The following standards were applied: (Omni) „ Radio: EN 300-328 v1.6.1 (2.4-GHz operation) „ EN 301-893 v1.2.3 (5-GHz operation) „ EMC: EN 301.489-1 v1.4.1, EN 301.489-17 v1.2.1 „ Safety: IEC 60950 ( 1999 3rd Edition with Amend. 1,2,3,4 ) & EN 60950 ( 2000 ) Note: This equipment is intended to be used in all EU and EFTA countries. Outdoor use may be restricted to certain frequencies and/or may require a license for operation. For more details, contact your customer service representative. To comply with RF exposure compliance requirements, a separation distance of at least 20 cm must be maintained between the antenna of this device and all persons. This device must not be co-located or operating in conjunction with any other antenna or transmitter. Member States shall ensure that the manufacturer or the person responsible for placing the apparatus on the market provides information for the user on the intended use of the apparatus, together with the declaration of conformity to the essential requirements. Where it concerns radio equipment, such information shall be sufficient to identify on the packaging and the instructions for use of the apparatus the Member States or the geographical area within a Member State where the equipment is intended to be used and shall alert the user by the marking on the apparatus referred to in Annex VII, paragraph 5, to potential restrictions or requirements for authorization of use of the radio equipment in certain Member States. Česky [Czech] HONDA tímto prohlašuje, že tento 70410-QAB je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Dansk [Danish] Undertegnede HONDA erklærer herved, at følgende udstyr 70410-QAB overholder de væsentlige krav og øvrige relevante krav I direktiv 1999/5/EF. Deutsch [German] Hiermit erklärt HONDA dass sich das Gerät 70410-QAB in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. Eesti [Estonian] Käesolevaga kinnitab HONDA seadme 70410-QAB vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. English Hereby, HONDA declares that this 70410-QAB is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Español [Spanish] Por medio de la presente HONDA declara que el 70410-QAB cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Ελληνική [Greek] ΜΕ ΤΗΝ ΠΑΡΟΥΣΑHONDA ∆ΗΛΩΝΕΙ ΟΤΙ70410-QAB ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ 1999/5/ΕΚ. Français [French] Par la présente HONDA déclare que l'appareil 70410-QAB est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Italiano [Italian] Con la presente HONDA dichiara che questo 70410-QAB è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Latviski [Latvian] Ar šo HONDA deklarē, ka 70410-QAB atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem. Lietuvių [Lithuanian] Šiuo HONDA deklaruoja, kad šis 70410-QAB atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. Nederlands [Dutch] Hierbij verklaart HONDA dat het toestel 70410-QAB in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. Malti [Maltese] Hawnhekk, HONDA , jiddikjara li dan 70410-QAB) jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC. Magyar [Hungarian] Alulírott, HONDA nyilatkozom, hogy a 70410-QAB megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. Polski [Polish] Niniejszym, HONDA , deklaruję, że 70410-QAB spełnia wymagania zasadnicze oraz stosowne postanowienia zawarte Dyrektywie 1999/5/EC. Português [Portuguese] HONDA declara que este 70410-QAB está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Slovensko [Slovenian] HONDA izjavlja, da je ta 70410-QAB v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES. Slovensky [Slovak] HONDA týmto vyhlasuje, že 70410-QAB spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES. Suomi [Finnish] HONDA vakuuttaa täten että 70410-QAB tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Svenska [Swedish] Härmed intygar HONDA att denna 70410-QAB står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. This device complies withP a rt 15 of the FCCR ules. Operation is subject to following two conditions:(1) this device may not cause harmful interference. and (2) this device must accept any inter ference received, including inte rference that may cause undesired operation.

Honda Motor Co.,Ltd. PROPOSED ID LABEL LOCATION

REPORT NO: 06J10176-2 DATE: JUNE 05, 2006 EUT: WIRELESS ACCESS POINT FCC ID: T4S-70410-QAB Page 20 of 71 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 7.1.3. MAXIMUM PERMISSIBLE EXPOSURE LIMITS §1.1310 The criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in §1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of §2.1093 of this chapter. REPORT NO: 06J10176-2 DATE: JUNE 05, 2006 EUT: WIRELESS ACCESS POINT FCC ID: T4S-70410-QAB Page 21 of 71 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. CALCULATIONS Given E = √ (30 * P * G) / d and S = E ^ 2 / 3770 where E = Field Strength in Volts/meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power Density in milliwatts/square centimeter Combining equations and rearranging the terms to express the distance as a function of the remaining variables yields: d = √ ((30 * P * G) / (3770 * S)) Changing to units of Power to mW and Distance to cm, using: P (mW) = P (W) / 1000 and d (cm) =100 * d (m) yields d = 100 * √ ((30 * (P / 1000) * G) / (3770 * S)) d = 0.282 * √ (P * G / S) where d = distance in cm P = Power in mW G = Numeric antenna gain S = Power Density in mW/cm^2 Substituting the logarithmic form of power and gain using: P (mW) = 10 ^ (P (dBm) / 10) and G (numeric) = 10 ^ (G (dBi) / 10) yields d = 0.282 * 10 ^ ((P + G) / 20) / √ S where d = MPE distance in cm P = Power in dBm G = Antenna Gain in dBi S = Power Density Limit in mW/cm^2 Rearranging terms to calculate the power density at a specific distance yields S = 0.0795 * 10 ^ ((P + G) / 10) / (d^2) REPORT NO: 06J10176-2 DATE: JUNE 05, 2006 EUT: WIRELESS ACCESS POINT FCC ID: T4S-70410-QAB Page 22 of 71 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. LIMITS From §1.1310 Table 1 (B), the maximum value of S = 1.0 mW/cm^2 RESULTS No non-compliance noted: (MPE distance equals 20 cm) NOTE: For mobile or fixed location transmitters, the minimum separation distance is 20 cm, even if calculations indicate that the MPE distance would be less. ModeMPEOutputAntennaPower DistancePowerGainDensity (cm)(dBm)(dBi)(mW/cm^2) 802.11a20.014.595.700.02

