Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
1 Introduction 1.1 Phone Display We continuously strive to improve our products. Therefore, we reserve the right to revise this user manual or withdraw it at any time without prior notice. 2 1.2 Key Key Function Dial/ Answer Key Make or answer a call. View call logs in standby mode. End/Power Key Press and hold to turn the phone on/off. End a call or reject an incoming call. Return to the idle mode. Right Soft Key In idle mode, press to access Call history. Return to the previous menu. Left Soft Key Access the Main menu in idle mode. When keypad is locked, press Left Soft key and * key to unlock the keypad OK Enter the Main menu in idle mode. Confirm a selection. Numeric Key Enter numbers, letters or characters. Select a submenu item labeled with the corresponding number. * Press twice quickly to enter ‘+’ to make an international call. Press and hold to enter the pause character (P) or the wait character (W) 3 when entering number. Press to enter a symbol when editing text. # Press and hold to activate or deactivate the silent mode in idle mode. Press to switch input modes when entering text. Navigation Key Within a menu, press Up, Down, Left or Right to scroll through menu options. Note: “Press” in this manual, means press the key and release; “press and hold” means to press and hold the key for at least two seconds. 1.3 Icons & Symbols Icon Description Network - The left portion indicates whether your phone is already registered with a network and the right portion indicates signal strength (from no signal to strongest signal). Battery - Indicates battery level with 3 battery level indicator bars. When charging, a scrolling icon will be displayed. The more bars, the stronger the charge. 4 SMS - Indicates you have a new SMS. Alert type is “Silent”. Alert type is “Ring”. Missed call - Indicates there is a missed call. Call Divert - Indicates that the call divert unconditional function is activated. Lock - Indicates that the keypad is locked. Headset is in use Alarm - Indicates that the alarm clock is on. 2 Getting Started 2.1 Inserting the SIM Card 2.1.1 Remove the back cover and battery 2.1.2 Insert the SIM card 5 2.1.3 Install the battery and back cover 2.2 Turning on the Phone To turn the phone on, press and hold the End/Power Key. 2.3 Charging the Battery Make sure the battery is inserted. To charge the battery, plug in the charger connector at the bottom of your phone (Charger port) and then plug the other end into an AC power socket. The battery symbol indicates the charging status. During charging, the charge indicators will scroll. When all the scroll bars are steady, the battery is fully charged. 6 3Text Entry 3.1 Input Method During text editing, you can press the # Key to switch input modes or press the Left Soft Key [Options] and select Input method to select different input modes. In any input mode, press the * Key to open the symbols input screen. 3.1.1 Predictive Text entry “2~9” Press to input letters. 1 Press to input symbols. 0 Press to enter a space. Navigation Key ▲/▼/◀/▶ Press to browse the last or next available word. Left Soft Key [Select] Press to confirm the letter or word. Right Soft Key [Clear] Press to clear a letter, press and hold to clear all entries. # Press to switch the input modes. * Press to activate punctuation mode. Example: How to enter the word " ERROR " 1. Press the # Key to switch to ABC. 2. Press 3 7 7 6 7, “ERROR” appears.. 7 3. Press the OK Key to confirm “ERROR”. 