T8GCONMODTelematic control unit with wireless technologies, used in automotive industry.

VW AG CONMOD Models: TKCMOD12E00 TKCMOD11000 TKCMOD12T00 TKCMOD12R00  TKCMOD12N00- Installation: CONMOD is placed in the cars like in bellow picture Description: ConMod is a VW crosscar TCU solution to be used in different platforms within the Volkswagen Group. Included key technologies are 2G, 3G,LTE, 5G, WLAN, Bluetooth, GNSS receiver, depending on the model. Bellow you can find Menus available for CONMOD PPE:  Bluetooth WIFI: Create a Hotspot: Initiate a call: CERTIFICATION INFORMATION For EU : Models: TKCMOD12E00 TKCMOD11000 TKCMOD12T00 TKCMOD12R00 Hereby, Harman Becker Automotive Systems GmbH declares that the radio equipment type CONMOD is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity will be available on the Harmany official Address: http://www.harman.com/compliance The Transmitter Power at the NAD antenna terminal at Room Temperature:  GSM low bands (800/900): +32.5 ±1.5 dBm  GSM hi bands (1800/1900): +29.5 ±1.5 dBm  WCDMA bands: +23.5 +1.5/-2.5 dBm  LTE bands: +23.0 ±2 dBm*  5G NR bands: +23.0 ±2 dBm*  HPUE bands: +26.0 +2/-3 dBm** * For most bands. Some exceptions exist, per 3GPP standard ** Applies to LTE and 5G NR bands which are HPUE capable. Bluetooth Parameter:  Frequency: 2,402-2,480 GHz  Output power: < 10 dBm WLAN Parameter:  Frequency: 2,400 - 2,4835 GHz Country specific 5GHz Bands (5.1/5.7 GHz)  Output power: @ 2,4GHz : < 20 dBm @ 5.1/5,7GHz : < 20 dBm * (country specific) Supported Bands Homologation name 5G NR Bands LTE Bands (FDD + TDD) UMTS Bands GSM GNSS Region - EU FE5EU0020 n1, n3, n5, n7, n8, n28, n77, n78 1, 3, 5, 7, 8, 20, 28A, 28B, 32Rx, 38, 40 1, 3, 5, 8 3, 8 L1 The system supports the following frequency bands for GNSS:  GALILEO (L1 carrier frequency = 1.575,42 MHz)  GPS (L1 carrier frequency = 1.575,42 MHz)  GLONASS (L1 carrier frequency = 1602 MHz)  BEIDOU (L1 carrier frequency = 1560 MHz) FCC / ISED statement : Model: TKCMOD12N00 FCC ID: T8GCONMOD IC: 6434A-CONMOD This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le present appareil est confore aux CNR d`industie Caqnada applicables aux appareil radio exempts de cicence. L`exploitation est autorisée aux deux conditions suivantes : (1)l`appareil ne doit pas produire de brouillage, te (2)l`utilisateur de l`appareil doit accepter tout brouillage radio électrique subi, même si le brouillage est susceptible d`en compromettre le fonctionnement. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. To comply with FCC and ISED RF exposure compliance requirements, the differente antennas must be professionaled installed at the minimum distance used for the RF evaluations according to FCC and ISED rules Supported bands Homologation name 5G NR Bands LTE Bands (FDD + TDD) UMTS Bands GSM GNSS Region - NA FE5NA0020 n2, n5, n7, n41, n66, n71, n77, n78 1, 2, 3, 4, 5, 7, 12, 13, 14, 17, 25, 26, 29Rx, 30Rx, 41, 66, 71 1, 2, 3, 4, 5, 6 2, 3, 5, 8 L1 FCC/ISED Regulatory notices Modification statement Harman Becker Automotive Systems GmbH has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. Harman Becker Automotive Systems GmbH n’approuve aucune modification apportée à l’appareil par l’utilisateur, quelle qu’en soit la nature. Tout changement ou modification peuvent annuler le droit d’utilisation de l’appareil par l’utilisateur. Wireless notice This device complies with FCC/ISED radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS‐102 of the ISED radio frequency (RF) Exposure rules. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Le présent appareil est conforme à l'exposition aux radiations FCC / ISED définies pour un environnement non contrôlé et répond aux directives d'exposition de la fréquence de la FCC radiofréquence (RF) et RSS‐102 de la fréquence radio (RF) ISED règles d'exposition. L'émetteur ne doit pas être colocalisé ni fonctionner conjointement avec à autre antenne ou autre émetteur. FCC Class B digital device notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. CAN ICES-3 (B) / NMB-3 (B) This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de classe B est conforme à la norme canadienne ICES-003. Manufacturer: Harman Becker Automotive Systems GmbH Becker-Goering-Strasse 16 76307 Karlsbad, Germany

