SWX-M900802.11 g & n MIMO 2x2 outdoor radio

M900 OEM Users Guide TECH SPECS DataRateAvg. TXToleranceDataRateSensitivityTolerance 1-24Mbps23 dBm+/-2dB24Mbps-83 dBm+/-2dB 36Mbps23 dBm+/-2dB36Mbps-80 dBm+/-2dB 48Mbps23 dBm+/-2dB48Mbps-77 dBm+/-2dB 54Mbps22 dBm+/-2dB54Mbps-75 dBm+/-2dB MCS023 dBm+/-2dBMCS0-96 dBm+/-2dB MCS123 dBm+/-2dBMCS1-95 dBm+/-2dB MCS223 dBm+/-2dBMCS2-92 dBm+/-2dB MCS323 dBm+/-2dBMCS3-90 dBm+/-2dB MCS423 dBm+/-2dBMCS4-86 dBm+/-2dB MCS523 dBm+/-2dBMCS5-83 dBm+/-2dB MCS622 dBm+/-2dBMCS6-77 dBm+/-2dB MCS721 dBm+/-2dBMCS7-74 dBm+/-2dB MCS823 dBm+/-2dBMCS8-95 dBm+/-2dB MCS923 dBm+/-2dBMCS9-93 dBm+/-2dB MCS1023 dBm+/-2dBMCS10-90 dBm+/-2dB MCS1123 dBm+/-2dBMCS11-87 dBm+/-2dB MCS1223 dBm+/-2dBMCS12-84 dBm+/-2dB MCS1323 dBm+/-2dBMCS13-79 dBm+/-2dB MCS1422 dBm+/-2dBMCS14-78 dBm+/-2dB MCS1521 dBm+/-2dBMCS15-75 dBm+/-2dB Operating Temperature -30C to 75C Operating Humidity5 to 95% Condensing Shock and VibrationETSI300-019-1.4 Pole Mounting Kit included Max Power Consumption6.5 Watts Power Supply24V, 1A POE Supply Included Power MethodPassive Power over Ethernet (pairs 4,5+; 7,8 return) Enclosure Size16cm length x 8cm width x 3cm height Weight0.5 kg RF Connector2x RPSMA (Waterproof) 1 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet Interface REGULATORY / COMPLIANCE INFORMATION Wireless ApprovalsFCC Part 15.247 RoHS ComplianceYES SYSTEM INFORMATION Processor SpecsAtheros MIPS 24KC, 400MHz Memory Information64MB SDRAM, 8MB Flash Networking Interface Enclosure CharacteristicsOutdoor UV Stabalized Plastic Mounting Kit PHYSICAL / ELECTRICAL / ENVIRONMENTAL RX SPECIFICATIONS OFDMOFDM MIMOMIMO OPERATING FREQUENCY 907-922 MHz TX POWER SPECIFICATIONS COMPLIANCE INFORMATION FCC Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. The antennas used for this transmitter must be installed to provide a separation distance of at least 23cm from all persons and must not be located or operating in conjunction with any other antenna or transmitter. INDUSTRY CANADA This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication. The device has been designed to operate with the antennas listed below and having a maximum gain of 13dBi. Antennas not included in this list or having a gain greater than 13dBi are strictly prohibited for use with this device. The required antenna impedance is 50 ohms

Ubiquiti Networks, Inc. 91 E. Tasman San Jose, CA 95134 3/13/10 Attn: MET laboratories 914 West Patapsco Ave. Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR M900 (FCC ID: SWX-M900) To Whom It May Concern: This letter serves as an official request for confidentiality under FCC Rule Section 0.457 & 0.459. We have requested that the schematics, block diagrams, theory of operation, and internal photos required to be submitted with this application be withheld from public review. These documents contain proprietary information that would sacrifice our competitive advantage in the marketplace if made public. Please contact me if there is any information you may need. Sincerely, Robert J. Pera Senior RF Engineer

M900 FCC ID: SWX-M900 IC: 6545A-M900 Ubiquiti Networks This device complies with Part15 of FCC rules. Operation is subject to the following two conditions: 1.) This device may not cause harmful interference and, 2.) This device must accept any interference received, including interference that maay cause undesired operation www.ubnt.com

900MHz Antenna list M9 Ubiquiti RP-9M-13 Gain: 13dBi Dimensions: 19x13 inches

Electromagnetic Compatibility Ubiquiti Networks Intentional Radiators M900 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 MET Report: EMCS82106-FCC247 © 2010, MET Laboratories, Inc. Page 73 of 147 DOC-EMC702 6/18/2009 Electromagnetic Compatibility Criteria for Intentional Radiators § 15.247(b) RF Exposure RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. MPE Limit Calculation: EUT’s operating frequencies @ 907-922MHz ; highest conducted power = 23dBm (peak) therefore, Limit for Uncontrolled exposure: 0.6 mW/cm 2 EUT maximum antenna gain = 13dBi Panel Equation from page 18 of OET 65, Edition 97-01 S = PG / 4R 2 or R = √PG / 4S where, S = Power Density (1 mW/cm 2 ) P = Power Input to antenna (199.52mW) G = Antenna Gain (19.95 numeric) R = (199.52*19.95/ 4*3.14*0.6) 1/2 = (3981.072/ 7.536) 1/2 = 22.98cm

MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE ! BALTIMORE, MARYLAND 21230-3432 ! PHONE (410) 354-3300 ! FAX (410) 354-3313 33439 WESTERN AVENUE ● UNION CITY, CALIFORNIA 94587 ● PHONE (510) 489-6300 ● FAX (510) 489-6372 3162 BELICK STREET ● SANTA CLARA, CALIFORNIA 95054 ● PHONE (408 748-3585 ● FAX (510) 489-6372 The Nation’s First Licensed Nationally Recognized Testing Laboratory March 30, 2010 Ubiquiti Networks 91 E. Tasman San Jose, CA 95134 Dear Robert Pera, Enclosed is the EMC Wireless test report for compliance testing of the Ubiquiti Networks, M900 as tested to the requirements of Title 47 of the CFR, Ch. 1 (10-1-06 ed.), Part 15, Subpart B, ICES-003, Issue 4 February 2004 for a Class A Digital Device and FCC Part 15 Subpart C, RSS-210, Issue 7, June 2007 for Intentional Radiators. Thank you for using the services of MET Laboratories, Inc. If you have any questions regarding these results or if MET can be of further service to you, please feel free to contact me. Sincerely yours, MET LABORATORIES, INC. Jennifer Sanchez Documentation Department Reference: (\Ubiquiti Networks\EMCS82106-FCC247_Rev1) Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. Electromagnetic Compatibility Ubiquiti Networks Cover Page M900 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 MET Report: EMCS82106-FCC247_Rev1 © 2010, MET Laboratories, Inc. Page ii of xii DOC-EMC702 6/18/2009 Electromagnetic Compatibility Criteria Test Report for the Ubiquiti Networks M900 Tested under the FCC Certification Rules contained in Title 47 of the CFR, Parts 15 Subpart B & ICES-003 for Class A Digital Devices & 15.247 Subpart C & RSS-210, Issue 7, June 2007 for Intentional Radiators MET Report: EMCS82106-FCC247_Rev1 March 30, 2010 Prepared For: Ubiquiti Networks 91 E. Tasman San Jose, CA 95134 Prepared By: MET Laboratories, Inc. 3162 Belick St. Santa Clara, CA 95054 Electromagnetic Compatibility Ubiquiti Networks Cover Page M900 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 MET Report: EMCS82106-FCC247_Rev1 © 2010, MET Laboratories, Inc. Page iii of xii DOC-EMC702 6/18/2009 Electromagnetic Compatibility Criteria Test Report for the Ubiquiti Networks M900 Tested under the FCC Certification Rules contained in Title 47 of the CFR, Parts 15 Subpart B & ICES-003 for Class A Digital Devices & 15.247 Subpart C & RSS-210, Issue 7, June 2007 for Intentional Radiators Anderson Soungpanya, Project Engineer Jennifer Sanchez Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC Rules Parts 15B, 15.247 and Industry Canada standards ICES-003, Issue 4 February 2004, RSS-210, Issue 7, June 2007 under normal use and maintenance. Shawn McMillen, Wireless Manager, Electromagnetic Compatibility Lab Electromagnetic Compatibility Ubiquiti Networks Report Status M900 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 MET Report: EMCS82106-FCC247_Rev1 © 2010, MET Laboratories, Inc. Page iv of xii DOC-EMC702 6/18/2009 Report Status Sheet Revision Report Date Reason for Revision  February 23, 2010 Initial Issue. 1 March 18, 2010 Final Issue (Update Model Number) 2 March 30, 2010 Update OBW tables Electromagnetic Compatibility Ubiquiti Networks Table of Contents M900 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 MET Report: EMCS82106-FCC247_Rev1 © 2010, MET Laboratories, Inc. Page v of xii DOC-EMC702 6/18/2009 Table of Contents I. Executive Summary .................................................................................................................................................1 A. Purpose of Test ...................................................................................................................................................2 B. Executive Summary ............................................................................................................................................2 II. Equipment Configuration .......................................................................................................................................3 A. Overview.............................................................................................................................................................4 B. References...........................................................................................................................................................5 C. Test Site ..............................................................................................................................................................5 D. Description of Test Sample.................................................................................................................................5 E. Equipment Configuration....................................................................................................................................8 F. Support Equipment .............................................................................................................................................8 G. Ports and Cabling Information ............................................................................................................................8 H. Mode of Operation......................................................................................................…

Text truncated - open the document above for the full version.

Electromagnetic Compatibility Ubiquiti Networks Unintentional Radiators M900 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 Conducted Emission Limits Test Setup Photograph 2. Conducted Emissions, Test Setup MET Report: EMCS82106-FCC247 © 2010, MET Laboratories, Inc. Page 14 of 147 DOC-EMC702 6/18/2009 Electromagnetic Compatibility Ubiquiti Networks Unintentional Radiators M900 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 Radiated Emission Limits Test Setup Photograph 3. Radiated Emission, 30MHz – 1GHz Test Setup MET Report: EMCS82106-FCC247 © 2010, MET Laboratories, Inc. Page 19 of 147 DOC-EMC702 6/18/2009 Electromagnetic Compatibility Ubiquiti Networks Unintentional Radiators M900 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 Radiated Emission Limits Test Setup Photograph 4. Radiated Emission, Test Setup Back View MET Report: EMCS82106-FCC247 © 2010, MET Laboratories, Inc. Page 20 of 147 DOC-EMC702 6/18/2009 Electromagnetic Compatibility Ubiquiti Networks Unintentional Radiators M900 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 Radiated Emission Limits Test Setup Photograph 5. Radiated Emission, above 1GHz Test Setup MET Report: EMCS82106-FCC247 © 2010, MET Laboratories, Inc. Page 21 of 147 DOC-EMC702 6/18/2009 Electromagnetic Compatibility Ubiquiti Networks Intentional Radiators M900 CFR Title 47, Part 15B, 15.247; RSS-210, Issue 7, June 2007 & ICES-003 15.207 Conducted Emissions Test Setup Photo Photograph 6. Conducted Emissions, 15.207, Test Setup MET Report: EMCS82106-FCC247 © 2010, MET Laboratories, Inc. Page 27 of 147 DOC-EMC702 6/18/2009