3.2 Multi-tap Input Using this mode requires you to press a key as many times as the order of the letters listed on the key. For example, to enter the word “casa” in basic text input mode “es”, press key 2 (ABC) three times, press 2 (ABC) once, press key 7 (PQRS) four times, press key 2 (ABC) once. 3.3 Numeric Input Press the # Key to select “123” then enter the numbers using the keypad. 4 Calling 4.1 Making a Call In idle mode, enter the phone number. Press the Dial Key to dial the number. Press the End/Power Key to end the call. Note: During a call, press the Navigation Key Up/Down to adjust the volume. 4.1.1 Making an International Call 1. Press * twice quickly to enter "+" appears on the screen. 2. Enter the country code. 3. Enter the area code followed by the phone number. 4. Press the Dial Key to call directly. 8 4.2 Answering a Call Press the Answer Key to answer it. Press the End/Power key to reject it. 5 Function Menu 5.1 Main Menu STK Fun&Games Messages Call Center Multimedia Phonebook Organizer Extra Settings 5.2 STK Note: The submenus of this feature depend on the operator and different operators may provide different services (some SIM cards do not support STK). 5.3 Messages 5.3.1 Create Message 1. Select Menu > Messages>Write message. 9 2. In content, you are able to add text message into your message. 3. After finished, press the Left Soft Key [Options] and select send to to go to the following options:enter number,Add from Phonebook. 5.4 Fun&Games You can enjoy the built-in games here. You can also adjust the game settings when you enter the game menu. 5.5 Call Center 5.5.1 View Call Center 1. Select Menu > Call Center. 2. Press the Navigation Key to view different call logs. 3. Choose a particular number and press the Dail/Answer Key to call the number directly. 4. Select Delete to delete call logs if you want. 5.6 Multimedia 5.6.1 FM Radio 10 Note: The radio will not work unless the headset is attached. Attach the headset to the USB port located at the bottom of the phone. To operate the radio: 1. Select Menu > Multimedia > FM radio. 2. Press the Navigation Key Down to activate or deactivate the FM radio. 3. Press the * / # Key to adjust the volume. 4. Press the Navigation Key Up to activate or deactivate Auto search. 5. Press the Navigation Key Right/Left to switch the channels. If auto search is activated, pressing the Navigation Key Right/Left will switch the available searched channels; if auto search is deactivated, pressing the Navigation Key Right/Left will …
Text truncated - open the document above for the full version.
SAMPLE CONFIDENTIALITY FORM {print on your company letterhead} Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. { Cellon Communications Technology(Shenzhen)Co., Ltd. } would like the following documents regarding this submission for FCC ID: { T38C1021ECL } to be kept confidential. 1. Schematics 2. Block diagram 3. Operational Description 4. Tune Up Procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Name:{ Maggie Xu } Title:{ TA Manager } Date:{ 2013-07-08 }
Annex external Photographs
Page : 1 of 2 Version:1.0 Annex Label exhibit Page : 2 of 2 Version:1.0
Company Name :Cellon Communications Technology(Shenzhen)Co., Ltd. Company Adress :11f,Skyworth C Buuilding,Gaoxin S.Ave.1.,Hi-Tech Industrial Park,Nanshan.Shenzhen Tel: 0755-86365704 ; Fax: 0755-86365704 Date: Jul 08, 2013 Statement We, Cellon Communications Technology(Shenzhen)Co., Ltd , states that our device, FCC ID: T38C1021ECL , has no space to put the label except the battery compartment of this device. The label will put under the battery inside the battery compartment and it is visible to the users as they purchase the products and install the battery. Sincerely yours, Maggie Xu / CTA Manager Company Name: Cellon Communications Technology(Shenzhen)Co., Ltd.
