SU7318LIPW4CKENTRY REMOTE CONTROL

Transmitter Flat 318LIPW4CK 1A - General Information CONTENTS 1A - General information 1B - Technical specifications 1C - Main components 1 - TRANSMITTER OVERVIEW 2 - TRANSMITTER TEST 3 - OPENING AND CLOSING THE CASE 4 - BATTERY ACCESS 5 - TROUBLESHOOTING Manual Community Controls Thank you for choosing a Community Controls product. Please read this manual carefully before using the product. Made in Italy. Copyright © 2012 byCommunity Controls. The Community Controls Chameleon transmitter is designed for use with gates and door automation systems. It is made through a high-technological, three-injection molding process and is water resistant. The Chameleon is available in many different inter-changeable colorful plastic covers. The Community Controls - 318 R receiver, which operates with this transmitter has a Wiegand 26-bit format output, the receiver will operate any type of access control system equipped to accept a 26-bit Wiegand input. The CR2032 lithium batteries have a shelf life of about 6 months. The product fully complies with Part 15 of FCC Regulations and the European Directives 1999/5/CE. 1B - Technical Specifications Operating frequency318 MHz Number of keys:4 Battery:1 x 3V lithium batteries CR2032 Battery life:18 - 24 months Protocol:Linear® compatible Number combinations:65,536 Different Facilities codes16 Operating temperature: Chameleon 318 Linear® 34B 14°F÷+131°F (-10°C÷+55°C) Overall dimensions:2.48”x 1.27”x 0.417” Weight:1 oz. (20 gr.) 1C - Main Components 2 - TRANSMITTER TEST Press any button on the front of the transmitter and verify that the LED light illuminates. The LED light flashes when the battery is low. When replacing the battery, ensure the battery polarity is correct as shown in Figure D. To memorize the transmitter to the receiver, please check the instructions on the receiver. The Chameleon is compatible with 318 MHz frequency receivers. 3 - OPENING AND CLOSING THE CASE IMPORTANT: Always open and close the case using the following instructions to avoid damaging the casing. 1. Using a screwdriver, remove the screw on the bottom of the case. See Figure A. 2. carefully lift the top cover from the back, leaving a small gap (0.2 in or 0.5 cm). See Figure B. Then gently push forward the front cover. See Figure C. Do not open trying to force the front of the transmitter. See Figure D. Figure A Figure B (0.2 in or 0.5 cm) Figure CFigure D The Chameleon has covers available in the following colors: • black • white • gray • magenta • blue • green • orange • red Linear is a registered trademark owned by Linear Corporation. Figure E 5 - TROUBLESHOOTING Problem The system does not receive thetransmitter signal. The system does not receive thetransmitter signal. The transmitter led is OFF. The transmitter led is blinking. The operating range is reduced. The transmitter led is ON. Solution Replace the transmitter battery Check the power supply of the receiver NOTICE This device complies with part 15 of the FCC rules and Industry Canada ICES-003. Operating is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Community Controls could void the user’s authority to operate the equipment. IMPORTANT! Any changes or modifications not expressly approved by Community Controls could void the user’s authority to operate this equipment. WARRANTY The warranty period of Community Controls Chameleon transmitters is twenty-four (24) months. This warranty shall begin on the date the transmitter is manufactured. During the warranty period, the product will be repaired or replaced (at the sole discretion of Community Controls) if the product does not operate correctly due to a defective component. This warranty does not extend to (a) the transmitter case, which can be damaged by conditions outside the control of Community Controls, or (b) battery life of the transmitter. This warranty is further limited by the following disclaimer of warranty and liability: EXCEPT AS SET FORTH ABOVE, COMMUNITY CONTROLS MAKES NO WARRANTIES REGARDING THE GOODS, EXPRESS OR IMPLIED, INCLUDING WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE. BUYER MAKES NO RELIANCE ON ANY REPRESENTATION OF COMMUNITY CONTROLS, EXPRESS OR IMPLIED, WITH REGARD TO THE GOODS AND ACCEPTS THEM “AS-IS/WHERE-IS”. COMMUNITY CONTROLS SELLS THE GOODS TO BUYER ON CONDITION THAT COMMUNITY CONTROLS WILL HAVE NO LIABILITY OF ANY KIND AS A RESULT OF THE SALE. BUYER AGREES THAT COMMUNITY CONTROLS SHALL HAVE NO LIABILITY FOR DAMAGES OF ANY KIND, WHETHER DIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING INJURIES TO PERSONS OR PROPERTY, TO BUYER, ITS EMPLOYEES OR AGENTS, AS A RESULT OF THE SALE. BUYER ALSO AGREES TO HOLD COMMUNITY CONTROLS HARMLESS FROM ANY CLAIMS BUYER, OR ANY THIRD PARTY, MAY HAVE AS A RESULT OF BUYER’S USE OR DISPOSAL OF THE GOODS. BUYER HAS READ THIS DISCLAIMER AND AGREES WITH ITS TERMS IN CONSIDERATION OF RECEIVING THE GOODS. Figure I 3. After opening the case, remove the electronic board containing the battery. See Figure E. 4. To close the case, place the metal insert in its slot on the bottom of the case, then replace the electronic board inside. Align the top cover of the case with the bottom loop. See Figure F. Check that both the upper clips are aligned, then press together the two sides. See Figure G. Replace the screw on the bottom of the case. See Figure H. NOTE: Never force the case closed. 4 - BATTERY ACCESS Replacing the Battery: Place the new battery with the negative facing down, towards the electronic board. See Figure I. NOTE: Please dispose of batteries correctly, they are hazardous waste. Always use the proper battery, using a non-equivalent battery may cause damage to the transmitter. Figure F Figure G Figure H

