T8GNTG6NH1Automotive head unit FM AM DAB USB Bluetooth WLAN and GNSS

User Instruction Manual NTG6N Infotainment System Model: NTG6N HIGH2 , NTG6N HIGH Model: NTG6N ENTRY/MID Brand: Mercedes-Benz Version: 1.1 - english Date: 2019-04-11 4-User instruction manual-171214.docx 04-User instruction manual-190411.docx Version 1.1 Inputs for User Manual NTG6N HIGH2 NTG6N ENTRY/MID 1 Technical Information 1.1 Materials NTG6N infotainment system está em conformidade com os mais recentes lançamentos de directivas RoHS (2002/95/EC) e ELV (2000/53/EC), e também o regulamento REACH (CE) No. 1907/2006. Marcação de polímero partes acc. a VDA 260, respectivamente EN ISO 1043.Declaration of Conformity to RED regulation 1.2 Declaration of Conformity to RED regulation 2014/53/EU Declaration of Conformity (DoC) English: Hereby, Harman Becker Automotive Systems GmbH declares that the radio equipment type NTG6N HIGH2 and NTG6N ENTRY/MID is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet Address: (*1) Bulgarian: С настоящото Harman Becker Automotive Systems GmbH декларира, че този тип радиосъоръжение NTG6N HIGH2 and NTG6N ENTRY/MID е в съответствие с Директива 2014/53/ЕС. Цялостният текст на ЕС декларацията за съответствие може да се намери на следния интернет адрес: (*1) Spanish: Por la presente, Harman Becker Automotive Systems GmbH declara que el tipo de equipo radioeléctrico NTG6N HIGH2 and NTG6N ENTRY/MID es conforme con la Directiva 2014/53/UE. El texto completo de la declaración UE de conformidad está disponible en la dirección Internet siguiente: (*1) Czech: Tímto Harman Becker Automotive Systems GmbH prohlašuje, že typ rádiového zařízení NTG6N HIGH2 and NTG6N ENTRY/MID je v souladu se směrnicí 2014/53/EU. Úplné znění EU prohlášení o shodě je k dispozici na této internetové adrese: (*1) Danish: Hermed erklærer Harman Becker Automotive Systems GmbH, at radioudstyrstypen NTG6N HIGH2 and NTG6N ENTRY/MID er i overensstemmelse med direktiv 2014/53/EU. EU- overensstemmelseserklæringens fulde tekst kan findes på følgende internetadresse: (*1) German: Hiermit erklärt Harman Becker Automotive Systems GmbH, dass das Gerät mit Funkfunktion NTG6N HIGH2 and NTG6N ENTRY/MID der Richtlinie 2014/53/EU entspricht. Der vollständige Text der EU- Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: (*1) Estonian: Käesolevaga deklareerib Harman Becker Automotive Systems GmbH, et käesolev raadioseadme tüüp NTG6N HIGH2 and NTG6N ENTRY/MID vastab direktiivi 2014/53/EL nõuetele. ELi vastavusdeklaratsiooni täielik tekst on kättesaadav järgmisel internetiaadressil: (*1) 04-User instruction manual-190411.docx Version 1.1 Inputs for User Manual NTG6N HIGH2 NTG6N ENTRY/MID Greek: Με την παρούσα ο/η Harman Becker Automotive Systems GmbH, δηλώνει ότι ο ραδιοεξοπλισμός NTG6N HIGH2 and NTG6N ENTRY/MID πληροί την οδηγία 2014/53/ΕΕ. Το πλήρες κείμενο της δήλωσης συμμόρφωσης ΕΕ διατίθεται στην ακόλουθη ιστοσελίδα στο διαδίκτυο: (*1) French: Le soussigné, Harman Becker Automotive Systems GmbH, déclare que