Annex internal Photographs
ItemNumber Item Description Qty Reference Designator Mfr Name Mfr Part Number EX3001281 CON SIM CAF99-06153-1524CZX 1 CON602 LCN CAF99-06153-1524CZX EX5000661 CON BAT PAN25-03543-1501 1 BAT1 LCN PAN25-03543-1501 EX9002241 CON OTH 10PIN MINI UAF04-10374-1507 1 CON603 LCN UAF04-10374-1507 HC124105K CAP X5R 0402 1U0 6V3 +/-10% 20 C126 , C129 , C201 , C304 , C307 , C308 ,C309 , C311 , C313 , C316 , C318 , C319 ,C321 , C323 , C324 , C606 , C695 , C696 ,C697 , C913 TDK C1005X5R0J105K HC125104K CAP X5R 0402 100N 10V +/-10% 8 C125 , C317 , C326 , C715 , C787 , C788 ,C789 , C103 TDK C1005X5R1A104K HC134225M CAP X5R 0603 2U2 6V3 +/-20% 7 C127 , C312 , C314 , C315 , C320 , C322 , C325 TDK C1608X5R0J225M HC134226M CAP X5R 0603 22u 6.3 V ±20% 1 C302 SAMSUNG CL10A226MQ8NRNE HC134475K CAP X5R 0603 4U7 6V3 +/-10% 4 C501 , C783 , C784 , C630 TDK C1608X5R0J475K HC136105K CAP X5R 0603 1U0 16V +/-10% 1 C306 TDK C1608X5R1C105K HC144106M CAP X5R 0805 10U 6V3 +/-20% 2 C785 , C792 TDK C2012X5R0J106M HC144226M CAP X5R 0805 22U 6V3 +/-20% 1 C310 TDK C2012X5R0J226MT HC228221K CAP X7R 0402 220P 50V +/-10% 2 C121 , C327 TDK C1005X7R1H221K HC428101J CAP NP0 0402 100P 50V +/-5% 5 C28 , C704 , C705 , C791 , C798 ROHM MCH155A101J HC428109C CAP NP0 0402 1P0 50V +/-0,25pF 1 C143 TDK C1005C0G1H010C HC428189C CAP NP0 0402 1P8 50V +/-0.25pF 1 C140 YAGEO/PHYCOMP CC0402CRNPO9BN1R8 HC428220J CAP NP0 0402 22P 50V +/- 5% 6 C104 , C106 , C112 , C116 , C176 , C177 TDK C1005C0G1H220J HC428330J CAP NP0 0402 33P 50V +/-5% 11 C701 , C702 , C703 , C706 , C781 , C782 ,C786 , C790 , C793 , C797 , C799 ROHM MCH155A330J HC428470J CAP NP0 0402 47P 50V +/-5% 2 C105 , C301 ROHM MCH155A470J HC428609D CAP NP0 0402 6P0 50V +/-0,5pF 1 C119 TDK C1005C0G1H060D HC644226M CAP TAN,0805,22u,6.3V,+/-20% 1 C102 NICHICON F920J226MPA HD1000561 TRA Ch arg i ng T rans i s t or PNP TSOP - 6 PT236T30E2 1 Q300 Prisemi PT236T30E2 HD2000751 TRA MOS N-channel SOT-723 PNM723T703E0-2 1 Q301 Prisemi PNM723T703E0-2 HD3000221 ICD NPN , 100 m A/50V , b u ilt - i n resistor LDTC113ZWT1G 1 Q340 LRC LDTC113ZWT1G HG1001191 OSC XTL 26MHz 7.5pF SQ3D02600A2JBA 1 X101 SAMSUNG SQ3D02600A2JBA HH1100541 DIO LED White LTW-270TLA 2 CON341 , CON342 LITEON LTW-270TLA HH1600121 DIO LED BLUE LTST-C193SBKT-5A 4 LED902 , LED903 , LED904 , LED905 LITEON LTST-C193SBKT-5A HL120183J IND CER 0402 18N +/-5% 2 L103 , L105 TDK MLK1005S18NJ HL120272S IND CER 0402 2N7 +/-0,3nH 1 L108 TDK MLK1005S2N7S HL120273J IND CER 0402 27N +/-5% 1 L106 TDK MLK1005S27NJ HL120562S IND CER 0402 5N6 +/-0,3nH 2 L104 , L109 TDK MLG1005S5N6S HL120622S IND CER 0402 6N2 +/-0,3nH 2 L107 , L110 MURATA LQG15HN6N2S02 HL330221A IND FER 0603 220R +/-25% 2 B701 , B702 MURATA BLM18EG221SN1D HL9000171 IND FER 0805 1000ohm@100MHz Rated current1500mA max +/-25% 1 B601 Microgate MGLB2012M102T1R5-LF HL920102A IND FER 0402 1000R +/-25% 3 B602 , B603 , B604 MURATA BLM15AG102SN1 HR120000A RES 0402 0R0 18 R101 , R102 , R104 , R132 , R133 , R301 ,R302 , R320 , R321 , R602 , R604 , R510 ,R512 , B703 , B704 , L705 , L798 , LCR103 YAGEO/PHYCOMP RC0402JR-130R HR120101J RES 0402 100R +/-5% 1 R901 ROHM MCR01MZPJ101 HR120102J RES 0402 1K0 +/-5% 20 R129 , R130 , R131 , R211 , R212 , R213 , R214 , R215 , R216 , R217 , R218 , R219 ,R220 , R304 , R309 , R710 , R792 , R795 , R798 R799 ROHM MCR01MZPJ102 HR120103J RES 0402 10K +/-5% 2 R190 , R343 ROHM MCR01MZPJ103 HR120104J RES 0402 100K +/-5% 1 R305 ROHM MCR01MZPJ104 HR120120J RES 0402 12R +/-5% 2 R702 , R703 ROHM MCR01MZPJ120 HR120152J RES 0402 1K5 +/-5% 4 R311 , R791 , R793 , R797 ROHM MCR01MZPJ152 HR120153J RES 0402 15K +/-5% 1 R106 ROHM MCR01MZPJ153 HR120221J RES 0402 220R +/-5% 4 R630 , R631 , R706 , R796 ROHM MCR01MZPJ221 HR120222J RES 0402 2K2 +/-5% 1 R303 ROHM MCR01MZPJ222 HR120304F RES 0402 300K +/-1% 1 R507 YAGEO/PHYCOMP RC0402FR-07300KL HR120330J RES 0402 33R +/-5% 1 R701 ROHM