T8GMGU21Automotive head unit to be installed in cars with the following features Bluetooth WLAN and GNSS

WELCOME TO BMW. O wner's Handbook. Navigation, Entertainment, Communication. Congratulations on your choice of a BMW. The better you are acquainted with your vehicle, the easier you will find it is to operate. We would therefore like to offer you the following advice: Please read the Owner's Handbook before setting out in your new BMW. Also use the Integrated Owner's Handbook in your vehicle. It contains impor‐ tant notes on how to operate the vehicle, enabling you to derive maximum benefit from the technical advantages of your BMW. It also contains useful in‐ formation which will help you to maintain both the operating and road safety of your BMW as well as its full resale value. If applicable, you will find updates after the editorial deadline in the appendix of the printed Owner's Handbook for the vehicle. Supplementary information is provided in the other documents of on-board literature. Your BMW AG wishes you pleasant and safe driving. 3 TABLE OF CONTENTS NAVIGATION Navigation system ............................................................................................................ 8 Destination input ............................................................................................................ 11 Map .................................................................................................................................... 18 Settings ............................................................................................................................. 30 ENTERTAINMENT Entertainment system .................................................................................................. 34 Sound ................................................................................................................................ 37 Radio ................................................................................................................................. 40 Audio ................................................................................................................................. 43 Video ................................................................................................................................. 50 Television, TV ................................................................................................................. 51 COMMUNICATION Telephone ........................................................................................................................ 56 Services and applications ............................................................................................ 65 REFERENCE Everything from A to Z ................................................................................................. 76 © 2018 Bayerische Motoren Werke Aktiengesellschaft Munich, Germany Not to be reproduced, wholly or in part, without written permission from BMW AG, Munich. English VI/18, 07 18 490 Printed on environmentally friendly paper, bleached without chlorine, suitable for recycling. 4 Navigation, entertainment and communication can be called up in the following Owner's Handbooks: Integrated Owner's Handbook in the vehicle, Online Owner's Handbook, BMW Driver’s Guide app. 5 6 NAVIGATION Navigation system ....................................................................................... 8 Destination input ........................................................................................ 11 Map .............................................................................................................. 18 Settings ....................................................................................................... 30 7 Navigation system Vehicle equipment This chapter describes all standard, country-spe‐ cific and special equipment available for the model series. It may therefore describe equip‐ ment and functions which are not installed in your vehicle, for example on account of the op‐ tional equipment selected or the country specifi‐ cation. This also applies to safety-relevant func‐ tions and systems. Please comply with the relevant laws and regulations when using the corresponding functions and systems. O verview General The navigation system can determine the pre‐ cise position of the vehicle by means of satellites and guide you reliably to any specified destina‐ tion. Navigation data is saved in the vehicle and can be updated with a USB data storage medium. Certain navigation system services are only avail‐ able in full if you agree to the data protection terms. The services, see page 30, can be con‐ figured individually. Calling up the navigation system 1. Press the button on the Controller. 2. "NAV" Buttons on the Controller The buttons on the Controller enable quick ac‐ cess to the navigation system. Symbol Function Call up the destination input menu. Call up map view. If route guidance is active, call up the information window. Safety notes WARNING Operating integrated information systems and communication devices during a journey may distract you from the traffic. You could lose control of the vehicle. There is a danger of acci‐ dents. Only operate the systems or devices if permissible in the traffic situation. Stop if nec‐ essary and operate the systems or devices with the vehicle at a standstill. WARNING The current road and traffic situation may differ from the instructions given by the navigation system, for example due to changes in road routing or roadworks. There is a danger of acci‐ dents. Always obey the traffic regulations and road signs. Split screen Principle Additional information for navigation can be shown on the right-hand part of the split screen. Seite 6 NAVIGATION Navigation system 8 Switching on/off 1. Press the button on the Controller. 2. Tilt the Controller to the right. 3. "Split screen" 4. "Split screen" Selecting the display 1. Press the button on the Controller. 2. Tilt the Controller to the right. 3. "Split screen" 4. Select the desired setting. Ar…

Text truncated - open the document above for the full version.

