SWX-PBE5MAccess Point

High-Performance airMAX ® Omni Model: PBE-M5-Omni Introduction Thank you for purchasing the Ubiquiti Networks® PowerBeam ™ Omni. This Quick Start Guide is designed to guide you through installation and also includes warranty terms. Package Contents Antenna Feed with Omni Rear Housing Mounting Bracket Pole Clamp U-BoltBolts (Qty. 4)Flange Nuts (Qty. 2)Washers (Qty. 2) High-Performance airMAX ® Omni Model: PBE-M5-Omni Gigabit PoE Adapter with Mounting Bracket Power Cord Quick Start Guide Installation Requirements • Phillips screwdriver • 10 mm wrench • Shielded Category 5 (or above) cabling should be used for all wired Ethernet connections and should be grounded through the AC ground of the PoE. We recommend that you protect your networks from the most brutal environments and devastating ESD attacks with industrial-grade shielded Ethernet cable from Ubiquiti Networks. For more details, visit www.ubnt.com/toughcable TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet cable and earth grounding must be used as conditions of product warranty. TOUGHCable ™ is designed for outdoor installations. It is the customer’s responsibility to follow local country regulations, including operation within legal frequency channels, output power, and Dynamic Frequency Selection (DFS) requirements. Hardware Overview Bottom View Reset Button Release Button Ethernet Port Reset Button To reset to factory defaults, press and hold the Reset button for more than 10 seconds while the PowerBeam is already powered on. Alternatively, the PowerBeam may be reset remotely via a Reset button located on the bottom of the Gigabit PoE Adapter. Release Button After you assemble the PowerBeam, check the Release button; it should be fully engaged in the Release Button Slot of the Rear Housing. This ensures that the Antenna Feed is locked into place. If you need to remove the Antenna Feed, you must depress the Release button first. LEDs Signal The default values (from left to right) are shown below: LED will light blue when the wireless signal strength is equal to or above -65 dBm. LED will light blue when the wireless signal strength is equal to or above -73 dBm. LED will light blue when the wireless signal strength is equal to or above -80 dBm. LED will light blue when the wireless signal strength is equal to or above -94 dBm. Ethernet The Ethernet LED will light steady blue when an active Ethernet connection is made and flash when there is activity. Power The Power LED will light blue when the device is connected to a power source. Installation 1. Push in the sides of the Cable Door and detach it from the Rear Housing. 2. Insert the Antenna Feed with Omni into the Rear Housing, and push until it locks into place with a click. 3. Connect an Ethernet cable to the Ethernet Port of the Antenna Feed, and re-attach the Cable Door to the Rear Housing. *640-543231-01* 640-543231-01 4. Attach the Rear Housing to the Mounting Bracket with four Bolts. 5. Insert the U-Bolt into the Pole Clamp and Mounting Bracket. Secure each end of the U-Bolt with a Washer and a Flange Nut. Note: The mounting assembly can accommodate a Ø 32 - 56 mm pole. 6. Connect the other end of the Ethernet cable from the PowerBeam to the Ethernet port labeled POE on the Gigabit PoE Adapter. 7. Connect an Ethernet cable from your LAN or computer to the Ethernet port labeled LAN on the adapter. 8. Connect the Power Cord to the power port on the adapter. Connect the other end of the Power Cord to a power outlet. Mounting the PoE Adapter (Optional) 1. Slide the PoE Mounting Bracket down to remove it from the Gigabit PoE Adapter. 2. Place the PoE Mounting Bracket at the desired location and mark the two holes. Pre-drill the holes if necessary, and then secure the bracket using two fasteners (not included). 3. Align the slots of the Gigabit PoE Adapter with the tabs of the PoE Mounting Bracket, and then slide the adapter down. Accessing airOS Verify connectivity in the airOS Configuration Interface. 