MCR01MZPJ330 HR120334J RES 0402 330K +/-5% 1 R310 ROHM MCR01MZPJ334 HR120363J RES 0402 36K +/-5% 1 R189 ROHM MCR01MZPJ363 HR120390J RES 0402 39R +/-5% 1 R340 YAGEO/PHYCOMP RC0402JR-0739RL HR120393J RES 0402 39K +/-5%(1/16W,50V) 1 R315 ROHM MCR01MZPJ393 HR120473 J RES 0402 47K + / -5% 2 R201 , R203 ROHM MCR01MZP J 473 HR120752J RES 0402 7K5+/-5% 1 R316 YAGEO/PHYCOMP RC0402JR-077K5L HR220180N2 VDR 0402 18V 15pF +/-30% 4 RV701 , RV702 , RV705 , RV706 Yageo VRS0402SR180150N HR320473J NTC 0402 47K +/-5% 1 TR301 TDK NTCG104BF473JT1X HR4000131 RES OTH(high power) 0805 0R2 1/4W +/-1% 1 R306 YAGEO/PHYCOMP RL0805FR-7W0R2L HV3000561 DIO ZEN SOD-323 PZ3D4V2H 1 ZD300 Prisemi PZ3D4V2H HW1002151 ICS BB GSM/GPRS/EDGE-RX 233-TFBGA9.8x9.6x1.1mm MT6250MA/BMB-PCU-H 1 U200 MTK MT6250MA/BMB-PCU-H HW2001351 ICS RF GSM/GPRS QUAD-BAND PA,WITH ANTENNASWITCH RPF88174B 1 U101 RENESAS RPF88174B HZ2002701 FIL SAW QUAL BAND LFB21914MDZ3D384 1 Z101 MURATA LFB21914MDZ3D384 MR3140481 C1021ECL ShieldingCover,32*26.5*1.7mm,T=0.2mm(Longke) 1 J403 龙科(Longke) LK-MR3140481 MR412861A C1021ECL Mainboard PCBlayer4,98X38.9X0.8mm,P1,至卓飞高 1 PCB TOPSEARCH(至卓飞高) SR19341 EA1000911 MIC Pin type,-42±3dB,D4mm,OB-F15PD42-92-C10C33EP 1 EA2002951 EAR/LSP speaker 13x18x3.5,wire type,WireLength 15+/-2 FR1318-008B-635RD(DAIWA) 1 EA4000841 VIB 4.4*4.8*11.4 spring Z4TH5B1242432 1 LL1101711 Water proof label, ajanta project 1 MM1154242 C1021ECL Antenna assy,black,GSM850/1900MHz(Topant) 1 MR3125321 C2050 Screw,T5 K15XL4.5X0.67PITCH(寸金) 4 MR3129581 T5 K15XL5.0X0.67PITCH White(cunjin) 2 MR6128191 C1021 Speaker electric cloth(鼎正兴) 1 MR6128431 C1021 LCD art gasket(鼎正兴) 1 MS3111421 C1021 Metal Dome(钜欣) 1 MS5125911 C1020+ LCM TFT 1.44 TXDT144TF-42(TXD) 1 MM1154201 C1021 Rear housing Assy,black,raw materialVDI21#(Xwoda) 1 MM1154231 C1021 Light cover assy,raw material(Xwoda) 1 MM1165312 C1021 Main Lens assy,Black,Ring Logo(Surun) 1 MM1168601 C1021ECL Front housing Assy,Black,rawmaterial,VDI 21#(Xwoda) 1 MM2110471 C1021ECL Keypad Assy,black,Rubber(Sinco) 1 MM1165321 C1021 Battery cover Assy,black,raw materialVDI24#,Ring Logo(Xwoda) 1 MS5128671 C1021 Ring logo Battery,BTR1031,400mAhCell,4…
Text truncated - open the document above for the full version.
SAR TEST REPORT For C1021ECL,1021EC Model Number: C1021EC, Ring 201, C1021ECL,C1021 FCC ID: T38C1021ECL Report Number : WT 138001643 Test Laboratory : Shenzhen Academy of Metrology and Quality Inspection National Digital Electronic Product Testing Center Site Location : No.4 TongFa Road, Xili Town, Nanshan District, Shenzhen, China Tel : 0086-755-86009898 Fax : 0086-755-86009898-31396 Web : www.smq.com.cn Report No.:WT138001643 Page 2 of 95 Test report declaration Applicant : Cellon Communications Technology(Shenzhen)Co., Ltd. Address : 13/F, Skyworth Building C Gaoxin S. Ave. 1st, High-Tech industrial Park NanShan, ShenZhen Manufacturer : Cellon Communications Technology(Shenzhen)Co., Ltd. Address : 13/F, Skyworth Building C Gaoxin S. Ave. 1st, High-Tech industrial Park NanShan, ShenZhen EUT Description : C1021ECL,1021EC Model No. : C1021EC, Ring 201, C1021ECL,C1021 Trade mark : Ring, enspire, Claro Serial Number : 861047003725123 861047003725131 FCC ID : T38C1021ECL Test Standards: IEEE 1528-2003 FCC OET Bulletin 65 The EUT described above is tested by Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory to determine the compliance of the applicable standards stated above. Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory is assumed full responsibility for the accuracy of the test results. The results documented in this report only apply to the tested sample, under the conditions and modes of operation as described herein. The test report shall not be reproduced in part without written approval of the laboratory. Project Engineer: Date: 2013.07.02 (Wu Feiyun) Checked by: Date: 2013.07.02 (Yang Dongping) Approved by: Date: 2013.07.02 (Lin Bin) Report No.:WT138001643 Page 3 of 95 TABLE OF CONTENTS TEST REPORT DECLARATION ......................................................................................................... 