SWX-NBE5M16Access Point

5 GHz, 16 dBi airMAX ® ac CPE Model: NBE-5AC-16 Introduction Thank you for purchasing the Ubiquiti Networks® NanoBeam® ac. This Quick Start Guide is designed to guide you through installation and also includes warranty terms. Package Contents NanoBeam acBall Joint Mount Lock Ring 5 GHz, 16 dBi airMAX ® ac CPE Model: NBE-5AC-16 Metal StrapGigabit PoE Adapter with Mounting Bracket (24V, 0.5A) Power Cord Quick Start Guide TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet cable and earth grounding must be used as conditions of product warranty. TOUGHCable™ is designed for outdoor installations. It is the customer’s responsibility to follow local country regulations, including operation within legal frequency channels, output power, and Dynamic Frequency Selection (DFS) requirements. Installation Requirements The NanoBeam can be mounted on a pole or to a wall. A Metal Strap (included) is used for pole-mounting. For wall-mounting, a suitable fastener such as a screw or bolt (not included) is required. • 7 mm socket wrench or screwdriver (for pole-mounting) • Wall fastener (for wall-mounting) • Shielded Category 5 (or above) cabling should be used for all wired Ethernet connections and should be grounded through the AC ground of the PoE. We recommend that you protect your networks from the most brutal environments and devastating ESD attacks with industrial-grade shielded Ethernet cable, TOUGHCable from Ubiquiti Networks. For more details, visit www.ubnt.com/toughcable Hardware Overview LEDs Reset Button Ethernet Port (10/100/1000 Mbps) Reset Button To reset to factory defaults, press and hold the Reset button for more than 10 seconds while the NanoBeam is already powered on. Alternatively, the NanoBeam may be reset remotely via a Reset button located on the bottom of the PoE Adapter. Ethernet Port The Ethernet port is used to connect the power and should be connected to the LAN and DHCP server. Power can be provided by any of the following: • PoE Adapter (included) • Ubiquiti Networks EdgeSwitch ™ • Ubiquiti Networks EdgeRouter ™ PoE LEDs Power The Power LED will light blue when the device is connected to a power source. Ethernet The Ethernet LED will light steady blue when an active Ethernet connection is made and flash when there is activity. Signal In airOS, you can modify the wireless signal strength threshold values for each LED on the Advanced tab under Signal LED Thresholds. The default values are shown below: LED will light blue when the wireless signal strength is above -94 dBm. LED will light blue when the wireless signal strength is above -80 dBm. LED will light blue when the wireless signal strength is above -73 dBm. LED will light blue when the wireless signal strength is above -65 dBm. Hardware Installation The NanoBeam can be mounted on a pole or to a wall. Perform the steps for the appropriate installation: Pole-Mount 1. Insert the Ball Joint Mount into the Lock Ring with the threads of the Lock Ring facing the ball joint. 2. Open the Metal Strap and feed it through the base of the Ball Joint Mount. 3. Wrap the Metal Strap around the pole. Use a 7 mm socket drive or screwdriver to turn the screw clockwise and securely fasten the strap to the pole. 4. Attach the NanoBeam to the Ball Joint Mount and turn the Lock Ring to secure it. Keep the Lock Ring loose enough to allow the NanoBeam to pivot for aiming. Wall-Mount The NanoBeam must be mounted directly to a wood stud or other structurally stable surface to avoid damage to the mounting hole when you adjust the aim. Optional Accessory To enhance stability, you can use the NanoBeam Wall Mount Kit, model NBE-WMK (sold separately). Note: Center screw included. Two optional screws (not included) provide additional stability. Installation Instructions 1. Mark the desired location of the mounting point. 2. If needed, drill a pilot hole for the fastener. 3. Insert the Ball Joint Mount into the Lock Ring with the threads of the Lock Ring facing the ball joint. 4. If you are using the optional NanoBeam Wall Mount Kit, skip to step b. a. To attach the Ball Joint Mount to the wall, insert a fastener (not included) through the center of the ball joint, and into the wall. Securely tighten the fastener. Proceed to step 5. b. To attach the Ball Joint Mount to the wall, insert the Wall Mount Kit screw through the center of the ball joint, through the Wall Mount Kit plate, and into the wall. Securely tighten the screw. 5. Attach the NanoBeam to the Ball Joint Mount and turn the Lock Ring to secure it. Keep the Lock Ring loose enough to allow the NanoBeam to pivot for aiming. Aiming 1. Ensure the opening of the Ethernet cable is pointed towards the ground. 2. Aim the front of the NanoBeam towards the other end of the wireless link. 3. Hand-tighten the Lock Ring to lock the aim. Note: Do not use a tool to tighten the Lock Ring. Tighten the Lock Ring by hand only. Connecting to the Gigabit PoE Adapter 1. Remove the port cover by pressing down the center of the cover and sliding the cover out. 2. Connect an Ethernet cable to the Ethernet port. 3. Replace the port cover. 4. Connect the other end of the Ethernet cable from the NanoBeam to the Ethernet port labeled POE on the Gigabit PoE Adapter. 5. Connect an Ethernet cable from your LAN or computer to the Ethernet port labeled LAN on the Gigabit PoE Adapter. 6. Connect the Power Cord to the power port on the Gigabit PoE Adapter. Connect the other end of the Power Cord to a power outlet. Mounting the PoE Adapter (Optional) 1. Slide the PoE Mounting Bracket down to remove it from the Gigabit PoE Adapter. 2. Place the PoE Mounting Bracket at the desired location and mark the two holes. Pre-drill the holes if necessary, and then secure the bracket using two fasteners (not included). 3. Align the slots of the Gigabit PoE Adapter with the tabs of the PoE Mounting Bracket, and then slide the adapter down. Accessing airOS Verify connectivity in the airOS Configuration Int…

