SRVLWS110FIP DVR SERVER

IP DVR SERVER USER MANUAL 1 User Manual Version 1.0.3 / 2008.3 1. Product Description. 1.1. Outline. This user manual is intended to help its users to understand the usage and setup of IP DVR SERVER, by listing and explaining appearance, network connectivity, functional capability and etc. The software of this product can be and will be upgraded without any notice, in order to improve its quality. Its users can check the current software version of the product in the administration page. Linudix Co., Ltd. has intellectual property rights relating to technology embodied in the product described in this document. It is prohibited by law to copy part or all of this user manuals contents without prior consent of Linudix Co., Ltd. 1.2. Main Function. 1.2.1. Definition of IP DVR SERVER. IP DVR SERVER is capable of transmitting live video on real time basis and record at the same time. Simply by connecting a network cable, its user can have an access to real time streaming and recorded images, regardless of time and place via internet. 1.2.2. Dual Codec & Resolution. IP DVR SERVER uses MPEG-4 and Motion JPEG, simultaneously. MPEG-4 supports 640x480(VGA) and 320x240(QVGA) for its resolution and Motion JPEG supports 640x480(VGA), 320x240(QVGA) and 160x120(1/8 VGA) for its resolution. 1.2.3. Audio Support. User can connect an active speaker with built-in amp to its Line-Out (mono) and condenser microphone to its Line-In (mono) or output signal (to audio equipment) to the Line-Level. It supports Simplex, Half-duplex, and Full-duplex, allowing its user to have an access to audio along with video on real time basis. 1.2.4. Recording Capability. IP DVR SERVER is capable of saving detected events, per event condition preset, to its built-in memory, allowing its user to view and search the saved images or back-up to the hard drive of user’s PC, working as a miniature DVR. IP DVR SERVER USER MANUAL 2 1.2.5. External Devices Connectivity. IP DVR SERVER comes with RS485 for PTZ driver connection and input/output terminal for various alarm connections. 1.3. Product Terms. 1.3.1. Terms. IP DVR SERVER USER MANUAL 3 Terminology Description Camera Install Hole To be used when connecting CCD to the server’s body and requires a designated screw. NETWORK Indicates the status of network connection. If running on ‘DHCP’ network, LED will be on once IP is obtained successfully. LIVE If there is at least one user connected to the ‘IP DVR SERVER’, it will indicate by flashing periodically. LED RECORD When it is saving to its built-in memory, it will flash periodically. Preset Returns back to factory default setting. Press and hold it down for 1 second or till all the LED indicators go off. In Connects a condenser microphone or output signal of audio equipment. Audio Out Connects an active speaker (with built-in amp) or headset. Video Port for connecting to CCD camera. ‘IP DVR SERVER’ distinguishes the difference between NTSC/PAL and performs accordingly. 75Ω If video is connected along with external device concurrently, it allows its user to choose to use 75Ω vertical resistance or not. If it is connected without any external device connected concurrently, it must be ‘On’. ETH 10/100 RJ-45 connector, for connecting network LAN cable. Comes with auto-MDIX function, compatible with every kind of cable used in the market today. Green On when power is being supplied to IP DVR SERVER and operating normally. LED Yellow Indicates the STATUS. If IP DVR SERVER stops to function, it will be on. In other cases, it will use different methods to indicate. RS485(-) RS485(+) RS485 connector for connecting PTZ equipment. DI Alarm input connector, connecting an external alarm device to the IP DVR SERVER to be used along with GND connector. DO Alarm output connector, to be used along with GND connector. GND To be used along with alarm or power connector. I/O Terminal DC 12/24 Connector, which provides power to connected camera. DC 12/24V Power outlet. IP DVR SERVER USER MANUAL 4 2. Connecting to Network. Temporary IP address needs to be assigned via using NetSetup Utility or ARP/Ping in the initial stage of using the product, in order to connect to the IP DVR SERVER. The default network setup is as following; z IP Address: 192.168.1.200 z Subnet Mask: 255.255.255.0 z Default Gateway: 192.168.1.1 2.1. IP Address Setup. There are two methods to assign a temporary IP address, ARP/Ping and using NetSetup. ARP/Ping is processed in user’s computer, executing the commands given in order of inputs and NetSetup is designated software to be used in Microsoft Windows 2.1.1. Using ARP/Ping. After checking the MAC address from the bottom of IP DVR SERVER run the ‘Terminal’ screen on your computer (dos if you are using Microsoft Windows). (１) Connect the computer and IP DVR SERVER in the same network. (２) After checking the computer’s network, choose the temporary IP address for your ‘IP DVR SERVER’. (You can simply use the IP address from your computer, by changing the last digit only, as long as that specific IP address is not used by other devices in the same network). (３) Reboot the IP DVR SERVER and wait for 1 minute or so till it powers back on. (４) Here is a sample per O/S used in the computer. O/S Methods Example Windows arp –s <IP address> <MAC address> ping <IP address> arp –s 192.168.1.200 00-30-ba-bf-56-10 ping 192.168.1.200 Unix Linux Mac arp –s <IP address> <MAC address> temp ping <IP address> arp –s 192.168.1.200 00:30:ba:bf:56:10 temp ping 192.168.1.200 (５) If you are getting a feedback from the temporary IP address, when ping, go to next step. If not, please check the status of IP DVR SERVER and start from the beginning again. (６) Try to connect to the IP DVR SERVER by entering the temporary IP address in the web browser’s address section. (７) If you are not getting an answer from the web browser, click on `PRESET’ to return to factory default setting and start from the beginning again. IP DVR SERVER USER MANUAL 5 2.1.2. Temporarily …