User Instruction Manual MGU21 Infotainment System Model: MGU 21 4-User instruction manual 04-User instruction manual Version 1.0 Inputs for User Manual MGU21 1 Technical Information 1.1 Materials MGU21 infotainment system está em conformidade com os mais recentes lançamentos de directivas RoHS (2002/95/EC) e ELV (2000/53/EC), e também o regulamento REACH (CE) No. 1907/2006. Marcação de polímero partes acc. a VDA 260, respectivamente EN ISO 1043.Declaration of Conformity to RED regulation 1.2 Declaration of Conformity to RED regulation 2014/53/EU Declaration of Conformity (DoC) English: Hereby, Harman Becker Automotive Systems GmbH declares that the radio equipment type MGU21 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet Address: (*1) Bulgarian: С настоящото Harman Becker Automotive Systems GmbH декларира, че този тип радиосъоръжение MGU21 a в съответствие с Директива 2014/53/ЕС. Цялостният текст на ЕС декларацията за съответствие може да се намери на следния интернет адрес: (*1) Spanish: Por la presente, Harman Becker Automotive Systems GmbH declara que el tipo de equipo radioeléctrico MGU21 es conforme con la Directiva 2014/53/UE. El texto completo de la declaración UE de conformidad está disponible en la dirección Internet siguiente: (*1) Czech: Tímto Harman Becker Automotive Systems GmbH prohlašuje, že typ rádiového zařízení MGU21 je v souladu se směrnicí 2014/53/EU. Úplné znění EU prohlášení o shodě je k dispozici na této internetové adrese: (*1) Danish: Hermed erklærer Harman Becker Automotive Systems GmbH, at radioudstyrstypen MGU21 EU- er i overensstemmelse med direktiv 2014/53/EU. overensstemmelseserklæringens fulde tekst kan findes på følgende internetadresse: (*1) German: Hiermit erklärt Harman Becker Automotive Systems GmbH, dass das Gerät mit Funkfunktion MGU21 der Richtlinie 2014/53/EU entspricht. Der vollständige Text der EU- Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: (*1) Estonian: Käesolevaga deklareerib Harman Becker Automotive Systems GmbH, et käesolev raadioseadme tüüp MGU21 vastab direktiivi 2014/53/EL nõuetele. ELi vastavusdeklaratsiooni täielik tekst on kättesaadav järgmisel internetiaadressil: (*1) 04-User instruction manual Version 1.0 Inputs for User Manual MGU21 Greek: Με την παρούσα ο/η Harman Becker Automotive Systems GmbH, δηλώνει ότι ο ραδιοεξοπλισμός MGU21 πληροί την οδηγία 2014/53/ΕΕ. Το πλήρες κείμενο της δήλωσης συμμόρφωσης ΕΕ διατίθεται στην ακόλουθη ιστοσελίδα στο διαδίκτυο: (*1) French: Le soussigné, Harman Becker Automotive Systems GmbH, déclare que l'équipement radioélectrique du type MGU21 est conforme à la directive 2014/53/UE. Le texte complet de la déclaration UE de conformité est disponible à l'adresse internet suivante: (*1) Croatian: Harman Becker Automotive Systems GmbH ovime izjavljuje da je radijska oprema tipa MGU21u skladu s Direktivom 2014/53/EU. Cjeloviti tekst EU izjave o sukladnosti dostupan je na sljedećoj internetskoj adresi: (*1) Italian: Il fabbricante, Harman Becker Automotive Systems GmbH, dichiara che il tipo di apparecchiatura radio MGU21 è conforme alla direttiva 2014/53/UE. Il testo completo della dichiarazione di conformità UE è disponibile al seguente indirizzo Internet: (*1) Latvian: Ar šo Harman Becker Automotive Systems GmbH deklarē, ka radioiekārta MGU21 atbilst Direktīvai 2014/53/ES. Pilns ES atbilstības deklarācijas teksts ir pieejams šādā interneta vietnē: (*1) Lithuanian: Aš, Harman Becker Automotive Systems GmbH, patvirtinu, kad radijo įrenginių tipas MGU21 atitinka Direktyvą 2014/53/ES. Visas ES atitikties deklaracijos tekstas prieinamas šiuo interneto adresu: (*1) Hungarian: Harman Becker Automotive Systems GmbH igazolja, hogy a MGU21 típusú rádióberendezés megfelel a 2014/53/EU irányelvnek. Az EU-megfelelőségi nyilatkozat teljes szövege elérhető a következő internetes címen: 2014.5.22. L 153/104 Az Európai Unió Hivatalos Lapja HU: (*1) Maltese: B'dan, Harman Becker Automotive Systems GmbH, niddikjara li dan it-tip ta' tagħmir tar-radju MGU21 huwa konformi mad-Direttiva 2014/53/UE. It-test kollu tad- dikjarazzjoni ta' konformità tal-UE huwa disponibbli f'dan l-indirizz tal-Internet li ġej: (*1) Dutch: Hierbij verklaar ik, Harman Becker Automotive Systems GmbH, dat het type radioapparatuur MGU21 conform is met Richtlijn 2014/53/EU. De volledige tekst van de EU- conformiteitsverklaring kan worden geraadpleegd op het volgende internetadres: (*1) Polish: Harman Becker Automotive Systems GmbH niniejszym oświadcza, że typ urządzenia radiowego MGU21 jest zgodny z dyrektywą 2014/53/UE. Pełny tekst deklaracji zgodności UE jest dostępny pod następującym adresem internetowym: (*1) Portuguese: O(a) abaixo assinado(a) Harman Becker Automotive Systems GmbH declara que o presente tipo de equipamento de rádio MGU21 está em conformidade com a Diretiva 2014/53/UE. O texto integral da declaração de conformidade está disponível no seguinte endereço de Internet: (*1) 04-User instruction manual Version 1.0 Inputs for User Manual MGU21 Romanian: Prin prezenta, Harman Becker Automotive Systems GmbH declară că tipul de echipamente radio MGU21 este în conformitate cu Directiva 2014/53/UE. Textul integral al declarației UE de conformitate este disponibil la următoarea adresă internet: (*1) Slovak: Harman Becker Automotive Systems GmbH týmto vyhlasuje, že rádiové zariadenie typu MGU21 je v súlade so smernicou 2014/53/EÚ. Úplné EÚ vyhlásenie o zhode je k dispozícii na tejto internetovej adrese: (*1) Slovenian: Harman Becker Automotive Systems GmbH potrjuje, da je tip radijske opreme MGU21 skladen z Direktivo 2014/53/EU. Celotno besedilo izjave EU o skladnosti je na voljo na naslednjem spletnem naslovu: (*1) Finnish: Harman Becker Automotive Systems GmbH vakuuttaa, että radiolaitetyyppi MGU21 on direktiivin 2014/53/EU mukainen. EU-vaatimustenmukaisuusvakuutuksen täysimittainen teksti on saatavilla seuraavassa internetosoittee…

