T37PL9667-B3PlugLink HD AV Pass-Through Adapter

PlugLink HD AV Pass-Through Adapter User’s Guide PL9667-B3 QUICKFIND LOCATOR Contact Information Getting Help Table of Contents Installation 66‐0348‐05Rev.001 2 of 40 PlugLink HD AVPass-Through Adapter © 2010 Asoka USA Corporation ALL RIGHTS RESERVED Notice: No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or stored in a database or retrieval system for any purpose without the express written permission of Asoka USA Corporation. Asoka USA Corporation reserves the right to make changes to this user’s guide at any time without notice and assumes no responsibility for its use. Asoka USA products and services can only be ordered under the terms and conditions of Asoka USA Corporation's applicable agreements. All of the features described in this user’s guide may not be currently available. Refer to the most recent product announcement for information about feature and product availability. This user’s guide contains the most current information available at the time of publication. When new and/ or revised information becomes available, this entire user’s guide is updated and distributed to all registered users. All company and product names mentioned herein are trademarks of their respective companies. Mention of third-party products is for informational purposes only and constitutes neither an endorsement nor a recommendation. Asoka USA Corporation assumes no responsibility with regard to the performance or use of these products. Revision Date Description 66-0348-05Rev.001 Oct. 2010 Preliminary Release Changes in This Revision • Not applicable (preliminary release) 3 of 40 PlugLink HD AVPass-Through Adapter Contact Information For more information about the PlugLink HD AV Pass-Through Adapter or any of Asoka’s other leading-edge solutions, please contact us using any of the following methods: z Voice calls: We welcome your calls Monday through Friday, from 9:00 am to 5:00 pm Pacific Time at (408) 550-8167. Voice mail is available during non- business hours. z Email: If you prefer, you can send information requests to our e-mail address: [email protected]. z Fax calls: You can also send your requests for information to our 24-hour fax number: (408) 884-2390. z Web site: Our Web site contains valuable information about our products, solutions, and services. We encourage you to visit us at http://www.asokausa.com. Getting Help Asoka USA backs its products with unparalleled customer service and technical support for our valued customers. Customer Service Customer service, the customer-satisfaction arm of Asoka USA, is available Monday through Friday, from 9:00 am to 5:00 pm Pacific Time, by calling (408) 550-8167 or emailing [email protected]. Technical Support Technical support is available Monday through Friday, from 6:00 am to 6:00 pm Pacific Time, by calling (408) 550-8173 or through email at [email protected]. Please provide the following information about the problem: z Product name, model number, part number (if applicable) and serial number z System configuration, including a description of the devices connected to your PL9667 z The circumstances surrounding the error or failure z A detailed description of the problem and what has been done to try to solve it 4 of 40 PlugLink HD AVPass-Through Adapter Table of Contents 1 Simple Installation ............................................................................. 5 Package Contents ....................................................................................................... 5 Types of Connections ................................................................................................. 5 Simple Connection (Peer to Peer) ................................................................................. 6 Simple Broadband Connection ..................................................................................... 6 Other Connections ...................................................................................................... 7 Finding a Suitable Location ......................................................................................... 7 Installing the Hardware .............................................................................................. 7 2 Advanced Configuration(Expert Users Only) ......................................... 8 Installing the Software ................................................................................................ 8 3 Network Management .......................................................................13 Viewing the Device Information (Profile) .................................................................... 13 Changing your device Name and Network Encryption Key (NEK) .................................. 14 DEVICE NETWORK ENCRYPTION KEY (NEK) .............................................................. 17 Resetting and Upgrading the PlugLink HD AV Pass-Through Adapter ............................ 21 Prioritizing the Network Traffic .................................................................................. 22 Viewing the Network Statistics screen ........................................................................ 23 Viewing the Link screen ............................................................................................ 23 Viewing the LED screen ............................................................................................ 25 Rescanning your Powerline Network .......................................................................... 25 Manually Resetting the Firmware and Network ID (NID) ............................................. 26 4 Troubleshooting ................................................................................27 A Specifications ...................................................................................29 B Components ..............................................…

Text truncated - open the document above for the full version.

