SRVWMGMR01802.11 WIRELESS LAN SIP MODULE

All rights are reserved by USI. No part of this technical document can be reproduced in any form without permission of USI. 1 Data Sheet of 802.11g WM-G-MR -01 B2B Wireless LAN Module Data Sheet Jan 19th. 2006 Rev 2.7 802.11g Wireless LAN SiP Module (WM-G-MR -01) www.usi.com.tw 802.11g Wireless LAN SiP Module V2.7 All rights are reserved by USI. No part of this technical document can be reproduced in any form without permission of USI. 3 Change Sheet Rev. Date Description of change Approval & Date Page Par Change(s) 1.0 09/14/04 All All Draft version for Review 1.1 11/12/04 Update the pin assignment Update the mechanical drawing 2.0 12/25/04 Update the picture & outpower of 802.11g 2.1 04/11/05 6,15,2 1 1. Updated Executive summary for available date from “the middle of 1Q 2005” to “the end of 2Q 2005”. 2.Update the mechanical drawing (more specific one) ; update pin description for xxx_B is from “ Active low” to Active high” 2.2 04/28/05 21,22 1. Update Pin”A10” pin definition from “left open no use” to “ using as address line for CIS and memory access “and Type change from “No connection “ to “ Input PD 5VT” 2.3 04/28/05 14 1. Update Power consumption and sensitivity 2.4 11/8/05 21,22, 23, 24 Add SDIO Pin Definition 2.5 11/28 8, 15, 18, 23 1. Operation Voltage 2. Temperature 3. Radio Specification 4. Radio Pre-test 5. Drawing of Pin definition 2.6 01/06/06 9,15 4.3.2 4.5 1.IOH ; IOL value is corrected to typical not Min 2.Remove VOH on Min. 3.Tx output power add 12,24,36Mbps on the power range 14 +/-1dBm ; 12+/-1 dBm is for 48;54Mbps 2.7 01/19/06 15 4.5 Update 802.11b output power tolerance from +1.5/-1.0 dBm to +2.0/-1.0 dBm 802.11g Wireless LAN SiP Module V2.7 All rights are reserved by USI. No part of this technical document can be reproduced in any form without permission of USI. 4 TABLE OF CONTENTS 1. SUMMARY........................................................................................................................................6 2. DELIVERABLES.............................................................................................................................6 3. REFERENCE DOCUMENTS.........................................................................................................7 4. TECHNICAL SPECIFICATION.....................................................................................................7 4.1. ABSOLUTE MAXIMUM RATING...............................................................................................7 4.2. RECOMMENDABLE OPERATION CONDITION......................................................................8 4.2.1. TEMPERATURE, HUMIDITY.............................................................................................8 4.2.2 SUPPLY VOLTAGE...........................................................................................................8 4.3. COMPACTFLASH SPECIFICATION.........................................................................................9 4.3.1. DC ELECTRICALS.............................................................................................................9 4.3.2. AC ELECTRICALS.............................................................................................................9 4.3.3. COMPACTFLASH PROTOCAL TIMING.........................................................................10 4.4. WIRELESS SPECIFICATIONS................................................................................................15 4.5. RADIO SPECIFICATIONS 802.11G........................................................................................15 4.6. RECEIVER SPECIFICATIONS................................................................................................15 4.7. DIMENSIONS, WEIGHT AND MOUNTING.............................................................................16 4.7.1. DIMENSIONS...................................................................................................................16 4.7.2. WEIGHT............................................................................................................................16 4.7.3. MOUNTING......................................................................................................................16 4.8. SHOCK AND VIBRATION........................................................................................................16 5. COMPATIBILITY AND INTEROPERABILITY.........................................................................17 5.1. WI-FI LOGO..............................................................................................................................17 5.2. WHQL COMPLIANCE..............................................................................................................17 6. CONFIGURABILITY.....................................................................................................................17 7. SECURITY......................................................................................................................................17 8. OPERATING SYSTEM COMPATIBILITY.................................................................................17 9. LEGAL, REGULATORY & OTHER TECHNICAL CONSTRAINTS.....................................17 9.1. EMC..........................................................................................................................................18 9.2. COMPONENT SPECIFICATION.............................................................................................18 9.3. RADIO PRETEST.....................................................................................................................19 9.4. PRODUCT MARKING..............................................................................................................20 9.5. ENVIRONMENTALLY SAFE MATERIAL RESTRICTIONS....................................................21 802.11g Wireless LAN SiP Module V2.7 All rights are reserved by US…

Text truncated - open the document above for the full version.