Text truncated - open the document above for the full version.

HARMAN International. Confidential. Copyright 2020 1 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 I&K21 MGU21 HU External photos CORBU Alexandru George NEACSU Costin Alexandru 17 JULY 2020 2 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 22 I&K21 MGU21 HU –External photos FRONT 3 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 33 I&K21 MGU21 HU –External photos BACK 4 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 44 I&K21 MGU21 HU –External photos UPPER SIDE 5 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 55 I&K21 MGU21 HU –External photos LOWER SIDE 6 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 66 I&K21 MGU21 HU –External photos RIGHT / LEFT 7 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 THANK YOU

MGU21 Label status (available Certificates) – 08.10.2020:

HARMAN International. Confidential. Copyright 2020 1 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 I&K21 MGU21 HU Internal photos CORBU Alexandru George NEACSU Costin Alexandru 09 Octomber2020 2 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 22 I&K21 MGU21 HU –Internal photos MAIN BOARD 4010 3 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 33 I&K21 MGU21 HU –Internal photos MAIN BOARD 4010 4 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 44 I&K21 MGU21 HU –Internal photos MAIN BOARD –Upper side BT/WLAN connector –ST5900 USB port 2 –ST5830 APIX –ST4200 MAIN connector –ST3900 GNSS –ST3600 1GBASE-T1 –ST15600 100BASE-T1 –ST8550 AR-CAM –ST4100 5 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 55 I&K21 MGU21 HU –Internal photos MAIN BOARD –Upper side AR-CAM DeSerializer GNSS Main Power Supply IO-Controller 6 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 66 I&K21 MGU21 HU –Internal photos MAIN BOARD –Lower side BT/WLAN connector APIX3 SoCAPL Ethernet BroadR-Reach 100BASE-T1 Ethernet Gbit phy 1000BASE-T1 7 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 77 I&K21 MGU21 HU –Internal photos Main board (lower side) W/O SoCBOARD (W/O LGA module) 8 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 88 I&K21 MGU21 HU –Internal photos SoCBOARD (front & back side) 9 HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020HARMAN INTERNATIONAL. CONFIDENTIAL COPYRIGHT 2020 THANK YOU

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 66440RAN.002 2020-10-14 Test report No: NIE: 66440RAN.002 Assessment report RF EXPOSURE REPORT ACCORDING TO FCC 47 CFR Part 2.1093 ISED RSS -102 Issue 5:2015 (*) Identification of item under evaluation Automotive Infotainment System (*) Trademark BMW (*) Model and /or type reference MGU21 (*) Other identification of the product HW version: 1.3 SW version: 20w27.4-1-15 FCC ID: T8GMGU21 IC: 6434A-MGU21 (*) Features USB 2.0 (including support for Apple Devices), Bluetooth, WLAN Modul 2.4 / 5 GHz, GNSS, AR-CAM input, Video-out APIX3, CAN, 100Base-T1 and 1000Base-T1 (*) Manufacturer HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH BECKER-GOERING-STR. 16; 76307 KARLSBAD, GERMANY Test method requested, standard FCC 47 CFR Part 2.1093. Radiofrequency radiation exposure evaluation: portable devices. ISED RSS-102 Issue 5 (2015-03) – Radio Frequency Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) Summary IN COMPLIANCE Approved by (name / position & signature) Miguel Lacave Antennas Lab Manager Date of issue 2020-10-14 Report template No FAN24_02 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 66440RAN.002 Page 2 of 12 2020-10-14 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Data provided by the client .......................................................................................................... 3 Identification of the client............................................................................................................. 3 Document history ........................................................................................................................ 3 General description of the device under evaluation ..................................................................... 4 Assessment summary ................................................................................................................. 4 Evaluation Results ...................................................................................................................... 5 Appendix A: FCC RF Exposure information ................................................................................ 7 FCC SAR test exclusion considerations for portable devices ................................................. 8 Appendix B: ISED RF Exposure information ............................................................................. 11 ISED SAR test exclusion considerations .............................................................................. 12 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 66440RAN.002 Page 3 of 12 2020-10-14 Competences and guarantees In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification, S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification, S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification, S.A.U. at the time of performance of the test. DEKRA Testing and Certification, S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Assessment Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification, S.A.U. General conditions 1. This report is only referred to the item that has undergone the assessment. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification, S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification, S.A.U. and the Accreditation Bodies Data provided by the client The following data has been provided by the client: 1. Information relating to the description of the sample ("Identification of the item tested", "Trademark", "Model and/or type reference tested", “General description of the device” and "Other identification of the product"). 2. Maximum antenna gain and use distance information DEKRA Testing and Certification S.A.U. declines any responsibility with respect to the information provided by the client and that may affect the validity of results. Identification of the client HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH BECKER-GOERING-STR. 16; 76307 KARLSBAD, GERMANY Document history Report number Date Description 66440RAN.002 2020-10-14 First release DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 66440RAN.002 Page 4 of 12 2020-10-14 General description of the device under evaluation The device under evaluation …

