STF358iLauncher Thunder

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Dream Link Limited 15 Nov.,2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Dream Link Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Item Description :iLauncher Thunder Item No : 358 We affirm that between SIEMIC and Dream Linked Ltd. , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, ________________________________ Nixon Wu Chief Operations Officer Room 1207, Peninsula Centre, 67 Mody Road, Tsim Sha Tsui, Kowloon, Hong Kong.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID:STF358 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematic - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Dream Link Limited 19 Nov.,2011 ________________________________ Nixon Wu Chief Operations Officer Room 1207, Peninsula Centre, 67 Mody Road, Tsim Sha Tsui, Kowloon, Hong Kong.

Front View of the project Rear view of the Project Bottom view of the Project

Label Location Brand name location

Internal PCB-A PCB-B

FCC ID : STF358 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) Frequency Range Low Frequency (MHz) High Frequency(MHz) Center frequency (MHz) 60/f SAR Limitation (mw) 2402 2480 2441 25 Maximum measured transmitter power Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 1.24 0 1.24 Threshold at which no SAR required is 25 mw. Maximum Tx power is 0.3mw EIRP. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A

Date : 2011-12-07 Page 1 of 1 No. : MH186148 Applicant (WAS003): Dream Link Limited Room 1207, Peninsula Centre, 67 Mody Road, Tsim Sha Tsui, Kowloon, Hong Kong Manufacturer: Dream Link Limited Room 1207, Peninsula Centre, 67 Mody Road, Tsim Sha Tsui, Kowloon, Hong Kong Description of Sample(s): Product: iLaunch Thunder Brand Name: Dream Cheeky Model Number: 358 FCC ID: STF358 Date Sample(s) Received: 2011-11-08 Date Tested: 2011-11-30 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2010 and ANSI C63.4:2009 for FCC Certification. Conclusion(s): The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remark(s): --- Dr. LEE Kam Chuen Authorized Signatory ElectroMagnetic Compatibility Department For and on behalf of The Hong Kong Standards and Testing Centre Ltd. Date : 2011-12-07 Page 2 of 2 No. : MH186148 CONTENT: Cover Page 1 of 45 Content Page 2 of 45 1.0 General Details 1.1 Test Laboratory Page 3 of 45 1.2 Equipment Under Test [EUT] Page 3 of 45 Description of EUT operation 1.3 Date of Order Page 3 of 45 1.4 Submitted Sample Page 3 of 45 1.5 Test Duration Page 3 of 45 1.6 Country of Origin Page 3 of 45 2.0 Technical Details 2.1 Investigations Requested Page 4 of 45 2.2 Test Standards and Results Summary Page 4 of 45 3.0 Test Results 3.1 Emission Page 5 – 39 of 45 Appendix A List of Measurement Equipment Page 40 of 45 Appendix B Ancillary Equipment Page 41 of 45 Appendix C Photographs Page 42- 45 of 45 Date : 2011-12-07 Page 3 of 3 No. : MH186148 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong 1.2 Equipment Under Test [EUT] Description of Sample(s) Product: iLaunch Thunder Manufacturer: Dream Link Limited Room 1207, Peninsula Centre, 67 Mody Road, Tsim Sha Tsui, Kowloon, Hong Kong Brand Name: Dream Cheeky Model Number: 358 Input Voltage: Rechargeable Li-ion Battery BL-5C 3.7V 1000mAh;and USB charge port: 5Vd.c 500mA 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is a Dream Link Limited, iLaunch Thunder, it is Audio System, modulation by IC; and type is frequency hopping speed spectrum Modulation. 1.3 Date of Order 2011-11-08 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2011-11-09 to 2011-11-30 1.6 Country of Origin China Date : 2011-12-07 Page 4 of 4 No. : MH186148 2.0 Technical Details 2.1 Investigations Requested Perform Electromagnetic Interference measurements in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2010 Regulations and ANSI C63.4:2009 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Fail N/A Output Power of Fundamental Emissions FCC 47CFR 15.247(b)(1)ANSI C63.4:2009N/A RF Conduct Spurious Emission FCC 47CFR 15.247(c) N/A N/A Radiated Spurious Emissions FCC 47CFR 15.209 ANSI C63.4:2009N/A AC Mains Conducted Emissions FCC 47CFR 15.207 N/A N/A Number of Operating Channel FCC 47CFR 15.247(a)(2)(b)(1) N/A N/A Band-edge compliance of Conducted Emission FCC 47CFR 15.247© N/A N/A Channel Separation FCC 47CFR 15.247(a)(1)N/A N/A Pseudorandom Hopping Algorithm FCC 47CFR 15.247(a)(1)N/A N/A RF Exposure compliance FCC 47CFR 1.1307, 2.1091, 2.1093 N/A N/A Time of Occupancy FCC 47CFR 15.247(a)(1)(iii) N/A N/A 20dB Bandwidth FCC 47CFR 15.247(a)(2)N/A N/A Antenna requirement FCC 47CFR 15.203 N/A N/A Note: N/A - Not Applicable Date : 2011-12-07 Page 5 of 5 No. : MH186148 3.0 Test Results 3.1 Emission 3.1.1 Maximum Peak Output Power Test Requirement: FCC 47CFR 15.247(b)(1) Test Method: N/A Test Date: 2011-11-28 Ambient Temperature: 21 o C Relative Humidity: 49 % Mode of Operation: Tx mode Test Method: The RF output of the EUT was connected to the spectrum analyzer. All the attenuation or cable loss will be added to the measured maximum output power. The results are recorded in mW. Spectrum Analyzer Setting: RBW = 3 MHz, VBW= 3MHz, Sweep = Auto, Span = 10MHz Detector = Peak, Trace = Max. hold Test Setup: EUT Attenuator Spectrum Analyzer Date : 2011-12-07 Page 6 of 6 No. : MH186148 Limits for Peak Output Power of Fundamental & Harmonics Emissions [FCC 47CFR 15.247]: The maximum peak output power shall not exceeded the following limits: For frequency hopping systems employing at least 75 hopping channels: 1 Watt For all other frequency hopping systems in the 2400-2483.5 MHz band: 0.125 Watts For Digital Transmission systems in 2400-2483.5 MHz Band: 1 Watt Results of Tx Mode (2402.0 MHz to 2480.0MHz) : Pass (TX Unit) Maximum conducted output power Transmitter Frequency (MHz) Maximum conducted output power (mW) 2402 1.05 Transmitter Frequency (MHz) Maximum conducted output power (mW) 2441 0.90 Transmitter Frequency (MHz) Maximum conducted output power (mW) 2480 1.24 Limit: 0.125W (125.0mW) Calculated measurement uncertainty :30MHz to 1GHz 1.7dB 1GHz to 18GHz 1.7dB Date : 2011-12-07 Page 7 of 7 No. : MH186148 3.1.2 Radiated Emissions Test Requirement: FCC 47CFR 15.209 Test Method: ANSI C63.4:2003 Test Date: 2011-11-28 Ambient Temperature: 21 o C Relative Humidity: 48 % Mode of Operation: Tx mode Test Method: The sample was placed 0.8m above the ground plane of semi-anechoic Chamber*. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, onsidered typical configuration to obtain worst position, manipulating interconnecting cables, rotating turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the followin…

Text truncated - open the document above for the full version.

Measurement of Radiated Emission Test Set Up Measurement of Radiated Emission Test Set Up Measurement of Conducted Emission Test Set Up Measurement of Conducted Emission Test Set Up
