CHC ® i50 GNSS Receiver User Guide Revision 1.0 June 01, 2018 Table of Content 2 Table of Content Table of Content.................................................................................................... 2 Preface ................................................................................................................. 5 Copyright ................................................................................................................ 5 Safety Warnings ..................................................................................................... 5 FCC Interference Statement ................................................................................... 5 CE Interference Statement ..................................................................................... 6 1 Introduction ................................................................................................... 7 1.1 Safety Information ..................................................................................... 7 1.1.1 Warnings and Cautions ...................................................................... 7 1.1.2 Regulations and Safety ....................................................................... 7 1.1.3 Use and Care ...................................................................................... 8 1.2 Technical Support ....................................................................................... 8 1.3 Disclaimer ................................................................................................... 8 1.4 Your Comments .......................................................................................... 8 2 Getting Started with i50 .................................................................................. 9 2.1 About the Receiver .................................................................................... 9 2.2 Parts of the Receiver .................................................................................. 9 2.2.1 Front Panel ......................................................................................... 9 2.2.2 Lower Housing ................................................................................. 11 2.2.3 Receiver Ports .................................................................................. 12 2.3 Batteries and Power ................................................................................. 13 2.3.1 Internal Batteries ............................................................................. 13 2.3.2 External Power Supply ..................................................................... 14 2.4 Inserting Battery and SIM Card ................................................................ 15 2.5 Product Basic Supply Accessories ............................................................ 16 2.5.1 Base Kit Basic Supply ........................................................................ 16 2.5.2 Rover Kit Basic Supply ...................................................................... 18 2.6 Connecting to an Office Computer .......................................................... 19 2.7 Connecting to a Controller ....................................................................... 19 2.7.1 Connecting via Wi-Fi with LandStar 7 Software ............................... 19 2.7.2 Connecting via Bluetooth with LandStar 7 Software ....................... 21 2.8 Downloading Logged Data ....................................................................... 23 3 Base Station Setup and Operation .................................................................. 25 3.1 Base Station Setup Guidelines ................................................................. 25 3.2 Outputting Corrections Using Internal Radio Modem ............................. 26 3.2.1 Base Station Setup ........................................................................... 26 3.3 Outputting Corrections Using External Radio .......................................... 27 4 Rover Station Setup And Operation ................................................................ 29 Table of Content 3 4.1 Rover Station Setup Guidelines................................................................ 29 4.2 Rover Station Setup .................................................................................. 30 5 Configuring Through a Web Browser .............................................................. 31 5.1 Status Menu ............................................................................................. 32 5.1.1 Position Submenu ............................................................................ 33 5.1.2 Activity Submenu ............................................................................. 33 5.1.3 Google Map Submenu ..................................................................... 34 5.2 Satellites Menu ........................................................................................ 35 5.2.1 Tracking Table Submenu .................................................................. 35 5.2.2 Tracking Info. Table Submenu .......................................................... 36 5.2.3 Tracking Skyplot Submenu ............................................................... 36 5.2.4 Satellite Activation Submenu ........................................................... 36 5.2.5 Tracking Enable Submenu ................................................................ 37 5.3 Receiver Configuration Menu .................................................................. 38 5.3.1 Description ....................................................................................... 38 5.3.2 Antenna Configuration Submenu .................................................... 38 5.3.3 Reference Station Settings Submenu ............................................... 39 5.3.4 Receiver Reset Submenu ................................................................. 42 5.3.…

Text truncated - open the document above for the full version.

1) FCC 15.19 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2）FCC 15.21 Warning: Changes or modifications to this unit not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 3) FCC 15.105 For a Class B digital device or peripheral, the instructions furnished the user shall include the following or similar statement, placed in a prominent location in the text of the manual: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. 4）FCC RF Exposure- portable This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 50cm between the radiator & your body.

Shanghai Huace Navigation Technology LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020-07-31 Subject; Request for Long Term Confidentiality FCC ID: SY4-A02026 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram BOM Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Chu Sheng Title: CERTIFICATION MANAGER

Shanghai Huace Navigation Technology LTD. D:\杨玉龙专用\案件进行中\A2006165-C01-M01_FCC_GNSS_华测_甘梅丽\8.机构文件\POA_Letter_140225.docx Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2020-08-06 SUBJECT: FCC Application for SY4-A02026 To Whom It May Concern: We, the undersigned, hereby authorize Mark Zhu at Shenzhen Alpha Product Testing Co., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen Alpha Product Testing Co., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Signature: Date: 2020-08-06 Name: Chu Sheng Title: CERTIFICATION MANAGER Company: Shanghai Huace Navigation Technology LTD.

FCC ID: SY4-A02026 UHF ANT FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026

Label Location

FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 FCC ID: SY4-A02026 GSM/WCDMA/LTE ANT