l'équipement radioélectrique du type NTG6N HIGH2 and NTG6N ENTRY/MID est conforme à la directive 2014/53/UE. Le texte complet de la déclaration UE de conformité est disponible à l'adresse internet suivante: (*1) Croatian: Harman Becker Automotive Systems GmbH ovime izjavljuje da je radijska oprema tipa NTG6N HIGH2 and NTG6N ENTRY/MID u skladu s Direktivom 2014/53/EU. Cjeloviti tekst EU izjave o sukladnosti dostupan je na sljedećoj internetskoj adresi: (*1) Italian: Il fabbricante, Harman Becker Automotive Systems GmbH, dichiara che il tipo di apparecchiatura radio NTG6N HIGH2 and NTG6N ENTRY/MID è conforme alla direttiva 2014/53/UE. Il testo completo della dichiarazione di conformità UE è disponibile al seguente indirizzo Internet: (*1) Latvian: Ar šo Harman Becker Automotive Systems GmbH deklarē, ka radioiekārta NTG6N HIGH2 and NTG6N ENTRY/MID atbilst Direktīvai 2014/53/ES. Pilns ES atbilstības deklarācijas teksts ir pieejams šādā interneta vietnē: (*1) Lithuanian: Aš, Harman Becker Automotive Systems GmbH, patvirtinu, kad radijo įrenginių tipas NTG6N HIGH2 and NTG6N ENTRY/MID atitinka Direktyvą 2014/53/ES. Visas ES atitikties deklaracijos tekstas prieinamas šiuo interneto adresu: (*1) Hungarian: Harman Becker Automotive Systems GmbH igazolja, hogy a NTG6N HIGH2 and NTG6N ENTRY/MID típusú rádióberendezés megfelel a 2014/53/EU irányelvnek. Az EU-megfelelőségi nyilatkozat teljes szövege elérhető a következő internetes címen: 2014.5.22. L 153/104 Az Európai Unió Hivatalos Lapja HU: (*1) Maltese: B'dan, Harman Becker Automotive Systems GmbH, niddikjara li dan it-tip ta' tagħmir tar-radju NTG6N HIGH2 and NTG6N ENTRY/MID huwa konformi mad-Direttiva 2014/53/UE. It-test kollu tad- dikjarazzjoni ta' konformità tal-UE huwa disponibbli f'dan l-indirizz tal-Internet li ġej: (*1) Dutch: Hierbij verklaar ik, Harman Becker Automotive Systems GmbH, dat het type radioapparatuur NTG6N HIGH2 and NTG6N ENTRY/MID conform is met Richtlijn 2014/53/EU. De volledige tekst van de EU- conformiteitsverklaring kan worden geraadpleegd op het volgende internetadres: (*1) Polish: Harman Becker Automotive Systems GmbH niniejszym oświadcza, że typ urządzenia radiowego NTG6N HIGH2 and NTG6N ENTRY/MID jest zgodny z dyrektywą 2014/53/UE. Pełny tekst deklaracji zgodności UE jest dostępny pod następującym adresem internetowym: (*1) Portuguese: O(a) abaixo assinado(a) Harman Becker Automotive Systems GmbH declara que o presente tipo de equipamento de rádio NTG6N HIGH2 and NTG6N ENTRY/MID está em conformidade com a Diretiva 2014/53/UE. O texto integral da declaração de conformidade está disponível no seguinte endereço de Internet: (*1) 04-User instruction manual-190411.docx Version 1.1 Inputs for User Manual NTG6N HIGH2 NTG6N ENTRY/MID Romanian: Prin prezenta, Harman Becker Automotive Systems GmbH declară că tipul de echipamente radio NTG6N HIGH2 and NTG6N ENTRY/MID este în conformitate cu Directiva 2014/53/UE. Textul integral al declarației UE de…

Text truncated - open the document above for the full version.

