SZ23267T49RF Remote Control Transmitter

Planet Toys (HK) Ltd.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Dec 21, 2005
Application Purpose: Original Equipment
Date of Application: Dec 21, 2005
Equipment Note: RF Remote Control Transmitter
Frequency Range: 49.86000000 - 49.86000000
Company: Planet Toys (HK) Ltd.
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

External Photos

Technical Report: (5205) 333-0526 Date: 5 December 2005 Page 1 of 2 Photographs: EUT Exterior Sample Description: Malibu Boats Radio Remote Control Transmitter (49.860 MHz) FCC ID (if applicable): SZ23267T49 Photo No. 1 : The Front View Technical Report: (5205) 333-0526 Date: 5 December 2005 Page 2 of 2 Photographs: EUT Exterior Sample Description: Malibu Boats Radio Remote Control Transmitter (49.860 MHz) FCC ID (if applicable): SZ23267T49 Photo No. 2 : The Back View

ID Label/Location Info

Technical Report: (5205) 333-0526 Date: 5 December 2005 Page 1 of 2 Photographs: Label and Its Location Sample Description: Malibu Boats Radio Remote Control Transmitter (49.860 MHz) FCC ID (if applicable): SZ23267T49 Photo No. 1 : The Label Technical Report: (5205) 333-0526 Date: 5 December 2005 Page 2 of 2 Photographs: Label and its Location Sample Description: Malibu Boats Radio Remote Control Transmitter (49.860 MHz) FCC ID (if applicable): SZ23267T49 Photo No. 2 : The Location of the Label

Internal Photos

Technical Report: (5205) 333-0526 Date: 5 December 2005 Page 1 of 3 Photographs: EUT Interior Sample Description: Malibu Boats Radio Remote Control Transmitter (49.860 MHz) FCC ID (if applicable): SZ23267T49 Photo No. 1 : PCB Solder Side Technical Report: (5205) 333-0526 Date: 5 December 2005 Page 2 of 3 Photographs: EUT Interior Sample Description: Malibu Boats Radio Remote Control Transmitter (49.860 MHz) FCC ID (if applicable): SZ23267T49 Photo No. 2 : PCB Component Side Technical Report: (5205) 333-0526 Date: 5 December 2005 Page 3 of 3 Photographs: EUT Interior Sample Description: Malibu Boats Radio Remote Control Transmitter (49.860 MHz) FCC ID (if applicable): SZ23267T49 Photo No. 3 : The component placement and the assembly

Test Setup Photos

Technical Report: (5205) 333-0526 Date: 5 November 2005 Page 1 of 3 Photographs: Test Setup Sample Description: Malibu Boats Radio Remote Control Transmitter (49.860 MHz) FCC ID (if applicable): SZ23267T49 Photo No. 1 : Test Setup – Vertically Erected (z – direction) Technical Report: (5205) 333-0526 Date: 5 November 2005 Page 2 of 3 Sample Description: Malibu Boats Radio Remote Control Transmitter (49.860 MHz) FCC ID (if applicable): SZ23267T49 Photo No. 2 : Test Setup – Horizontal (y – direction) Technical Report: (5205) 333-0526 Date: 5 November 2005 Page 3 of 3 Sample Description: Malibu Boats Radio Remote Control Transmitter (49.860 MHz) FCC ID (if applicable): SZ23267T49 Photo No. 3 : Test Setup – Horizontal (x-direction)