Text truncated - open the document above for the full version.

f¡ I UBIOUITI" NETWORKS December 22,2014 Compliance Testing LLC 1724 S. Nevada Way Mesa, AZ852A4 RE: LETTER OF AGENT AUTHORIZATION To Whom lt May Concern: We, the undersigned, hereby authorize Compliance Testing LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, MichaelTaylor Compliance Manager 2580 Orchard Parkway San Jose, CA 9513'l USA 408-942-3085 x442 [email protected]

July 14, 2015 Compliance Testing LLC 1724 S. Nevada Way Mesa, AZ 85204 RE: CONFIDENTIALITY REQUEST FOR NanoBeam 5M – 16, NBE-M5-16, FCC ID: SWX- NBE5M16 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the following documents required to be submitted with this application be permanently withheld from public review.  Block Diagram  Schematics  Theory of Operation  Parts List/BOM  U-NII Security Exhibit These documents contain detailed system and equipment descriptions and related information about the product, which manufacturer/applicant considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, manufacturer/applicant feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Michael Taylor Compliance Manager 2580 Orchard Parkway San Jose, CA 95131, USA 408-942-3085 [email protected]

July 14, 2015 Compliance Testing LLC 1724 S. Nevada Way Mesa, AZ 85204 RE: Short Term Confidentiality Request for NanoBeam 5M - 16, NBE-5M-16, ( FCC ID: SWX- NBE5M16) To Whom It May Concern: In accordance with sections 0.457 and 0.459 of CFR 47, Ubiquiti Networks, Inc. requests short- term Confidentiality of following sections of this application for a period of 45 days after grant is issued. 1. Test setup photos 2. External photos 3. Internal photos 4. User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which manufacturer/applicant considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, manufacturer/applicant feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Grantee will not market or distribute product during the period requested. Once product is available for marketing, Grantee will notify FCC or TCB. Please contact me if there is any information you may need. Sincerely, Michael Taylor Compliance Manager 2580 Orchard Parkway San Jose, CA 95131, USA 408-942-3085 [email protected]

Form: CB-7.2.1 Issued by: QM Issue Date: 9/22/2011 Page 1 of 1 Revised by: QM-JS Revised Date: 6/23/2014 L:\Project\2014\p14a0021-Ubiquiti\TCB Folder\RT's\CB-7.2.1 - Technical Review RT Form.docx CB-7.2.1 – Technical Review RT Form FCC ID: SWX-NBE5M16 IC ID: CT Project: P14a0021 From: Shawn McMillen Date: RTs 08-05-2015 1--The separation distance in the user’s manual is inconsistent with the calculated RF exposure distance. MIKE: Provided updated manual. 2--There are no test setup photos provided with this application. DW: Provided for filing. CT - Response by: Submitted by: Date:

3.646 mm BOTTOM VIEW 9.5 mm 19 mm 4.17 mm 6.864 mm 0.897 mm PMS Cool Gray 9C PMS Cool Gray 9C PMS Cool Gray 9C SIDE VIEW File Name: Date: Revision: Designer: NBE-M5-16 Artwork v03 11/21/14 v03 - Change FCC and IC IDs Vivian Liu ME: PM: Arena Number: Addison Su Letitia Chiu 388-00065 Colors: PANTONE Cool Gray 9 C COVER VIEW 62.892 mm 12.6 mm 11.197 mm NanoBeam M5-16 Silkscreen Artwork PMS Cool Gray 9C RESET RESET Polarity Align This device complies with Part 15 of FCC rules. Operation is subject to the following 2 conditions: 1) this device may not cause harmful interference and, 2) this device must accept any interference received, including interference that may cause undesired operation. M/N: NBE-M5-16 24V 0.5A POE FCC ID: SWX- NBE5M16 IC: 6545A-NBE5M16 Polarity Align This device complies with Part 15 of FCC rules. Operation is subject to the following 2 conditions: 1) this device may not cause harmful interference and, 2) this device must accept any interference received, including interference that may cause undesired operation. M/N: NBE-M5-16 24V 0.5A POE FCC ID: SWX- NBE5M16 IC: 6545A-NBE5M16

p14a0021_FCC_Part 1.1310_Rev 1.0 Page 1 of 5 Test Report Prepared for: Ubiquiti Networks, Inc Model: NBE-M5-16 Description: NanoBeam M5 16 FCC ID: SWX-NBE5M16 To FCC Part 1.1310 Date of Issue: July 31, 2015 On the behalf of the applicant: Ubiquiti Networks, Inc 91 E. Tasman Drive San Jose, CA 95134 Attention of: Michael Taylor, Compliance Manager Ph: (408) 942-3085 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p14a0021 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p14a0021_FCC_Part 1.1310_Rev 1.0 Page 2 of 5 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 June 26, 2015 Alex Macon Original Document p14a0021_FCC_Part 1.1310_Rev 1.0 Page 3 of 5 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless below Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A EUT Description Model: NBE-M5-16 Description: NanoBeam M5 16 Firmware: N/A Software: N/A Serial Number: N/A Additional Information: The EUT is a 2x2 MIMO 802.11n radio p14a0021_FCC_Part 1.1310_Rev 1.0 Page 4 of 5 Source Based Time Averaged Power Calculation Average Power Calculations Average Power = Peak Power * duty-cycle% Tuned Frequency (MHz) Conducted Peak Output Power (mW) Duty Cycle (%) Average Power (mW) 5200 355 100 355 p14a0021_FCC_Part 1.1310_Rev 1.0 Page 5 of 5 MPE Evaluation This is a fixed/mobile device used in uncontrolled /general population exposure environment. Limits Uncontrolled Exposure 47 CFR 1.1310 Table 1, (B) 0.3-1.234 MHz: Limit [mW/cm²] = 100 1.34-30 MHz: Limit [mW/cm²] = (180/f²) 30-300 MHz: Limit [mW/cm²] = 0.2 300-1500 MHz: Limit [mW/cm²] = f/1500 1500-100,000 MHz Limit [mW/cm²] = 1.0 Test Data Test Frequency, MHz 5200 Power, Conducted, mW (P) 355 Antenna Gain Isotropic 16 Antenna Gain Numeric (G) 39.81 Antenna Type Point to point Distance (R) 20 푆= 푃∗퐺 4휋푟 2 Power Density (S) mw/cm 2 Power mW (P) Numeric Gain (G) Distance (r 2 ) cm 2.8116644119 355 39.81 20 Power Density (S) = 2.81 Limit =(from above table) = 1.0 The Power Density of 2.81 mw/cm 2 is over the limit of 1.0 mw/cm 2 for the uncontrolled /general population exposure environment so Minimum Safe Distance was calculated. R=√(PG/4πL) Distance (R) cm Power mW (P) Numeric Gain (G) Limit (L) 33.54404605 355 39.81 1 The minimum safe distance is 33.5 cm. END OF TEST REPORT