Hinman Secker vw AG ., . Alllomotlve 5Y's1ems OmtlH w-«eu>Jn i ,·,;J;4 85A 035 282 eeckor-0111ng-s11ae, 1 6 "·''" �'""'""' A Y135 78307 l<ilrlsbaa, oe,manv B5A 035 282: A H12 C2 3 MUST ""' "'"""" ''" �i 1)CONMOD · - ""' """'"""" �-;.; - Modd: TXCM00X® H8-SH; V037G9MmgQIJGG2 � A ECAL L Vt11lon· xx _Onllne Made In Hungary/ Yrop� • A .A � H8 V037 EC. 942 4043,US 23 , 11.l021 JTH JTH-07623.1121609!i0ME 11 �2't 00 x:xxx ® 144A-XXXX'KX C E: XX-Yn'YY (In ll) u , 11,� 1nttr;111' n<o:m w •uu,'l-: ll\>'I< �,o.o K U"CA Cle!l'lery addren & ,..,, ,'C,,)tl,')'),e. N1t;t'�i :'> ... J.'(.� 11� 'l'°)n:'I') 1,011 X)(XXXXX:XXXXX .___ _"VUf·,;o ·,, .. � .,,�;\ I(.';., C A xxxxxxxxxxx x � CCARXXGXVXXXXX II\ A � � � -..... ,��, PPr I� I c(J\ ;S J\ lA-XXXX/YVY � (!]� •• • H·\fll!f\O\'JO· � 4041136 ., ECALL le 1 / 00 ,r-,o,· ,r c? .11 MUST ,,,. .. _,,., ,�rMOP•X" v .... ,.... ' ,-, ,, .. ,, .... Hit trl'I� IC """' .. ,. . ., r,.1,ulP IM H°<lt>O"'V I .n,.�... "" 11 ;oo11::,1 ®) 144A '11')':lf'!<W)' l(lt ,.,.,. .. ,. ,.., .... ltt ,.. .... ..... ..... - '"' ... ... ,. !' LJ K ul(CA <ff'lr"'""" •ddr,.•• xxxxxxxxxxxx CA xxxxxxxxxxxx •' /0. L� "-""C::: "-""c.;. xrxx,xx,xxxx Cornphr� vv1th IMOA StJtnd�"f�t::l!I tC(ASA TA XXXXIY'fY 144R-XX)t()t(XX JTH ,,., ""'�" 1 "'""-.a""' /©:-,. C E. AXX){)()( . . . . -. �a: I� 1-: � - � (LLI) => \.....1 I � �; � t "C I � . . \ ·, . - .. -. . l-(l'lo./1�11; I I t,',./R IUI l l l r ,,.,.,. \\ �J '•""'-""'· ,'V(;, \\ I\C<ll\, \\>\ ' ' .,. ' "'""""'' "' .. ,,,�_,, �·�·���.,.�·�,\ll\ ··��-;�;,, "1111!11\<l'lJ!f'Y.l,-,<IH ; IU\ H' Ill\ .,., . ..,.,., .,., ,., l.Sr\\r.\-£.(.'a 7!1 .. , '""' ... h ,, ., .. , (\Q ., .... \\ � �-v "-\\'1'::,,:\ "V

MISSION 7 HARMAN INTERNATIONAL. CONFIDENTIAL. COPYRIGHT 2021 NAR –V038, V039, V047 2807E-FE5NA0020 T8GCONMOD 6434A-CONMOD LHJ-FE5NA0020

• • • : xxxxxxxxxxxxxxx·13,a C)I lJ�) xxxxxS.3:! ! . �D •• 'r d � i" I< oc:l��<lj 5U L "tJ..; oo: 1 �-�., · B 2lit"1C�J:. iO�"', ... ec! ·-·· ······· ·· · ·· ·- - - � � � �- • • " .. ••••• • • • • • • • • • • • • • • • • • • •••• • • .. • . � .. C • t ..1.t • c) I'. rt

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67003RAN.010 2023-01-17 Test report No: NIE: 67003RAN.010 Assessment report RF EXPOSURE REPORT ACCORDING TO FCC 47 CFR Part 2.1091; FCC 47 CFR Part 1.1307 FCC 47 CFR Part 1.1310 (*) Identification of item under evaluation Telematic control unit with wireless technologies, used in automotive industry. (*) Trademark VW AG (*) Model and /or type reference TKCMOD12N00, TKCMOD12E00, TKCMOD11000, TKCMOD12C00, TKCMOD12J00, TKCMOD12R00, TKCMOD12T00 and TKCMOD13C00 (*) Other identification of the product IMEI TAC : 35194028 HW version: C2.3, SW Version: X152 FCC ID: T8GCONMOD Contains FCC ID: LHJ-FE5NA0020 IC: 6434A-CONMOD Contains IC: 2807E-FE5NA0020 (*) Features GSM, UMTS, LTE, 5G, GNSS, Wi-Fi, BTLE, BT_EDR (*) Manufacturer HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH BECKER-GOERING-STR. 16; 76307 KARLSBAD GERMANY Test method requested, standard FCC 47 CFR Part 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. FCC 47 CFR Part 1.1307: Actions that may have a significant environmental effect, for which Environmental Assessments (EAs) must be prepared. FCC 47 CFR Part 1.1310: Radiofrequency radiation exposure limits. Summary IN COMPLIANCE Approved by (name / position & signature) Miguel Lacave Antennas Lab Manager Date of issue 2023-01-17 Report template No FAN36_02 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67003RAN.010 Page 2 of 13 2023-01-17 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Data provided by the client .......................................................................................................... 3 Identification of the client............................................................................................................. 5 Document history ........................................................................................................................ 5 Appendix A: FCC RF Exposure assessment result ..................................................................... 6 General description of the device under evaluation ................................................................ 7 Evaluation Results .................................................................................................................. 9 Appendix B: FCC RF Exposure information .............................................................................. 10 RF Exposure determination of exemption ............................................................................. 11 RF Exposure evaluation ....................................................................................................... 13 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67003RAN.010 Page 3 of 13 2023-01-17 Competences and guarantees In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification, S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification, S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification, S.A.U. at the time of performance of the test. DEKRA Testing and Certification, S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Assessment Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification, S.A.U. General conditions 1. This report is only referred to the item that has undergone the assessment. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification, S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification, S.A.U. and the Accreditation Bodies Data provided by the client The following data has been provided by the client: 1. Information relating to the description of the sample ("Identification of the item under evaluation", "Trademark", "Model and/or type reference", “General description of the device”, “Other identification of the product”). 2. Maximum output power, maximum antenna gain and use distance information. 3. The device under evaluation consists of a telematics control unit with wireless technologies. 4. Derived model not tested. These models have been declared by the supplier of the sample as being the same as the model under test. DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67003RAN.010 Page 4 of 13 2023-01-17 DEKRA Testing and Certification S.A.U. declines any responsibility with respect to the information pr…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67003RAN.012 2022-12-23 Test report No: NIE: 67003RAN.012 Assessment report RF EXPOSURE REPORT ACCORDING TO FCC 47 CFR Part 2.1091; FCC 47 CFR Part 1.1307 FCC 47 CFR Part 1.1310 (*) Identification of item under evaluation Telematic control unit with wireless technologies, used in automotive industry. (*) Trademark VW AG (*) Model and /or type reference TKCMOD12N00, TKCMOD12E00, TKCMOD11000, TKCMOD12C00, TKCMOD12J00, TKCMOD12R00, TKCMOD12T00 and TKCMOD13C00 (*) Other identification of the product IMEI TAC : 35194028 HW version: C2.3, SW Version: X152 FCC ID: T8GCONMOD Contains FCC ID: LHJ-FE5NA0020 IC: 6434A-CONMOD Contains IC: 2807E-FE5NA0020 (*) Features GSM, UMTS, LTE, 5G, GNSS, Wi-Fi, BTLE, BT_EDR (*) Manufacturer HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH BECKER-GOERING-STR. 16; 76307 KARLSBAD GERMANY Test method requested, standard FCC 47 CFR Part 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. FCC 47 CFR Part 1.1307: Actions that may have a significant environmental effect, for which Environmental Assessments (EAs) must be prepared. FCC 47 CFR Part 1.1310: Radiofrequency radiation exposure limits. Summary IN COMPLIANCE Approved by (name / position & signature) Miguel Lacave Antennas Lab Manager Date of issue 2022-12-23 Report template No FAN36_02 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67003RAN.012 Page 2 of 16 2022-12-23 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Data provided by the client .......................................................................................................... 3 Identification of the client............................................................................................................. 5 Document history ........................................................................................................................ 5 Appendix A: FCC RF Exposure assessment result ..................................................................... 6 General description of the device under evaluation ................................................................ 7 Evaluation Results ................................................................................................................ 11 Appendix B: FCC RF Exposure information .............................................................................. 13 RF Exposure determination of exemption ............................................................................. 14 RF Exposure evaluation ....................................................................................................... 16 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67003RAN.012 Page 3 of 16 2022-12-23 Competences and guarantees In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification, S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification, S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification, S.A.U. at the time of performance of the test. DEKRA Testing and Certification, S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Assessment Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification, S.A.U. General conditions 1. This report is only referred to the item that has undergone the assessment. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification, S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification, S.A.U. and the Accreditation Bodies Data provided by the client The following data has been provided by the client: 1. Information relating to the description of the sample ("Identification of the item under evaluation", "Trademark", "Model and/or type reference", “General description of the device”, “Other identification of the product”). 