T8GNTG6EM FCC Confidentiality Request 171106 Geschäftsführung: Dr. Udo Hüls, Michael Mauser Vorsitzender des Aufsichtsrats: Dr. Frank Groth Sitz der Gesellschaft: Karlsbad | Amtsgericht Mannheim: HRB-Nr. 361395 Karlsbad, 2021-04-26 Harman Becker Automotive Systems GmbH | Postfach 2260 | 76303 Karlsbad DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía C/ Severo Ochoa 2 & 6 29590 Campanillas Málaga, España Ref: Confidentiality request for FCC ID: T8GNTG6NH1 To whom it may concern: Pursuant to §0.457(d)(1)(ii) and §0.459 of the Commission’s Rules (47 C.F.R.) and §552 (b)(4) of the Freedom of Information Act, Harman Becker Automotive Systems hereby request requests that a part of the subject FCC application be held confidential to avoid release of sensitive information of the product to the public. For the product stated above, we request that the following information be withheld from public disclose: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Internal Photos Short Term Permanent Operation Description Short Term Permanent Parts List & Placement/BOM Short Term Permanent Schematics Short Term Test Setup Photos Short Term User’s Manual Permanent Confidentiality: The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to us and provide unjustified benefits to our competitors. Short-Term Confidentiality: We hereby request short-term confidentiality for the product stated above to avoid premature release of sensitive information prior to marketing or release of the product to the public. Release date of short term confidentiality is: 45 days from grant date marked 90 days from grant date marked 135 days from grant date marked 180 days from grant date marked Specific date: We are also aware that we are responsible to notify DEKRA in the event information regarding the product or the product is made available to the public. DEKRA will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, Mr. Stefan Blaschek, Regulatory Compliance Expert Karlsbad 26.04.2021 (Place) (Date) (Signature) Mr. Simon Voegele, Regulatory Compliance Expert Karlsbad 26.04.2021 (Place) (Date) (Signature) H ARM AN AUTOMOTIVE DIVISION HAR MAN BE CKER AUTO MOT IVE S YSTE MS G MBH BECKER-G OER ING -STRASSE 16 76307 KARLSBAD, GE R MAN Y TEL: +49 7248 71 3667 FA X: +49 7248 71 4667 E-MA IL: S IMO N .VOE GE LE@HA R MAN .CO M

T8GNTG6EM _ FCC Agent letter_signed 171106 Geschäftsführung: Dr. Mann Vorsitzender des Aufsichtsrats: Dr. Frank Groth Sitz der Gesellschaft: Karlsbad | Amtsgericht Mannheim: HRB-Nr. 361395 Karlsbad, 2021-04-26 Harman Becker Automotive Systems GmbH | Postfach 2260 | 76303 Karlsbad DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía C/ Severo Ochoa 2 & 6 29590 Campanillas Málaga, España Ref: Agent letter for FCC ID: T8GNTG6NH1 T8GNTG6NH2 T8GNTG6NEM We, Harman Becker Automotive Systems Becker-Goering-str. 16; 76307 Karlsbad, Germany hereby authorize DEKRA Testing and Certification, S.A.U., Parque Tecnológico de Andalucía C/ Severo Ochoa nº 2 29590 Campanillas – Malaga Spain Mr. Ignacio Colilles, e-mail: [email protected], Phone: +34 952 61 94 05 to act as our agent in the preparation of this application for equipment certification, including the signing of all documents relating to these matters. The present authorization considers the development of documents on behalf of the client, written under his own letterhead and related to the necessary information tobe provided on his behalf to complete the certification process. We also hereby certify that neither we nor any party to this application are subject to a denial of U.S. Federal benefits, which include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862 because of conviction for possession or distribution of controlled substance. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by DEKRA Testing and Certification, S.A.U., still resides with us. This agreement expires one year from the current date. Regards i.V. i.V. Stefan Blaschek Regulatory Compliance Management Harman Infotainment Division Harman Becker Automotive Systems GmbH Becker-Göring-Straße 16 76307 Karlsbad Phone: +49 7248 71 3382 Fax: +49 7248 71 3802 Mobile: +49 172 94 191 49 Email : [email protected] Web: www.harman.com Simon Vögele Regulatory Compliance Management Harman Infotainment Division Harman Becker Automotive Systems GmbH Becker-Göring-Straße 16 76307 Karlsbad Phone: +49 7248 71 3667 Fax: +49 7248 71 3802 Mobile: +49 175 4366188 Email : [email protected] Web: www.harman.com H ARM AN AUTOMOTIVE DIVISION HAR MAN BE CKER AUTO MOT IVE S YSTE MS G MBH BECKER-G OER ING -STRASSE 16 76307 KARLSBAD, GE R MAN Y TEL: +49 7248 71 3382 FA X: +49 7248 71 4667 E-MA IL: STE FAN .BLASCHEK @H AR MA N.C O M