FCC ID: SY4-A02026 BT/WIFI/GPS ANT

FCC ID: SY4-A02026 Prediction of MPE at a given distance 1. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) 2. Test Procedure Equation from page 18 of OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to the antenna G = numeric gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna FCC ID: SY4-A02026 3. Result Worse case is as below: Mode Frequency (MHz) Prediction distance (cm) RF output power MPE (mW/cm 2 ) Limit (mW/cm 2 ) SAR Test Exclusion dBm mW BT EDR 2441 50 1.804 1.515 0.00006 1 Yes BLE 2440 50 3.064 2.025 0.00008 1 Yes WIFI 2462 50 17.07 50.933 0.00204 1 Yes GSM 848.80 50 30.93 1238.797 0.04964 0.5659 Yes WCDMA 1880 50 23.67 232.809 0.00886 1 Yes LTE 1715 50 23.88 244.343 0.00930 1 Yes UHF 469.850 50 30.003 1000.691 0.03808 0.3132 Yes Maximum Simultaneous transmission MPE Ratios for BLE+WIFI +GSM+UHF: Max MPE ratio BLE /Limit Max MPE ratio WIFI /Limit Max MPE ratio GSM /Limit Max MPE ratio UHF /Limit ∑MPE ratios Limit Result 0.00008 0.00204 0.08772 0.12158 0.21142 1 PASS BT&WIFI Antenna Gain: 1dBi, 1.259(numeric) GSM, WCDMA & LTE Antenna Gain: 0.775dBi, 1.195(numeric) UHF Antenna Gain: 4dBi, 2.512(numeric) Then SAR evaluation is not required.

FCC TEST REPORT FCC ID: SY4-A02026 On Behalf of Shanghai Huace Navigation Technology LTD. Geodetic GNSS Receiver Model No.: i50 Prepared for : Shanghai Huace Navigation Technology LTD. Address : 599 Gaojing Road, Building D, Shanghai 201702, China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2006165-C01-R04 Date of Receipt : June 18, 2020 Date of Test : June 18, 2020 – July 15, 2020 Date of Report : July 15, 2020 Version Number : V0 Page 2 of 53 Report No.: A2006165-C01-R04 TABLE OF CONTENTS Description Page 1 TEST SUMMARY ......................................................................................................................................5 2 GENERAL INFORMATION .......................................................................................................................6 2.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................6 2.2 RELATED SUBMITTAL(S) / GRANT (S) ....................................................................................................8 2.3 TEST FACILITY.....................................................................................................................................8 2.4 MEASUREMENT UNCERTAINTY .............................................................................................................8 3 TEST INSTRUMENTS LIST ......................................................................................................................9 4 SYSTEM TEST CONFIGURATION ........................................................................................................10 4.1 TEST MODE .......................................................................................................................................10 4.2 CONFIGURATION OF TESTED SYSTEM .................................................................................................10 4.3 CONDUCTED AV OUTPUT POWER ......................................................................................................11 4.4 PEAK-TO-AVERAGE RATIO .................................................................................................................13 4.5 OCCUPY BANDWIDTH .........................................................................................................................17 4.6 MODULATION CHARACTERISTIC ................................................................................................22 4.7 OUT OF BAND EMISSION AT ANTENNA TERMINALS ................................................................................22 4.8 ERP, EIRP MEASUREMENT ...............................................................................................................31 4.9 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT ..................................................................39 4.10 FREQUENCY STABILITY V.S. TEMPERATURE MEASUREMENT ................................................................47 4.11 FREQUENCY STABILITY V.S. VOLTAGE MEASUREMENT ........................................................................51 Page 3 of 53 Report No.: A2006165-C01-R04 TEST REPORT DECLARATION Applicant : Shanghai Huace Navigation Technology LTD. Address : 599 Gaojing Road, Building D, Shanghai 201702, China Manufacturer : Shanghai Huace Navigation Technology LTD. Address : 599 Gaojing Road, Building D, Shanghai 201702, China EUT Description : Geodetic GNSS Receiver (A) Model No. : i50 (B) Trademark : Measurement Standard Used: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part22 Subpart H FCC CFR Title 47 Part24 Subpart E ANSIC 63.26:2015 TIA/EIA-603-E:2016 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed of full responsibility for the accuracy and completeness of these tests. After the test, our opinion is that EUT compliance with the requirement of the above standards. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).........: Reak Yang Project Engineer Approved by (name + signature).......: Simple Guan Project Manager Date of issue...... .......................: July 15, 2020 Page 4 of 53 Report No.: A2006165-C01-R04 Revision History Revision Issue Date Revisions Revised By V0 July 15, 2020 Initial released Issue Reak Yang Page 5 of 53 Report No.: A2006165-C01-R04 1 Test Summary Test Item Section in CFR 47 Result RF Exposure (SAR) Part 2.1310 Part 2.1091 Pass* (Please refer to SAR Report) RF Output Power Part 2.1046 Part 22.913 (a)(5) Part 24.232 (c) Pass Peak-to-Average Ratio Part 2.1046 Part 22.913(d) Part 24.232 (d) Pass Modulation Characteristics Part 2.1047 N/A 99% & -26 dB Occupied Bandwidth Part 2.1049 Pass Spurious Emissions at Antenna Terminal Part 2.1051 Part 22.917 (a) Part 24.238 (a) Pass Field Strength of Spurious Radiation Part 2.1053 Part 22.917 (a) Part 24.238 (a) Pass Out of band emission, Band Edge Part 22.917 (a) Part 24.238 (a) Pass Frequency stability vs. temperature Part 2.1055(a)(1)(b) Part 22.355 Part 24.235 Pass Frequency stability vs. voltage Part 2.1055(d)(1)(2) Part 22.355 Part 24.235 Pass Pass: The EUT complies with the essential requirements in the standard. Page 6 of 53 Report No.: A2006165-C01-R04 2 General Information 2.1 General Description of EUT Description/PMN : Geodetic GNSS Receiver Trademark : Model Number/HVIN(s) : i50 Diff : N/A Test Voltage : DC 12-36V, 2A (for DC port) or DC 7.4V, 3400mAh (for replaceable lithium battery) Support Networks GPRS, EGPRS, WCDMA Support Bands GSM850, PCS1900, WCDMA Band V, WCDMA Band II TX Frequen…