2. Maximum output power, maximum antenna gain and use distance information. 3. The device under evaluation consists of a telematics control unit with wireless technologies. 4. Derived model not tested. These models have been declared by the supplier of the sample as being the same as the model under test. DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67003RAN.012 Page 4 of 16 2022-12-23 DEKRA Testing and Certification S.A.U. declines any responsibility with respect to the information pro…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa No. 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67003RRF.008A1 2022-12-20 ISED CABid: ES1909 Test Report No: NIE: 67003RRF.008A1 Test Report USA FCC Part 15.247, 15.209 CANADA RSS-247, RSS-Gen (*) Identification of item tested Telematic control unit with wireless technologies, used in automotive industry (*) Trademark VW AG (*) Model and /or type reference TKCMOD12N00 (*) Derived model not tested TKCMOD12E00, TKCMOD11000, TKCMOD12C00, TKCMOD12J00, TKCMOD12R00, TKCMOD12T00 and TKCMOD13C00 Other identification of the product HW version: C2.3 SW version: X152 FCC ID: T8GCONMOD IC: 6434A-CONMOD (*) Features GSM, UMTS, LTE, 5G, GNSS, Wi-Fi, BTLE, BT EDR Manufacturer HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH BECKER-GOERING-STR. 16 76307 KARLSBAD GERMANY Test method requested, standard USA FCC Part 15.247 (10-1-20 Edition): Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz. USA FCC Part 15.209 (10-1-20 Edition): Radiated emission limits; general requirements. CANADA RSS-247 Issue 2 (Feb. 2017). CANADA RSS-Gen Issue 5 Amendment 2 (Feb. 2021). Guidance for Performing Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid Systems Devices Operating Under Section 15.247 of the FCC Rules. 558074 D01 Meas Guidance v05r02 dated April 2, 2019. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices. Summary IN COMPLIANCE Approved by (name / position & signature) Rafael López Martín EMC Consumer & RF Lab. Manager Date of issue 2022-12-20 Report template No. FDT08_24 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa No. 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67003RRF.008A1 Page 2 of 82 2022-12-20 Index INDEX ........................................................................................................................................................................... 2 ACRONYMS ................................................................................................................................................................. 3 COMPETENCES AND GUARANTEES ....................................................................................................................... 3 GENERAL CONDITIONS ............................................................................................................................................. 3 UNCERTAINTY ............................................................................................................................................................ 4 DATA PROVIDED BY THE CLIENT ............................................................................................................................ 4 USAGE OF SAMPLES ................................................................................................................................................. 6 TEST SAMPLE DESCRIPTION ................................................................................................................................... 8 IDENTIFICATION OF THE CLIENT ............................................................................................................................. 9 TESTING PERIOD AND PLACE .................................................................................................................................. 9 DOCUMENT HISTORY ................................................................................................................................................ 9 ENVIRONMENTAL CONDITIONS ............................................................................................................................... 9 REMARKS AND COMMENTS ................................................................................................................................... 10 TESTING VERDICTS ................................................................................................................................................. 11 SUMMARY .................................................................................................................................................................. 11 APPENDIX A: TEST RESULTS. BLUETOOTH LOW ENERGY 5.0 (2M, 1M) ......................................................... 12 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa No. 