Front View of the EUT – White Plastic Housing Back View of the EUT – White Plastic Housing EUT in Blue Plastic Housing EUT in Orange Plastic Housing

Battery Side of the PCB Button Side of the PCB

Transmitter Flat 318LIPW4CK 1A - General Information CONTENTS 1A - General information 1B - Technical specifications 1C - Main components 1 - TRANSMITTER OVERVIEW 2 - TRANSMITTER TEST 3 - OPENING AND CLOSING THE CASE 4 - BATTERY ACCESS 5 - TROUBLESHOOTING Manual Community Controls Thank you for choosing a Community Controls product. Please read this manual carefully before using the product. Made in Italy. Copyright © 2012 byCommunity Controls. The Community Controls Chameleon transmitter is designed for use with gates and door automation systems. It is made through a high-technological, three-injection molding process and is water resistant. The Chameleon is available in many different inter-changeable colorful plastic covers. The Community Controls - 318 R receiver, which operates with this transmitter has a Wiegand 26-bit format output, the receiver will operate any type of access control system equipped to accept a 26-bit Wiegand input. The CR2032 lithium batteries have a shelf life of about 6 months. The product fully complies with Part 15 of FCC Regulations and the European Directives 1999/5/CE. 1B - Technical Specifications Operating frequency318 MHz Number of keys:4 Battery:1 x 3V lithium batteries CR2032 Battery life:18 - 24 months Protocol:Linear® compatible Number combinations:65,536 Different Facilities codes16 Operating temperature: Chameleon 318 Linear® 34B 14°F÷+131°F (-10°C÷+55°C) Overall dimensions:2.48”x 1.27”x 0.417” Weight:1 oz. (20 gr.) 1C - Main Components 2 - TRANSMITTER TEST Press any button on the front of the transmitter and verify that the LED light illuminates. The LED light flashes when the battery is low. When replacing the battery, ensure the battery polarity is correct as shown in Figure D. To memorize the transmitter to the receiver, please check the instructions on the receiver. The Chameleon is compatible with 318 MHz frequency receivers. 3 - OPENING AND CLOSING THE CASE IMPORTANT: Always open and close the case using the following instructions to avoid damaging the casing. 1. Using a screwdriver, remove the screw on the bottom of the case. See Figure A. 2. carefully lift the top cover from the back, leaving a small gap (0.2 in or 0.5 cm). See Figure B. Then gently push forward the front cover. See Figure C. Do not open trying to force the front of the transmitter. See Figure D. Figure A Figure B (0.2 in or 0.5 cm) Figure CFigure D The Chameleon has covers available in the following colors: • black • white • gray • magenta • blue • green • orange • red Linear is a registered trademark owned by Linear Corporation. Figure E 5 - TROUBLESHOOTING Problem The system does not receive thetransmitter signal. The system does not receive thetransmitter signal. The transmitter led is OFF. The transmitter led is blinking. The operating range is reduced. The transmitter led is ON. Solution Replace the transmitter battery Check the power supply of the receiver NOTICE This device complies with part 15 of the FCC rules and Industry Canada ICES-003. Operating is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Community Controls could void the user’s authority to operate the equipment. IMPORTANT! Any changes or modifications not expressly approved by Community Controls could void the user’s authority to operate this equipment. WARRANTY The warranty period of Community Controls Chameleon transmitters is twenty-four (24) months. This warranty shall begin on the date the transmitter is manufactured. During the warranty period, the product will be repaired or replaced (at the sole discretion of Community Controls) if the product does not operate correctly due to a defective component. This warranty does not extend to (a) the transmitter case, which can be damaged by conditions outside the control of Community Controls, or (b) battery life of the transmitter. This warranty is further limited by the following disclaimer of warranty and liability: EXCEPT AS SET FORTH ABOVE, COMMUNITY CONTROLS MAKES NO WARRANTIES REGARDING THE GOODS, EXPRESS OR IMPLIED, INCLUDING WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE. BUYER MAKES NO RELIANCE ON ANY REPRESENTATION OF COMMUNITY CONTROLS, EXPRESS OR IMPLIED, WITH REGARD TO THE GOODS AND ACCEPTS THEM “AS-IS/WHERE-IS”. COMMUNITY CONTROLS SELLS THE GOODS TO BUYER ON CONDITION THAT COMMUNITY CONTROLS WILL HAVE NO LIABILITY OF ANY KIND AS A RESULT OF THE SALE. BUYER AGREES THAT COMMUNITY CONTROLS SHALL HAVE NO LIABILITY FOR DAMAGES OF ANY KIND, WHETHER DIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING INJURIES TO PERSONS OR PROPERTY, TO BUYER, ITS EMPLOYEES OR AGENTS, AS A RESULT OF THE SALE. BUYER ALSO AGREES TO HOLD COMMUNITY CONTROLS HARMLESS FROM ANY CLAIMS BUYER, OR ANY THIRD PARTY, MAY HAVE AS A RESULT OF BUYER’S USE OR DISPOSAL OF THE GOODS. BUYER HAS READ THIS DISCLAIMER AND AGREES WITH ITS TERMS IN CONSIDERATION OF RECEIVING THE GOODS. Figure I 3. After opening the case, remove the electronic board containing the battery. See Figure E. 4. To close the case, place the metal insert in its slot on the bottom of the case, then replace the electronic board inside. Align the top cover of the case with the bottom loop. See Figure F. Check that both the upper clips are aligned, then press together the two sides. See Figure G. Replace the screw on the bottom of the case. See Figure H. NOTE: Never force the case closed. 4 - BATTERY ACCESS Replacing the Battery: Place the new battery with the negative facing down, towards the electronic board. See Figure I. NOTE: Please dispose of batteries correctly, they are hazardous waste. Always use the proper battery, using a non-equivalent battery may cause damage to the transmitter. Figure F Figure G Figure H