Text truncated - open the document above for the full version.

Anyang K-Center 6F, 1591-9, Kwanyang-Dong, Dongan-Gu, Anyang, Gyeonggi, Korea TEL No : +82-31-381-4294 FAX No : +82-31-381-7684 March 14, 2008 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize LTA Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: SRVLWS110F. including signing of all documents relating to these matters. Any and all acts carried out by LTA Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from LINUDIX Co., Ltd. LTA Co.,LTD. (Contact Person) Contact name: LEE, Kyung-Taek Position: Manager LINUDIX Co.,Ltd. (Contact Person) Contact name: LEE, Su-Gu Position: Assistant Engineer Sincerely, Yu-Chul, KIM / Manager LINUDIX Co.,Ltd.

Anyang K-Center 6F, 1591-9, Kwanyang-Dong, Dongan-Gu, Anyang, Gyeonggi, Korea TEL No : +82-31-381-4294 FAX No : +82-31-381-7684 March 14, 2008 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : LINUDIX CO.,Ltd FCC ID : SRVLWS110F Request for Confidentiality Gentlemen: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics (File name: [SRVLWS110F] SCH.pdf), Parts list(File name: [SRVLWS110F] PL .pdf), Block diagram (File name: [SRVLWS110F] BLK.pdf), and Operational description (File name: [SRVLWS110F] OpDes.pdf). The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Yu-Chul, KIM / Manager LINUDIX Co.,Ltd.

Anyang K-Center 6F, 1591-9, Kwanyang-Dong, Dongan-Gu, Anyang, Gyeonggi, Korea TEL No : +82-31-381-4294 FAX No : +82-31-381-7684 March 14, 2008 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : LINUDIX CO.,Ltd FCC ID : SRVLWS110F Cover letter Gentlemen: The product have WLAN module. The modules are already authorized under separate FCC ID’s. WLAN Module FCC ID: SRVWMGMR01 The digital/computer portion of the device was authorized under the Declaration Conformity procedure. Sincerely, Yu-Chul, KIM / Manager LINUDIX Co.,Ltd.

FCC ID:SRVLWS110F Copyright ○ c 2008, LTA Co., Ltd. Page 1 of 4 FCC ID:SRVLWS110F Copyright ○ c 2008, LTA Co., Ltd. Page 2 of 4 FCC ID:SRVLWS110F Copyright ○ c 2008, LTA Co., Ltd. Page 3 of 4 FCC ID:SRVLWS110F Copyright ○ c 2008, LTA Co., Ltd. Page 4 of 4

SAMPLE LABEL & LOCATION Model name: LWS-110F FCC ID: SRVLWS110F LNX-LWS-110F(B) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, Including interference that may cause undesired operation. 당해 무선설비는 운용중 전파혼신 가능성이 있음

FCC ID: SRVLWS110F Copyright ○ c 2008, LTA Co., Ltd. Page 1 of 5 FCC ID: SRVLWS110F Copyright ○ c 2008, LTA Co., Ltd. Page 2 of 5 FCC ID: SRVLWS110F Copyright ○ c 2008, LTA Co., Ltd. Page 3 of 5 FCC ID: SRVLWS110F Copyright ○ c 2008, LTA Co., Ltd. Page 4 of 5 FCC ID: SRVLWS110F Copyright ○ c 2008, LTA Co., Ltd. Page 5 of 5