1. Make sure that your host system is connected via Ethernet to the PowerBeam. 2. Configure the Ethernet adapter on your host system with a static IP address on the 192.168.1.x subnet. 3. Launch your web browser and type https://192.168.1.20 in the address field. Press enter (PC) or return (Mac). 4. The login screen will appear. Enter ubnt in the Username and Password fields. Select your Country and Language. You must agree to the Terms of Use to use the product. Click Login. Note: U.S. product versions are locked to the U.S. Country Code to ensure compliance with FCC regulations. The airOS Configuration Interface will appear, allowing you to customize your settings as needed. For details, refer to the User Guide available at documentation.ubnt.com/airmax Installer Compliance Responsibility Devices must be professionally installed and it is the professional installer's responsibility to make sure the device is operated within local country regulatory requirements. Since Ubiquiti Networks equipment can be paired with a variety of antennas and cables, the Antenna and Output Power fields are provided to the professional installer to assist in meeting regulatory requirements. Specifications PBE-M5-Omni Dimensions 311.12 x 150 x 150 mm (12.25 x 5.91 x 5.91") Weight1.3 kg (2.87 lb) Operating FrequencyWorldwide: 5150 - 5875 MHz USA: 5150 - 5250, 5725 - 5850 MHz Gain6 dBi Networking Interface(1) 10/100/1000 Ethernet Port EnclosureOutdoor UV Stabilized Plastic Max. Power Consumption6W Power Supply24V, 0.5A Gigabit PoE Supply (Included) Power MethodPassive PoE (Pairs 4, 5+; 7, 8 Return) Wind Survivability200 km/h (125 mph) CertificationsCE, FCC, IC MountingPole Mounting Kit Included Operating Temperature-40 to 70° C (-40 to 158° F) Operating Humidity5 to 95% Noncondensing Shock and VibrationsETSI300-019-1.4 Safety Notices 1. Read, follow, and keep these instructions. 2. Heed all warnings. 3. Only use attachments/accessories specified by the manufactur…

Text truncated - open the document above for the full version.

High-Performance Integrated InnerFeed ™ airMAX ® Bridge Model: PBE-M5-300 Introduction Thank you for purchasing the Ubiquiti Networks® PowerBeam ™ . This Quick Start Guide is designed to guide you through installation and also includes warranty terms. Package Contents 20 20 10 10 0 Dish ReflectorAntenna FeedRear HousingDish Bracket Pole ClampU-BoltFlange Nuts (M6, Qty. 2) Washers (M6, Qty. 2) High-Performance Integrated InnerFeed ™ airMAX ® Bridge Model: PBE-M5-300 PoE Adapter (24V, 0.5A) Power Cord Quick Start Guide TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet cable and earth grounding must be used as conditions of product warranty. TOUGHCable ™ is designed for outdoor installations. It is the customer’s responsibility to follow local country regulations, including operation within legal frequency channels, output power, and Dynamic Frequency Selection (DFS) requirements. Hardware Overview Bottom View Cable Door Rear Housing Antenna Feed Ethernet Port Release Button Slot Dish Bracket Release Button Dish Reflector Alignment Pins Reset Button Reset Button To reset to factory defaults, press and hold the Reset button for more than 10 seconds while the PowerBeam is already powered on. Release Button After you assemble the PowerBeam, check the Release button; it should be fully engaged in the Release Button Slot of the Rear Housing. This ensures that the Antenna Feed is locked into place. If you need to remove the Antenna Feed, you must depress the Release button first. LEDs Signal In airOS, you can modify the wireless signal strength threshold values for each LED on the Advanced tab under Signal LED Thresholds. The default values are shown below: LED will light green when the wireless signal strength is above -65 dBm. LED will light green when the wireless signal strength is above -73 dBm. LED will light amber when the wireless signal strength is above -80 dBm. LED will light red when the wireless signal strength is above -94 dBm. Ethernet The Ethernet LED will