T8GMGUFAThe main functionalities are Navigation, DVD/CD, HDD, USB, voice recognition, different interfaces to the car, Bluetooth and WLAN.

Inputs for User Manual MGU FA User Instruction Recommendation for Manual out of homologation requirements MGU Infotainment System Model: MGU FA Brand: BMW Version: 1.0 Date: 2022-10-26 Recommendation for User Instruction Version 1.0 Page 2 Inputs for User Manual MGU FA ` European target market (EU and EFTA countries) Declaration of Conformity to RED regulation 2014/53/EU Declaration of Conformity (DoC) English: Hereby, Harman Becker Automotive Systems GmbH declares that the radio equipment type MGU FA is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet Address: (*1) Bulgarian: С настоящото Harman Becker Automotive Systems GmbH декларира, че този тип радиосъоръжение MGU FA е в съответствие с Директива 2014/53/ЕС. Цялостният текст на ЕС декларацията за съответствие може да се намери на следния интернет адрес: (*1) Spanish: Por la presente, Harman Becker Automotive Systems GmbH declara que el tipo de equipo radioeléctrico MGU FA es conforme con la Directiva 2014/53/UE. El texto completo de la declaración UE de conformidad está disponible en la dirección Internet siguiente: (*1) Czech: Tímto Harman Becker Automotive Systems GmbH prohlašuje, že typ rádiového zařízení MGU FA je v souladu se směrnicí 2014/53/EU. Úplné znění EU prohlášení o shodě je k dispozici na této internetové adrese: (*1) Danish: Hermed erklærer Harman Becker Automotive Systems GmbH, at radioudstyrstypen MGU FA er i overensstemmelse med direktiv 2014/53/EU. EU- overensstemmelseserklæringens fulde tekst kan findes på følgende internetadresse: (*1) German: Hiermit erklärt Harman Becker Automotive Systems GmbH, dass das Gerät mit Funkfunktion MGU FA der Richtlinie 2014/53/EU entspricht. Der vollständige Text der EU- Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: (*1) Estonian: Käesolevaga deklareerib Harman Becker Automotive Systems GmbH, et käesolev raadioseadme tüüp MGU FA vastab direktiivi 2014/53/EL nõuetele. ELi vastavusdeklaratsiooni täielik tekst on kättesaadav järgmisel internetiaadressil: (*1) Recommendation for User Instruction Version 1.0 Page 3 Inputs for User Manual MGU FA ` Greek: Με την παρούσα ο/η Harman Becker Automotive Systems GmbH, δηλώνει ότι ο ραδιοεξοπλισμός MGU FA πληροί την οδηγία 2014/53/ΕΕ. Το πλήρες κείμενο της δήλωσης συμμόρφωσης ΕΕ διατίθεται στην ακόλουθη ιστοσελίδα στο διαδίκτυο: (*1) French: Le soussigné, Harman Becker Automotive Systems GmbH, déclare que l'équipement radioélectrique du type MGU FA est conforme à la directive 2014/53/UE. Le texte complet de la déclaration UE de conformité est disponible à l'adresse internet suivante: (*1) Croatian: Harman Becker Automotive Systems GmbH ovime izjavljuje da je radijska oprema tipa MGU FA u skladu s Direktivom 2014/53/EU. Cjeloviti tekst EU izjave o sukladnosti dostupan je na sljedećoj internetskoj adresi: (*1) Italian: Il fabbricante, Harman Becker Automotive Systems GmbH, dichiara che il tipo di apparecchiatura radio MGU FA è conforme alla direttiva 2014/53/UE. Il testo completo della dichiarazione di conformità UE è disponibile al seguente indirizzo Internet: (*1) Latvian: Ar šo Harman Becker Automotive Systems GmbH deklarē, ka radioiekārta MGU FA atbilst Direktīvai 2014/53/ES. Pilns ES atbilstības deklarācijas teksts ir pieejams šādā interneta vietnē: (*1) Lithuanian: Aš, Harman Becker Automotive Systems GmbH, patvirtinu, kad radijo įrenginių tipas MGU FA atitinka Direktyvą 2014/53/ES. Visas ES atitikties deklaracijos tekstas prieinamas šiuo interneto adresu: (*1) Hungarian: Harman Becker Automotive Systems GmbH igazolja, hogy a MGU FA típusú rádióberendezés megfelel a 2014/53/EU irányelvnek. Az EU-megfelelőségi nyilatkozat teljes szövege elérhető a következő internetes címen: 2014.5.22. L 153/104 Az Európai Unió Hivatalos Lapja HU: (*1) Maltese: B'dan, Harman Becker Automotive Systems GmbH, niddikjara li dan it-tip ta' tagħmir tar-radju MGU FA huwa konformi mad-Direttiva 2014/53/UE. It-test kollu tad- dikjarazzjoni ta' konformità tal-UE huwa disponibbli f'dan l-indirizz tal-Internet li ġej: (*1) Dutch: Hierbij verklaar ik, Harman Becker Automotive Systems GmbH, dat het type radioapparatuur MGU FA conform is met Richtlijn 2014/53/EU. De volledige tekst van de EU- conformiteitsverklaring kan worden geraadpleegd op het volgende internetadres: (*1) Polish: Harman Becker Automotive Systems GmbH niniejszym oświadcza, że typ urządzenia radiowego MGU FA jest zgodny z dyrektywą 2014/53/UE. Pełny tekst deklaracji zgodności UE jest dostępny pod następującym adresem internetowym: (*1) Portuguese: O(a) abaixo assinado(a) Harman Becker Automotive Systems GmbH declara que o presente tipo de equipamento de rádio MGU FA está em conformidade com a Diretiva 2014/53/UE. O texto integral da declaração de conformidade está disponível no seguinte endereço de Internet: (*1) Recommendation for User Instruction Version 1.0 Page 4 Inputs for User Manual MGU FA ` Romanian: Prin prezenta, Harman Becker Automotive Systems GmbH declară că tipul de echipamente radio MGU FA este în conformitate cu Directiva 2014/53/UE. Textul integral al declarației UE de conformitate este disponibil la următoarea adresă internet: (*1) Slovak: Harman Becker Automotive Systems GmbH týmto vyhlasuje, že rádiové zariadenie typu MGU FA je v súlade so smernicou 2014/53/EÚ. Úplné EÚ vyhlásenie o zhode je k dispozícii na tejto internetovej adrese: (*1) Slovenian: Harman Becker Automotive Systems GmbH potrjuje, da je tip radijske opreme MGU FA skladen z Direktivo 2014/53/EU. Celotno besedilo izjave EU o skladnosti je na voljo na naslednjem spletnem naslovu: (*1) Finnish: Harman Becker Automotive Systems GmbH vakuuttaa, että radiolaitetyyppi MGU FA on direktiivin 2014/53/EU mukainen. EU-vaatimustenmukaisuusvakuutuksen täysimittainen teksti on saatavilla seuraavassa internetosoitteessa: (*1) Swedish: Härmed försäkrar Harman Becker Automotive Systems GmbH att denna typ av radioutrustning MGU FA öve…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 71290RAN.002A1 2022-11-17 Test report No: NIE: 71290RAN.002A1 Assessment report RF EXPOSURE REPORT ACCORDING TO FCC 47 CFR Part 2.1093 FCC 47 CFR Part 1.1307 (*) Identification of item under evaluation Automotive infotainment System (*) Trademark BMW (*) Model and /or type reference MGU FA (*) Other identification of the product HW version: 3.2 SW version: L18_22w10.5-1 FCC ID: T8GMGUFA IC: 6434A-MGUFA (*) Features USB 2.0 (including support for Apple Devices), Bluetooth, WLAN Modul 2.4 / 5 GHz, GNSS, Video-out APIX3, CAN, 100Base-T1 (*) Manufacturer HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH BECKER-GOERING-STR. 16; 76307 KARLSBAD GERMANY Test method requested, standard FCC 47 CFR Part 2.1093. Radiofrequency radiation exposure evaluation: portable devices. FCC 47 CFR Part 1.1307: Actions that may have a significant environmental effect, for which Environmental Assessments (EAs) must be prepared. Summary IN COMPLIANCE Approved by (name / position & signature) Miguel Lacave Antennas Lab Manager Date of issue 2022-11-17 Report template No FAN24_02 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 71290RAN.002A1 Page 2 of 9 2022-11-17 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Data provided by the client .......................................................................................................... 3 Identification of the client............................................................................................................. 3 Document history ........................................................................................................................ 3 Appendix A: FCC RF Exposure assessment result ..................................................................... 