Nemko-CCL, Inc. 1940 West Alexander Street Salt Lake City, UT 84119 801-972-6146 Test Report Certification Test Of: 318LIPW4CK Test Specifications: FCC Part 15, Subpart C FCC ID #: SU7318LIPW4CK Test Report Serial No: 216749-3.1 Applicant: Controlled Entry Distributors, Inc. DBA Community Controls 2500 South 3850 West, Suite A Salt Lake City, UT 84120 U.S.A. Dates of Test: August 8, 2012 Report Issue Date: August 30, 2012 Accredited Testing Laboratory By: NVLAP Lab Code 100272-0 Nemko-CCL, Inc. TEST REPORT: 216749-3.1 REPORT ISSUE DATE: 08/30/12 Page 2 of 30 CERTIFICATION OF ENGINEERING REPORT This report has been prepared by Nemko-CCL, Inc. to document compliance of the device described below with the certification requirements of FCC Part 15, Subpart C. This report may be reproduced in full. Partial reproduction of this report may only be made with the written consent of the laboratory. The results in this report apply only to the sample tested. - Applicant: Controlled Entry Distributors, Inc. DBA Community Controls - Manufacturer: Key Automation S.r.l. - Brand Name: Key - Model Number: 318LIPW4CK - FCC ID #: SU7318LIPW4CK On this 30 th day of August 2012, I, individually, and for Nemko-CCL, Inc., certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge, and are made in good faith. Although NVLAP has accredited the Nemko-CCL, Inc. EMC testing facilities, this report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Nemko-CCL, Inc. Tested by: Norman P. Hansen EMC Technician Reviewed by: Thomas C. Jackson General Manager Nemko-CCL, Inc. TEST REPORT: 216749-3.1 REPORT ISSUE DATE: 08/30/12 Page 3 of 30 TABLE OF CONTENTS PAGE SECTION 1.0 CLIENT INFORMATION .................................................................................4 SECTION 2.0 EQUIPMENT UNDER TEST (EUT) ..................................................................5 SECTION 3.0 TEST SPECIFICATION, METHODS & PROCEDURES .............................6 SECTION 4.0 OPERATION OF EUT DURING TESTING ..................................................10 SECTION 5.0 SUMMARY OF TEST RESULTS ...................................................................11 SECTION 6.0 MEASUREMENTS, EXAMINATIONS AND DERIVED RESULTS ..........12 APPENDIX 1 TEST PROCEDURES AND TEST EQUIPMENT ..........................................19 APPENDIX 2 PHOTOGRAPHS ................................................................................................22 Nemko-CCL, Inc. TEST REPORT: 216749-3.1 REPORT ISSUE DATE: 08/30/12 Page 4 of 30 SECTION 1.0 CLIENT INFORMATION 1.1 Applicant: Company Name: Controlled Entry Distributors, Inc. DBA Community Controls 2500 South 3850 West, Suite A Salt Lake City, UT 84120 U.S.A. Contact Name: Brad Kofford Title: President 1.2 Manufacturer: Company Name: Key Automation S.r.l. Via Alessandro Volta, 30 30020 Noventa di