light steady green when an active Ethernet connection is made and flash when there is activity. Power The Power LED will light green when the device is connected to a power source. Application Examples The PowerBeam mounted outdoors with the Dish Reflector installed provides directional outdoor coverage (gain is reflector-dependent). The PowerBeam mounted outdoors without the Dish Reflector installed provides outdoor-to-indoor coverage using the 3 dBi Antenna Feed only. Installation Requirements • 10 mm wrench • Shielded Category 5 (or above) cabling should be used for all wired Ethernet connections and should be grounded through the AC ground of the PoE. We recommend that you protect your networks from the most brutal environments and devastating ESD attacks with industrial-grade shielded Ethernet cable from Ubiquiti Networks. For more details, visit www.ubnt.com/toughcable Installation 1. Align and insert the tabs of the Dish Bracket into the slots of the Dish Reflector. Rotate the Dish Bracket counter-clockwise until the tabs lock into place. 20 20 10 0 10 2. Line up the Alignment Pins of the Rear Housing with the alignment holes of the Dish Bracket. Insert the pins and push until they lock into place. 20 20 10 0 10 *640-00067-04* 640-00067-04 3. Push in the sides of the Cable Door and detach it from the Rear Housing. 20 20 10 0 10 4. Attach the Antenna Feed: a. Insert the Antenna Feed into the Rear Housing, and push until it locks into place with a click. b. Lightly pull the Antenna Feed to ensure that it is locked into place and the Release button is fully engaged. Release Button Bottom View 5. Connect the Ethernet cable: a. Connect an Ethernet cable to the Ethernet Port of the Antenna Feed. b. Re-attach the Cable Door to the Rear Housing. 20 20 10 0 10 6. Insert the U-Bolt into the Pole Clamp and Dish Bracket. Secure each end of the U-Bolt with a Washer and a Flange Nut. 20 20 10 10 0 10 N-m Note: The mounting assembly can accommodate a Ø 32 - 56 mm pole. 7. Connect the other end of the Ethernet cable from the PowerBeam to the Ethernet port labeled POE on the PoE Adapter. 8. Connect an Ethernet cable from your LAN or computer to the Ethernet port labeled LAN on the PoE Adapter. 9. Connect the Power Cord to the power port on the PoE Adapter. Connect the other end of the Power Cord to a power outlet. Accessing airOS Verify connectivity in the airOS Configuration Interface. 1. Make sure that your host machine is connected via Ethernet to the PowerBeam. 2. Configure the Ethernet adapter on your host system with a static IP address on the 192.168.1.x subnet. 3. Launch your web browser and type https://192.168.1.20 in the address field. Press enter (PC) or return (Mac). 4. The login screen will appear. Enter ubnt in the Username and Password fields. Select your Country and Language. You must agree to the Terms of Use to use the product. Click Login. Note: U.S. product versions are locked to the U.S. Country Code to ensure compliance with FCC regulations. 5. Select the PowerBeam Dish Reflector size: a. Click the Wireless tab. b. From the Antenna drop-down list, select the appropriate option. c. Click Change to save. d. Click OK to confirm. Customize additional settings as needed to complete the configuration. For additional details on the airOS Configuration Interface, refer to the User Guide available at documentation.ubnt.com/airmax Installer Compliance Responsibility Devices must be professionally installed and it is the professional installer's responsibility to make sure the device is operated within local country regulatory requirements. Since Ubiquiti Networks equipment can be paired with a variety of antennas and cables, the Antenna and Output Power fields are provided to the professional installer to assist in meeting regulatory requirements. Specifications PowerBeamM5 Dimensions325 x 325 x 256 mm (12.8 x 12.8 x 10.1") Weight (Mount Included)1.203 kg (2.65 lb) Operating FrequencyWor…

Text truncated - open the document above for the full version.