p14a0021_FCC_Part 1.1310_UNII-2_Rev 1.0 Page 1 of 5 Test Report Prepared for: Ubiquiti Networks, Inc Model: NBE-M5-16 Description: NanoBeam M5 16 FCC ID: SWX-NBE5M16 To FCC Part 1.1310 Date of Issue: July 31, 2015 On the behalf of the applicant: Ubiquiti Networks, Inc 91 E. Tasman Drive San Jose, CA 95134 Attention of: Michael Taylor, Compliance Manager Ph: (408) 942-3085 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p14a0021 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p14a0021_FCC_Part 1.1310_UNII-2_Rev 1.0 Page 2 of 5 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 June 26, 2015 Alex Macon Original Document p14a0021_FCC_Part 1.1310_UNII-2_Rev 1.0 Page 3 of 5 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless below Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A EUT Description Model: NBE-M5-16 Description: NanoBeam M5 16 Firmware: N/A Software: N/A Serial Number: N/A Additional Information: The EUT is a 2x2 MIMO 802.11n radio p14a0021_FCC_Part 1.1310_UNII-2_Rev 1.0 Page 4 of 5 Source Based Time Averaged Power Calculation Average Power Calculations Average Power = Peak Power * duty-cycle% Tuned Frequency (MHz) Conducted Peak Output Power (mW) Duty Cycle (%) Average Power (mW) 5800 155 100 155 p14a0021_FCC_Part 1.1310_UNII-2_Rev 1.0 Page 5 of 5 MPE Evaluation This is a fixed/mobile device used in uncontrolled /general population exposure environment. Limits Uncontrolled Exposure 47 CFR 1.1310 Table 1, (B) 0.3-1.234 MHz: Limit [mW/cm²] = 100 1.34-30 MHz: Limit [mW/cm²] = (180/f²) 30-300 MHz: Limit [mW/cm²] = 0.2 300-1500 MHz: Limit [mW/cm²] = f/1500 1500-100,000 MHz Limit [mW/cm²] = 1.0 Test Data Test Frequency, MHz 5800 Power, Conducted, mW (P) 155 Antenna Gain Isotropic 16 Antenna Gain Numeric (G) 39.81 Antenna Type Point to Point Distance (R) 20 푆= 푃∗퐺 4휋푟 2 Power Density (S) mw/cm 2 Power mW (P) Numeric Gain (G) Distance (r 2 ) cm 1.2276281235 155 39.81 20 Power Density (S) = 1.23 Limit =(from above table) = 1.0 The Power Density of 1.23 mw/cm 2 is over the limit of 1.0 mw/cm 2 for the uncontrolled /general population exposure environment so Minimum Safe Distance was calculated. R=√(PG/4πL) Distance (R) cm Power mW (P) Numeric Gain (G) Limit (L) 22.1649 155 39.81 1 The minimum safe distance is 22.2 cm. END OF TEST REPORT

