Appendix P Photo Documentation Page 1 of 2 10048334 001; 10048327 001; 110048329 001; 10048330 001; 110048331 001 Product: Brand Name: RUNNING WATCH GPS AVID FIT Type Identification: 700 Appendix P Photo Documentation Page 2 of 2 10048334 001; 10048327 001; 110048329 001; 10048330 001; 110048331 001 Product: Brand Name: RUNNING WATCH GPS AVID FIT Type Identification: 700

Lucas 2014/11/19RW700 R5355-1RW700-001 Product Label,RW700,AVIDFIT V1.0 材質50#反銀龍貼紙+黑色印刷+霧P S/N:Barcode用Code128, 依照"成品序號機種代碼表"編號。 編號必須與Serial Label上的號碼相同。 成品序號14碼 A1A2 B1B2 C1C2 S1S2 D1D2D3D4D5D6 A1A2 共二碼，為機種代碼 B1B2 共二碼，為西元年後二碼 C1C2 共二碼，為客戶代碼 S1S2 共二碼，為BOM後二碼 D1~D6 共六碼，為序號流水號 22.5mm 25.5mm Input: IC:12485A-700 M/N:700 FCC ID:SZF700

Label Location here

Appendix P Photo Documentation Page 1 of 4 10048334 001; 10048327 001; 110048329 001; 10048330 001; 110048331 001 Product: Brand Name: RUNNING WATCH GPS AVID FIT Type Identification: 700 Appendix P Photo Documentation Page 2 of 4 10048334 001; 10048327 001; 110048329 001; 10048330 001; 110048331 001 Product: Brand Name: RUNNING WATCH GPS AVID FIT Type Identification: 700 Appendix P Photo Documentation Page 3 of 4 10048334 001; 10048327 001; 110048329 001; 10048330 001; 110048331 001 Product: Brand Name: RUNNING WATCH GPS AVID FIT Type Identification: 700 Appendix P Photo Documentation Page 4 of 4 10048334 001; 10048327 001; 110048329 001; 10048330 001; 110048331 001 Product: Brand Name: RUNNING WATCH GPS AVID FIT Type Identification: 700 Chip Antenna

Produkte Products Prüfbericht - Nr.: Test Report No. 10048331 001 Seite 30 von 34 Page 30 of 34 6. Safety Human exposure 6.1 Radio Frequency Exposure Compliance 6.1.1 Electromagnetic Fields RESULT: Passed Test standard : FCC KDB Publication 447498 D01 v05 The maximum peak output power of the transmitter is 2.12 mW. The separation between hand and antenna is more than 2mm. Hence the EUT is exclueded from SAR evaluation. Please also refer to FCC KDB publication 447498 D01 v05: Mobile Portable RF Exposure

