SWX-M5GHPAccess Point

5 GHz High-Performance Model: 1 Introduction Introduction Thank you for purchasing the Ubiquiti Networks ™ airGrid ™ 5 GHz High-Performance Integrated InnerFeed Antenna, model AGM5-HP-1724. This Quick Start Guide is designed to guide you through the installation, and show you how to access the airOS ™ Configuration Interface. Package Contents Antenna FeedFeed ExtenderGrid Reflector Rear HousingL-BracketPole ClampM8 U-Bolt 5 GHz High-Performance Integrated InnerFeed Antenna Model: AGM5-HP-1724 M8 Flange Nuts (Qty. 2) PoE Adapter (24V, 0.5A) Power CordQuick Start Guide Grid reflector and mounting hardware packaged separately. Products may be different from pictures and are subject to change without notice. 2 airGrid ™ AGM5-HP-1724 Quick Start Guide Installation Requirements • 13 mm or ½" wrench • Shielded Category 5 (or above) cabling should be used for all wired Ethernet connections and should be grounded through the AC ground of the PoE. We recommend that you protect your networks from the most brutal environments and devastating ESD attacks with industrial-grade shielded Ethernet cable from Ubiquiti Networks. For more details, visit www.ubnt.com/toughcable Application Examples The airGrid mounted outdoors with the Grid Reflector installed provides directional outdoor coverage (gain reflector-dependent). The airGrid mounted outdoors without the Grid Reflector installed provides outdoor-to-indoor coverage using the 3 dBi Antenna Feed only. 3 LEDs LEDs Signal In airOS, you can modify the wireless signal strength threshold values for each LED on the Advanced tab under Signal LED Thresholds. The default values are shown below: LED will light green when the wireless signal strength is above -65 dBm. LED will light green when the wireless signal strength is above -73 dBm. LED will light amber when the wireless signal strength is above -80 dBm. LED will light red when the wireless signal strength is above -94 dBm. Ethernet The Ethernet LED will light steady green when an active Ethernet connection is made and flash when there is activity. Power The Power LED will light green when the device is connected to a power source. 4 airGrid ™ AGM5-HP-1724 Quick Start Guide Hardware Installation Assemble the airGrid according to your chosen polarization. 1. Attach the L-Bracket to the Grid Reflector by sliding the tabs into the slots. Vertical PolarizationHorizontal Polarization WARNING: The polarization of the airGrid must match the polarization of its corresponding device (horizontal to horizontal, vertical to vertical). 2. On the front of the airGrid, ensure the polarization mark, V or H, properly matches your desired polarization. Vertical PolarizationHorizontal Polarization 5 Hardware Installation 3. Attach the Rear Housing: a. Ensure the four alignment holes on the Grid Reflector and L-Bracket are lined up. b. Orient the Rear Housing with the locking tab of the cable feed door facing up. c. Insert the alignments pins of the Rear Housing into the alignment holes, and push until the Rear Housing locks into place with a click. Vertical PolarizationHorizontal Polarization 4. Insert the Feed Extender into the Rear Housing with the Release Button facing down. Push until it locks into place with a click. Release Button 6 airGrid ™ AGM5-HP-1724 Quick Start Guide 5. Lift the locking tab of the cable feed door and detach the door from the Rear Housing. 6. Route an Ethernet cable through the Rear Housing and Feed Extender. Connect the cable to the Ethernet port on the back of the Antenna Feed. 7 Hardware Installation 7. Attach the Antenna Feed: a. Rotate the Antenna Feed to match the signal polarization. b. Insert the Antenna Feed into the Feed Extender, and push until it locks into place with a click. Vertical PolarizationHorizontal Polarization 8. Lightly pull the Antenna Feed to ensure that the Release Button is fully engaged and locked into place. Antenna Feed Feed Extender Release Button Bottom View 8 airGrid ™ AGM5-HP-1724 Quick Start Guide 9. The Release Button indicates the Antenna Feed polarization. Confirm that the Antenna Feed polarization matches the Grid Reflector polarization shown in step 2. Vertical PolarizationHorizontal Polarization Note: If you need to remove the Antenna Feed, you must depress the Release Button first. 10. Re-attach the cable feed door to the Rear Housing. Ensure the locking tab securely latches to the Rear Housing. 9 Hardware Installation 11. Slide the Pole Clamp onto the L-Bracket. 12. Insert the M8 U-Bolt into the Pole Clamp and L-Bracket. Secure each end of the M8 U-Bolt with a M8 Flange Nut. 9 N-m (80 lb-in) Note: The mounting assembly can accommodate a Ø 1.25" - 2.2" pole. 10 airGrid ™ AGM5-HP-1724 Quick Start Guide Connecting Power over Ethernet 1. Connect the other end of the Ethernet cable from the airGrid to the Ethernet port labeled POE on the PoE Adapter. 2. Connect an Ethernet cable from your LAN to the Ethernet port labeled LAN on the PoE Adapter. 3. Connect the Power Cord to the power port on the PoE Adapter. Connect the other end of the Power Cord to a power outlet. 11 airOS Configuration airOS Configuration Verify connectivity in the airOS Configuration Interface and select the airGrid antenna size. 1. Make sure that your host machine is connected via Ethernet to the airGrid. 2. Configure the Ethernet adapter on your host system with a static IP address on the 192.168.1.x subnet. 3. Launch your web browser and type https://192.168.1.20 in the address field. Press enter (PC) or return (Mac). 4. The login screen will appear. Enter ubnt in the Username and Password fields. Select your Country and Language. You must agree to the Terms of Use to use the product. Click Login. Note: U.S. product versions are locked to the U.S. Country Code to ensure compliance with FCC regulations. 12 airGrid ™ AGM5-HP-1724 Quick Start Guide 5. Select the airGrid antenna size: a. Click the Wireless tab. b. From the Antenna drop-down list, select the appropriate option. c. Click Ch…