External Monopole Antenna APPROVAL SHEET CUSTOMER : ITEM : External WLAN Antenna DESCRIPTION : Monopole Ant. CUSTOMER P/NO : DATE : 2004 . 05 . 06 CUSTOMER’S APPROVED REV NO ; CUIT. MECH. SAFETYEMI CHKD APPD KOSAN I & T Co., Ltd A P P R O V E D EN’GR CHKD APPD Approval Date Approval No. BEAUCOM DESC KOSAN I & T Co., Ltd. www.kosan.co.kr 2 Subject External Monopole Antenna Approval Sheet Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 Date May 6, 2004 Application System WLAN Customer Notice All the specifications and data in this sheet may vary for each different product board of you. KOSAN I & T Co., Ltd. R&D Center, 3209, C-Dong Dongil technotown, 889-1 Kwanyang-Dong, Dongan-Ku, Anyang-City, Kyounggi-Do 431-060, Korea Tel : +82-31-424-7167, Fax : +82-31-424-7166 Investigation Verification Approval SEOK KEE SONG Approval No. KOSAN Approval Date KOSAN I & T Co., Ltd. www.kosan.co.kr 3 - CONTENTS - 1. Electrical & Mechanical Specifications 2. Mechanical Drawing 3. Measurement Setup 4. Test Procedures 5. Reliability Test 6. Measurement Data 7. Packing 8. QC Process chart KOSAN I & T Co., Ltd. www.kosan.co.kr 4 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 1. Electrical & Mechanical Specifications Electrical Specifications Frequency Range 2400~2483.5 MHz 5150~5875 MHz V.S.W.R 1.9 : 1 (Max) 1.9 : 1 (Max) Gain(Max) 4±0.5 dBi 4±0.5 dBi Nominal Impedance 50 ohm Radiation Pattern Omni - Directional Polarization Linear Power Handling 3 watts (max) Mechanical Specifications Dimensions 128 mm × 11 Weight 15g Radiator Copper Operating Temp -20 ~ 90 Operating Humidity 0 ~ 95 % Option N/A KOSAN I & T Co., Ltd. www.kosan.co.kr 5 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 2. Mechanical Drawing KOSAN I & T Co., Ltd. www.kosan.co.kr 6 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 3. Measurement Setup 3-1. Test Equipments Network Analyzer HP8753ES Calibration Kit HP85033D High Resistance Meter HP4277A Withstanding Voltage Tester TOS-8750 Adaptor SMA Reverse Type Adaptor Measurement Cable 8120-4779 (Hewlett Packard) 3-2. Test Equipments Setting 2.1 Display Dual channel : On Split display : On 2.2 Menu Number of points : 201 Power : 0 dBm 2.3 Measure Channel 1 : S11 3-3. Calibration Calibration- Cal. Kit : 50 Calibration menu Full-2 Port Reflection Forward : Open Short Load Reverse : Open Short Load Done Transmission Do Both FWD + REV Done Isolation Omit Isolation Done KOSAN I & T Co., Ltd. www.kosan.co.kr 7 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 4. Test Procedures 4-1. V.S.W.R. Step 1. Connect ANT Port With Cable included Adaptor to Port1 of Network Analyzer. Step 2. Point out Markers on Network Analyzer Display at2400MHz , 2483.5MHz, and 5150MHz, 5475 MHz, 5875MHz Step 3. Inspect V.S.W.R < 1.9 Step 4. Measurement KOSAN I & T Co., Ltd. www.kosan.co.kr 