Geschäftsführung: Dr. Udo Hüls, Sachin Lawande, Michael Mauser Vorsitzender des Aufsichtsrats: Edwin C. Summers Sitz der Gesellschaft: Karlsbad | Amtsgericht Mannheim: HRB-Nr. 361395 Karlsbad, 2015-07-23 Harman Becker Automotive Systems GmbH | Postfach 2260 | 76303 Karlsbad Dear Ladies and Gentleman, The following information and mentioned statements and paragraphs will be forwarded to our OEM customer to print this into the final user manual. FCC ID: T8G-HERMES IC: 6434A-HERMES FCC § 15.19 Labelling requirements This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC § 15.21 Information to user Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Exposure Requirements To comply with FCC RF exposure compliance requirements, the device must be installed to provide a separation distance of at least 20 cm from all persons. INDUSTRY CANADA Statements Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. RF Exposure Requirements This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Déclaration d’exposition aux radiations: Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps. In case of any questions please do not hesitate and contact us. Sincerely, Stefan Blaschek Regulatory Compliance Management Harman Automotive Division Harman Becker Automotive Systems GmbH Becker-Göring-Straße 16 76307 Karlsbad Phone: +49 7248 71 3382 Fax: +49 7248 71 3802 Mobile: +49 172 94 191 49 Email : [email protected] Web: www.harman.com Simon Vögele Regulatory Compliance Management Harman Automotive Division Harman Becker Automotive Systems GmbH Becker-Göring-Straße 16 76307 Karlsbad Phone: +49 7248 71 3667 Fax: +49 7248 71 3802 Mobile: +49 175 436 6188 Email : [email protected] Web: www.harman.com To whom it may concern HARMAN AUTOMOTIVE DIVISION H A R MAN BE C KER AU TO MO TIV E S YSTE MS G MB H BE C KE R -G O ER ING -STR A SSE 16 7 630 7 KA RL SBA D , G ER MA N Y TEL : +49 7 2 48 7 1 36 6 7 F A X: +49 7 2 48 7 1 46 6 7 E-M AIL : S IMO N .V O EG E LE @H A RMAN .C O M

ANTENNA INFORMATION Bluetooth / WLAN Antenna Type: internal PCB antenna Manufacturer: Harman Automotive Systems GmbH Antenna Gain: max. 1.82 dBi

Geschäftsführung: Dr. Udo Hüls, Sachin Lawande, Michael Mauser Vorsitzender des Aufsichtsrats: Edwin C. Summers Sitz der Gesellschaft: Karlsbad | Amtsgericht Mannheim: HRB-Nr. 361395 Karlsbad, 2015-07-23 Harman Becker Automotive Systems GmbH | Postfach 2260 | 76303 Karlsbad Authorization Letter for FCC / IC certification Dear Ladies and Gentleman, The company 7layers AG has been contracted by HARMAN/BECKER Automotive Systems GmbH to obtain “FCC and IC certification” for the following electronic component manufactured and/or released by HARMAN/BECKER: MODEL NAME (please insert) FCC ID: T8GHERMES IC: 6434A-HERMES The following persons at 7 layers AG will be authorized: - Carsten Steinroeder - Berthold Braun - Aleksey Yevdokymov Unless future correspondence from HARMAN/BECKER directs otherwise, please extend your full cooperation to 7 layers regarding matters to the above mentioned products for the period beginning 23 July 2015 through end of the project date. Thank you. Sincerely, Stefan Blaschek Regulatory Compliance Management Harman Automotive Division Harman Becker Automotive Systems GmbH Becker-Göring-Straße 16 76307 Karlsbad Phone: +49 7248 71 3382 Fax: +49 7248 71 3802 Mobile: +49 172 94 191 49 Email: [email protected] Web: www.harman.com Simon Vögele Regulatory Compliance Management Harman Automotive Division Harman Becker Automotive Systems GmbH Becker-Göring-Straße 16 76307 Karlsbad Phone: +49 7248 71 3667 Fax: +49 7248 71 3802 Mobile: +49 175 436 6188 Email: [email protected] Web: www.harman.com To whom it may concern HARMAN AUTOMOTIVE DIVISION H A R MAN BE C KER AU TO MO TIV E S YSTE MS G MB H BE C KE R -G O ER ING -STR A SSE 16 7 630 7 KA RL SBA D , G ER MA N Y TEL : +49 7 2 48 7 1 36 6 7 F A X: +49 7 2 48 7 1 46 6 7 E-M AIL : S IMO N .V O EG E LE @H A RMAN .C O M

