SWX-M5PX3802.11a/n 3x3 MIMO, AirMax BaseStation

Carrier Class AirMax BaseStation 1 Introduction Introduction Thank you for purchasing the PowerBridge M5 X3. This is a point- to-point CPE wireless device. Package Contents PowerBridge M5 X3 48V PoE Adapter Power CordAntenna Bracket Clamps (Qty. 2) Pole Bracket Clamps (Qty. 2) Carrier Class AirMax BaseStation M8X135 Carriage Bolts (Qty. 4) Serrated Flange Bolts (Qty. 4) Serrated Flange Lock Nuts (Qty. 4) GPS Patch Antenna Quick Start Guide Installation Requirements • Adjustable wrench or one 16 mm and one 24 mm wrench • Flathead screwdriver • Shielded Category 5 (or above) cabling should be used for all wired Ethernet connections and should be grounded through the AC ground of the PoE. We recommend that you protect your networks from the most brutal environments and devastating ESD attacks with industrial-grade shielded Ethernet cable from Ubiquiti Networks. For more details, visit www.ubnt.com/toughcable 2 PowerBridge M5 X3 Hardware Overview Connects to GPS Patch Antenna Ethernet Port Cover LEDs Power The Power LED will light steady green when the PowerBridge is connected to a power source. Ethernet The Ethernet LED will light steady green when an active Ethernet connection is made and flash when there is activity. GPS The GPS LED lights up green when the GPS signal strength can sustain AirSync operation. This requires a minimum of 3 satellite connections. Signal The first Signal LED is lit when the wireless signal strength is above -94 dBm, the second LED when the wireless signal strength is above -77 dBm, and the third LED when the wireless signal signal strength is above -65 dBm. 3 Hardware Installation Note: By default, the Signal LEDs represent the wireless signal strength with default threshold values. In the airOS interface, you can modify the threshold values for each LED or configure the LEDs to display the GPS connection quality instead. The settings can be configured on the Advanced tab under Signal LED Thresholds. Hardware Installation To install the PowerBridge M5 X3, perform the following steps: 1. Use a flathead screwdriver to unlock the cover. Turn the screw counter-clockwise until it is loose. The screw remains attached to the cover. Lift the cover by pressing down and raising it up. 2. Connect an Ethernet cable and the GPS Patch Antenna. There are grooves for the cables on the cover. Align them properly and slide the cover back on and secure it with the screw. 4 PowerBridge M5 X3 3. Insert the M8X135 Carriage Bolts into the Antenna Bracket Clamps. 4. Connect the Antenna Bracket Clamps to the PowerBridge using the four Serrated Flange Bolts. 5 Hardware Installation 5. Mount the PowerBridge to the pole by performing the following steps: a. Position the PowerBridge in the desired mounting location on the pole. b. Slide the Pole Bracket Clamps on to the Carriage Bolts. c. Use the four Serrated Flange Lock Nuts to secure the PowerBridge to the pole. 6. Adjust the operating angle of the PowerBridge by adjusting the Serrated Flange Bolts on the top Antenna Bracket Clamp. 6 PowerBridge M5 X3 7. Connect the other end of the Ethernet cable from the PowerBridge to the Ethernet port labeled POE on the PoE Adapter. 8. Connect an Ethernet cable from your LAN to the Ethernet port labeled LAN on the PoE Adapter. 7 Hardware Installation 9. Connect the power cord to the power port on the PoE Adapter. Connect the other end of the power cord to a power outlet. 10. Place the GPS Patch Antenna on the mounting hardware. 8 PowerBridge M5 X3 Accessing the AirOS Utility 1. Make sure that your host machine is connected to the LAN that is connected to the PowerBridge. 2. Configure the Ethernet adapter on your host system with a static IP address on the 192.168.1.x subnet (e.g. 192.168.1.100). 3. Launch your Web browser and type http://192.168.1.20 in the address field and press enter (PC) or return (Mac). 4. The login screen will appear. Enter ubnt in the Username and Password fields. Select your Country and Language. You must agree to the Terms of Use to use the product. Click Login. Note: U.S. product versions are locked to the U.S. Country Code to ensure compliance with FCC regulations. The AirOS Interface will appear allowing you to customize your settings as needed. Installer Compliance Responsibility Devices must be professionally installed and it is the professional installer's responsibility to make sure the device is operated within local country regulatory requirements. 9 Specifications Specifications Enclosure Size 445 x 416 x 34 mm Weight 3.82 kg Max Power Consumption 8 Watts Power Supply 48V, 0.5A surge protection integrated PoE adapter included Power Method Passive PoE (Pairs 4, 5+; 7,8 return) Operating Temperature -30 to 80° C Operating Humidity 5 to 95% Condensing Operating Frequency Device Supports 5170 - 5875 MHz USA/Canada Supports* 5745 - 5850 MHz Networking Interface (1) 10/100/1000 Ethernet Port * Products shipped in the USA/Canada are locked to the US Country Code to ensure compliance with FCC regulations. 10 PowerBridge M5 X3 Safety Notices 1. Read, follow, and keep these instructions. 2. Heed all warnings. 3. Only use attachments/accessories specified by the manufacturer. WARNING: Do not use this product in location that can be submerged by water. WARNING: Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning. Electrical Safety Information 1. Compliance is required with respect to voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified may result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed. 2. There are no operator serviceable parts inside this equipment. Service should be provided only by a qualified service technician. 3. This equipment is provided with a detachable power cord which has an integral safety ground wire intended for connection to a grounded safety out…