2 1. GENERAL INFORMATION ...................................................................................................... 5 1.1. Report information .......................................................................................................... 5 1.2. Laboratory Accreditation and Relationship to Customer ......................................... 5 2. DESCRIPTION OF THE DEVICE UNDER TEST(DUT) ............................................... 7 2.1. DUT Description ............................................................................................................. 7 2.2. RF output power Tune up limit ..................................................................................... 7 2.3. Applied Standards .......................................................................................................... 8 2.4. SAR Limit ......................................................................................................................... 8 3. TEST CONDITIONS .................................................................................................................. 9 3.1. Temperature and Humidity ........................................................................................... 9 3.2. Introduction of SAR ........................................................................................................ 9 3.3. Test Configuration .......................................................................................................... 9 4. DESCRIPTION OF THE TEST EQUIPMENTS ................................................................. 11 4.1. Measurement System and Components .................................................................. 11 4.2. Isotropic E-field Probe Type ES3DV3 ....................................................................... 12 4.3. Phantoms....................................................................................................................... 12 4.4. Tissue-equivalent Liquids ........................................................................................... 13 4.5. Device Holder ............................................................................................................... 15 4.6. Test Position ................................................................................................................. 16 4.7. Scan Procedures .......................................................................................................... 18 4.8. SAR Averaging Methods ............................................................................................. 18 5. MEASUREMENT UNCERTAINTY ....................................................................................... 19 5.1. Uncertainty for Sar Test .............................................................................................. 19 5.2. Uncertainty for System Validation ............................................................................. 20 6. CONDUCTED TEST RESULTS ........................................................................................... 21 7. EXPOSURE POSITIONS CONSIDERATION .................................................................... 22 8. SAR TEST RESULTS ............................................................................................................. 23 8.1. GSM 850 SAR results ................................................................................................. 23 8.2. GSM 1900 SAR results ............................................................................................... 23 Report No.:WT138001643 Page 4 of 95 8.3. Repeated SAR results ................................................................................................. 24 9. SIMULTANEOUS TRANSMISSION SAR ANALYSIS ...................................................... 25 APPENDIX A: SYSTEM CHECKING SCANS ............................................................................ 26 APPENDIX B: MEASUREMENT SCANS.................................................................................... 30 APPEN…