4 General description of the device under evaluation ................................................................ 5 Evaluation Results .................................................................................................................. 6 Appendix B: FCC RF Exposure information ................................................................................ 7 RF Exposure determination of exemption ............................................................................... 8 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 71290RAN.002A1 Page 3 of 9 2022-11-17 Competences and guarantees In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification, S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification, S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification, S.A.U. at the time of performance of the test. DEKRA Testing and Certification, S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Assessment Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification, S.A.U. General conditions 1. This report is only referred to the item that has undergone the assessment. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification, S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification, S.A.U. and the Accreditation Bodies Data provided by the client The following data has been provided by the client: 1. Information relating to the description of the sample ("Identification of the item under evaluation", "Trademark", "Model and/or type reference", “General description of the device”, “Other identification of the product” and “Features”). 2. Maximum output power, maximum antenna gain and installation distance information. 3. The device under evaluation consists of an Automotive infotainment System. DEKRA Testing and Certification S.A.U. declines any responsibility with respect to the information provided by the client and that may affect the validity of results. Identification of the client HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH BECKER-GOERING-STR. 16; 76307 KARLSBAD GERMANY Document history Report number Date Description 71290RAN.002 2022-10-17 First release 71290RAN.002A1 2022-11-17 Second release. Updated maximum output power values. DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 71290RAN.002A1 Page 4 of 9 2022-11-17 Appendix A: FCC RF Exposure assessment result DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · …

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: (NIE) 71290RRF.010A1 2022-11-23 ISED CABid: ES1909 Test report No: NIE: 71290RRF.010A1 Test Report USA FCC Part 15.407, 15.209 CANADA RSS-247, RSS-Gen (*) Identification of item tested Automotive infotainment System (*) Trademark BMW (*) Model and /or type reference MGU FA Other identification of the product FCC ID: T8GMGUFA IC: 6434A-MGUFA (*) Features USB 2.0 (including support for Apple Devices), Bluetooth, WLAN Modul 2.4 / 5 GHz, GNSS, Video-out APIX3, CAN, 100Base-T1 HW version: 3.2 SW version: L18_22w10.5-1 Applicant HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH Becker-Goering-Str. 16 76307, Karlsbad, GERMANY Test method requested, standard USA FCC Part 15.407 (10-1-20) Edition: Unlicensed National Information Infrastructure (U-NII) Devices. General technical requirements. USA FCC Part 15.209 (10-1-20) Edition: Radiated emission limits; general requirements. CANADA RSS-247 Issue 2 (February 2017). CANADA RSS-Gen Issue 5 (April 2018). Guidance for Compliance Testing of Unlicensed National Information Infrastructure (U-NII) Devices 789033 D02 General U-NII Test Procedures New Rules v02r01 dated Dec 14, 2017. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices. Summary IN COMPLIANCE Approved by (name / position & signature) Rafael López EMC Consumer & RF Lab. Manager Date of issue 2022-11-23 Report template No. FDT08_24 (*) “Data provided by the client”