ISED Confidentiality request signed 171106 Vor sitzender des Aufsichtsrats: Dr. Frank Groth Sitz der Gesellschaft: Karlsbad | Amtsgericht Mannheim: HRB-Nr. 361395 Karlsbad, 2021-03- 22 Harman Becker Automotive Systems GmbH | Postfach 2260 | 76303 Karlsbad DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía C/ Severo Ochoa 2 & 6 29590 Campanillas Málaga, España Ref: sDoC declaration letter for equipment with FCC ID: T8GNTG6NH1 Pursuant to §15.101 of the Commission’s Rules (47 C.F.R.), HARMAN BECKER AUTOMOTIVE SYSTEMS GmbH hereby declare that the device above mentioned is classified under the following equipment class/classes: JAB Part 15 Class B Digital Device JAD Part 15 Class A Digital Device JAV Other Non-Digital SDoC Devices JBP Part 15 Class B Computing Device/Personal Computer JBC Part 15 Class B Computing Device/Personal Computer CXX Communications Rcvr for use w/ licensed Tx and CBs CRR Superregenerative Receiver CYY Communications Receiver used w/Pt 15 Transmitter HID Part 15 TV Interface Device And will follow the Authorization procedure Supplier’s Declaration of Conformity prior to the initiation of marketing. Sincerely, i.V.i. V. Stefan Blaschek Regulatory Compliance Management Ha rman Infotainment Division Harman Becker Automotive Systems GmbH Becker-Göring-Straße 16 76307 Karlsbad Phone: +49 7248 71 3382 Fax: +49 7248 71 3802 Mobile: +49 172 94 191 49 Email: [email protected] Web: www.harman.com Simon Vögele Regulatory Compliance Management Harman Infotainment Division Harman Becker Automotive Systems GmbH Becker-Göring-Straße 16 76307 Karlsbad Phone: +49 7248 71 3667 Fax: +49 7248 71 3802 Mobile: +49 175 4366188 Email: [email protected] Web: www.harman.com H ARM AN AUTOMOTIVE DIVISION HAR MAN BE CKER AUTO MOT IVE S YSTE MS G MBH BECKER-G OER ING -STRASSE 16 76307 KARLSBAD, GE R MAN Y TEL: +49 7248 71 3667 FA X: +49 7248 71 4667 E-MA IL: S IMO N .VOE GE LE@HA R MAN .CO M

Geschäftsführung: Holger Mann, Michael Mauser Vorsitzender des Aufsichtsrats: Dr. Frank Groth Sitz der Gesellschaft: Karlsbad | Amtsgericht Mannheim: HRB-Nr. 361395 Harman Becker Automotive Systems GmbH | Postfach 2260 | 76303 Karlsbad FCC - Wi-Fi Operations declaration Ref: Attestation letter regarding WIFI without radar detection capability for: Type of equipment: automotive headunit Brand name: Mercedes-Benz FCC ID: T8GNTG6NH2 / T8GNTG6NH1 / T8GNTG6NEM IC ID: 6434A-NTG6NH2 / 6434A-NTG6NH1 / 6434A-NTG6NEM Dear Ladies and Gentleman, we hereby declare that above mentioned device is programmed to operate only in the following frequencies: 2.4 GHz Band, Channels 1-11, Frequency Range 2.412 - 2.462 GHz The final user in North America cannot use the channels 12 and 13, and cannot change the configuration. 5GHz Band, Channels 36-48, Frequency Range 5.180 – 5.240 GHz -For IEEE 802.11a, all the channels operates in 20MHz -For IEEE 802.11n, all the channels operates in 20MHz and 40MHz -For IEEE 802.11ac, all the channels operates in 20MHz, 40MHz and 80MHz. Channels 149-165, Frequency Range 5.745 – 5.825 GHz -For IEEE 802.11a, all the channels operates in 20MHz -For IEEE 802.11n, all the channels operates in 20MHz and 40MHz -For IEEE 802.11ac, all the channels operates in 20MHz, 40MHz and 80MHz. Operation modes, DFS and TPC This device does not support DFS, and limited to the channels listed above in Client and Access point mode, thus the criteria for FCC are the same. Future changes in this device will not change theses operational characteristics, in any mode of operation. As client device, this product does not initiate transmission of any probes, beacons and does not initiate Ad-Hoc operations when not associated with and under the control of a certified master device, according to Section 15.202 of FCC