TA8AKRC161457-1Remote Radio Unit supports LTE

Ericsson Internal EXHIBIT 13 1 (1) Prepared (also subject responsible if other) No. EHUAYAN TA8AKRC161457-1 Approved Checked Date Rev Reference CBC/XRV/D Hua Yang 2014-11-05 A Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Attention: Equipment Authorization Branch TUV SUD BABT Octagon House, Concorde Way Fareham, Hampshire, PO15 5RL United Kingdom November 05, 2014 Subject: Certification for FCC ID: TA8AKRC161457-1 To Whom It May Concern: Ericsson AB requests a Grant of Certification (Type Acceptance) for the above mentioned FCC Identifier. This base station transceiver (Remote Radio Unit – RRUS 11 B26B) is designed for use in LTE cellular telephone system. The transmitter will operate from 859 MHz to 869 MHz. The receiver circuit supports 814 MHz to 824 MHz. It supports Channel Bandwidth of 1.4, 3, 5 and 10 MHz. This base station transceiver (RRU) supports modulation type QPSK, 16QAM and 64QAM. The base station transceiver (RRU) operates in the Advanced Wireless services band as per 47 CFR Part 90. It meets the requirements of Third Generation Partnership Project (3GPP) for the Universal Mobile Telephone System (UMTS 3G) mobile standard (cellular telephone system) for operation in LTE cellular system. This base station transceiver (RRUS 11 B26B) will in normal mode operates at a nominal power out of 10, 20, 30 and 40 watts at each output connector. The Exhibit 8 user manuals submitted with this application is generic and may cover multiple products. This application is only valid for the model specified in the Exhibit 12 circuit description. Ericsson AB requests confidentiality under CFR 0.459 according to attached letter. We further certify that the applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to section 5301 of the Anti-Drug abuse Act of 1988, 21 U.S.C. Section 862. Ericsson AB accept by this request the agreement set out in the document "Bilaga SPCR 125 -Avtal om marknadskontroll för radioutrustning certifierad för USA-marknaden". If additional information is needed, please contact me on the below listed number. Hua Yang Staff Engineer, Regulatory Programs Ericsson AB Isafjordsgatan 10 Kista, SE-164 80 Stockholm Sweden Telephone No.: +86 10 8476 7133 e-mail: [email protected]

Exhibit 2 FCC Authorization Letter

Ericsson Internal EXHIBIT 13 1 (2) Prepared (also subject responsible if other) No. EHUAYAN TA8AKRC161457-1 Approved Checked Date Rev Reference CBC/XRV/D Hua Yang 2014-12-03 A Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Attention: Equipment Authorization Branch TUV SUD BABT Octagon House, Concorde Way Fareham, Hampshire, PO15 5RL United Kingdom December 03, 2014 Subject: Request for Confidentiality To Whom It May Concern: We, Ericsson AB, hereby request that the Exhibits/Items listed below be withheld from public inspection in accordance with Sections 0.457 and 0.459 of the Commission’s Rules. This due to the following reasons: Ericsson Base Stations (BS) are designed strictly based on the technical specifications of the international project 3GPP (the 3rd Generation Partnership Project). The competition in this field is very intense and a less advanced solution/design could get an unfair advantage by accessing the information as listed below from common domain. As we believe that we have implemented groundbreaking solutions and designs into our recent BS/Radio Unit (RU)/Radio Dot (RD) compared to the previous BS/RU/RD, the listed Exhibits/Items need to be protected from disclosure to our competitors in the industry. As the FCC records have in-depth information and a very wide distribution, we believe that you can understand our concerns. We are strong in our belief that all vendors in the industry need to compete by their own merits. We regard these Exhibits/Items to be our intellectual property and therefore as confidential information. There are advanced technical and design solutions/information in the Exhibits/Items, as mentioned above, that we regard as Ericsson proprietary, with actual and potential patents pending. The information can be advantageous to our competitors as well as sources seeking ways to hack past the built in security functionality. These solutions or information thereof are not accessible even for our customers or partners unless non-disclosure agreements for particular item(s) have been signed. Confidential product information can be found in, but not necessarily limite d to, internal photos of the BS, RU and the RD, block diagrams, schematics diagrams, and parts lists as well as certain documents, such as the user’s manuals. Those documents can only be accessible by the customers who purchase our BS/RU/RD and accept the conditions and therefore are provided with unique information access tools. EXHIBIT 4 Block Diagrams EXHIBIT 5 Schematic Diagrams EXHIBIT 8 Manuals EXHIBIT 9 Internal Photos of Radio Unit EXHIBIT 10 Parts List EXHIBIT 12 Technical Circuit Description If additional information is needed, please contact me on the below listed number. Ericsson Internal EXHIBIT 13 2 (2) Prepared (also subject responsible if other) No. EHUAYAN TA8AKRC161457-1 Approved Checked Date Rev Reference CBC/XRV/D Hua Yang 2014-12-03 A Hua Yang Staff Engineer, Regulatory Programs Ericsson AB FCC Registration Number (FRN): 0013476155 Isafjordsgatan 10 Kista, SE-164 80 Stockholm Sweden Telephone No.: +86 10 84767133 e-mail: [email protected]

Date Page Exhibit 3 External photos 11/18/2014 1(3) FCC ID: TA8AKRC161457-1 Front side Rear side Date Page Exhibit 3 External photos 11/18/2014 2(3) FCC ID: TA8AKRC161457-1 Left side Right side Date Page Exhibit 3 External photos 11/18/2014 3(3) FCC ID: TA8AKRC161457-1 Top side Bottom side