Produkte Products Prüfbericht - Nr.: Test Report No. 10048331 001 Seite 2 von 34 Page 2 of 34 TEST SUMMARY 5.1.1 ANTENNA REQUIREMENT RESULT: Passed 5.1.2 PEAK OUTPUT POWER RESULT: Passed 5.1.3 6DB BANDWIDTH RESULT: Passed 5.1.4 POWER DENSITY RESULT: Passed 5.1.5 CONDUCTED SPURIOUS EMISSIONS AND FREQUENCY BAND EDGE MEASURED IN 100KHZ BANDWIDTH RESULT: Passed 5.1.6 SPURIOUS EMISSION RESULT: Passed 6.1.1 ELECTROMAGNETIC FIELDS RESULT: Passed Produkte Products Prüfbericht - Nr.: Test Report No. 10048331 001 Seite 3 von 34 Page 3 of 34 Contents 1. GENERAL REMARKS ............................................................................................... 4 1.1 COMPLEMENTARY MATERIALS ................................................................................. 4 2. TEST SITES ............................................................................................................ 5 2.1 TEST FACILITIES ..................................................................................................... 5 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS ...................................................... 6 2.3 TRACEABILITY ........................................................................................................ 7 2.4 CALIBRATION ......................................................................................................... 7 2.5 MEASUREMENT UNCERTAINTY ................................................................................. 7 3. GENERAL PRODUCT INFORMATION ........................................................................... 8 3.1 PRODUCT FUNCTION AND INTENDED USE ................................................................. 8 3.2 SYSTEM DETAILS AND RATINGS ............................................................................... 8 3.3 INDEPENDENT OPERATION MODES ........................................................................... 9 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS .............................................. 9 3.5 SUBMITTED DOCUMENTS ......................................................................................... 9 4. TEST SET-UP AND OPERATION MODES ................................................................... 10 4.1 PRINCIPLE OF CONFIGURATION SELECTION ............................................................ 10 4.2 TEST OPERATION AND TEST SOFTWARE................................................................. 10 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ............................................... 10 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE .............................................. 11 4.5 TEST SETUP DIAGRAM .......................................................................................... 11 5. TEST RESULTS ..................................................................................................... 13 5.1 TRANSMITTER REQUIREMENT & TEST SUITES ......................................................... 13 5.1.1 Antenna Requirement ................................................................................................................ 13 5.1.2 Peak Output Power .................................................................................................................... 14 5.1.3 6dB Bandwidth ........................................................................................................................... 17 5.1.4 Power Density ............................................................................................................................ 22 5.1.5 Conducted spurious emissions and Frequency Band Edge measured in 100kHz Bandwidth ................................................................................................................................... 25 5.1.6 Spurious Emission ..................................................................................................................... 29 6. SAFETY HUMAN EXPOSURE ................................................................................... 30 6.1 RADIO FREQUENCY EXPOSURE COMPLIANCE ......................................................... 30 6.1.1 Electromagnetic Fields ............................................................................................................... 30 7. PHOTOGRAPHS OF THE TEST SET-UP ..................................................................... 31 Produkte Products Prüfbericht - Nr.: Test Report No. 10048331 001 Seite 4 von 34 Page 4 of 34 8. LIST OF TABLES ................................................................................................... 34 9. LIST OF PHOTOGRAPHS......................................................................................... 34 1. General Remarks 1.1 Complementary Materials All attachments are integral parts of this test report. This applies especially to the following appendix: Appendix P: Photo Documentation internal view (File Name: 10048331APPENDIX P) Appendix D: Test Result of Radiated Emissions (File Name: 10048331APPENDIX D) Test Specifications The following standards were applied. Table 1: Applied Standard and Test Levels Radio FCC CFR47 Part 15: Subpart C Section 15.247 ANSI C63.10:2009, KDB558074 D01 DTS Meas Guidance v02 Produkte Products Prüfbericht - Nr.: Test Report No. 10048331 001 Seite 5 von 34 Page 5 of 34 2. Test Sites 2.1 Test Facilities TUV Rheinland Taiwan Ltd. 11F. No.758, Sec. 4, Bade Rd., Songshan Dist. Taipei City 105 Taiwan (R.O.C.) FCC Registration No.: 365730 IC Canada Registration No.: 9465A-1 TAF Accredited NCC Test Lab. No.:0759 TAF ISO17025 Certification effective periods: 2013-Jul-1st to 2016-Jun-30th Produkte Products Prüfbericht - Nr.: Test Report No. 10048331 001 Seite 6 von 34 Page 6 of 34 2.2 List of Test and Measurement Instruments Table 2: List of Test and Measurement Equipment Kind of Equipment Manufacturer Type S/N Calibrated until EMI Test Receiver R&S ESR7 101062 30-Aug-15 Bilog Antenna TESEQ CBL6111D 29802 4-Jul-15 Spectrum A…

Text truncated - open the document above for the full version.