High-Performance Integrated InnerFeed ™ airMAX ® Bridge Models: PBE-M2-400, PBE-M5-400 Introduction Thank you for purchasing the Ubiquiti Networks® PowerBeam ™ . This Quick Start Guide is designed to guide you through installation and also includes warranty terms. If you want to add a radome to enclose the Dish Reflector, Ubiquiti Networks offers the PowerBeam Radome, 400 mm, model PBE-RAD-400 as an optional accessory. Product details are available on our website at www.ubnt.com/airmax Package Contents or Dish ReflectorPBE-M2-400 Antenna Feed PBE-M5-400 Antenna Feed * 20 10 10 0 Rear HousingDish BracketPole ClampU-Bolt High-Performance Integrated InnerFeed ™ airMAX ® Bridge Models: PBE-M2-400, PBE-M5-400 Flange Nuts (M8, Qty. 2) PoE Adapter (24V, 0.5A) Power CordQuick Start Guide * The PBE-M5-400 Antenna Feed has a thin gray ring around the center of the cap to differentiate it from the PBE-M5-300 Antenna Feed. TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet cable and earth grounding must be used as conditions of product warranty. TOUGHCable ™ is designed for outdoor installations. It is the customer’s responsibility to follow local country regulations, including operation within legal frequency channels, output power, and Dynamic Frequency Selection (DFS) requirements. Hardware Overview Bottom View Cable Door Rear Housing Technology Ethernet Port Release Button Slot Dish Bracket Release Button Dish Reflector Alignment Pins Reset Button Antenna Feed Antenna Feed The PowerBeamM2 Antenna Feed is shown; however, the PowerBeamM5 Antenna Feed has the same layout for the Ethernet Port, Reset button, and Release button. Reset Button To reset to factory defaults, press and hold the Reset button for more than 10 seconds while the PowerBeam is already powered on. Release Button After you assemble the PowerBeam, check the Release button; it should be fully engaged in the Release Button Slot of the Rear Housing. This ensures that the Antenna Feed is locked into place. If you need to remove the Antenna Feed, you must depress the Release button first. LEDs Signal In airOS, you can modify the wireless signal strength threshold values for each LED on the Advanced tab under Signal LED Thresholds. The default values are shown below: LED will light green when the wireless signal strength is above -65 dBm. LED will light green when the wireless signal strength is above -73 dBm. LED will light amber when the wireless signal strength is above -80 dBm. LED will light red when the wireless signal strength is above -94 dBm. Ethernet The Ethernet LED will light steady green when an active Ethernet connection is made and flash when there is activity. Power The Power LED will light green when the device is connected to a power source. Application Examples The PowerBeam mounted outdoors with the Dish Reflector installed provides directional outdoor coverage (gain is reflector-dependent). The PowerBeam mounted outdoors without the Dish Reflector installed provides outdoor-to-indoor coverage using the 3 dBi Antenna Feed only. Installation Requirements • 13 mm wrench • Shielded Category 5 (or above) cabling should be used for all wired Ethernet connections and should be grounded through the AC ground of the PoE. We recommend that you protect your networks from the most brutal environments and devastating ESD attacks with industrial-grade shielded Ethernet cable from Ubiquiti Networks. For more details, visit www.ubnt.com/toughcable Installation The installation instructions show the PowerBeamM2; however, the same instructions apply to the PowerBeamM5. 1. Align and insert the tabs of the Dish Bracket into the slots of the Dish Reflector. Rotate the Dish Bracket counter-clockwise until the tabs lock into place. 20 10 10 0 2. Line up the Alignment Pins of the Rear Housing with the alignment holes of the Dish Bracket. Insert the pins and push until they lock into place. 20 10 10 0 *640-00073-05* 640-00073-05 3. Push in the sides of the Cable Door and detach it from the Rear Housing. 20 10 0 10 4. Attach the Antenna Feed: a. Insert the Antenna Feed into the Rear Housing, and push until it locks into place with a click. b. Lightly pull the Antenna Feed to ensure that it is locked into place and the Release button is fully engaged. Release Button Bottom View 5. Connect the Ethernet cable: a. Connect an Ethernet cable to the Ethernet Port of the Antenna Feed. b. Re-attach the Cable Door to the Rear Housing. 20 10 0 10 6. Slide the Pole Clamp onto the Dish Bracket. 20 10 10 0 7. Insert the U-Bolt into the Pole Clamp and Dish Bracket. Secure each end of the U-Bolt with a Flange Nut. 20 10 10 0 25 N-m Note: The mounting assembly can accommodate a Ø 32 - 56 mm pole. 8. Optional: If you have the PowerBeam Radome (optional accessory), then align the arrows on the bottoms of the Radome and Dish Reflector so the Drain Holes on the Radome point downward. Snap the Radome onto the Dish Reflector. 9. Connect the other end of the Ethernet cable from the PowerBeam to the Ethernet port labeled POE on the PoE Adapter. 10. Connect an Ethernet cable from your LAN or computer to the Ethernet port labeled LAN on the PoE Adapter. 11. Connect the Power Cord to the power port on the PoE Adapter. Connect the other end of the Power Cord to a power outlet. Accessing airOS Verify connectivity in the airOS Configuration Interface. 1. Make sure that your host machine is connected via Ethernet to the PowerBeam. 2. Configure the Ethernet adapter on your host system with a static IP address on the 192.168.1.x subnet. 3. Launch your web browser and type https://192.168.1.20 in the address field. Press enter (PC) or return (Mac). 4. The login screen will appear. Enter ubnt in the Username and Password fields. Select your Country and Language. You must agree to the Terms of Use to use the product. Click Login. Note: U.S. product versions are locked to the U.S. Country Code to ensure compliance with FCC regulations. 5. Se…

Text truncated - open the document above for the full version.