FCC CFR47 PART 15 SUBPART C CERTIFICATION TEST REPORT FOR WIRELESS ACCESS POINT MODEL NUMBER: 70410-QAB FCC ID: T4S-70410-QAB REPORT NUMBER: 06J10176-2B ISSUE DATE: JUNE 07, 2006 Prepared for HONDA R&D CO., LTD 8-1 HONCHO, WAKO-SHI SAITAMA-KEN, 351-0114 JAPAN Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 06J10176-2B DATE: JUNE 07, 2006 EUT: WIRELESS ACCESS POINT FCC ID: T4S-70410-QAB Page 2 of 71 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issue Date Revisions Revised By -- 6/05/06 Initial Issue Thu B 6/07/06 Revised Sections 5.1, 5.4, and 5.7 Thu REPORT NO: 06J10176-2B DATE: JUNE 07, 2006 EUT: WIRELESS ACCESS POINT FCC ID: T4S-70410-QAB Page 3 of 71 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS.....................................................................................4 2. TEST METHODOLOGY.........................................................................................................5 3. FACILITIES AND ACCREDITATION...................................................................................5 4. CALIBRATION AND UNCERTAINTY..................................................................................5 4.1. MEASURING INSTRUMENT CALIBRATION......................................................................5 4.2. MEASUREMENT UNCERTAINTY.......................................................................................5 5. EQUIPMENT UNDER TEST..................................................................................................6 5.1. DESCRIPTION OF EUT.....................................................................................................6 5.2. MODIFICATION................................................................................................................6 5.3. MAXIMUM OUTPUT POWER............................................................................................6 5.4. DESCRIPTION OF AVAILABLE ANTENNAS......................................................................6 5.5. SOFTWARE AND FIRMWARE............................................................................................7 5.6. WORST-CASE CONFIGURATION AND MODE..................................................................7 5.7. DESCRIPTION OF TEST SETUP........................................................................................8 6. TEST AND MEASUREMENT EQUIPMENT.......................................................................10 7. LIMITS AND RESULTS........................................................................................................11 7.1. CHANNEL TESTS FOR THE 5150 TO 5250 MHz BAND....................................................11 7.1.1. EMISSION BANDWIDTH.........................................................................................11 7.1.2. PEAK POWER..........................................................................................................15 7.1.3. MAXIMUM PERMISSIBLE EXPOSURE..................................................................20 7.1.4. AVERAGE POWER..................................................................................................23 7.1.5. PEAK POWER SPECTRAL DENSITY......................................................................24 7.1.6. PEAK EXCURSION..................................................................................................28 7.1.7. CONDUCTED SPURIOUS EMISSIONS....................................................................32 7.1.8. FREQUENCY STABILITY........................................................................................36 7.2. RADIATED EMISSIONS...................................................................................................38 7.2.1. TRANSMITTER RADIATED SPURIOUS EMISSIONS.............................................38 7.2.2. TRANSMITTER ABOVE 1 GHZ FOR 5150 TO 5250 MHz BANDWIDTH INTERNAL ANTENNA...............................................................................................................................41 7.2.3. TRANSMITTER ABOVE 1 GHZ FOR 5150 TO 5250 MHz BANDWIDTH EXTERNAL ANTENNA...............................................................................................................................50 7.2.4. WORST-CASE RADIATED EMISSIONS BELOW 1 GHz..........................................59 7.3. POWERLINE CONDUCTED EMISSIONS.........................................................................63 8. SETUP PHOTOS...................................................................................................................67 REPORT NO: 06J10176-2B DATE: JUNE 07, 2006 EUT: WIRELESS ACCESS POINT FCC ID: T4S-70410-QAB Page 4 of 71 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: HONDA R&D CO., LTD. 8-1 HONCHO, WAKO-SHI SAITAMA-KEN, 351-0114, JAPAN EUT DESCRIPTION: WIRELESS ACCESS POINT MODEL: 70410-QAB SERIAL NUMBER: CCS# 1690 & CCS# 1728 DATE TESTED: April 3 – May 23, 2006 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15 SUBPART C NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with…