EXTERNAL PHOTOS

INTERNAL PHOTOS

7 layers AG Aufsichtsratsvorsitzenderh Registergerichth registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Peter Mertel USt-IdNr h VAT No.: Phone: +49 (0) 2102 749 0 Vorstandh Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H. Ansorge TAX No. 147/5869/0385 www.7Layers.com A Bureau Veritas Group Company Carsten Steinroeder 03.08.2015 Phone +49 (0) 2102 749 331 Fax +49 (0) 2102 749 350 Maximum Permissible Exposure PRSE Dear Mr. Voegele, please find our Maximum Permissible Exposure calculations for the HERMES. Best Regards i.V. Carsten Steinröder Harman/Becker Automotive Systems GmbH Becker-Göring-Straße 16 76307 Karlsbad Germany MDE_HARMAN_1504 - 2 - Maximum Permissible Exposure (as specified in Table 1B of 47 CFR 1.1310 – Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure) Frequency range (MHz) Power density (mW/cm²) 300 – 1500 f/1500 1,500 – 100000 1.0 Calculations 2.4 GHZ and 5 GHz band SAR Limit: 1 mW/cm² Equation OET bulletin 65, page 18, edition 97-01: S = P*G / (4πR²) S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna

Test Laboratory: 7Layers AG Borsigstrasse 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7 layers AG Aufsichtsratsvorsitzender h Registergerichth registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Peter Mertel USt-IdNr h VAT No.: Phone: +49 (0) 2102 749 0 Vorstandh Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H. Ansorge TAX No. 147/5869/0385 www.7Layers.com A Bureau Veritas Group Company FCC Measurement Report on WLAN transceiver HERMES FCC ID: T8GHERMES IC: 6434A-HERMES Report Reference: MDE_HARMAN_1504_FCCc_rev1 Test report Reference: MDE_HARMAN_1504_FCCc_rev1 Page 2 of 48 Table of Contents 0 Applied Standards and Test Summary 3 0.1 Applied Standards 3 0.2 FCC-IC Correlation Table 4 0.3 Measurement Summary / Signatures 5 Revision History 7 1 Administrative Data 8 1.1 Testing Laboratory 8 1.2 Project Data 8 1.3 Applicant Data 8 1.4 Manufacturer Data 8 2 Test object Data 9 2.1 General EUT Description 9 2.2 EUT Main components 10 2.3 Ancillary Equipment 10 2.4 Auxiliary Equipment 10 2.5 EUT Setups 11 2.6 Operating Modes 11 2.7 Special software used for testing 11 2.8 Product labelling 11 3 Test Results 12 3.1 26 / 6 dB Emission bandwidth / 99 % occupied bandwidth 12 3.2 Maximum conducted output power 19 3.3 Maximum Power Spectral Density 24 3.4 Frequency Stability 28 3.5 Undesirable Emissions / General Field Strength Limits; Restricted Band and Radiated Emission Limits, Band Edge 29 4 Test Equipment 38 5 Photo Report 47 6 Measurement Uncertainty 47 7 Setup Drawings 48 Test report Reference: MDE_HARMAN_1504_FCCc_rev1 Page 3 of 48 0 Applied Standards and Test Summary 0.1 Applied Standards Type of Authorization Certification for an Intentional Radiator (Digital Device / Spread Spectrum). Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 2 (10-1-13 Edition) and 15 (10-1-13 Edition). The following subparts are applicable to the results in this test report. Part 2, Subpart J - Equipment Authorization Procedures, Certification Part 15, Subpart C – Intentional Radiators § 15.201 Equipment authorization requirement § 15.207 Conducted limits § 15.209 Radiated emission limits; general requirements Part 15, Subpart E – Unlicensed National Information Infrastructure Devices § 15.403 Definitions § 15.407 General technical requirements Note: The tests were