rules. To whom it may concern H ARM AN AUTOMOTIVE DIVISION HAR MAN BE CKER AUTO MOT IVE S YSTE MS G MBH BECKER-G OER ING -STRASSE 16 76307 KARLSBAD, GE R MAN Y TEL: +49 7248 71 3382 FA X: +49 7248 71 4667 E-MA IL: STE FAN .BLASCHEK @H AR MA N.C O M Karlsbad, 2021.04.26 Seite 2 / 4 Software security description per KDB 594280 D02: General Description 1. Describe how any software/firmware updates for elements than can affect the device’s RF parameters will be obtained, downloaded, validated and installed. For software that is accessed through manufacturer’s website or device’s management system, describe the different levels of security as appropriate. NTG6N will be installed within car by OEM customer. Service (as SW updates) will be executed by car service garages or Over-The- Air from OEM customer server. End customer has no possibility to do SW update. Additionally, all SW update packages are signed and the signature is verified on the system before new SW can be installed. 2. Describe the RF parameters that are modified by any software/firmware without any hardware changes. Are these parameters in some way limited such that any other software/firmware changes will not allow the device to exceed the authorized RF characteristics? RF Parameters are determined by the binary image. The end user cannot modify RF parameters. 3. Describe in detail the authentication protocols that are in place to ensure that the source of the RF-related software/firmware is valid. Describe in detail how the RF-related software is protected against modification. All software is signed by using public-private key signatures. No software is installed without valid signatures. The installed SW is verified on each boot using the Secure Boot mechanism which ensures that the SW has not been altered/changed. No port available/open to install any software or do changes on the existing one. Seite 2 / 4 4. Describe in detail any encryption methods used to support the use of legitimate RF- related software/firmware. The SW is checked on each startup using Secure Boot with digital signatures and a fused public key (not changeable). Further parts are integrity protected using dm-verity. The update/installation data of RF parameters is encrypted and secure by the secure SW update process. Changes in the RF parameters at runtime are only done by SW covered by secure boot. 5. For a device that can be configured as a master and client (with active or passive scanning), explain how the device ensures compliance for each mode? In particular if the device acts as master in some band of operation and client in another; how is compliance ensured in each band of operation? Device is master and Client. By configuration file (clm/blob) which is written during production and protected it is ensured that only allowed channels and modes are used. EndCustomer has no possibility to change that configuration file. Third-Party Access Control 1. Explain if any third parties have the capability to operate a U.S.-sold device on any other regulatory domain, frequencies, or in any manner that may allow the device to operate in violation of the device’s authorization if activated in the U.S. Not possible for 3rd parties to load any software or drivers. Country settings can only be changed by Daimler and authorized service garages. System is bind to car and cannot be used outside its regulatory domain. Option is not provided for any third party usage. 2. Describe, if the device permits third-party software or firmware installation, what mechanisms are provided by the manufacturer to permit integration of such functions while ensuring that the RF parameters of the device cannot be operated outside its authorization for operation in the U.S. In the description include what controls and/or agreements are in place with providers of third-party functionality to ensure the devices’ underlying RF parameters are unchanged and how the manufacturer verifies the functionality. Not possible for 3rd parties to load any software or drivers. Seite 2 / 4 3. For Certified Transmitter modular devices, describe how the module grantee ensures that host manufacturers fully …

Text truncated - open the document above for the full version.