High-Performance Integrated InnerFeed ™ airMAX ® Bridge Model: PBE-M5-620 Introduction Thank you for purchasing the Ubiquiti Networks® PowerBeam ™ . This Quick Start Guide is designed to guide you through installation and also includes warranty terms. Package Contents Dish Reflector with Mounting Bracket Antenna Feed Rear Housing Support Arm Upper Pole Bracket Assembly Lower Pole Bracket BraceScrews (M6, Qty. 4) Hex Head Bolts (M8, Qty. 5) Lock Washers (M8, Qty. 5) Flat Washers (M8, Qty. 5) Stabilizer Brackets (Qty. 2) M10x100 Bolts (Qty. 2) Serrated Flange Nuts (M10, Qty. 2) High-Performance Integrated InnerFeed ™ airMAX ® Bridge Model: PBE-M5-620 M8x150 Carriage Bolts (Qty. 4) Pole Clamps (Qty. 2) Gigabit PoE Adapter with Mounting Bracket Power Cord Quick Start Guide TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet cable and earth grounding must be used as conditions of product warranty. TOUGHCable ™ is designed for outdoor installations. It is the customer’s responsibility to follow local country regulations, including operation within legal frequency channels, output power, and Dynamic Frequency Selection (DFS) requirements. Hardware Overview Bottom View Cable Door Rear Housing Technology Ethernet Port Release Button Slot Release Button Dish Reflector Alignment Pins Reset Button Antenna Feed Mounting Bracket Reset Button To reset to factory defaults, press and hold the Reset button for more than 10 seconds while the PowerBeam is already powered on. Alternatively, the PowerBeam may be reset remotely via a Reset button located on the bottom of the Gigabit PoE Adapter. Release Button After you assemble the PowerBeam, check the Release button; it should be fully engaged in the Release Button Slot of the Rear Housing. This ensures that the Antenna Feed is locked into place. If you need to remove the Antenna Feed, you must depress the Release button first. LEDs Signal The default values (from left to right) are shown below: LED will light blue when the wireless signal strength is equal to or above -65 dBm. LED will light blue when the wireless signal strength is equal to or above -73 dBm. LED will light blue when the wireless signal strength is equal to or above -80 dBm. LED will light blue when the wireless signal strength is equal to or above -94 dBm. Ethernet The Ethernet LED will light steady blue when an active Ethernet connection is made and flash when there is activity. Power The Power LED will light blue when the device is connected to a power source. Application Examples The PowerBeam mounted outdoors with the Dish Reflector installed provides directional outdoor coverage. ( The gain depends on the reflector.) The PowerBeam mounted outdoors without the Dish Reflector installed provides outdoor-to-indoor coverage using the 3 dBi Antenna Feed only. Installation Requirements • Phillips screwdriver • 13 mm wrench • 16 mm wrench • Shielded Category 5 (or above) cabling should be used for all wired Ethernet connections and should be grounded through the AC ground of the PoE. We recommend that you protect your networks from the most brutal environments and devastating ESD attacks with industrial -grade shielded Ethernet cable from Ubiquiti Networks. For more details, visit www.ubnt.com/toughcable Installation 1. Line up the Alignment Pins of the Rear Housing with the alignment holes of the Dish Reflector. Insert the pins and push until they lock into place. 2. Push in the sides of the Cable Door and detach it from the Rear Housing. 3. Attach the Antenna Feed: a. Insert the Antenna Feed into the Rear Housing, and push until it locks into place with a click. b. Lightly pull the Antenna Feed to ensure that it is locked into place and the Release button is fully engaged. Release Button Bottom View 4. Connect the Ethernet cable: a. Connect an Ethernet cable to the Ethernet Port of the Antenna Feed. b. Re-attach the C able Door to the Rear Housing. 