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67003RRF.008A1 Page 3 of 82 2022-12-20 Acronyms Acronym ID Acronym Description Detector Detector used Equipment Equipment Type Freq Frequency Freq Rng Frequency Range Lvl Level Mod Modulation Occ Ch BW Occupied Channel Bandwidth Operation Band Operation Band PSD Power Spectral Density Pol Polarization Unwanted Freq Unwanted Emissions Frequency Unwanted Lvl Unwanted Emissions Level Competences and guarantees DEKRA Testing and Certification S.A.U. is a testing laboratory accredited by the National Accreditation Body (ENAC - Entidad Nacional de Acreditación) to perform the tests indicated in the Certificate No. 51/LE 147. DEKRA Testing and Certification is a FCC-recognized accredited testing laboratory with appropriate scope of accreditation that covers the performed tests in this report. DEKRA Testing and Certification is an ISED-recognized accredited testing laboratory, CABid: ES1909, with the appropriate scope of accreditation that covers the performed tests in this report. In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measu…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa No. 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67003RRF.008A1 Page 58 of 82 2022-12-20 Operation Band (MHz) = [2400, 2483.5], Frequency (MHz) = 2480.00000, Equipment Type: Digital Transmission System (DTS), Modulation: BTLE 5.0 (GFSK 2 Mbit/s), Frequency Range (GHz) = [3, 17] Plots: Operation Band (MHz) = [2400, 2483.5], Equipment Type: Digital Transmission System (DTS), Modulation: BTLE 5.0 (GFSK 2 Mbit/s), Frequency Range (GHz) = [17, 26] Plots: This plot is valid for Low, Middle and High Channels. Level in dBμV/m Level in dBμV/m DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa No. 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67003RRF.008A1 Page 59 of 82 2022-12-20 Modulation: BTLE 5.0 (GFSK 1 Mbit/s) Results Frequency range 30 MHz – 1 GHz: ID Comments -- The spurious frequencies detected do not depend on the operating channel. Freq Rng (GHz) Unwanted Freq (MHz) Unwanted Lvl (dBμV/m) Pol Detector [0.03, 1] 375.0193 38.77 H QP 449.9712 38.89 V QP 624.9786 31.77 V QP Frequency range 1 GHz – 26 GHz: ID Comments -- The results in the next table show the maximum measured levels in the 1 – 26 GHz range including the restricted bands 2.31 – 2.39 GHz and 2.4835 – 2.5 GHz. Spurious frequencies with peak levels above the average limit (54 dBμV/m at 3 m) are measured with average detector for compliance checking with the average limit. Freq (MHz) Freq Rng (GHz) Unwanted Freq (MHz) Unwanted Lvl (dBμV/m) Pol Detector 2402.00000 [3, 17] 7205.7400 (*) 48.34 V PK 9607.0200 (*) 53.10 V PK 14410.4200 (*) 53.87 V PK 2440.00000 [3, 17] 7319.1400 47.82 V PK 9760.8800 (*) 52.16 V PK 14641.5600 (*) 52.70 V PK 2480.00000 [3, 17] 4959.8600 40.05 V PK 7440.8000 48.33 V PK 9920.6200 (*) 50.38 V PK (*) This Spurious Frequency is outside the restricted bands as defined in §15.205(a). The peak spurious level is more than 20 dB below the peak carrier level. Verdict Pass DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa No. 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67003RRF.008A1 Page 60 of 82 2022-12-20 Attachments Operation Band (MHz) = [2400, 2483.5], Equipment Type: Digital Transmission System (DTS), Modulation: BTLE 5.0 (GFSK 1 Mbit/s), Frequency Range (GHz) = [0.03, 1] Plots: This plot is valid for Low, Middle and High Channels. Operation Band (MHz) = [2400, 2483.5], Frequency (MHz) = 2402.00000, Equipment Type: Digital Transmission System (DTS), Modulation: BTLE 5.0 (GFSK 1 Mbit/s), Frequency Range (GHz) = [1, 3] Plots: Level in dBμV/m Level in dBμV/m DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa No. 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67003RRF.008A1 Page 61 of 82 2022-12-20 Level in dBμV/m Level in dBμV/m DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa No. 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67003RRF.008A1 Page 62 of 82 2022-12-20 Operation Band (MHz) = [2400, 2483.5], Frequency (MHz) = 2440.00000, Equipment Type: Digital Transmission System (DTS), Modulation: BTLE 5.0 (GFSK 1 Mbit/s), Frequency Range (GHz) = [1, 3] Plots: Level in dBμV/m Level in dBμV/m DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa No. 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67003RRF.008A1 Page 63 of 82 2022-12-20 Operation Band (MHz) = [2400, 2483.5], Frequency (MHz) = 2480.00000, Equipment Type: Digital Transmission System (DTS), Modulation: BTLE 5.0 (GFSK 1 Mbit/s), Frequency Range (GHz) = [1, 3] Plots: Level in dBμV/m Level in dBμV/m DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa No. 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: NIE: 67003RRF.008A1 Page 64 of…