@ Mercedes-Benz A 177 900 XX XX Model: NTGGN HIGH2 LU STG VST HEADUNIT A-HIGH US Model: Version: Type No: WLAN-MAC t: NTGGN HIGH USA HB Mxxx 746FF78AOFE3 E22.0 AGREE PAR'L ANRT MAROC 111111111111111111 Numero d'agrément: MR 20721 ANRT 2019 21 / 20 IC: 6434A-NTG6NH1 Date of Manufacture: 2021 / 05 / 01 [ HOOOOJuép,rrA.,PCf' '"' l E C : 994 CM II T _!Q_: 2019A J 10877 ,silir,nce<ruC""-<at<!,confO,,ti THE PRODUCT COMPU ES WITH DHHS RULES 21 CFR SUBCHAPTER J APPLICABLE TO THE DATE OF MANUFACTURE. FCC ID: TSGNTG6NH1 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS S UBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE �IUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNOESIRE D OPERATION. [ R ESO [ t ? • CC XXxxYYyyy Z zW [ � 1�11IZICTA 12V ¡¡.,¡¡¡-¡¡¡; 3,SA ZMBIZICTNTN2019ll/126 loi1..._.lot i'f'A ()019. (érA � [TPJ � iJ ti NTC Type accepted No,;E$D-1920372C C N € C -23093 TRA REGISTERED No: ER74188/19 DEALER No: 2019--0 OMAN-TRA TRA/TA-Rn929/19 0172338 RCPMENT19-0874 NOM f!t NVCE H2}Radio· 0028019/10 63774/SDPPl/2019 7163 HORaclo Ted'VlOlogynm� �r!ICenSE-;tm IBIQlity txgUCO!porat!orl U.S. a'l(I F«"elgn P�enr.&. for p.lte'IIS see rrt;r.HGts.<:Ol'l\l)J!ms . HD Raclo <f'ICI trie HD, HD Rad:o. and "AAC' 1(9)6 are tegl5tele0 tra0:n'.ark$ or · � Of IBlquty Clgta! COrpcra!IOl'l lntl'le 1.Ktt.:<1 StaK ana.rorotte COll'l!r!e$._ HARMAN BECKER AUTOMOTIVE SYSTEMS Becker-Goring-Strasse 16 C.OM?c5c...'l &no USé Of ini$ cornmt.11\iCalions • E " · • L.. _equ;_ ·.-._ .. M _ ;,_p""' _ º_"'_"'_ ... _._�·_"" _ _, 1 e A . . · s A r A-2019114 04 COO'.nunit.:1!iort$ cocñssi::o "APPROVED" C I R I IN I : I H I BMxx l x l H l o l o l o l oo l 1 1 7 11 I I I I soé�A/TA/2020/5398 111111111 Ij����[�!�1-19.0797s Complies with IMDA Standards 51-70317 (NZG6N H I GH-IL) Xlil n11�¡7nil Tl\!Jn 'nu •i.,1n1n< 11\U'N 190n 1'<'11 l'\!,,.-)Oil '1w n•11¡7n;, illOll<il n1'< cr'?nil"l 1101'< inH 1 1)0 •u·�'?) 1::1. n1\!J:V'1 76307 Karlsbad, Germany Ma.nufactured in Hungary R.C-T8G­ NTG6NH N2945-19

INTERNAL PICTURES Model: NTG6N HIGH US M249 Brand: Mercedes‐Benz Version: D9 Type: M249 PCBA 4010 MAIN BB D9 M248 WLAN modules (see next page) BT/WLAN‐Module with shielding plate (20x20mm) without shielding plate

CSB M128 4065 CSB US top/bot PCBA 4110 MAIN MMB D9 M127

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67713RAN.002A1 2021-04-28 Test report No: NIE: 67713RAN.002A1 Assessment report RF EXPOSURE REPORT ACCORDING TO FCC 47 CFR Part 2.1093 (*) Identification of item under evaluation Automotive infotainment System (*) Trademark Mercedes-Benz (*) Model and /or type reference NTG6N HIGH (*) Other identification of the product HW version: D9 SW version: E870 FCC ID: T8GNTG6NH1 IC: 6434A-NTG6NH1 (*) Features FM, AM, DAB, TV, USB, Bluetooth, WLAN, GPS (*) Manufacturer HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH BECKER-GOERING-STR. 16, 76307 KARLSBAD, GERMANY Test method requested, standard FCC 47 CFR Part 2.1093. Radiofrequency radiation exposure evaluation: portable devices Summary IN COMPLIANCE Approved by (name / position & signature) Miguel Lacave Antennas Lab Manager Date of issue 2021-04-28 Report template No FAN24_02 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67713RAN.002A1 Page 2 of 10 2021-04-28 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Data provided by the client .......................................................................................................... 3 Identification of the client............................................................................................................. 3 Document history ........................................................................................................................ 3 Appendix A: FCC RF Exposure assessment result ..................................................................... 4 General description of the device under evaluation ................................................................ 5 Assessment summary ............................................................................................................ 5 Evaluation Results .................................................................................................................. 