5. Attach two Hex Head Bolts, two Lock Washers, and two Flat Washers to the bottom of the Mounting Bracket. Ensure that there is a gap of 8 mm between each Flat Washer and the Mounting Bracket. Note: Ensure that each Lock Washer is always installed between the Hex Head Bolt and Flat Washer. Flat Washer Lock Washer Hex Head Bolt 8 mm 6. Attach the horizontal slot of the Support Arm to the Upper Pole Bracket using a Hex Head Bolt, Lock Washer, and Flat Washer. Note: Ensure that the degree settings are the same on both arms of the Upper Pole Bracket. Degree markings facing outward 7. Attach the Brace to the pole brackets using the four Screws. 8. Each M8x150 Carriage Bolt includes a serrated flange nut. Remove these and use them in the next step. 9. Attach one Pole Clamp to each pole bracket. a. Insert two M8x150 Carriage Bolts into each pole bracket. b. Slide the hole of a Pole Clamp over one bolt of each pole bracket. c. Place one serrated flange nut on each bolt.

10. Attach the Stabilizer Brackets to the pole just beneath the area where the PowerBeam will be attached. Note: The pole-bracket assembly can accommodate a Ø 38 - 101 mm pole. a. Plac e one Stabilizer Bracket on each side of the pole. b. Insert the two M10x100 Bolts into the Stabilizer Brackets. c. Secure each bolt with one Serrated Flange Nut. 50 N-m 11. Attach the pole-bracket assembly to the pole: a. Slide the slot of each Pole Clamp over the corresponding M8x150 Carriage Bolt. b. Tighten the serrated flange nuts of the bolts to secure the pole-bracket assembly to the pole. Proper slot orientation 25 N-m 12. Lift the Dish Reflector and align the two lower Hex Head Bolts with the slots on the Lower Pole Bracket. Seat the bolts in the slots. 13. Attach each arm of the Upper Pole Bracket to the Mounting Bracket using a Hex Head Bolt, Lock Washer, and Flat Washer. 14. Before adjusting the tilt angle, ensure that the six Hex Head Bolts are loose enough to allow movement. IMPORTANT: If you cannot spin the washers freely by hand, then loosen the Hex Head Bolts until you can. 15. To adjust the tilt angle, turn the screw head of the elevation rod until the desired tilt is reached. 16. Lock the alignment by tightening all six Flange Bolts to 25 N-m. 17. Connect the other end of the Ethernet cable from the PowerBeam to the Ethernet port labeled POE on the Gigabit PoE Adapter. 18. Connect an Ethernet cable from your LAN or computer to the Ethernet port labeled LAN on the adapter. 19. Connect the Power Cord to the power port on the adapter. Connect the other end of the Power Cord to a power outlet. *640-00147-04* 640-00147-04 Mounting the PoE Adapter (Optional) 1. Slide the PoE Mounting Bracket down to remove it from the Gigabit PoE Adapter. 2. Place the PoE Mounting Bracket at the desired location and mark the two holes. Pre-drill the holes if necessary, and then secure the bracket using two fasteners (not included). 3. Align the slots of the Gigabit PoE Adapter with the tabs of the PoE Mounting Bracket, and then slide the adapter down. Accessing airOS Verify connectivity in the airOS Configuration Interface. 1. Mak e sure that your host system is connected via Ethernet to the PowerBeam. 2. Configure the Ethernet adapter on your host system with a static IP address on the 192.168.1.x subnet. 3. Launch your web browser and type https://192.168.1.20 in the address field. Press enter (PC) or return (Mac). 