SZV-TCM320UTRANSCEIVER MODULE

USER MANUAL EnOcean GmbH Kolpingring 18a 82041 Oberhaching Germany Phone +49.89.67 34 689-0 Fax +49.89.67 34 689-50 [email protected] www.enocean.com Subject to modifications TCM 300 / TCM 320 User Manual 10 February 6 th , 2013 Page 1/53 Patent protected: WO98/36395, DE 100 25 561, DE 101 50 128, WO 2004/051591, DE 103 01 678 A1, DE 10309334, WO 04/109236, WO 05/096482, WO 02/095707, US 6,747,573, US 7,019,241 Observe precautions! Electrostatic sensitive devices! Transceiver Module TCM 300 / TCM 300C / TCM 300U TCM 320 / TCM 320C / TCM 320U February 6 th , 2013 USER MANUAL © 2013 EnOcean | www.enocean.com TCM 300x / TCM 320x User Manual | Page 2/53 TCM 300 / TCM 300C / TCM 300U TCM 320 / TCM 320C / TCM 320U REVISION HISTORY The following major modifications and improvements have been made to the first version of this document: No Major Changes 1.01 Tape running direction added in 3.8 1.02 Dimension of TCM 320 corrected (width 18 mm instead of 19 mm) 1.03 Editorial changes 1.10 Timing information regarding serial protocol added in A.2, A.3. 0xFFFF_FFFF ex- cluded from usable ID range, because this ID will be used as broadcast ID. 1.20 Error corrected in 3.2.1. and 4.1: Maximum gain of external antenna at 50 Ohm output RF_50 is 0 dBi! Error corrected in 2.2: WXODIO is configured as output and provides information on VON signal 1.21 Note added in 3.5 1.25 Remarks added regarding use of IOVDD in 2.2.; Antenna specification in 3.3.1 ex- tended. Updated information on conducted output power in 1.2; A.2.2 changed to point to EnOcean Alliance Website; A.2.3 and A.2.4 removed; editorial changes 1.26 Start-up time added in 1.2; Layout recommendations improved in 3.6 1.27 Antenna recommendations removed and referred to application note AN102 and AN105; Maximum Rating for IOVDD modified (IOVDD may now exceed VDD); Chapter “Related Documents” added; figure added in 3.2.1; parameters for anten- na requirements relaxed in 4.2.1.; pin numbers added in 3.2; Update of FCC grants in 5.2; TCM 320 drawing modified in 2.3. 1.29 New module variants for 902.875 MHz 1.30 Several Changes to meet FCC and IC manual requirements for Limited Modular Approval Published by EnOcean GmbH, Kolpingring 18a, 82041 Oberhaching, Germany www.enocean.com, [email protected], phone +49 (89) 6734 6890 © EnOcean GmbH All Rights Reserved Important! This information describes the type of component and shall not be considered as assured characteris- tics. No responsibility is assumed for possible omissions or inaccuracies. Circuitry and specifications are subject to change without notice. For the latest product specifications, refer to the EnOcean web- site: http://www.enocean.com. As far as patents or other rights of third parties are concerned, liability is only assumed for modules, not for the described applications, processes and circuits. EnOcean does not assume responsibility for use of modules described and limits its liability to the replacement of modules determined to be defective due to workmanship. Devices or systems contain- ing RF components must meet the essential requirements of the local legal authorities. The modules must not be used in any relation with equipment that supports, directly or indirectly, human health or life or with applications that can result in danger for people, animals or real value. Components of the modules are considered and should be disposed of as hazardous waste. Local government regulations are to be observed. Packing: Please use the recycling operators known to you. USER MANUAL © 2013 EnOcean | www.enocean.com TCM 300x / TCM 320x User Manual | Page 3/53 TCM 300 / TCM 300C / TCM 300U TCM 320 / TCM 320C / TCM 320U TABLE OF CONTENT 1 MODULE VARIANTS AND RELATED DOCUMENTS ............................................... 5 2 GENERAL DESCRIPTION ................................................................................. 6 2.1 Basic functionality ......................................................................................... 6 2.2 Technical data TCM 300 / TCM 320 (868.300 MHz) ............................................ 7 2.3 Technical data TCM 300C / TCM 320C (315.000 MHz) ........................................ 8 2.4 Technical data TCM 300U/ TCM 320U (902.875 MHz) ......................................... 8 2.5 Physical dimensions TCM 300x ........................................................................ 9 2.6 Physical dimensions TCM 320x ........................................................................ 9 2.7 Environmental conditions ............................................................................. 10 2.8 Ordering information .................................................................................... 10 3 FUNCTIONAL DESCRIPTION .......................................................................... 11 3.1 Pin out ....................................................................................................... 11 3.2 Pin description and operational characteristics ................................................. 12 3.2.1 GPIO supply voltage - IOVDD .................................................................... 14 3.3 Absolute maximum ratings (non operating) .................................................... 15 3.4 Maximum ratings (operating) ........................................................................ 15 3.5 Operating modes ......................................................................................... 16 3.6 Mode selection ............................................................................................ 17 3.7 Repeater configuration ................................................................................. 18 3.8 Teach-in procedure ...................................................................................... 19 3.8.1 Setting the receiver to learning mode ........................................................ 19 3.8.2 Confirmation of Learning Mode ..............................…