6 Appendix B: FCC RF Exposure information ................................................................................ 7 FCC SAR test exclusion considerations for portable devices ................................................. 8 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67713RAN.002A1 Page 3 of 10 2021-04-28 Competences and guarantees In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification, S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification, S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification, S.A.U. at the time of performance of the test. DEKRA Testing and Certification, S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Assessment Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification, S.A.U. General conditions 1. This report is only referred to the item that has undergone the assessment. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification, S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification, S.A.U. and the Accreditation Bodies Data provided by the client The following data has been provided by the client: 1. Information relating to the description of the sample ("Identification of the item under evaluation", "Trademark", "Model and/or type reference tested" and “Other identification of the product”). 2. Maximum antenna gain and use distance information. DEKRA Testing and Certification S.A.U. declines any responsibility with respect to the information provided by the client and that may affect the validity of results. Identification of the client HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH BECKER-GOERING-STR. 16, 76307 KARLSBAD, GERMANY Document history Report number Date Description 67713RAN.002 2021-04-08 First release 67713RAN.002A1 2021-04-28 Second release. Updated FCC ID and IC. DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67713RAN.002A1 Page 4 of 10 2021-04-28 Appendix A: FCC RF Exposure assessment result DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 67713RAN.002A1 Page 5 of 10 2021-04-28 General description of the device under evaluation The device under evaluation consists of an automotive head unit to be installed in cars with the following feature…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: (NIE) 66084RRF.018A1 2021-04-26 Test report No: NIE: 66084RRF.018A1 Test Report USA FCC Part 15.247, 15.209 CANADA RSS-247, RSS-Gen (*) Identification of item tested Automotive infotainment System (*) Trademark Mercedes-Benz (*) Model and /or type reference NTG6N HIGH Other identification of the product HW version: D9 SW version: E870 FCC ID: T8GNTG6NH1 IC: 6434A-NTG6NH1 (*) Features FM, AM, DAB, TV, USB, UFS, Bluetooth, WLAN, GPS Applicant HARMAN BECKER AUTOMOTIVE SYSTEMS GMBH BECKER-GOERING-STR. 16, 76307 KARLSBAD, GERMANY Test method requested, standard USA FCC Part 15.247 (10-1-19) Edition: Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz. USA FCC Part 15.209 (10-1-19) Edition: Radiated emission limits; general requirements. CANADA RSS-247 Issue 2 (February 2017). CANADA RSS-Gen Issue 5 Amendment 1 (March 2019). Guidance for Performing Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid Systems Devices Operating Under Section 15.247 of the FCC Rules. 558074 D01 Meas Guidance v05r02 dated April 2, 2019. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices. Summary IN COMPLIANCE Approved by (name / position & signature) José Carlos Luque RF Lab. Supervisor Date of issue 2021-04-26 Report template No FDT08_23 (*) “Data provided by the client” Firmado digitalmente por 74841983Y JOSE CARLOS LUQUE (C:A29507456) Fecha: 2021.04.26 16:26:44 +02'00' DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: (NIE) 66084RRF.018A1 Page 2 of 119 2021-04-26 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Uncertainty ................................................................................................................................. 3 Data provided by the client .......................................................................................................... 3 Usage of samples .........................................................................................…

Text truncated - open the document above for the full version.