External Photos

Internal Photos

FCC TEST REPORT 47 CFR FCC Part 15 Subpart B FCC ID..............................................: Report Reference No......................: T37PL9667-B3 WE10110011 Compiled by ( position+printed name+signature)..: File administrators Wenliang Li Supervised by ( position+printed name+signature)..: Test Engineer Eric Zhang Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: Dec 02, 2010 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: ASOKA USA Corporation Address ............................................: 2344-A Walsh Avenue, Santa Clara City, CA 95051 Test specification: Standard ...........................................: 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2009 TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: PlugLink HD AV Pass-Through Adapter Trade Mark .......................................: / Model/Type reference.......................: PL9667-B3 Listed Models ..................................: / Result................................................: Positive V1.0 Page 2 of 29 Report No.: WE10110011 FCC ID: T37PL9667-B3 Shenzhen Huatongwei International Inspection Co., Ltd T E S T R E P O R T Test Report No. : WE10110011 Dec 02,2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : PlugLink HD AV Pass-Through Adapter Model /Type : PL9667-B3 Listed Models : / Applicant : ASOKA USA Corporation Address : 2344-A Walsh Avenue, Santa Clara City, CA 95051 Manufacturer : Asoka USA Corporation Address : 2344-A Walsh Avenue Santa Clara City, CA 95051 Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 29 Report No.: WE10110011 FCC ID: T37PL9667-B3 Shenzhen Huatongwei International Inspection Co., Ltd Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. Related Submittal(s) / Grant (s) 5 2.6. Modifications 5 2.7. Configuration of Tested System 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Statement of the measurement uncertainty 8 3.5. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 14 5. TEST SETUP PHOTOS OF THE EUT .......................................... 20 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 22 V1.0 Page 4 of 29 Report No.: WE10110011 FCC ID: T37PL9667-B3 Shenzhen Huatongwei International Inspection Co., Ltd 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2009 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz V1.0 Page 5 of 29 Report No.: WE10110011 FCC ID: T37PL9667-B3 Shenzhen Huatongwei International Inspection Co., Ltd 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Nov 23, 2010 Testing commenced on : Nov 23, 2010 Testing concluded on : Dec 26, 2010 2.2. Equipment Under Test Power supply system utilised Power supply voltage : z 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ○ Other (specified in blank below) / 2.3. Short description of the Equipment under Test (EUT) The EUT PlugLink HD AV Pass-Through Adapter is an In-House BPL device. For more details, refer to the user’s manual of the EUT. Sample Type: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. 2.5. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: T37PL9667-B3 filing to comply with the FCC Part 15, Subpart B Rules. 2.6. Modifications No modifications were implemented to meet testing criteria. V1.0 Page 6 of 29 Report No.: WE10110011 FCC ID: T37PL9667-B3 Shenzhen Huatongwei International Inspection Co., Ltd 2.7. Configuration of Tested System Configuration of Tested System Equipment Used in Tested System No. Equipment Manufacturer Model No. Serial No. Notes 1 PC HP Compaq dx2310MT CNG8390Q6X (1) 2 Moniter DELL 1707FPt CN-OFC237-71618-65G-AAKC (1) 3 Notebook PC DELL PP01L 2F485A00 (1) 4 Printer HP Laserjet 6L C3990A JPZP024664 (1) 5 Keyboard DELL L100 CNRH65665890726009L (1) 6 Mouse DELL MO56UOA G0E02SY7 (1) 7 PlugLink AV 9560 Wireless Adapter ASOKA PL9560-WAP / (2) 8 Coupler ASOKA / / (2) Note: (1) - supplied by test lab. (2) - supplied by manufacturer. EUT PC Moniter Printer Keyboard mouse 120V/60Hz AC Main Coupler Coupler PLC A…

Text truncated - open the document above for the full version.

Test Setup Photos of the EUT
