T94XINBOND070910Wireless Mouse

JD-9318 Optical wireless mini Mouse user manul This is one of our latest wireless mice, which the working frequency is 27MHz. It has exquisite appearance and extremely comfortable sense of touch, it is designed for laptop. You can free from the mouse with cable and enjoy your working with any sitting position. It facilitates to enhance your working efficiency and enjoy your wonderful life. Feature description 1． Radio frequency 27MHz, enjoy your freely wireless space . 2． It has 256ID code, there is no interference even many mice being used at the same time. 3． Use the most advanced IC ,800DPI, accurate position, free yourself on internet 4． Auto-sleeping save power function, batteries life be prolonged. 5． Ergonomic Design, Novel, exquisite appearance. 6． Big space for thumb finger of left hand, sand-blasting anti-slip finishing, comfortable feeling. 7． Compared with common mouse，two buttons are added on the left side of mouse（forward、 backward button），this greatly improve your working efficiency。 System Compatibility 1．Computer model: IBM PC/AT Compatible, Power Macintosh 2．Operation system : Windows 98se/ME/ 2000/XP/Vista 3．Interface : USB Step of charging 1． USB wire of mouse connect to port of computer to start charging。 2． In charging，the blue indicator under roller will light on, and it will close when charge is finished。 KEY4 and KEY5 function description 1． KEY4is forward button。 2． KEY5 is backward button。 The step of Installing Battery 1. Prepare for two PCS new AAA alkaline batteries 2. Please insert the batteries correctly according to the polarity marks of the battery grooves.（Do not insert the batteries in reverse，otherwise damage the mouse） 3. Push the upper cover from back to front，when you hear “crack” sound which shows the upper cover is locked successfully。。 The Steps of Installing receiver 1． Insert directly receiver into USB port of computer case. 2． If you use desk PC, there is a little far between the case and your working surface, suggest you use an extended USB cable to connect your case and the receiver, so you can place the receiver on your working surface conveniently. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. KEY4 KEY5 Place for thumb finger，sand blasted, anti-slip，good feeling

SHENZHEN XINBOND TECHNOLOGY CO., LTD Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. { SHENZHEN XINBOND TECHNOLOGY CO., LTD } would like the following documents regarding this submission for FCC ID: T94 XINBOND070910 to be kept confidential. Document: {Operational Description, Block Diagram and Schematics }. The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely,

ShenZhen Xinbond Technology Co.,Ltd Statement We Shenzhen Xinbond technology Co.,Ltd would like to have the test report of the certification with FCC ID: T94XINBOND070910 (Date:09/19/2007) superseeded, because we have new test report containing 2 more models(models NO:. F21-M888D/JD-9268), The new models are identical with the original one. Your assistance on this matter is highly appreciated. Yours sincerely, Company Name: ShenZhen Xinbond Technology Co.,Ltd Signature:

FCC ID: T94XINBOND070910 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Proposed Label Location on EUT FCC ID Label Location

ISO/IEC17025 Accredited Lab. Report No: FCC0708215 File reference No: 2007-09-12 Applicant: Shenzhen Xinbond Technology Co., Ltd Product: Wireless Mouse Model No: JD-9318 Brand Name: N/A Test Standards: FCC Part 15 Subpart C, Paragraph 15.227 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.4&FCC Part 15 Subpart C, Paragraph 15.227 regulations for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: Sep, 12,2007 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TECHNOLOGY CONSULTING CO LTD East 5/Block 4, Anhua Industrial Zone, No.8,Tairan Rd. CheGongMiao, FuTian District, Shenzhen, CHINA. Tel (755) 83448688 Fax (755) 83442996 Report No: 0708215 Page 2 of 22 Date: 2007-09-12 TEST REPORT The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the Shenzhen Timeway Technology Consulting Co .,Ltd. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the Shenzhen Timeway Technology Consulting co .,Ltd to his customer. Supplier or others persons directly concerned. Shenzhen Timeway Technology Consulting co .,Ltd will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The Shenzhen Timeway Technology Consulting co .,Ltd reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meets with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:1999 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 899988 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.:899988. IC- Registration No.: IC5205 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. The acceptance letter from the IC is maintained in our files. Registration No.: IC 5205. Report No: 0708215 Page 3 of 22 Date: 2007-09-12 TEST REPORT The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the Shenzhen Timeway Technology Consulting Co .,Ltd. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the Shenzhen Timeway Technology Consulting co .,Ltd to his customer. Supplier or others persons directly concerned. Shenzhen Timeway Technology Consulting co .,Ltd will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The Shenzhen Timeway Technology Consulting co .,Ltd reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration.................................................................................................... 4 1.6 Test Uncertainty.................................................................................................5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 5 3.0 Technical Details............................................................................................. 7 3.1 Summary of Test Results..................................................................................... 7 3.2 Test Standards.................................................................................................. 7 4.0 EUT Modification............................................................................................. 7 5.0 Power Line Conducted Emission Test...................................................................... 8 5.1 Schematics of the Test........................................................................................ 8 5.2 Test Method and Test Procedure............................................................................ 8 5.3 Configuration of the EUT.................................................................................... 8 5.4 EUT Operating Condition...........................................…