4. The login screen will appear. Enter ubnt in the Username and Password fields. Select your Country and Language. You must agree to the Terms of Use to use the product. Click Login. Note: U.S. product versions are locked to the U.S. Country Code to ensure compliance with FCC regulations. The airOS Configuration Interface will appear, allowing you to customize your settings as needed. For details, refer to the User Guide available at documentation.ubnt.com/airmax Installer Compliance Responsibility Devices must be professionally installed and it is the professional installer's responsibility to make sure the device is operated within local country regulatory requirements. Since Ubiquiti Networks equipment can be paired with a variety of antennas and cables, the Antenna and Output Power fields are provided to the professional installer to assist in meeting regulatory requirements. Specifications PowerBeam PBE-M5-620 Dimensions 650 x 650 x 386 mm (25.6 x 25.6 x 15.2") Weight6.4 kg (14.11 lb) Operating FrequencyWorldwide: 5150 - 5875 MHz USA: 5150-5250, 5725 - 5850 MHz Gain29 dBi Networking Interface(1) 10/100/1000 Ethernet Port EnclosureOutdoor UV Stabilized Plastic Max. Power Consumption8.5W Power Supply24V, 0.5A Gigabit PoE Supply (Included) Power MethodPassive PoE (Pairs 4, 5+; 7, 8 Return) Wind Survivability200 km/h (125 mph) Wind Loading872 N @200 km/h (196 lbf @125 mph) CertificationsCE, FCC, IC MountingPole Mounting Kit Included Operating Temperature-40 to 70° C (-40 to 158° F) Operating Humidity5 to 95% Noncondensing Shock and VibrationsETSI300-019-1.4

Safety Notices 1. Read, follow, and keep these instructions. 2. Heed all warnings . 3. Only use attachments/accessories specified b y the manufacturer. WARNING: Do not use this product in location that can be submerged by water. WARNING: Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning. Electrical Safety Information 1. Compliance is required with respect to voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified may result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed. 2. There are no operator serviceable parts inside this equipment. Service should be provided only by a qualified service technician. 3. This equipment is pr ovided with a detachable power cord which has an integral safety ground wire intended for connection to a grounded safety outlet. a. Do not substitute the power cord with one that is not the provided approved type. Never use an adapter plug to connect to a 2-wire outlet as this will defeat the continuity of the grounding wire. b. The equipment r equires the use of the ground wire as a part of the safety certification, modification or misuse can provide a shock hazard that can result in serious injury or death. c. Contac t a qualified electrician or the manufacturer if there are questions about the installation prior to connecting the equipment. d. Protective earthing is provided by Listed AC adapter. Building installation shall provide appropriate short-circuit backup protection. e. Pr otective bonding must be installed in accordance with local national wiring rules and regulations. Limited Warranty UBIQUITI NETWORKS, Inc (“UBIQUITI NETWORKS”) warrants that the product(s) furnished hereunder (the “Product(s)”) shall be free from defects in material and workmanship for a period of one (1) year from the date of shipment by UBIQUITI NETWORKS under normal use and operation. UBIQUITI NETWORKS’ sole and exclusive obligation and liability under the foregoing warranty shall be for UBIQUITI NETWORKS, at its discretion, to repair or replace any Product that fails to conform to the above warranty during the above warranty period. The expense of removal and reinstallation of any Product is not included in this warranty. The warranty period of any repaired or replaced Product shall not extend beyond its original term. Warranty Conditions The above warranty does not apply if the Product: (I) has been modified and/or altered, or an addition made thereto, except by Ubiquiti Networks, or Ubiquiti Networks’ authorized representatives, or as approved by Ubiquiti Networks in writing; (II) has been painted, rebranded or physically modified in any way; (III) has been damaged due to errors or defects in cabling; (IV) has been subjected to misuse, abuse, negligence, abnormal physical, electromagnetic or electrical stress, including lightning strikes, or accident; (V) has been damaged or im…

Text truncated - open the document above for the full version.