Test Report No.10048331 001 Appendix D: Radiated Spurious Emission Data (File: 10048331AppendixD) Contents Spurious Emissions, Band Edges, 2.35-2.5G ............................................................................................. 2 Spurious Emissions, TX Mode, 1-18G ....................................................................................................... 6 Spurious Emissions, TX Mode, 18-26G ................................................................................................... 12 Spurious Emissions, TX Mode, 30M-1G ................................................................................................. 18 Spurious Emissions, Band Edge, 2.35-2.5G 2 Spurious Emissions, Band Edges, 2.35-2.5G adiated Bandedge (GFSK) Low Channel (Hor) Spurious Emissions, Band Edge, 2.35-2.5G 3 Low Channel (Ver) Spurious Emissions, Band Edge, 2.35-2.5G 4 Radiated Bandedge (GFSK) High Channel (Hor) Spurious Emissions, Band Edge, 2.35-2.5G 5 High Channel (Ver) Spurious Emissions, TX Mode, 1-18G 6 Spurious Emissions, TX Mode, 1-18G Service No.: 114026367-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Horizontal Test item: Radiation Emission Test Time: 2014/9/24 22:51:14 Applicant: COMPASS Test Rating: DC 5V Product: Sport Watch Temp.( °C °C°C °C)/Hum.(%): 22(°C °C°C °C)/57% Model No.: 7xx Test Engineer: Hugo Chang Test Mode: 2402-TX Remark: No. Frequency (MHz) Factor (dB/m) Reading (dBuV) Level (dBuV/m) Limit (dBuV/m) Margin (dB) Det. Height (cm) Azimuth (。 。。 。) Remark 1 1517.628 -10.56 61.02 50.46 74.00 -23.54 peak 100 143 2 4804.000 -2.59 50.15 47.56 74.00 -26.44 peak 3 7206.000 5.44 46.27 51.71 74.00 -22.29 peak Tel:+886-2-2172-7000 Fax:+886-2-2528-0018 11F.,No.758,Sec. 4,Bade Rd.,Songshan Dist.,Taipei 105,Taiwan TUV Rheinland Taiwan Spurious Emissions, TX Mode, 1-18G 7 Service No.: 114026367-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Vertical Test item: Radiation Emission Test Time: 2014/9/24 22:52:16 Applicant: COMPASS Test Rating: DC 5V Product: Sport Watch Temp.(°C °C°C °C)/Hum.(%): 22(°C °C°C °C)/57% Model No.: 7xx Test Engineer: Hugo Chang Test Mode: 2402-TX Remark: No. Frequency (MHz) Factor (dB/m) Reading (dBuV) Level (dBuV/m) Limit (dBuV/m) Margin (dB) Det. Height (cm) Azimuth (。 。。 。) Remark 1 1517.628 -10.56 60.18 49.62 74.00 -24.38 peak 100 176 2 4804.000 -2.59 49.02 46.43 74.00 -27.57 peak 3 7206.000 5.44 44.99 50.43 74.00 -23.57 peak Tel:+886-2-2172-7000 Fax:+886-2-2528-0018 11F.,No.758,Sec. 4,Bade Rd.,Songshan Dist.,Taipei 105,Taiwan TUV Rheinland Taiwan Spurious Emissions, TX Mode, 1-18G 8 Service No.: 114026367-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Horizontal Test item: Radiation Emission Test Time: 2014/9/24 22:53:54 Applicant: COMPASS Test Rating: DC 5V Product: Sport Watch Temp.(°C °C°C °C)/Hum.(%): 22(°C °C°C °C)/57% Model No.: 7xx Test Engineer: Hugo Chang Test Mode: 2441-TX Remark: No. Frequency (MHz) Factor (dB/m) Reading (dBuV) Level (dBuV/m) Limit (dBuV/m) Margin (dB) Det. Height (cm) Azimuth (。 。。 