Text truncated - open the document above for the full version.
Report No.:WT138001643 Page 84 of 95 Report No.:WT138001643 Page 85 of 95 Report No.:WT138001643 Page 86 of 95 Report No.:WT138001643 Page 87 of 95 Report No.:WT138001643 Page 88 of 95 Report No.:WT138001643 Page 89 of 95 Report No.:WT138001643 Page 90 of 95 Report No.:WT138001643 Page 91 of 95 Report No.:WT138001643 Page 92 of 95 Report No.:WT138001643 Page 93 of 95 Report No.:WT138001643 Page 94 of 95 Report No.:WT138001643 Page 95 of 95
Report No.:WT138001 Page 1 of 45 Ver:EMC2009A FCC TEST REPORT For C1021ECL,1021EC Model Number: C1021EC, Ring 201, C1021ECL,C1021 FCC ID: T38C1021ECL Report Number : WT138001031 Test Laboratory : Shenzhen Academy of Metrology and Quality Inspection National Digital Electronic Product Testing Center Site Location : No.4 TongFa Road, Xili Town, Nanshan District, Shenzhen, China Tel : 0086-755-86009898 Fax : 0086-755-86009898-31396 Web : www.smq.com.cn Report No.:WT138001 Page 2 of 45 Ver:EMC2009A Test report declaration Applicant : Cellon Communications Technology(Shenzhen)Co., Ltd. Address : 13/F, Skyworth Building C Gaoxin S. Ave. 1st, High-Tech industrial Park NanShan, ShenZhen Manufacturer : Cellon Communications Technology(Shenzhen)Co., Ltd. Address : 13/F, Skyworth Building C Gaoxin S. Ave. 1st, High-Tech industrial Park NanShan, ShenZhen EUT Description : C1021ECL,1021EC Model No : C1021EC, Ring 201, C1021ECL,C1021 Trade mark : Ring, enspire, Claro Serial Number : 861047003725123 861047003725131 FCC ID : T38C1021ECL Test Standards: FCC PART 22H AND 24E (2012) The EUT described above is tested by Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory to determine the maximum emissions from the EUT. Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory is assumed full responsibility for the accuracy of the test results. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with FCC Rules Part 22H AND 24E. The test report is valid for above tested sample only and shall not be reproduced in part without written approval of the laboratory. Project Engineer: Date: July 2,2013 (Wu Feiyun) Checked by: Date: July 2,2013 (Yang Dongping) Approved by: Date: July 2,2013 (Lin Bin) Report No.:WT138001 Page 3 of 45 Ver:EMC2009A TABLE OF CONTENTS TEST REPORT DECLARATION........................................................................................................2 1. TEST RESULTS SUMMARY...................................................................................................4 2. GENERAL INFORMATION......................................................................................................5 2.1. Report information..........................................................................................................5 2.2. Laboratory Accreditation and Relationship to Customer.........................................5 2.3. Measurement Uncertainty.............................................................................................6 3. PRODUCT DESCRIPTION.......................................................................................................7 3.1. EUT Description..............................................................................................................7 3.2. Related Submittal(s) / Grant (s)...................................................................................7 3.3. Block Diagram of EUT