p14a0021_FCC_15.407_U-NII-1_Rev 1.0 Page 1 of 22 Test Report Prepared for: Ubiquiti Networks, Inc Model: NBE-M5-16 Description: NanoBeam M5 16 Serial Number: N/A FCC ID: SWX-NBE5M16 To FCC Part 15.407 Date of Issue: July 31, 2015 On the behalf of the applicant: Ubiquiti Networks, Inc 91 E. Tasman Drive San Jose, CA 95134 Attention of: Michael Taylor, Compliance Manager Ph: (408) 942-3085 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p14a0021 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing. All results contained herein relate only to the sample tested. p14a0021_FCC_15.407_U-NII-1_Rev 1.0 Page 2 of 22 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 June 26, 2015 Alex Macon Original Document p14a0021_FCC_15.407_U-NII-1_Rev 1.0 Page 3 of 22 Table of Contents Description Page Standard Test Conditions Engineering Practices 6 Test Results Summary 8 Peak Output Power 9 Transmitter Power Spectral Density 11 Undesirable Emissions Conducted 13 Undesirable Emissions Radiated 15 Occupied Bandwidth 17 Frequency Stability 18 RF Exposure 19 A/C Powerline Conducted Emission 21 Test Equipment Utilized 22 p14a0021_FCC_15.407_U-NII-1_Rev 1.0 Page 4 of 22 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer to the joint ISO-ILAC-IAF Communiqué dated January 2009). The tests results contained within this test report all fall within our scope of accreditation, unless noted below. Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A p14a0021_FCC_15.407_U-NII-1_Rev 1.0 Page 5 of 22 The applicant has been cautioned as to the following 15.21 - Information to User The user’s manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 15.27(a) - Special Accessories Equipment marked to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer without an additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. p14a0021_FCC_15.407_U-NII-1_Rev 1.0 Page 6 of 22 Standard Test Conditions Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.10-2013 and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104°F) unless the particular equipment requirements specified testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Measurement results, unless otherwise noted, are worst-case measurements. Environmental Conditions Temperature (ºC) Humidity (%) Pressure (mbar) 24.4 – 25.1 30.1 – 34.7 964.5 – 966.1 EUT Operation during Tests The EUT was configured to run in a continuous data stream using ART software through a POE adaptor and Ethernet connection. EUT Description Model: NBE-M5-16 Description: NanoBeam M5 16 Firmware: N/A Software: N/A Serial Number: N/A Additional Information: The EUT is a 2x2 MIMO 802.11n radio p14a0021_FCC_15.407_U-NII-1_Rev 1.0 Page 7 of 22 EUT Specifications Equipment Code NII Model(s)Tested NBE-M5-16 Model(s) covered NBE-M5-16 Maximum Conducted Output Power 25.5 dBm Frequency Range 5150-5250 MHz Bandwidths -40°C to 75°C Data Rates 10/20/30/40 MHz Modulations 6, 9, 12, 18, 24, 36, 48, 54, MCS0, MCS1, MCS2, MCS3, MCS4, MCS5, MCS6, MCS7, MCS8, MCS9 Antenna List No. Manufacturer Part # Antenna Type Peak Gain 1 Ubiquiti NBE-M5-16 Dish 16 dBi 15.203: Antenna Requirement: The antenna is permanently attached to the EUT The antenna uses a unique coupling X The EUT must be professionally installed The antenna requirement does not apply Accessories: None Cables: None Modifications: None p14a0021_FCC_15.407_U-NII-1_Rev 1.0 Page 8 of 22 Test Results Summary Specification Test Name Pass, Fail, N/A Comments §15.203 Antenna Requirements Pass §15.207 §15.407(b)(6) Line Conducted Emissions Pass §15.407(a)(1) Conducted Output Power Pass §15.407(a)(1),(5) Power Spectral Density Pass §15.403(i) 15.407(a)(5) 26dB Occupied Bandwidth Pass 99% Occupied Bandwi…

Text truncated - open the document above for the full version.

p14a0021_Annex A_UNII-1_Rev 1.0 Page 1 of 17 Annex A Unwanted Conducted Emissions p14a0021_Annex A_UNII-1_Rev 1.0 Page 2 of 17 10 MHz high ch 1 - 40 GHz_J1 10 MHz high ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 3 of 17 10 MHz low ch 1 - 40 GHz_J1 10 MHz low ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 4 of 17 10 MHz mid ch 1 - 40 GHz_J1 10 MHz mid ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 5 of 17 10MHz mid ch 30MHz-1GHz_J1 10MHz mid ch 30MHz-1GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 6 of 17 20 MHz high ch 1 - 40 GHz_J1 20 MHz high ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 7 of 17 20 MHz low ch 1 - 40 GHz_J1 20 MHz low ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 8 of 17 20 MHz mid ch 1 - 40 GHz_J1 20 MHz mid ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 9 of 17 20MHz mid ch 30MHz-1GHz_J1 20MHz mid ch 30MHz-1GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 10 of 17 30 MHz high ch 1 - 40 GHz_J1 30 MHz high ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 11 of 17 30 MHz low ch 1 - 40 GHz_J1 30 MHz low ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 12 of 17 30 MHz mid ch 1 - 40 GHz_J1 30 MHz mid ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 13 of 17 30MHz mid ch 30MHz-1GHz_J1 30MHz mid ch 30MHz-1GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 14 of 17 40 MHz high ch 1 - 40 GHz_J1 40 MHz high ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 15 of 17 40 MHz low ch 1 - 40 GHz_J1 40 MHz low ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 16 of 17 40 MHz mid ch 1 - 40 GHz_J1 40 MHz mid ch 1 - 40 GHz_J3 p14a0021_Annex A_UNII-1_Rev 1.0 Page 17 of 17 40MHz mid ch 30MHz-1GHz_J1 40MHz mid ch 30MHz-1GHz_J3