。) Remark 1 1517.628 -10.56 60.54 49.98 74.00 -24.02 peak 100 147 2 4882.000 -2.39 49.26 46.87 74.00 -27.13 peak 3 7323.000 5.76 44.96 50.72 74.00 -23.28 peak Tel:+886-2-2172-7000 Fax:+886-2-2528-0018 11F.,No.758,Sec. 4,Bade Rd.,Songshan Dist.,Taipei 105,Taiwan TUV Rheinland Taiwan Spurious Emissions, TX Mode, 1-18G 9 Service No.: 114026367-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Vertical Test item: Radiation Emission Test Time: 2014/9/24 22:54:57 Applicant: COMPASS Test Rating: DC 5V Product: Sport Watch Temp.(°C °C°C °C)/Hum.(%): 22(°C °C°C °C)/57% Model No.: 7xx Test Engineer: Hugo Chang Test Mode: 2441-TX Remark: No. Frequency (MHz) Factor (dB/m) Reading (dBuV) Level (dBuV/m) Limit (dBuV/m) Margin (dB) Det. Height (cm) Azimuth (。 。。 。) Remark 1 1517.628 -10.56 59.64 49.08 74.00 -24.92 peak 100 176 2 4882.000 -2.39 49.32 46.93 74.00 -27.07 peak 3 7323.000 5.76 44.01 49.77 74.00 -24.23 peak Tel:+886-2-2172-7000 Fax:+886-2-2528-0018 11F.,No.758,Sec. 4,Bade Rd.,Songshan Dist.,Taipei 105,Taiwan TUV Rheinland Taiwan Spurious Emissions, TX Mode, 1-18G 10 Service No.: 114026367-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Horizontal Test item: Radiation Emission Test Time: 2014/9/24 22:47:41 Applicant: COMPASS Test Rating: DC 5V Product: Sport Watch Temp.(°C °C°C °C)/Hum.(%): 22(°C °C°C °C)/57% Model No.: 7xx Test Engineer: Hugo Chang Test Mode: 2480-TX Remark: No. Frequency (MHz) Factor (dB/m) Reading (dBuV) Level (dBuV/m) Limit (dBuV/m) Margin (dB) Det. Height (cm) Azimuth (。 。。 。) Remark 1 1517.628 -10.56 60.40 49.84 74.00 -24.16 peak 100 146 2 4960.000 -2.19 47.29 45.10 74.00 -28.90 peak 3 7440.000 6.09 42.26 48.35 74.00 -25.65 peak Tel:+886-2-2172-7000 Fax:+886-2-2528-0018 11F.,No.758,Sec. 4,Bade Rd.,Songshan Dist.,Taipei 105,Taiwan TUV Rheinland Taiwan Spurious Emissions, TX Mode, 1-18G 11 Service No.: 114026367-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Vertical Test item: Radiation Emission Test Time: 2014/9/24 22:48:43 Applicant: COMPASS Test Rating: DC 5V Product: Sport Watch Temp.(°C °C°C °C)/Hum.(%): 22(°C °C°C °C)/57% Model No.: 7xx Test Engineer: Hugo Chang Test Mode: 2480-TX Remark: No. Frequency (MHz) Factor (dB/m) Reading (dBuV) Level (dBuV/m) Limit (dBuV/m) Margin (dB) Det. Height (cm) Azimuth (。 。。 。) Remark 1 1517.628 -10.56 60.15 49.59 74.00 -24.41 peak 100 176 2 4960.000 -2.19 48.77 46.58 74.00 -27.42 peak 3 7440.000 6.09 42.71 48.80 74.00 -25.20 peak Tel:+886-2-2172-7000 Fax:+886-2-2528-0018 11F.,No.758,Sec. 4,Bade Rd.,Songshan Dist.,Taipei 105,Taiwan TUV Rheinland Taiwan Spurious Emissions, TX Mode, 18-26G 12 Spurious Emissions, TX Mode, 18-26G Service No.: 114026367-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Horizontal Test item: Radiation Emission Test Time: 2014/9/24 23:13:09 Applicant: COMPASS Test Rati…

Text truncated - open the document above for the full version.

Produkte Products Prüfbericht - Nr.: Test Report No. 10048331 001 Seite 31 von 34 Page 31 of 34 7. Photographs of the Test Set-Up Photograph 1: Set-up for Spurious Emissions (Front View) Produkte Products Prüfbericht - Nr.: Test Report No. 10048331 001 Seite 32 von 34 Page 32 of 34 Photograph 2: Set-up for Spurious Emissions (Back View 1) Photograph 3: Set-up for Spurious Emissions (Back View 2) Produkte Products Prüfbericht - Nr.: Test Report No. 10048331 001 Seite 33 von 34 Page 33 of 34 Photograph 4: Set-up for Conducted testing