Anyang K-Center 6F, 1591-9, Kwanyang-Dong, Dongan-Gu, Anyang, Gyeonggi, Korea TEL No : +82-31-381-4294 FAX No : +82-31-381-7684 March 14, 2008 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize LTA Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: SRVWMGMR01. including signing of all documents relating to these matters. Any and all acts carried out by LTA Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from LINUDIX Co., Ltd. LTA Co.,LTD. (Contact Person) Contact name: LEE, Kyung-Taek Position: Manager LINUDIX Co.,Ltd. (Contact Person) Contact name: LEE, Su-Gu Position: Assistant Engineer Sincerely, Yu-Chul, KIM / Manager LINUDIX Co.,Ltd.

Anyang K-Center 6F, 1591-9, Kwanyang-Dong, Dongan-Gu, Anyang, Gyeonggi, Korea TEL No : +82-31-381-4294 FAX No : +82-31-381-7684 March 14, 2008 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : LINUDIX CO.,Ltd FCC ID : SRVWMGMR01 Request for Confidentiality Gentlemen: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics (File name: [SRVWMGMR01] SCH.pdf), Parts list(File name: [SRVWMGMR01] PL.pdf), Block diagram (File name: [SRVWMGMR01] BLK.pdf), and Operational description (File name: [SRVWMGMR01] OpDes.pdf). The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Yu-Chul, KIM / Manager LINUDIX Co.,Ltd.

March 14, 2008 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: FCC ID: SRVWMGMR01 To whom it may concern: Submitted herewith is an application for a Wireless LAN modular. In accordance with the requirements set forth in DA 00-1407 Released: June 26, 2000, this device incorporates the design features as described and listed below for Part 15 modular transmitter approval: 1. The modular transmitter has its own RF shielding. As can be seen from the test site photos, the device was tested outside the host equipment that provided data and power to the unit. 2. This modular transmitter has buffered modulation/data inputs that ensure the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. 3. This modular transmitter has its own power supply regulation to ensure that the module will comply with Part 15 requirements regardless of the design of the power supplying circuitry in the device into which the module is installed. 4. The modular transmitter complies with the antenna requirements of Section 15.203 and 15.204(c). The product will be installed inside of the CCD Camera. The antenna is located outside of the device and The antenna connector type is reverse SMA type and so meets the requirements of 15.203 and 15.204(c). 5. This modular transmitter was tested in a stand-alone configuration outside the host device during testing. No modifications were made to the host device. 6. This modular transmitter is labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed will also display a label referring to the enclosed module. This exterior label will use this wording: “Contains FCC ID: SRVWMGMR01”. 7. This modular transmitter complies with all operating requirements applicable to the transmitter. 8. This modular transmitter complies with applicable RF exposure requirements. Please refer to MPE Calculation. 9. This modular transmitter will be installed only in the product of LINUDIX Co., Ltd. Sincerely, Yu-Chul, KIM / Manager LINUDIX Co.,Ltd. Anyang K-Center 6F, 1591-9, Kwanyang-Dong, Dongan-Gu, Anyang, Gyeonggi, Korea TEL No : +82-31-381-4294 FAX No : +82-31-381-7684