Text truncated - open the document above for the full version.

Enoc€n GmbH, Kolpingring 1Ba, D-82041 Offi)adring Timco Engineering 849 N.W. State Road 45 PO Box 370 Newberry, FL 32669 Attn: Director of Certification Enoean GmbH Kolpingring 18a D-82041 Oberhaching www.enocean.com Oliver Sczesny Dipl.Ing. ( FH) Application Engineering Manager rel +1 (801) 3r2 OLLT mobil +1 (801) 989 0240 oliver.sczesn [email protected] Authoritv to Act as Aqent- FCC On our behalf, I authorize Tom Jackson, General Manager, or Merry Jackson, Office Manager, of Nemko-CCL, Inc. at 1940 W. Alexander Street, Salt Lake City, UT 84119, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in Federal Communications Commission regulations will have affixed to it a label identicalto that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti- Drug Abuse Act of 1988, 21 U.S.C. S 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1 .2002(b) for the definition of a "party" for these purposes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Timco Engineering still resides with EnOcean GmbH at Kolpingring 18a, Oberhaching 82041, Germany. Dated this 14thDay of January 2013 Agency agreement expiration date:December 312013 Oliver Sczesny Printed Title: ApplicationEngineeringManager On behalf of : Telephone: EnOcean GmbH +1 (801) 312 0117 Engcean GmbH, Kolpingring 18a, D-82041 Oberhaching I Geschziftsfllhrer: Laurent Giai-l4iniet und Uwe Thumm I Registergericht l4unchen, HRB 139781 I TFI +4q Rq 67 ?4 6Rq - n I Fay +4q 3q 67 ?4 6Aq - 54 | infnfilpnmcan.nm I Hvnn\/FrainshtnL Miinrhe^ Al7 -7i )^:t)Jn kh )44O6'1i

EnOceanGmbHKolpingring18a82041Oberhaching/Germany II To: FederalCommunicationsCommission OfficeofEngineeringandTechnology.LaboratoryDivision 7435OaklandMillsRd. Columbia,MD21046-1609 LaurentGiai-Miniet ChiefExecutiveOfficer Phone+49.89.6734'689-0 Fax+49.89.6734689-50 [email protected] Reference:SignatureAuthorizationforFCCCertifications ToWhomIt MayConcern: ThisAuthorizationwilldesignatethepersonnamedbelowtoaetonmy behalfandEnOcean'sbehalfasauthorizedagentandrepresentativeuntil furthernotice.Allactscan:ted.outandrequests.mad.ebythisnamed. representativerelatingtoanymatterbeforetheFCC,includingrequests fortOnfide'ntiäl"ity,shallhavethesameeffectasmine. Name: Title: Address: Telephone: Fax: Email: OliverSczesny ApplicationEngineeringManager 6914S.3000E.; CottonwoodHeights,UTi84121,U.S.Ä. +1(801)3120117 n.a. [email protected] QuestionsaboutthescopeandeffeetofthisAuthorizationshouldbe addressedasfolIows: Name: Title: Address: Telephone: Fax: Em'il: L LaurentGial-Miniet CEO Kolpingring18a,84021Oberhaching,Germany +49(89)6734689- 0 +(89)6734689- 50 [email protected] EnOceanGmbH Kolpingring183 82041Oberhaching Phone+49.89.6734689-0 Fax+49.89.6734689-50 [email protected] ManagingDirec!ors:Lauren!Giai-Minie!, UweThumm Regis!eredCourtMunichHRB139781 Account: HypoVereinsbankMünchen No.2440610