p14a0021_Annex B_UNII-1_Rev 1.0 Page 1 of 11 Annex B Undesireable Emissions Radiated Annex B Notes: 1. The emissions that are over the limit in the 30 – 1000 MHz plots are from digital circuitry and not the transmitter, therefor these emissions only need to meet the -27 dBM/MHz general emission requirements. 2. Throughout Annex C, for all plots above 1 GHz, other than the fundamental transmitter frequency, for any peak emission over the restricted band average limit was examined with an average detector and additional plots were supplied. p14a0021_Annex B_UNII-1_Rev 1.0 Page 2 of 11 10 MHz mid 2nd harmonic 10 MHz mid ch 1 - 18GHz p14a0021_Annex B_UNII-1_Rev 1.0 Page 3 of 11 10 MHz mid ch 30 - 1000MHz 10MHz mid ch 18-40 GHz p14a0021_Annex B_UNII-1_Rev 1.0 Page 4 of 11 20 MHz mid 2nd harmonic 20 MHz mid ch 1 - 18GHz p14a0021_Annex B_UNII-1_Rev 1.0 Page 5 of 11 20MHz mid ch 18-40 GHz 30 MHz mid 2nd harmonic p14a0021_Annex B_UNII-1_Rev 1.0 Page 6 of 11 30 MHz mid ch 1 - 18GHz 30MHz mid ch 18-40 GHz p14a0021_Annex B_UNII-1_Rev 1.0 Page 7 of 11 40 MHz mid 2nd harmonic 40 MHz mid ch 1 - 18GHz p14a0021_Annex B_UNII-1_Rev 1.0 Page 8 of 11 40MHz mid ch 18-40 GHz p14a0021_Annex B_UNII-1_Rev 1.0 Page 9 of 11 10MHz low side 20MHz low side p14a0021_Annex B_UNII-1_Rev 1.0 Page 10 of 11 30MHz low side 40MHz low side p14a0021_Annex B_UNII-1_Rev 1.0 Page 11 of 11 Band Edge integrated over 1 MHZ Bandwidth Frequency Data Rate TP J1 Level Limit J1 Margin MHz MHz dBm dBm/MHz dB 10 5160 vt0 20 -50.2 -27 -23.2 20 5165 vt0 20 -42.4 -27 -15.4 30 5170 vt0 15 -41.2 -27 -14.2 30 5175 vt0 20 -49.4 -27 -22.4 40 5175 vf0 11 -43.1 -27 -16.1 40 5180 vf0 13 -44.3 -27 -17.3 40 5185 vf0 17 -32.1 -27 -5.1

p14a0021_Annex C_UNII-1_Rev 1.0 Page 1 of 13 Annex C Occupied Bandwidth p14a0021_Annex C_UNII-1_Rev 1.0 Page 2 of 13 10MHZ high ch J1 10MHZ high ch J3 p14a0021_Annex C_UNII-1_Rev 1.0 Page 3 of 13 10MHZ low ch J1 10MHZ low ch J3 p14a0021_Annex C_UNII-1_Rev 1.0 Page 4 of 13 10MHZ mid ch J1 10MHZ mid ch J3 p14a0021_Annex C_UNII-1_Rev 1.0 Page 5 of 13 20MHZ high ch J1 20MHZ high ch J3 p14a0021_Annex C_UNII-1_Rev 1.0 Page 6 of 13 20MHZ low ch J1 20MHZ low ch J3 p14a0021_Annex C_UNII-1_Rev 1.0 Page 7 of 13 20MHZ mid ch J1 20MHZ mid ch J3 p14a0021_Annex C_UNII-1_Rev 1.0 Page 8 of 13 30MHZ high ch J1 30MHZ high ch J3 p14a0021_Annex C_UNII-1_Rev 1.0 Page 9 of 13 30MHZ low ch J1 30MHZ low ch J3 p14a0021_Annex C_UNII-1_Rev 1.0 Page 10 of 13 30MHZ mid ch J1 30MHZ mid ch J3 p14a0021_Annex C_UNII-1_Rev 1.0 Page 11 of 13 40MHZ high ch J1 40MHZ high ch J3 p14a0021_Annex C_UNII-1_Rev 1.0 Page 12 of 13 40MHZ low ch J1 40MHZ low ch J3 p14a0021_Annex C_UNII-1_Rev 1.0 Page 13 of 13 40MHZ mid ch J1 40MHZ mid ch J3