FCC ID:SRVWMGMR01 Copyright ○ c 2008, LTA Co., Ltd. Page 1 of 1

SAMPLE LABEL & LOCATION FCC ID: SRVWMGMR01

FCC ID: SRVWMGMR01 Copyright ○ c 2008, LTA Co., Ltd. Page 1 of 1

External Monopole Antenna APPROVAL SHEET CUSTOMER : ITEM : External WLAN Antenna DESCRIPTION : Monopole Ant. CUSTOMER P/NO : DATE : 2004 . 05 . 06 CUSTOMER’S APPROVED REV NO ; CUIT. MECH. SAFETYEMI CHKD APPD KOSAN I & T Co., Ltd A P P R O V E D EN’GR CHKD APPD Approval Date Approval No. BEAUCOM DESC KOSAN I & T Co., Ltd. www.kosan.co.kr 2 Subject External Monopole Antenna Approval Sheet Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 Date May 6, 2004 Application System WLAN Customer Notice All the specifications and data in this sheet may vary for each different product board of you. KOSAN I & T Co., Ltd. R&D Center, 3209, C-Dong Dongil technotown, 889-1 Kwanyang-Dong, Dongan-Ku, Anyang-City, Kyounggi-Do 431-060, Korea Tel : +82-31-424-7167, Fax : +82-31-424-7166 Investigation Verification Approval SEOK KEE SONG Approval No. KOSAN Approval Date KOSAN I & T Co., Ltd. www.kosan.co.kr 3 - CONTENTS - 1. Electrical & Mechanical Specifications 2. Mechanical Drawing 3. Measurement Setup 4. Test Procedures 5. Reliability Test 6. Measurement Data 7. Packing 8. QC Process chart KOSAN I & T Co., Ltd. www.kosan.co.kr 4 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 1. Electrical & Mechanical Specifications Electrical Specifications Frequency Range 2400~2483.5 MHz 5150~5875 MHz V.S.W.R 1.9 : 1 (Max) 1.9 : 1 (Max) Gain(Max) 4±0.5 dBi 4±0.5 dBi Nominal Impedance 50 ohm Radiation Pattern Omni - Directional Polarization Linear Power Handling 3 watts (max) Mechanical Specifications Dimensions 128 mm × 11 Weight 15g Radiator Copper Operating Temp -20 ~ 90 Operating Humidity 0 ~ 95 % Option N/A KOSAN I & T Co., Ltd. www.kosan.co.kr 5 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 2. Mechanical Drawing KOSAN I & T Co., Ltd. www.kosan.co.kr 6 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 3. Measurement Setup 3-1. Test Equipments Network Analyzer HP8753ES Calibration Kit HP85033D High Resistance Meter HP4277A Withstanding Voltage Tester TOS-8750 Adaptor SMA Reverse Type Adaptor Measurement Cable 8120-4779 (Hewlett Packard) 3-2. Test Equipments Setting 2.1 Display Dual channel : On Split display : On 2.2 Menu Number of points : 201 Power : 0 dBm 2.3 Measure Channel 1 : S11 3-3. Calibration Calibration- Cal. Kit : 50 Calibration menu Full-2 Port Reflection Forward : Open Short Load Reverse : Open Short Load Done Transmission Do Both FWD + REV Done Isolation Omit Isolation Done KOSAN I & T Co., Ltd. www.kosan.co.kr 7 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 4. Test Procedures 4-1. V.S.W.R. Step 1. Connect ANT Port With Cable included Adaptor to Port1 of Network Analyzer. Step 2. Point out Markers on Network Analyzer Display at2400MHz , 2483.5MHz, and 5150MHz, 5475 MHz, 5875MHz Step 3. Inspect