DOL1000-433RC4 Programming & Installation Manual INTRODUCTION The DOL1000-433RC4 is a versatile keypad that has the option of running wirelessly. The keypad- can work with 6 volts of batte ry power or 6-24 volts of AC/DC. It can store up to 1000 access codes. Guest access codes are also programmable, which are single-use codes for access. After 5 successive incorrect codes, the keypad will lock for 4 minutes. The very first time that you apply power to the keypad, you will hear a series of beeps followed by a regular repeating beep (1 beep at 3 second intervals) that lets you know you are in programming mode: Enter a 4 digit Master Code that only you will use for programming purposes. Write Master Code here You can now add up to 1000 access codes as well as a flash code (for one use only). To add Access Code 1934 To add Access Codes for channel 2, 3, and 4 - 2413, 888 and 9743 (you may add up to 1000 different codes) Example - Master Code 1234 Access Code: Master Code 1 2 3 41 9 3 4 Sub ModeAccess CodeChannelExit 1 #1 # To remove Access Code 1934 Master Code 1 2 3 41 9 3 4 Sub ModeAccess CodeExit 2 ## To change Master Code from 2580 to 1234 Master Code 1 2 3 44 3 2 1 Sub ModeNew Master CodeExit 7 ## To clear all Access, Flash and Latch codes Master Code 1 2 3 4 Sub Mode 8 # To add Flash Code 4437 (for one use only) Master Code 1 2 3 44 4 3 7 Sub ModeFlash CodeChannel 3 #1 Master Code 1 2 3 42 4 1 3 Sub ModeAccess CodeChannelExit 1 #2 # 8 8 8 83 # 9 7 4 34 # beep - Outside Back 4-Channel 433 MHz Receiver Antenna Inside Back Part No: DOL1000-433RC4 FC 0001 SN 12345 Part No: DOL1000-433RC4 FC 0001 SN 12345 Facility Code Part # Default Master Code: 1 234 Add Access 1 234, 1#, Access Code: __ __ __ __ , Channel:1 #(Repeat for channel 2, 3 & 4) Example: (Using Channel 1) STEP 1: Press 1 2 3 4 STEP 2: Press 1 # STEP 3: Enter access code __ __ __ __ STEP 4: Press 1 # (multiple beeps confirm) STEP 5: Press * * STEP 6: Test new access code. __ __ __ __ (Green light will flash 6 times confirming that t he new access code has been accepted.) STEP 8: Proceed to program the keypad to the receiver. STEP 7: Install 433 MHz wireless module (see next page) Codes Use Channel 1 if unsure. The diffe rent channels are dependent on the RF terminal used. Any channel can be assigned for devices that connect to normally open/normally closed. 1 2 3 4, 2#, Access Code: __ __ __ __ , # Remove Access Codes Enter the Access Code you would like to delete. 1 2 3 4, 3#, Guest Code: __ __ __ __ , Channel:1 Add Guest Code The Guest Code is a one-time use access code. Once used, the number will be cleared from memory. 1 2 3 4, 4#, Toggle Code: __ __ __ __ , Channel:1 Add Access Toggle Code Entering Access Toggle Code will toggle the keypad to continuously activate. Entering the code again will toggle the keypad off. Dip switch #6 on the circuit board needs to be in the off position in order for this mode to work. TOGGLE MODE ONLY FOR USE WHEN KEYPAD IS HARD WIRED. 1 2 3 4, 5#, Seconds:0-60, # Set Relay Output Time Set the number of seconds the device will grant access before locking again. 1 2 3 4, 7#, Master Code: __ __ __ __ , # Change Master Code Changes Master Code. If the Master Code is forgotte n, this manual contains instructions on how to reset the Master Code. 1 2 3 4, 8# Clear All Codes This will clear all data except the Master Code. PROGRAMMING THEDOL1000-MF with 433 MHz Module

Registration number: W6M21503-14866-C-1 FCC ID: SU7DOL1000-433RC4 Worldwide Testing Services(Taiwan) Co., Ltd Appendix Page 13 of 25 External Photos Registration number: W6M21503-14866-C-1 FCC ID: SU7DOL1000-433RC4 Worldwide Testing Services(Taiwan) Co., Ltd Appendix Page 14 of 25 Registration number: W6M21503-14866-C-1 FCC ID: SU7DOL1000-433RC4 Worldwide Testing Services(Taiwan) Co., Ltd Appendix Page 15 of 25