p14a0021_Annex D_UNII-1_Rev 1.0 Page 1 of 3 Annex D Frequency Stability p14a0021_Annex D_UNII-1_Rev 1.0 Page 2 of 3 UNII-1_-40 degrees UNII-1_25 degrees p14a0021_Annex D_UNII-1_Rev 1.0 Page 3 of 3 UNII-1_70 degrees

p14a0021_Annex E_UNII-1_Rev 1.0 Page 1 of 3 Annex E AC Line Conduction p14a0021_Annex E_UNII-1_Rev 1.0 Page 2 of 3 Compliance Testing Conducted Emissions - Class B Line 1 (Neutral) 100.0K1.0M10.0M100.0M Frequency MHz 0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100.0 Amplitude dBuV Job #: p14a002115.207_03Nov2014.TIL Operator: ms Points of Interest C orrected Peak D ata C ISPR B _QP C ISPR B _A V Compliance Testing Conducted Emissions - Class B Line 2 (Phase) 100.0K1.0M10.0M100.0M Frequency MHz 0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100.0 Amplitude dBuV Job #: p14a002115.207_03Nov2014.TIL Operator: ms C orrected Peak D ata C ISPR B _A V C ISPR B _QP Points of Interest p14a0021_Annex E_UNII-1_Rev 1.0 Page 3 of 3 L1 AVG Frequency Measured Data LISN Correction Factor Cable Correction Factor Attenuator Corrected Data Limit Margin 151.26 KHz 32.7 0.29 0.02 10.2 43.211 55.964 -12.753 151.1 KHz 32.24 0.29 0.02 10.2 42.746 55.969 -13.223 150.35 KHz 32.92 0.3 0.02 10.2 43.436 55.99 -12.553 150.26 KHz 32.55 0.3 0.02 10.2 43.064 55.993 -12.929 150.09 KHz 32.09 0.3 0.02 10.2 42.612 55.997 -13.385 150.05 KHz 32.34 0.3 0.02 10.2 42.86 55.999 -13.139 L2 AVG Frequency Measured Data LISN Correction Factor Cable Correction Factor Attenuator Corrected Data Limit Margin 154.0 KHz 30.28 0.26 0.02 10.2 40.76 55.886 -15.126 152.13 KHz 31.42 0.28 0.02 10.2 41.919 55.939 -14.02 151.46 KHz 31.68 0.29 0.02 10.2 42.189 55.958 -13.77 151.45 KHz 31.62 0.29 0.02 10.2 42.122 55.959 -13.836 151.35 KHz 31.52 0.29 0.02 10.2 42.027 55.961 -13.935 150.05 KHz 31.67 0.3 0.02 10.2 42.189 55.999 -13.809 L1 QP Frequency Measured Data LISN Correction Factor Cable Correction Factor Attenuator Corrected Data Limit Margin 151.26 KHz 49.8 0.287 0.02 10.2 60.307 65.964 -5.657 151.1 KHz 49.26 0.289 0.02 10.2 59.769 65.969 -6.2 150.35 KHz 50.1 0.296 0.02 10.2 60.616 65.99 -5.373 150.26 KHz 49.76 0.297 0.02 10.2 60.277 65.993 -5.715 150.09 KHz 49.34 0.299 0.02 10.2 59.859 65.997 -6.138 150.05 KHz 49.55 0.3 0.02 10.2 60.069 65.999 -5.929 L2 QP Frequency Measured Data LISN Correction Factor Cable Correction Factor At…