MANUFACTURER'S STATEMENT/ATTESTATION Applicant: EnOcean GmbH Address: Kolpingring l8a, Oberhaching 82041 Germany Contact Name: Oliver Sczesny Title: Application Engineering Manager Brand Name: EnOcean Model Number: TCM 320U FCC ID: SZV-TCM320U IC ID: 5713A-TCM320U Nemko- CCL Test Reporl s: 2249 49 - I ; 2249 49 -2'l ; 2249 49 -3 .l The manufacturer or responsible parly for the equipment tested hereby affirms: a) That he/she has reviewed and concurs that the tests shown in this report are reflective of the operational characteristics of the device for which certification is sought; b) That the device in this test report will be representative of production units; c) That the product will have all of the documented modifications incorporated ir-rto the product when manufactured and placed on the market; d) That all changes in hardware and software/firmware to the subject device will be reviewed. e) That any changes impacting the attributes, functionality or operational clraracteristics documented in this report will be communicated to the body responsible for approving or cerlifying the subject equipment. Oliver Sczesny 0rl t I I zct! Authorized Representative (please print) Date Signature ATT-001 Issue l March 2012

Front View of the EUT Back View of the EUT

Model: TCM 320U K320-2 CA 03/13 161103008367 12 mm IC: 5713A- TCM320U FCC ID: SZV-TCM320U 16mm