Configuration..........................................................................8 3.4. Operating Condition of EUT..........................................................................................8 3.5. Support Equipment List.................................................................................................8 3.6. Test Conditions...............................................................................................................8 3.7. Special Accessories.......................................................................................................8 3.8. Equipment Modifications...............................................................................................8 4. TEST EQUIPMENT USED........................................................................................................9 5. TEST RESULTS.......................................................................................................................10 5.1. RF Power Output..........................................................................................................10 5.2. Modulation Characteristics..........................................................................................11 5.3. Occupied Bandwidth/Emission Bandwidth...............................................................12 5.4. Spurious Emission at Antenna Terminal..................................................................17 5.5. Spurious Emissions Radiated....................................................................................35 5.6. Frequency Stability.......................................................................................................45 Report No.:WT138001 Page 4 of 45 Ver:EMC2009A 1. TEST RESULTS SUMMARY Table 1 Test Results Summary FCC Measuremen t Specification FCC Limits Part(s) Description Result 2.1046 22.913 24.232 Effective Radiated Power of Transmitter PASS 2.1046 22.913 24.232(b) Conducted Power of Transmitter PASS 2.1047 / Modulation Characteristics PASS 2.1049 22.917(b) 24.238(b) Occupied Bandwidth PASS 2.1051 22.917 24.238 Spurious Emission at Antenna Terminal PASS 2.1053 22.917 24.238 Radiated Spurious Emissions PASS 2.1055 22.355 24.235 Frequency Stability PASS Remark: “N/A” means “Not applicable.” The tests documented in this report were performed in accordance with TIA-603-C, FCC CFR 47 Part 2, FCC CFR 47 Part 22 Part 24. Report No.:WT138001 Page 5 of 45 Ver:EMC2009A 2. GENERAL INFORMATION 2.1. Report information 2.1.1.This report is not a certificate of quality; it only applies to the sample of the specific product/equipment given at the time of its testing. The results are not used to indicate or imply that they are application to the similar items. In addition, such results must not be used to indicate or imply that SMQ approves recommends or…
Text truncated - open the document above for the full version.
Test Position Photos Left Cheek Position Left Tilted position Right Cheek Position Right Tilted position Faceup position Facedown position
Page 1 of 3 Version:1.0 APPENDIX C. SETUP PHOTOGRAPHS ERP and EIRP Test Setup Page 2 of 3 Version:1.0 FCC Par t 22H/24E Radiated Emission below 1GHz - Front -Rear Page 3 of 3 Version:1.0 FCC Part 22H/24E Radiated Emission above 1GHz -Front -Rear
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 2 | 24E | 1.85 GHz - 1.91 GHz | 260.00 mW | 248KG7W | 0.01 ppm |

GSM quad band mobile phone
Equipment Class
PCE - PCS Licensed Transmitter held to ear
GSM/GPRS/WCDMA/BT/WIFI/GPS Mobile Phone
Equipment Class
JBP - Part 15 Class B Computing Device Peripheral
WCDMA mobile phone
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
WCDMA mobile phone
Equipment Class
JBP - Part 15 Class B Computing Device Peripheral
GSM/GPRS + Bluetooth Mobile Phone
Equipment Class
PCE - PCS Licensed Transmitter held to ear