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: (NIE) 63175RRF.006 2020-09-04 Test report No: NIE: 63175RRF.006 Test Report USA FCC Part 15.407, 15.209 CANADA RSS-247, RSS-Gen Unlicensed National Information Infrastructure (U-NII) Devices. General technical requirements. Radiated emission limits; general requirements. Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence-Exempt Local Area Network (LE-LAN) Devices. General Requirements and Information for the Certification of Radio Apparatus. (*) Identification of item tested Automotive Infotainment System (*) Trademark BMW (*) Model and /or type reference MGU21 Other identification of the product HW version: 1.3 SW version: 20w27.4-1-15 FCC ID: T8GMGU21 IC: 6434A-MGU21 (*) Features USB 2.0 (including support for Apple Devices), Bluetooth, WLAN Modul 2.4 / 5 GHz, GNSS, AR-CAM input, Video- out APIX3, CAN, 100Base-T1 and 1000Base-T1 Applicant HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH BECKER-GOERING-STR. 16; 76307 KARLSBAD, GERMANY Test method requested, standard USA FCC Part 15.407 (10-1-19) Edition: Unlicensed National Information Infrastructure (U-NII) Devices. General technical requirements. USA FCC Part 15.209 (10-1-19) Edition: Radiated emission limits; general requirements. CANADA RSS-247 Issue 2 (February 2017). CANADA RSS-Gen Issue 5 Amendment 1 (March 2019). Guidance for Compliance Testing of Unlicensed National Information Infrastructure (U-NII) Devices 789033 D02 General U-NII Test Procedures New Rules v02r01 dated Dec 14, 2017. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices. Summary IN COMPLIANCE Approved by (name / position & signature) José Carlos Luque RF Lab. Supervisor Date of issue 2020-09-04 Report template No FDT08_22 (*) “Data provided by the client” 74841983Y JOSE CARLOS LUQUE (C:A29507456) Firmado digitalmente por 74841983Y JOSE CARLOS LUQUE (C:A29507456) Fecha: 2020.09.04 10:32:11 +02'00' DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: (NIE) 63175RRF.006 Page 2 of 125 2020-09-04 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Uncertainty ................................................................................................................................. 3 Usage of samples ....................................................................................................................... 4 Test sample description .............................................................................................................. 5 Identification of the client............................................................................................................. 7 Testing period and place ............................................................................................................. 7 Document history ........................................................................................................................ 7 Environmental conditions ............................................................................................................ 7 Remarks and comments ............................................................................................................. 8 Testing verdicts ........................................................................................................................... 9 Summary .................................................................................................................................... 9 Appendix A: Test Common requirements for all bands ............................................................. 11 Appendix B: Tests results for the U-NII-1 Band 5.15 – 5.25 GHz .............................................. 33 Appendix C: Test results for the U-NII-3 Band 5.725 – 5.85 GHz .............................................. 75 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: (NIE) 63175RRF.006 Page 3 of 125 2020-09-04 Competences and guarantees DEKRA Testing and Certification is a testing laboratory accredited by the National Accreditation Body (ENAC - Entidad Nacional de Acreditación), to perform the tests indicated in the Certificate No. 51/LE 147. DEKRA Testing and Certification is a FCC-recognized accredited testing laboratory with appropriate scope of accreditation that include testing performed in this test report. DEKRA Testing and Certification is an ISED-recognized accredited testing laboratory with appropriate scope of accreditation that include testing performed in this test report. In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification at the time of performance of the test. DEKRA Testing and Certification is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or …