Text truncated - open the document above for the full version.

PowerBridge M5: Carrier Class 5GHz MIMO Bridging Solution MIMO TDMA Protocol Ubiquiti Networks Inc., 91 E. Tasman Dr., San Jose, CA 95134 www.ubnt.com DataRatePeak. TXToleranceDataRateSensitivityTolerance 1-24Mbps27 dBm+/-2dB24Mbps-83 dBm+/-2dB 36Mbps25 dBm+/-2dB36Mbps-80 dBm+/-2dB 48Mbps23 dBm+/-2dB48Mbps-77 dBm+/-2dB 54Mbps22 dBm+/-2dB54Mbps-75 dBm+/-2dB MCS027 dBm+/-2dBMCS0-96 dBm+/-2dB MCS127 dBm+/-2dBMCS1-95 dBm+/-2dB MCS227 dBm+/-2dBMCS2-92 dBm+/-2dB MCS327 dBm+/-2dBMCS3-90 dBm+/-2dB MCS426 dBm+/-2dBMCS4-86 dBm+/-2dB MCS524 dBm+/-2dBMCS5-83 dBm+/-2dB MCS622 dBm+/-2dBMCS6-77 dBm+/-2dB MCS721 dBm+/-2dBMCS7-74 dBm+/-2dB MCS827 dBm+/-2dBMCS8-95 dBm+/-2dB MCS927 dBm+/-2dBMCS9-93 dBm+/-2dB MCS1027 dBm+/-2dBMCS10-90 dBm+/-2dB MCS1127 dBm+/-2dBMCS11-87 dBm+/-2dB MCS1226 dBm+/-2dBMCS12-84 dBm+/-2dB MCS1324 dBm+/-2dBMCS13-79 dBm+/-2dB MCS1422 dBm+/-2dBMCS14-78 dBm+/-2dB MCS1521 dBm+/-2dBMCS15-75 dBm+/-2dB SYSTEM INFORMATION Processor SpecsAtheros MIPS 24KC, 400MHz Memory Information64MB SDRAM, 8MB Flash Networking Interface1 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet Interface REGULATORY / COMPLIANCE INFORMATION Wireless ApprovalsFCC Part 15.247, IC RS210, CE RoHS ComplianceYES OPERATING FREQUENCY 5470MHz-5825MHz 5GHz TX POWER SPECIFICATIONS5GHz RX SPECIFICATIONS 11a 11a 5GHz 11n 5GHz 11n PHYSICAL / ELECTRICAL / ENVIRONMENTAL Enclosure Size445 x 416 x 34mm Weight3.82kg Enclosure CharacteristicsOutdoor UV Stabalized Plastic Mounting KitPole Mounting Kit included Max Power Consumption8 Watts Power Supply24V, 1A surge portection integrated POE adapter included Power MethodPassive Power over Ethernet (pairs 4,5+; 7,8 return) Operating Temperature -30C to +80C Polarization Operating Humidity5 to 95% Condensing Shock and VibrationETSI300-019-1.4 INTEGRATED 2x2 MIMO ANTENNA 6 deg. Frequency Range4.9-6.0 GHzMax VSWR1.1:1 Gain24.8-26.5 dBiH-pol Beamwidth6 deg. VSWR H-Pol Azimuth H-Pol Elevation V-Pol Azimuth V-Pol Elevation Dual LinearV-pol Beamwidth6 deg. Cross-pol Isolation28dB minimumElevation Beamwidth Featuring Super-Efficient 25dBi MIMO Antenna Array