Date Page Exhibit 1 ID label and placement 11/7/2014 1( 1) FCC ID: TA8AKRC161457-1 The ID label is located under the solar shield. FCC ID: TA8AKRC161457-1

Document 75928436 Report 01 Issue 1 November 2014 Report On FCC Testing of the Ericsson AB (800MHz) RRUS 11 B26B KRC 161 457/1 Remote Radio Unit In accordance with FCC CFR 47 Part 90 COMMERCIAL-IN-CONFIDENCE FCC ID: TA8AKRC161457-1 PREPARED BY APPROVED BY DATED 17 November 2014 Guiying Zhao Steve Scarfe Project Engineer Authorised Signatory Document 75928436 Report 01 Issue 1 Page 1 of 70 CONTENTS Section Page No 1 REPORT INFORMATION ............................................................................................................ 2 1.1 Report Details ................................................................................................................................ 3 1.2 Brief Summary of Results .............................................................................................................. 4 1.3 Configuration Description .............................................................................................................. 5 1.4 Declaration of Build Status ............................................................................................................ 6 1.5 Product Information ....................................................................................................................... 7 1.6 Test Setup ..................................................................................................................................... 8 1.7 Test Conditions ............................................................................................................................ 10 1.8 Deviation From The Standard ..................................................................................................... 10 1.9 Modification Record ..................................................................................................................... 10 1.10 Alternative Test Site ..................................................................................................................... 10 2 TEST DETAILS .......................................................................................................................... 11 2.1 Maximum Output Power - Conducted ......................................................................................... 12 2.2 Occupied Bandwidth .................................................................................................................... 18 2.3 Emission Masks ........................................................................................................................... 29 2.4 Radiated Spurious Emissions ...................................................................................................... 46 2.5 Conducted Spurious Emissions ................................................................................................... 52 2.6 Frequency Stability ...................................................................................................................... 63 3 TEST EQUIPMENT USED ......................................................................................................... 65 3.1 Test Equipment Used .................................................................................................................. 66 3.2 Measurement Uncertainty............................................................................................................ 68 4 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................ 69 4.1 Accreditation, Disclaimers and Copyright .................................................................................... 70 Document 75928436 Report 01 Issue 1 Page 2 of 70 SECTION 1 REPORT INFORMATION Document 75928436 Report 01 Issue 1 Page 3 of 70 1.1 REPORT DETAILS The information contained in this report is intended to show verification of the Ericsson RRUS 11 B26B KRC 161 457/1 to the requirements of FCC CFR 47 Part 90. Testing was carried out in support of an application for Grant of RRUS 11 B26B KRC 161 457/1 in LTE mode. Manufacturer Ericsson AB Address Isafjordsgatan 10 SE-164 80 Stockholm 16480 Sweden Product Name RRUS 11 B26B Product Number KRC 161 457/1 Serial Number(s) CB4V574403 LTE Software Version CXP102051/21 Rev R26AK Hardware Version R1A Number of Sample Tested 1 Test Specification/Issue/Date FCC CFR 47 Part 90: 2013 Start of Test 28 October 2014 Finish of Test 05 November 2014 Name of Engineer(s) Guiying Zhao Related Document(s) ANSI C63.4: 2009 ANSI/TIA-603-C-2004 FCC CFR 47 Part 2: 2013 Document 75928436 Report 01 Issue 1 Page 4 of 70 1.2 BRIEF SUMMARY OF RESULTS A brief summary of results for each configuration, in accordance with FCC CFR 47 Part 2, Part 90 is shown below. Section Spec Clause Test Description Result Part 2 Part 90 2.1 2.1046 90.635 Maximum Output Power – Conducted Pass - - 90.635 Effective Radiated Power (ERP) N/A 1 2.2 2.1049 (h) - Occupied Bandwidth 1 Pass 2.3 2.1051 90.691 Emission Masks Pass 2.4 2.1053 90.691 Radiated Spurious Emissions Pass 2.5 2.1051 90.691 Conducted Spurious Emissions Pass 2.6 2.1055 90.213 Frequency Stability Pass - - 15.111 Receiver Spurious Emissions N/A 2 N/A 1 – Not Applicable, due to no Integral Antenna. N/A 2 – Not Applicable, due to this is a transceiver. Note 1: See FCC 12-25 Document 75928436 Report 01 Issue 1 Page 5 of 70 1.3 CONFIGURATION DESCRIPTION Configuration Code Carrier(s) Configuration Description L-MIMO-SC 1C LTE MIMO, Single Carrier L-MIMO-MC 2C LTE MIMO, Multi Carrier x2 The RRUS 11 B26B / KRC 161 457/1 supports Test Models E-TM1.1, E-TM3.2 and E-TM3.1 at 800MHz defined in 3GPP TS 36.141. Test Model E-TM1.1 is used to represent QPSK modulation only, and Test Model E-TM3.2 is used to represent 16QAM modulation, and Test Model E-TM3.1 is used to represent 64QAM modulation. The settings below were deemed representative for all traffic scenarios when settings with different modulations, channel bandwidths, number for carriers and RF configurations has been tested …

Text truncated - open the document above for the full version.

FCC ID: TA8AKRC161457-1 Ericsson AB RRUS 11 B26B / KRC 161 457/1 2014 Not to be reproduced, except in its entirety, Page 1 of 1 without the Permission of TÜV SÜD Product Service Reference: 75928436 PHOTOGRAPHS OF TEST SET UP Radiated Emissions