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: (NIE) 63175RRF.006 Page 48 of 125 2020-09-04 FCC 15.407 (a)(1)(iv). Transmitter Maximum Power Spectral Density / RSS-247 6.2.1.1. Transmitter EIRP Spectral Density FCC 15.407: The maximum power spectral density shall not exceed 11 dBm in any 1 megahertz band. If transmitting antennas of directional gain greater than 6 dBi are used, both the maximum conducted output power and the maximum power spectral density shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6 dBi. RSS-247: The e.i.r.p. spectral density shall not exceed 10 dBm in any 1.0 MHz band. RESULTS: The maximum power spectral density (PSD) was measured using the method according to point F) referencing E.2.b) (Method SA-1) and E.2.b) (Method SA-2) of Guidance 789033 D02 General UNII Test Procedures New Rules v02r01. The PSD test uses the same setup as the transmitter maximum conducted output power test. The result of the Peak PSD was measured by colocation a maker on the peak of the signal and the results are in the tables below. The e.i.r.p. levels are calculated by adding the declared maximum antenna gain (dBi). For all modes of operation, the antenna gain is < 6 dBi. Maximum Declared Antenna Gain: -5.4 dBi (antenna gain plus antenna cable loss). Mode 802.11 a20: Low Channel Middle Channel High Channel Maximum Average PSD (dBm/MHz) 0.41 0.88 -1.21 Duty Cycle Correction Factor (dB) 1.047431924 Maximum Average PSD Corrected (dBm/MHz) 1.457431924 1.927431924 -0.162568076 Maximum EIRP PSD Corrected (dBm/MHz) -3.942568076 -3.472568076 -5.562568076 Measurement uncertainty (dB) <±1.20 Mode 802.11 ac20 (VHT20): Low Channel Middle Channel High Channel Maximum Average PSD (dBm/MHz) -0.23 0.33 -1.46 Duty Cycle Correction Factor (dB) 1.101843955 Maximum Average PSD Corrected (dBm/MHz) 0.871843955 1.431843955 -0.358156045 Maximum EIRP PSD Corrected (dBm/MHz) -4.528156045 -3.968156045 -5.758156045 Measurement uncertainty (dB) <±1.20 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: (NIE) 63175RRF.006 Page 49 of 125 2020-09-04 Mode 802.11 n40 (HT40): Low Channel High Channel Maximum Average PSD (dBm/MHz) -5.27 -6.37 Duty Cycle Correction Factor (dB) 2.020944858 Maximum Average PSD Corrected (dBm/MHz) -3.249055142 -4.349055142 Maximum EIRP PSD Corrected (dBm/MHz) -8.649055142 -9.749055142 Measurement uncertainty (dB) <±1.20 Mode 802.11 ac80 (VHT80): Low Channel Maximum Average PSD (dBm/MHz) -8.21 Duty Cycle Correction Factor (dB) 3.53587835 Maximum Average PSD Corrected (dBm/MHz) -4.67412165 Maximum EIRP PSD Corrected (dBm/MHz) -10.07412165 Measurement uncertainty (dB) <±1.20 Verdict: PASS DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: (NIE) 63175RRF.006 Page 50 of 125 2020-09-04 FCC 15.407 (b)(1)(6) / RSS-247 6.2.1.2. Transmitter Out of Band Radiated Emissions SPECIFICATION: For transmitters operating in the 5.15–5.25 GHz band: all emissions outside of the 5.15–5.35 GHz band shall not exceed an EIRP of –27 dBm/MHz (68.23 dBμV/m at 3 m distance). Radiated emissions which fall in the restricted bands, as defined in §15.205(a), must also comply with the radiated emission limits specified in §15.209(a) (see §15.205(c)): Frequency Range (MHz) Field strength (μV/m) Field strength (dBμV/m) Measurement distance (m) 0.009-0.490 2400/F(kHz) - 300 0.490-1.705 24000/F(kHz) - 300 1.705 - 30.0 30 - 30 30 - 88 100 40 3 88 - 216 150 43.5 3 216 - 960 20…

Text truncated - open the document above for the full version.