91 E. Tasman Dr. | San Jose, CA 95134 | U.S.A. | Tel. 1-408-942-3085| Fax 1-408-351-4973. Ubiquiti Networks, Inc. 91 E. Tasman San Jose, CA 95134 October 11, 2011 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR PowerBridgeM5X3 (FCC ID: SWX-M5PX3) This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the schematics, block diagrams and theory of operation required to be submitted with this application be permanently withheld from public review. These documents contain proprietary information that would sacrifice our competitive advantage in the marketplace if made public. Please contact me if there is any information you may need. Sincerely, Robert J. Pera President

91 E. Tasman Dr. | San Jose, CA 95134 | U.S.A. | Tel. 1-408-942-3085| Fax 1-408-351-4973. November 1, 2011 Federal Communications Commission Certification and Engineering Bureau 7435 Oakland Mills Road Columbia, MD 21046 RE: SHORT TERM CONFIDENTIALITY REQUEST FOR PowerBridgeM5-X3 (FCC ID: SWX- M5PX3) To Whom It May Concern: This letter serves as an official request for Short-term confidentiality under FCC Rule Section 0.457 & 0.459. We request that the internal photos, external photos, test setup photos and manual required to be submitted with this application be withheld from public review for 45 days. These documents contain proprietary information that would sacrifice our competitive advantage in the marketplace if made public. We understand the documents were made public for 8 days. Please contact me if there is any information you may need. Sincerely, Robert J. Pera President

§ 15.247(i) Maximum Permissible Exposure RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. MPE Limit Calculation: EUT’s operating frequencies @ 5745 - 5825 MHz; highest conducted power = 18.58 dBm (peak) therefore, Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 EUT maximum antenna gain = 25 dBi. Equation from page 18 of OET 65, Edition 97-01 S = PG / 4R 2 or R = √PG / 4S where, S = Power Density (1 mW/cm 2 ) P = Power Input to antenna (72.11mW) G = Antenna Gain (316.23 numeric) R = (72.11*316.23/ 4*3.14*1.0) 1/2 = (22803.42 / 12.56) 1/2 = 42.61cm

MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE ! BALTIMORE, MARYLAND 21230-3432 ! PHONE (410) 354-3300 ! FAX (410) 354-3313 33439 WESTERN AVENUE ● UNION CITY, CALIFORNIA 94587 ● PHONE (510) 489-6300 ● FAX (510) 489-6372 3162 BELICK STREET ● SANTA CLARA, CALIFORNIA 95054 ● PHONE (408 748-3585 ● FAX (510) 489-6372 The Nation’s First Licensed Nationally Recognized Testing Laboratory October 10, 2011 Ubiquiti Networks, Inc. 91 E. Tasman San Jose, CA 95134 Dear Jennifer Sanchez, Enclosed is the EMC Wireless test report for compliance testing of the Ubiquiti Networks, Inc., PowerBridgeM5X3 as tested to the requirements of Title 47 of the CFR, Ch. 1 (10-1-06 ed.), Part 15, Subpart B, ICES-003, Issue 4 February 2004 for a Class A Digital Device and FCC Part 15 Subpart C, RSS-210, Issue 8, Dec. 2010 for Intentional Radiators. Thank you for using the services of MET Laboratories, Inc. If you have any questions regarding these results or if MET can be of further service to you, please feel free to contact me. Sincerely yours, MET LABORATORIES, INC. Jennifer Warnell Documentation Department Reference: (\Ubiquiti Networks, Inc.\EMCS32744-FCC247 Rev. 1) Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. Electromagnetic Compatibility Ubiquiti Networks, Inc. Cover Page PowerBridgeM5X3 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 8, Dec. 2010 & ICES-003 MET Report: EMCS32744-FCC247 Rev. 1 © 2011, MET Laboratories, Inc. Page ii of xii DOC-EMC702 6/18/2009 Electromagnetic Compatibility Criteria Test Report for the Ubiquiti Networks, Inc. PowerBridgeM5X3 Tested under the FCC Certification Rules contained in Title 47 of the CFR, Parts 15 Subpart B & ICES-003 for Class A Digital Devices & 15.247 Subpart C & RSS-210, Issue 8, Dec. 2010 for Intentional Radiators MET Report: EMCS32744-FCC247 Rev. 1 October 10, 2011 Prepared For: Ubiquiti Networks, Inc. 91 E. Tasman San Jose, CA 95134 Prepared By: MET Laboratories, Inc. 3162 Belick St. Santa Clara, CA 95054 Electromagnetic Compatibility Ubiquiti Networks, Inc. Cover Page PowerBridgeM5X3 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 8, Dec. 2010 & ICES-003 MET Report: EMCS32744-FCC247 Rev. 1 © 2011, MET Laboratories, Inc. Page iii of xii DOC-EMC702 6/18/2009 Electromagnetic Compatibility Criteria Test Report for the Ubiquiti Networks, Inc. PowerBridgeM5X3 Tested under the FCC Certification Rules contained in Title 47 of the CFR, Parts 15 Subpart B & ICES-003 for Class A Digital Devices & 15.247 Subpart C & RSS-210, Issue 8, Dec. 2010 for Intentional Radiators Anderson Soungpanya, Project Engineer Jennifer Warnell Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC Rules Parts 15B, 15.247 and Industry Canada standards ICES-003, Issue 4 February 2004, RSS-210, Issue 8, Dec. 2010 under normal use and maintenance. Shawn McMillen, Wireless Manager, Electromagnetic Compatibility Lab Electromagnetic Compatibility Ubiquiti Networks, Inc. Report Status PowerBridgeM5X3 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 8, Dec. 2010 & ICES-003 MET Report: EMCS32744-FCC247 Rev. 1 © 2011, MET Laboratories, Inc. Page iv of xii DOC-EMC702 6/18/2009 Report Status Sheet Revision Report Date Reason for Revision  October 10, 2011 Initial Issue. 1 October 20, 2011 Revised to reflect editorial correction. Electromagnetic Compatibility Ubiquiti Networks, Inc. Table of Contents PowerBridgeM5X3 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 8, Dec. 2010 & ICES-003 MET Report: EMCS32744-FCC247 Rev. 1 © 2011, MET Laboratories, Inc. Page v of xii DOC-EMC702 6/18/2009 Table of Contents I. Executive Summary .................................................................................................................................................1 A. Purpose of Test ...................................................................................................................................................2 B. Executive Summary ............................................................................................................................................2 II. Equipment Configuration .......................................................................................................................................3 A. Overview .............................................................................................................................................................4 B. References ...........................................................................................................................................................5 C. Test Site ..............................................................................................................................................................5 D. Description of Test Sample .................................................................................................................................6 E. Equipment Configuration ....................................................................................................................................7 F. Support Equipment .............................................................................................................................................7 G. Ports and Cabling Information .................................................................................................................…

Text truncated - open the document above for the full version.

Photograph 1. Conducted Emissions, Test Setup Photograph 2. Radiated Emissions, Test Setup, 30 MHz – 1 GHz Photograph 3. Radiated Emissions, Test Setup, 1 GHz – 18 GHz Photograph 4. Conducted Emissions, 15.207(a), Test Setup Photograph 5. Radiated Spurious Emissions, Test Setup, 30 MHz – 1 GHz Photograph 6. Radiated Spurious Emissions, Test Setup, 1 GHz – 18 GHz