selected and performed with reference to the FCC Public Notice “Guidelines for Compliance Testing of Unlicensed National Information Infrastructure (U-NII) Devices - Part 15, Subpart E, 789033 D02 General U-NII Test Procedures v01, 2014-06-06”. Instead of applying ANSI C63.4–1992 which is referenced in the FCC Public Note, the newer ANSI C63.4–2009 is applied. FCC ET Docket No. 13-49, FIRST REPORT AND ORDER, April 1, 2014 (“new rules”) is applied. Summary Test Results: The EUT complied with all performed tests as listed in chapter 0.3 Measurement Summary / Signatures. Test report Reference: MDE_HARMAN_1504_FCCc_rev1 Page 4 of 48 0.2 FCC-IC Correlation Table Correlation of measurement requirements for UNII / LE-LAN (e.g. WLAN 5 GHz) equipment UNII equipment Measurement FCC reference IC reference Conducted emissions on AC Mains § 15.207 RSS-Gen Issue 4: 8.8 Occupied bandwidth § 15.403 (i) (26 dB) / § 15.407 (e) (6 dB) RSS-247 Issue 1: 6.2.1 (1), 6.2.2 (1), 6.2.3 (1) (99%) RSS-247 Issue 1: 6.2.4 (1) (6 dB) Maximum conducted output power § 15.407 (a) (1),(2),(3),(4) RSS-247 Issue 1: : 6.2.1 (1), 6.2.2 (1), 6.2.3 (1), 6.2.4 (1) Maximum power spectral density § 15.407 (a) (1),(2),(3),(5) RSS-247 Issue 1: : 6.2.1 (1), 6.2.2 (1), 6.2.3 (1), 6.2.4 (1) Transmitter undesirable emissions; General Field Strength Limits, Restricted Bands 15.407 (b) § 15.209 (a) RSS-Gen Issue 4: 6.13/8.9/8.10; RSS-247 Issue 1: : 6.2.1 (2), 6.2.2 (2), 6.2.3 (2), 6.2.4 (2) Frequency stability § 15.407 (g) RSS-Gen Issue 4: 6.11/8.11 Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) § 15.407 (h) RSS-247 Issue 1: 6.2.2 (1), 6.2.3 (1), 6.3 Antenna requirement § 15.203 / 15.204 RSS-Gen Issue 4: 8.3 Receiver spurious emissions – - Test report Reference: MDE_HARMAN_1504_FCCc_rev1 Page 5 of 48 0.3 Measurement Summary / Signatures FCC Part 15, Subpart C § 15.207 Conducted emissions (AC power line) The measurement was performed according to ANSI C63.4 OP-Mode Setup Port Final Result - - - N/A 1) FCC Part 15, Subpart E § 15.403 (i), 15.407 (e) 26 / 6 dB Emission bandwidth / 99 % occupied bandwidth The measurement was performed according to FCC § 15.31 OP-Mode Setup Port Final Result a-Mode, CH 149, 20 MHz Setup_01 Temp.ant.connector passed a-Mode, CH 157, 20 MHz Setup_01 Temp.ant.connector passed a-Mode, CH 165, 20 MHz Setup_01 Temp.ant.connector passed n-Mode, CH 149, 20 MHz Setup_01 Temp.ant.connector passed n-Mode, CH 157, 20 MHz Setup_01 Temp.ant.connector passed n-Mode, CH 165, 20 MHz Setup_01 Temp.ant.connector passed n-Mode, CH 149, 40 MHz Setup_01 Temp.ant.connector passed n-Mode, CH 157, 40 MHz Setup_01 Temp.ant.connector passed FCC Part 15, Subpart E § 15.407 (a)(1,2,3,4) Maximum Conducted Output Power The measurement was performed according to FCC § 15.31 Final Result OP-Mode Setup Port FCC IC a-Mode, CH 36, 20 MHz Setup_01 Temp.ant.connector passed N/A a-Mode, CH 44, 20 MHz Setup_01 Temp.ant.connector passed N/A a-Mode, CH 48, 20 MHz Setup_01 Temp.ant.connector passed N/A a-Mode, CH 52, 20 MHz Setup_01 Temp.ant.connector N/A N/A a-Mode, CH 56, 20 MHz Setup_01 Temp.ant.connector N/A N/A a-Mode, CH 64, 20 MHz Setup_01 Temp.ant.connector N/A N/A a-Mode, CH 100, 20 MHz Setup_01 Temp.ant.connector passed passed a-Mode, CH 116, 20 MHz Setup_01 Temp.ant.connector passed passed a-Mode, CH 140, 20 MHz Setup_01 Temp.ant.connector passed passed a-Mode, CH 149, 20 MHz Setup_01…