V.S.W.R < 1.9 Step 4. Measurement KOSAN I & T Co., Ltd. www.kosan.co.kr 8 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 4-2. Gain and Pattern (Near Field Chamber) Step 1. Calibrate Chamber System for Gain Measurement Using Stargate 32 Sensor. At the Same Time Set Up Software Program for Chamber System Control. Step 2. Change Over from a Stargate 32 Sensor to Measuring Antenna on Target Positioner. Step 3. Start a Software Program for Chamber System Control & Measuring Step 4. Measurement Data KOSAN I & T Co., Ltd. www.kosan.co.kr 9 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 5. Reliability Test Item Specification Conditions Vibration Resistance No Momentary Disconnections or Noise for 300s to 600s No Damage, Crack or Parts Looseness Frequency of 100Hz to 20KHz , Amplitude of 1mm for versus deaction of Antenna , 1 Cycle Time of 60s Humidity Resistance Changeable range of RF Impedance in 505 No Electrical Short Temperature of 40, Humidity of 95% let stand for 96 hours Temperature Test Temperature(C) 30min 90 30min 40 25 Start point 30min 0 30min -20 1Cycle 1Cycle (Decreasing) (Increasing) Changeable range of RF Impedance in 505 No change of material characteristic No disconnection Decreasing form +25 to -0; 5min / Keeping on -0 for 30min / Decreasing form -0 to -20; 5min / Keeping on -20 for 30min / Increasing form -20 to +25; 30min / Cycle time = 5 Increasing form +25 to +40; 5min / Keeping on +40 for 30min / Increasing form +40 to +90; 5min / Keeping on +90 for 30min / Decreasing form +90 to +25; 60min / Cycle time = 5 Withstand Voltage No line or insulator breakdown No disconnection No damage 200V AC for 1 min Drop AUT 1.5m Steel Plate(2T) No disconnection No crack or damage Drop antenna’ set at 1.5m height From steel plate(2T) of ground KOSAN I & T Co., Ltd. www.kosan.co.kr 10 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 External Monopole Antenna 6. Measurement Data Model Name KWBE-2454TD90 Written by SEOK KEE SONG Authorized by PAN SIK CHOI Instrument Network Analyzer: 8753ES (HP) Subject External Monopole Antenna Frequency 2400~2483.5 MHz 5150~5875 MHz Items Spec. Test Result (#1) Frequency 2400~2483.5 MHz 5150~5875 MHz O.K V.S.W.R < 1.9 < 1.9 O.K Gain 4 ± 0.5 dBi (Max) 4 ± 0.5 dBi (Max) O.K Polarization Linear Linear Linear KOSAN I & T Co., Ltd. www.kosan.co.kr 11 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 S 11 VSWR KOSAN I & T Co., Ltd. www.kosan.co.kr 12 Radiation Pattern(AZIMUTH) - 2GHz- Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 KOSAN I & T Co., Ltd. www.kosan.co.kr 13 Radiation Pattern(ELEVATION ) - 2GHz - Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 KOSAN I & T Co., Ltd. www.kosan.co.kr 14 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 Radiation Pattern( AZIMUTH) - 5GHz- KOSAN I & T Co., Ltd. www.kosan.co.kr 15 Document No. KAT-0404-EX078P Rev. IR Model Name KWBE-2454TD90 Radiation Pattern( ELEVATION) - 5GHz-

Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 1 of 39 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com CERTIFICATION OF COMPLIANCE FCC ID. APPLICANT FCC Classification : FCC Part 15 Spread Spectrum Transceiver (DSS) Manufacturing Description : 802.11g Wireless LAN SiP Module Manufacturer : LINUDIX CO., LTD. Model name : WM-G-MR-01 Test Device Serial No.: : - Rule Part(s) : FCC Part 15.247 Subpart C; ANSI C-63.4-2003 Frequency Range : 2412MHz ~ 2462MHz RF power : 18.90dBm Peak Conducted (802.11b) 18.44dBm Peak Conducted (802.11g) Data of issue : February 22, 2008 This test report is issued under the authority of: The test was supervised by: Dong –Min JUNG, Technical Manager Kyung-Taek LEE, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by any agency. NVLAP LAB Code.: 200723-0 Dates of Tests: February 04 ~ 21, 2008 Test Report S/N: LR500190802B Test Site : LTA CO., LTD. SRVWMGMR01 LINUDIX CO., LTD. Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 2 of 39 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TECHNICAL CHARACTERISTICS TEST ------------------------------------------------------- 3.2.1 6dB BANDWIDTH ------------------------------------------------------------------------------ 3.2.2 PEAK OUTPUT POWER ----------------------------------------------------------------------- 3.2.3 POWER SPECTRAL DENSITY --------------------------------------------------------------- 3.2.4 BAND – EDGE & SPURIOUS ----------------------------------------------------------------- 3.2.5 FIELD STRENGTH OF HARMONICS ------------------------------------------------------ 3.2.6 RADIATED BAND-EDGE-RESTRICTED BANDS --------------------------------------- 3.2.7 AC CONDUCTED EMISSIONS -------------------------------------------------------------- APPENDIX APPENDIX 1 MAXIMUM PERMISSIBLE EXPOSURE CALCULATIONS ------------------- APPENDIX 2 TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 9 12 15 24 29 31 36 38 Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 3 of 39 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2008-09-30 ECT accredited Lab. RRL KOREA KR0049 2009-06-20 EMC accredited Lab. FCC U.S.A 610755 2008-03-28 FCC filing VCCI JAPAN R2133, C2307 2008-06-22 VCCI registration IC CANADA IC5799 2008-04-23 IC filing Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 4 of 39 2. Information’s about test item 2-1 Client & Manufacturer Company name : LINUDIX Co.,Ltd. Address : Anyang K-Center 6F, 1591-9, Kwanyang-Dong, Dongan-Gu, Anyang, Gyeonggi, Korea (431-060) Tel / Fax : +82-31-381-4294 / +82-31-381-7684 2-2 Equipment Under Test (EUT) Trade name : 802.11g Wireless LAN SiP Module FCC ID : SRVWMGMR01 Model name : WM-G-MR-01 Serial number : - Date of receipt : February 04, 2008 EUT condition : Pre-production, not damaged Antenna type : Monopole Antenna Max. Gain 4.33 dBi Frequency Range : 2412MHz ~ 2462MHz (DSSS) RF output power : 18.90dBm Peak Conducted (802.11b) 18.44dBm Peak Conducted (802.11g) Type of Modulation : CCK, DQPSK, DBPSK for DSSS 64QAM, 16QAM, QPSK, BPSK for OFDM Transfer Rate : 11/5.5/2/1Mbps for 802.11b 54/48/36/24/18/12/9/6Mbps for 802.11g Power Source : 3.3Vdc from host equipment 2-3 Tested frequency LOW MID HIGH Frequency (MHz) 2412 2437 2462 2-4 Ancillary Equipment Equipment Model No. Serial No. Manufacturer PC HP COMPAG dx2200 CNG6500RX9 HP Monitor VS11353 E060T0404 View Sonic Keyboard SK-8115 641-OEWW DELL Mouse M056U0 520107013 DELL Print STYLUS C65 N/A EPSON Router BR-015B SKY 11470Y20P3085 LANSTORY INC Zig Board N/A N/A LINUDIX Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 5 of 39 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) 15.247(a) 6 dB Bandwidth > 500kHz C 15.247(b) Transmitter Peak Output Power < 1Watt C 15.247(d) Transmitter Power Spectral Density < 8dBm @ 3kHz C 15.247(d) Band Edge & Spurious > 20 dBc Conducted C 15.209 Field Strength of Harmonics Emission Radiated C 15.207 AC Conducted Emissions Emissions Conducted C 15.203 Antenna requirement - - C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The data in this test report are traceable to the national or international standards. Æ Antenna Requirement The LINUDIX Co., Ltd. ‘WM-G-MR-01’ unit complies with the requirement of §15.203. The antenna connector of module is the MHF connector. The sample was tested according to the following specification: FCC Parts 15.247; ANSI C-63.4-2003 Ref. No.: LR500190802B Copyright ○ c 2008, LTA Co., Ltd. Page 6 of 39 3.2 Technical Characteristics Test (802.11b/g) 3.2.1 6 dB Bandwidth Procedure: The bandwidth at 6dB below the highest in-band spectral density was measured with a spectrum analyzer connected to the antenna terminal…

Text truncated - open the document above for the full version.

FCC ID:SRVWMGMR01 Copyright Ⓒ 2008, LTA Co., Ltd. Page 1 of 4 Radiated Emission FCC ID:SRVWMGMR01 Copyright Ⓒ 2008, LTA Co., Ltd. Page 2 of 4 Radiated Emission FCC ID:SRVWMGMR01 Copyright Ⓒ 2008, LTA Co., Ltd. Page 3 of 4 Conducted Emission FCC ID:SRVWMGMR01 Copyright Ⓒ 2008, LTA Co., Ltd. Page 4 of 4 Conducted Emission