Label Location

Front View of the EUT Back View of the EUT Circuitry Under RF Shield

Nemko-CCL, Inc. 1940 West Alexander Street Salt Lake City, UT 84119 801-972-6146 Test Report Certification Test Of: TCM 320U FCC ID: SZV-TCM320U Test Specifications: FCC Part 15, Subpart C Test Report Serial No: 224949-2.3 Applicant: EnOcean GmbH Kolpingring 18a Oberhaching 82041 Germany Dates of Test: November 19 and 26, 2012 Issue Date: January 3, 2013 Accredited Testing Laboratory By: NVLAP Lab Code 100272-0 Nemko-CCL, Inc. TEST REPORT: 224949-2.3 ISSUE DATE: 1/3/2013 Page 2 of 33 CERTIFICATION OF ENGINEERING REPORT This report has been prepared by Nemko-CCL, Inc. to document compliance of the device described below with the certification requirements of FCC Part 15, Subpart C. This report may be reproduced in full. Partial reproduction of this report may only be made with the written consent of the laboratory. The results in this report apply only to the sample tested. - Applicant: EnOcean GmbH - Manufacturer: EnOcean GmbH - Brand Name: EnOcean - Model Number: TCM 320U - FCC ID: SZV-TCM320U On this 3 rd day of January 2013, I, individually, and for Nemko-CCL, Inc., certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge, and are made in good faith. Although NVLAP has accredited the Nemko-CCL, Inc. EMC testing facilities, this report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Nemko-CCL, Inc. Tested by: Norman P. Hansen EMC Technician Reviewed by: Thomas C. Jackson General Manager Nemko-CCL, Inc. TEST REPORT: 224949-2.3 ISSUE DATE: 1/3/2013 Page 3 of 33 TABLE OF CONTENTS PAGE SECTION 1.0 CLIENT INFORMATION .................................................................................4 SECTION 2.0 EQUIPMENT UNDER TEST (EUT) ..................................................................5 SECTION 3.0 TEST SPECIFICATION, METHODS & PROCEDURES .............................7 SECTION 4.0 OPERATION OF EUT DURING TESTING ..................................................11 SECTION 5.0 SUMMARY OF TEST RESULTS ...................................................................12 SECTION 6.0 MEASUREMENTS, EXAMINATIONS AND DERIVED RESULTS ..........13 APPENDIX 1 TEST PROCEDURES AND TEST EQUIPMENT ..........................................21 APPENDIX 2 PHOTOGRAPHS ................................................................................................26 Nemko-CCL, Inc. TEST REPORT: 224949-2.3 ISSUE DATE: 1/3/2013 Page 4 of 33 SECTION 1.0 CLIENT INFORMATION 1.1 Applicant: Company Name: EnOcean GmbH Kolpingring 18a Oberhaching 82041 Germany Contact Name: Armin Anders Title: Director Product Marketing 1.2 Manufacturer: Company Name: EnOcean GmbH Kolpingring 18a Oberhaching 82041 Germany Contact Name: Armin Anders Title: Director Product Marketing Nemko-CCL, Inc. TEST REPORT: 224949-2.3 ISSUE DATE: 1/3/2013 Page 5 of 33 SECTION 2.0 EQUIPMENT UNDER TEST (EUT) 2.1 Identification of EUT: Brand Name: EnOcean GmbH Model Number: TCM 320U Serial Number: None 2.2 Description of EUT: The TCM 320U is a module with a 902.9 MHz transceiver. The module is designed for incorporation into other devices used in alarm and control applications operating at 902.9 MHz. 3.3 VDC is provided to the TCM 320U by the host system. The TCM 320U uses a wire whip antenna. This report covers the transmitter circuitry of the device subject to FCC Part 15, Subpart C. The circuitry of the device, subject to FCC Part 15, Subpart B, was tested, found compliant, and is covered in Nemko-CCL, Inc. report #224949-1. 2.3 EUT and Support Equipment: Brand Name Model Number FCC ID or Compliance Description Name of Interface Ports / Interface Cables BN: EnOcean MN: TCM 320U SN: None SZV-TCM320U Transmitter Module See Section 2.4 2.4 Interface Ports on EUT: Name of Ports No. of Ports Fitted to EUT Cable Descriptions/Length Module to System Interface (normally soldered directly to host PCB assembly) 1 Power conductors/ extended to 16.5 cm for testing Nemko-CCL, Inc. TEST REPORT: 224949-2.3 ISSUE DATE: 1/3/2013 Page 6 of 33 2.5 Modification Incorporated/Special Accessories on EUT: The following modifications were made to the EUT by the Client during testing to comply with the specification. This report is not complete without an accompanying signed attestation, that the product will have all of the documented modifications incorporated into the product when manufactured and placed on the market. 1. The maximum power setting in firmware was changed to 0 dB. Nemko-CCL, Inc. TEST REPORT: 224949-2.3 ISSUE DATE: 1/3/2013 Page 7 of 33 SECTION 3.0 TEST SPECIFICATION, METHODS & PROCEDURES 3.1 Test Specification: Title: FCC PART 15, Subpart C (47 CFR 15) Section 15.203 Section 15.231 Periodic operation in the band 40.66-40.70 MHz and above 70 MHz. Purpose of Test: The tests were performed to demonstrate initial compliance. 3.2 Methods & Procedures: 3.2.1 §15.203 An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this Section. The manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited. This requirement does not apply to carrier current devices or to devices operated under the provisions of Sections 15.211, 15.213, 15.217, 15.219, or 15.221. Further, this requirement does not apply to intentional radiators that must be professionally installed, such as perimeter protection systems and some field disturbance sensors, or to other intentional radiators which, in accordance with Section 15.31(d), must be measured at the installation site. However, the installer shall be responsible for ensuring that the proper antenna is e…

Text truncated - open the document above for the full version.

Radiated Disturbance – Flat or Horizontal Configuration View Radiated Disturbance – Vertical Configuration View Radiated Disturbance – On Edge Configuration Front View Conducted Disturbance Worst Case Configuration Back View Conducted Disturbance Worst Case Configuration