8 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 4-2. Gain and Pattern (Near Field Chamber) Step 1. Calibrate Chamber System for Gain Measurement Using Stargate 32 Sensor. At the Same Time Set Up Software Program for Chamber System Control. Step 2. Change Over from a Stargate 32 Sensor to Measuring Antenna on Target Positioner. Step 3. Start a Software Program for Chamber System Control & Measuring Step 4. Measurement Data KOSAN I & T Co., Ltd. www.kosan.co.kr 9 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 5. Reliability Test Item Specification Conditions Vibration Resistance No Momentary Disconnections or Noise for 300s to 600s No Damage, Crack or Parts Looseness Frequency of 100Hz to 20KHz , Amplitude of 1mm for versus deaction of Antenna , 1 Cycle Time of 60s Humidity Resistance Changeable range of RF Impedance in 505 No Electrical Short Temperature of 40, Humidity of 95% let stand for 96 hours Temperature Test Temperature(C) 30min 90 30min 40 25 Start point 30min 0 30min -20 1Cycle 1Cycle (Decreasing) (Increasing) Changeable range of RF Impedance in 505 No change of material characteristic No disconnection Decreasing form +25 to -0; 5min / Keeping on -0 for 30min / Decreasing form -0 to -20; 5min / Keeping on -20 for 30min / Increasing form -20 to +25; 30min / Cycle time = 5 Increasing form +25 to +40; 5min / Keeping on +40 for 30min / Increasing form +40 to +90; 5min / Keeping on +90 for 30min / Decreasing form +90 to +25; 60min / Cycle time = 5 Withstand Voltage No line or insulator breakdown No disconnection No damage 200V AC for 1 min Drop AUT 1.5m Steel Plate(2T) No disconnection No crack or damage Drop antenna’ set at 1.5m height From steel plate(2T) of ground KOSAN I & T Co., Ltd. www.kosan.co.kr 10 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 6. Measurement Data Model Name KWBE-2454TD90 Written by SEOK KEE SONG Authorized by PAN SIK CHOI Instrument Network Analyzer: 8753ES (HP) Subject External Monopole Antenna Frequency 2400~2483.5 MHz 5150~5875 MHz Items Spec. Test Result (#1) Frequency 2400~2483.5 MHz 5150~5875 MHz O.K V.S.W.R < 1.9 < 1.9 O.K Gain 4 ± 0.5 dBi (Max) 4 ± 0.5 dBi (Max) O.K Polarization Linear Linear Linear KOSAN I & T Co., Ltd. www.kosan.co.kr 11 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 S 11 VSWR KOSAN I & T Co., Ltd. www.kosan.co.kr 12 Radiation Pattern(AZIMUTH) - 2GHz- Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 KOSAN I & T Co., Ltd. www.kosan.co.kr 13 Radiation Pattern(ELEVATION ) - 2GHz - Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 KOSAN I & T Co., Ltd. www.kosan.co.kr 14 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 Radiation Pattern( AZIMUTH) - 5GHz- KOSAN I & T Co., Ltd. www.kosan.co.kr 15 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 Radiation Pattern( ELEVATION) - 5GHz-

Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 1 of 39 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com CERTIFICATION OF COMPLIANCE FCC ID. APPLICANT FCC Classification : FCC Part 15 Spread Spectrum Transceiver (DSS) Manufacturing Description : 802.11g Wireless LAN SiP Module Manufacturer : LINUDIX CO., LTD. Model name : WM-G-MR-01 Test Device Serial No.: : - Rule Part(s) : FCC Part 15.247 Subpart C; ANSI C-63.4-2003 Frequency Range : 2412MHz ~ 2462MHz RF power : 18.90dBm Peak Conducted (802.11b) 18.44dBm Peak Conducted (802.11g) Data of issue : February 22, 2008 This test report is issued under the authority of: The test was supervised by: Dong –Min JUNG, Technical Manager Kyung-Taek LEE, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by any agency. NVLAP LAB Code.: 200723-0 Dates of Tests: February 04 ~ 21, 2008 Test Report S/N: LR500190802B Test Site : LTA CO., LTD. SRVWMGMR01 LINUDIX CO., LTD. Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 2 of 39 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TECHNICAL CHARACTERISTICS TEST ------------------------------------------------------- 3.2.1 6dB BANDWIDTH ------------------------------------------------------------------------------ 3.2.2 PEAK OUTPUT POWER ----------------------------------------------------------------------- 3.2.3 POWER SPECTRAL DENSITY --------------------------------------------------------------- 3.2.4 BAND – EDGE & SPURIOUS ----------------------------------------------------------------- 3.2.5 FIELD STRENGTH OF HARMONICS ------------------------------------------------------ 3.2.6 RADIATED BAND-EDGE-RESTRICTED BANDS --------------------------------------- 3.2.7 AC CONDUCTED EMISSIONS -------------------------------------------------------------- APPENDIX APPENDIX 1 MAXIMUM PERMISSIBLE EXPOSURE CALCULATIONS ------------------- APPENDIX 2 TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 9 12 15 24 29 31 36 38 Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 3 of 39 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2008-09-30 ECT accredited Lab. RRL KOREA KR0049 2009-06-20 EMC accredited Lab. FCC U.S.A 610755 2008-03-28 FCC filing VCCI JAPAN R2133, C2307 2008-06-22 VCCI registration IC CANADA IC5799 2008-04-23 IC filing Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 4 of 39 2. Information’s about test item 2-1 Client & Manufacturer Company name : LINUDIX Co.,Ltd. Address : Anyang K-Center 6F, 1591-9, Kwanyang-Dong, Dongan-Gu, Anyang, Gyeonggi, Korea (431-060) Tel / Fax : +82-31-381-4294 / +82-31-381-7684 2-2 Equipment Under Test (EUT) Trade name : 802.11g Wireless LAN SiP Module FCC ID : SRVWMGMR01 Model name : WM-G-MR-01 Serial number : - Date of receipt : February 04, 2008 EUT condition : Pre-production, not damaged Antenna type : Monopole Antenna Max. Gain 4.33 dBi Frequency Range : 2412MHz ~ 2462MHz (DSSS) RF output power : 18.90dBm Peak Conducted (802.11b) 18.44dBm Peak Conducted (802.11g) Type of Modulation : CCK, DQPSK, DBPSK for DSSS 64QAM, 16QAM, QPSK, BPSK for OFDM Transfer Rate : 11/5.5/2/1Mbps for 802.11b 54/48/36/24/18/12/9/6Mbps for 802.11g Power Source : 3.3Vdc from host equipment 2-3 Tested frequency LOW MID HIGH Frequency (MHz) 2412 2437 2462 2-4 Ancillary Equipment Equipment Model No. Serial No. Manufacturer PC HP COMPAG dx2200 CNG6500RX9 HP Monitor VS11353 E060T0404 View Sonic Keyboard SK-8115 641-OEWW DELL Mouse M056U0 520107013 DELL Print STYLUS C65 N/A EPSON Router BR-015B SKY 11470Y20P3085 LANSTORY INC Zig Board N/A N/A LINUDIX Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 5 of 39 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) 15.247(a) 6 dB Bandwidth > 500kHz C 15.247(b) Transmitter Peak Output Power < 1Watt C 15.247(d) Transmitter Power Spectral Density < 8dBm @ 3kHz C 15.247(d) Band Edge & Spurious > 20 dBc Conducted C 15.209 Field Strength of Harmonics Emission Radiated C 15.207 AC Conducted Emissions Emissions Conducted C 15.203 Antenna requirement - - C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The data in this test report are traceable to the national or international standards. Æ Antenna Requirement The LINUDIX Co., Ltd. ‘WM-G-MR-01’ unit complies with the requirement of §15.203. The antenna connector of module is the MHF connector. The sample was tested according to the following specification: FCC Parts 15.247; ANSI C-63.4-2003 Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 6 of 39 3.2 Technical Characteristics Test (802.11b/g) 3.2.1 6 dB Bandwidth Procedure: The bandwidth at 6dB below the highest in-band spectral density was measured with a spectrum analyzer connected to the antenna terminal…

