 g) = 0.071 mW/g Maximum value of SAR (measured) = 0.154 mW/g 0 dB = 0.154mW/g Date/Time: 11/19/04 14:56:06 Test Laboratory: Compliance Certification Services Body Position DUT: Linudix; Type: LMT-3000S; Serial: 340600885 Phantom section: Flat Section Frequency: 1909.8 MHz;Duty Cycle: 1:8 Medium parameters used (interpolated): f = 1909.8 MHz; σ = 1.55 mho/m; ε r = 54.4; ρ = 1000 kg/m 3 Measurement Standard: DASY4 (High Precision Assessment) z Room Ambient Temperature: 24. 0 deg. C; Liquid Temperature: 23.0 deg. C z Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg z Probe: EX3DV3 - SN3531; ConvF(8.1, 8.1, 8.1); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 12/23/2003 z Phantom: SAM 2; Type: SAM 2; Serial: 1050 z Measurement SW: DASY4, V4.4 Build 3; Postprocessing SW: SEMCAD, V1.8 Build 130 d = 15 mm, H-ch/Area Scan (10x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.310 mW/g d = 15 mm, H-ch/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 9.48 V/m; Power Drift = 0.2 dB Peak SAR (extrapolated) = 0.435 W/kg SAR(1 g) = 0.293 mW/g; SAR(10 g) = 0.177 mW/g Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 0.363 mW/g d = 15 mm, H-ch/Zoom Scan (5x5x7)/Cube 1: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 9.48 V/m; Power Drift = 0.2 dB Peak SAR (extrapolated) = 0.340 W/kg SAR(1 g) = 0.227 mW/g; SAR(10 g) = 0.132 mW/g Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 0.283 mW/g 0 dB = 0.283mW/g Date/Time: 11/19/04 14:56:06 Test Laboratory: Compliance Certification Services Body Position DUT: Linudix; Type: LMT-3000S; Serial: 340600885 Phantom section: Flat Section Measurement Standard: DASY4 (High Precision Assessment) d = 15 mm, H-ch/Z Scan (1x1x41): Measurement grid: dx=20mm, dy=20mm, dz=2.5mm Info: Interpolated medium parameters used for SAR evaluation! Maximum value of SAR (measured) = 0.369 mW/g Date/Time: 11/19/04 18:05:31 Test Laboratory: Compliance Certification Services Body Position DUT: Linudix; Type: LMT-3000S; Serial: 340600885 Phantom section: Flat Section Frequency: 824.04 MHz;Duty Cycle: 1:8 Medium parameters used (interpolated): f = 824.04 MHz; σ = 0.961 mho/m; ε r = 54.6; ρ = 1000 kg/m 3 Measurement Standard: DASY4 (High Precision Assessment) z Room Ambient Temperature: 24.0 deg. C; Liquid Temperature: 23.0 deg. C z Area Scan setting - Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg z Probe: EX3DV3 - SN3531; ConvF(10.5, 10.5, 10.5); z Sensor-Surface: 2.5mm (Mechanical Surface Detection) z Electronics: DAE3 Sn500; Calibrated: 12/23/2003 z Phantom: SAM 2; Type: SAM 2; Serial: 1050 z Measurement SW: DASY4, V4.4 Build 3; Postprocessing SW: SEMCAD, V1.8 Build 130 d = 15 mm, L-ch/Area Scan (10x12x1): Measurement grid: d…

Text truncated - open the document above for the full version.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Sony Ericsson Mobile Communications. GR48 GSM/GPRS Communications Module To: FCC Part 15, 22 and 24 Test Report Serial No: …

Text truncated - open the document above for the full version.