Piave Venice, Italy Contact Name: Andrea Peruch Title: Export Sales Manager Nemko-CCL, Inc. TEST REPORT: 216749-3.1 REPORT ISSUE DATE: 08/30/12 Page 5 of 30 SECTION 2.0 EQUIPMENT UNDER TEST (EUT) 2.1 Identification of EUT: Brand Name: Key Model Number: 318LIPW4CK Serial Number: 7 Country of Manufacture: Italy 2.2 Description of EUT: The 318LIPW4CK is a transmitter operating at 318 MHz used for access control at doors and gates. The 318LIPW4CK is a pulse modulated device with 4 buttons. The 318LIPW4CK is powered by one CR2032 battery. 2.3 EUT and Support Equipment: Brand Name Model Number FCC ID Number or Compliance Description Name of Interface Ports / Interface Cables BN: Key MN: 318LIPW4CK SN: 7 SU7318LIPW4CK 318 MHz Transmitter See Section 2.4 2.4 Interface Ports on EUT: There are no interface ports on the EUT. 2.5 Modification Incorporated/Special Accessories on EUT: There were no modifications or special accessories required to comply with the specification Nemko-CCL, Inc. TEST REPORT: 216749-3.1 REPORT ISSUE DATE: 08/30/12 Page 6 of 30 SECTION 3.0 TEST SPECIFICATION, METHODS & PROCEDURES 3.1 Test Specification: Title: FCC PART 15, Subpart C (47 CFR 15) Section 15.203 Section 15.231 Periodic operation in the band 40.66-40.70 MHz and above 70 MHz. Purpose of Test: The tests were performed to demonstrate initial compliance. 3.2 Methods & Procedures: 3.2.1 §15.203 An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this Section. The manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited. This requirement does not apply to carrier current devices or to devices operated under the provisions of Sections 15.211, 15.213, 15.217, 15.219, or 15.221. Further, this requirement does not apply to intentional radiators that must be professionally installed, such as perimeter protection systems and some field disturbance sensors, or to other intentional radiators which, in accordance with Section 15.31(d), must be measured at the installation site. However, the installer shall be responsible for ensuring that the proper antenna is employed so that the limits in this Part are not exceeded. 3.2.2 §15.231 (a) The provisions of this section are restricted to periodic operation within the band 40.66-40.70 MHz and above 70 MHz. Except as Shown in paragraph (e) of this section, the intentional radiator is restricted to the transmission of a control signal such as those used with alarm systems, door openers, remote switches, etc. Radio control of toys is not permitted. Continuous transmissions, such as voice or video, and data transmissions are not permitted. The prohibition against data transmis…

Text truncated - open the document above for the full version.

View Radiated Disturbance - Vertical Configuration View Radiated Disturbance - Horizontal Configuration View Radiated Disturbance – On Edge Configuration