Text truncated - open the document above for the full version.

Ref. No.: LR500190802A Copyright ○ c 2008, LTA Co., Ltd. Page 1 of 20 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: February 04 ~ 21, 2008 Test Report S/N: LR500190802A Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID. APPLICANT FCC Classification : FCC Part 15 Spread Spectrum Transceiver (DSS) Manufacturing Description : IP DVR SERVER Manufacturer : LINUDIX CO., LTD. Model name : LWS-110F / LWS-110 Test Device Serial No.: : Identical prototype Rule Part(s) : FCC Part 15.247 Subpart C; ANSI C-63.4-2003 Frequency Range : 2412 ~ 2462MHz RF power : 18.90dBm Peak Conducted (802.11b) 18.44dBm Peak Conducted (802.11g) Data of issue : February 22, 2008 This test report is issued under the authority of: The test was supervised by: Dong –Min JUNG, Technical Manager Kyung-Taek LEE, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by any agency. NVLAP LAB Code.: 200723-0 SRVLWS110F LINUDIX CO., LTD. Ref. No.: LR500190802A Copyright ○ c 2008, LTA Co., Ltd. Page 2 of 20 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TECHNICAL CHARACTERISTICS TEST ------------------------------------------------------- 3.2.1 FIELD STRENGTH OF HARMONICS ------------------------------------------------------ 3.2.2 AC CONDUCTED EMISSIONS -------------------------------------------------------------- APPENDIX APPENDIX 1 MAXIMUM PERMISSIBLE EXPOSURE CALCULATIONS ------------------- APPENDIX 2 TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 10 17 19 Ref. No.: LR500190802A Copyright ○ c 2008, LTA Co., Ltd. Page 3 of 20 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2008-09-30 ECT accredited Lab. RRL KOREA KR0049 2009-06-20 EMC accredited Lab. FCC U.S.A 610755 2008-03-28 FCC filing VCCI JAPAN R2133, C2307 2008-06-22 VCCI registration IC CANADA IC5799 2008-04-23 IC filing Ref. No.: LR500190802A Copyright ○ c 2008, LTA Co., Ltd. Page 4 of 20 2. Information’s about test item 2-1 Applicant & Manufacturer Company name : LINUDIX Co.,Ltd. Address : Anyang K-Center 6F, 1591-9, Kwanyang-Dong, Dongan-Gu, Anyang, : Gyeonggi, Korea (431-060) TEL / FAX +82-31-381-4294 / +82-31-381-7684 2-2 Equipment Under Test (EUT) Trade name : IP DVR SERVER FCC ID : SRVLWS110F Model name : LWS-110F / LWS-110 Serial number : Identification Date of receipt : February 04, 2008 EUT condition : Production, not damaged Antenna type : Monopole Antenna Max. Gain 4.33 dBi Frequency Range : 2412MHz ~ 2462MHz (DSSS) RF output power : 18.90dBm Peak Conducted (802.11b) 18.44dBm Peak Conducted (802.11g) Type of Modulation : CCK, DQPSK, DBPSK for DSSS 64QAM, 16QAM, QPSK, BPSK for OFDM Transfer Rate : 11/5.5/2/1Mbps for 802.11b 54/48/36/24/18/12/9/6Mbps for 802.11g Power Source : 120V, 60Hz 2-3 Ancillary Equipment Equipment Model No. Serial No. Manufacturer PC HP COMPAG dx2200 CNG6500RX9 HP Monitor VS11353 E060T0404 View Sonic Keyboard SK-8115 641-OEWW DELL Mouse M056U0 520107013 DELL Print STYLUS C65 N/A EPSON Dome Camera SK-D106-TERMINAL N/A LINUDIX - - - - Ref. No.: LR500190802A Copyright ○ c 2008, LTA Co., Ltd. Page 5 of 20 3. Test Report 3.1 Summary of tests Parameter Limit Test Condition Status (note 1) I. FCC Part Section(s) 802.11b/g Module is certified by FCC(FCC ID: SRVLWS110F). II. Additional items 15.209 Field Strength of Harmonics < 54 dBuV (at 3m) Radiated C 15.207 AC Conducted Emissions EN 55022 Line Conducted C 15.203 Antenna requirement - - C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The data in this test report are traceable to the national or international standards. Æ Antenna Requirement The LINUDIX Co., Ltd. ‘LWS-110F’ unit complies with the requirement of §15.203. The antenna connector is the Reverse type SMA connector. The sample was tested according to the following specification: FCC Parts 15.247; ANSI C-63.4-2003 Ref. No.: LR500190802A Copyright ○ c 2008, LTA Co., Ltd. Page 6 of 20 3.2 Technical Characteristics Test 3.2.1 Field Strength of Harmonics Procedure: The EUT was placed on a 0.8m high wooden table inside a shielded enclosure. An antenna was placed near the EUT and measurements of frequencies and amplitudes of field strengths were recorded for reference during final measurements. For final radiated testing, measurements were performed in OATS. Measurements were performed with the EUT oriented in 3 orthogonal axis and rotated 360 degrees to determine worst-case orientation for maximum emissions. The spectrum analyzer is set to: Center frequency = the worst channel Frequency Range = 30 MHz ~ 10 th harmonic. RBW = 100 kHz ( 30MHz ~ 1 GHz) = 1 MHz (1 GHz ~ 10 th harmonic ) VBW ≥ RBW Span = 100 MHz Detector function = peak Trace = max hold Sweep = auto Measurement Data: Complies Minimum Standard: FCC Part 15.109 Frequency (MHz) Limit (uV/m) @ 10m 30 ~ 88 …

Text truncated - open the document above for the full version.

FCC ID:SRVLWS110F Copyright Ⓒ 2008, LTA Co., Ltd. Page 1 of 2 Radiated Emission FCC ID:SRVLWS110F Copyright Ⓒ 2008, LTA Co., Ltd. Page 2 of 2 Conducted Emission
