TA8AKRC163003

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	24E	1.93 GHz - 1.99 GHz	5.1 W	247KGXW	0.05ppm
2	24E	1.93 GHz - 1.99 GHz	20.1 W	247KGXW	0.05ppm
3	24E	1.93 GHz - 1.99 GHz	42 W	4M49W7D	0.05ppm
4	24E	1.94 GHz - 1.99 GHz	81.5 W	8M97W7D	0.05ppm
5	24E	1.94 GHz - 1.99 GHz	102.1 W	13M4W7D	0.05ppm
6	24E	1.94 GHz - 1.99 GHz	100.2 W	17M9W7D	0.05ppm
7	24E	1.94 GHz - 1.99 GHz	61.5 W	9M33W7D	0.05ppm
8	24E	1.94 GHz - 1.99 GHz	88.1 W	13M9W7D	0.05ppm
9	24E	1.94 GHz - 1.99 GHz	87.9 W	18M3W7D	0.05ppm
1	24E	1.93 GHz - 2.00 GHz	93.5 W	63M0W7D	0.05ppm
11	24E	1.93 GHz - 1.99 GHz	41.5 W	4M51W7D	0.05ppm
12	24E	1.94 GHz - 1.99 GHz	80 W	9M35W7D	0.05ppm
13	24E	1.94 GHz - 1.99 GHz	98.5 W	14M1W7D	0.05ppm
14	24E	1.94 GHz - 1.99 GHz	99.3 W	18M9W7D	0.05ppm
15	24E	1.94 GHz - 1.98 GHz	98.6 W	23M9W7D	0.05ppm
16	24E	1.95 GHz - 1.98 GHz	100.2 W	28M5W7D	0.05ppm
17	24E	1.95 GHz - 1.98 GHz	99.5 W	33M6W7D	0.05ppm
18	24E	1.95 GHz - 1.98 GHz	100.7 W	38M5W7D	0.05ppm
19	24E	1.95 GHz - 1.97 GHz	98.9 W	43M1W7D	0.05ppm
2	24E	1.93 GHz - 2.00 GHz	100.7 W	63M5W7D	0.05ppm
21	24E	1.94 GHz - 1.99 GHz	80.4 W	8M64W7D	0.05ppm
22	24E	1.94 GHz - 1.99 GHz	98.9 W	13M6W7D	0.05ppm
23	24E	1.94 GHz - 1.99 GHz	98.9 W	18M2W7D	0.05ppm
24	24E	1.94 GHz - 1.98 GHz	100.2 W	22M2W7D	0.05ppm
25	24E	1.95 GHz - 1.98 GHz	98.9 W	27M9W7D	0.05ppm
26	24E	1.95 GHz - 1.98 GHz	99.8 W	32M9W7D	0.05ppm
27	24E	1.95 GHz - 1.98 GHz	99.8 W	37M8W7D	0.05ppm
28	24E	1.95 GHz - 1.97 GHz	99.1 W	42M5W7D	0.05ppm
29	27	2.11 GHz - 2.20 GHz	41 W	4M49W7D	0.05ppm
3	27	2.12 GHz - 2.19 GHz	78.7 W	8M98W7D	0.05ppm
31	27	2.12 GHz - 2.19 GHz	98.4 W	13M4W7D	0.05ppm
32	27	2.12 GHz - 2.19 GHz	97.7 W	17M9W7D	0.05ppm
33	27	2.11 GHz - 2.20 GHz	93.1 W	87M7W7D	0.05ppm
34	27	2.12 GHz - 2.19 GHz	57.8 W	9M33W7D	0.05ppm
35	27	2.12 GHz - 2.19 GHz	85.7 W	13M9W7D	0.05ppm
36	27	2.12 GHz - 2.19 GHz	86.1 W	18M4W7D	0.05ppm
37	27	2.11 GHz - 2.20 GHz	40.5 W	4M51W7D	0.05ppm
38	27	2.12 GHz - 2.19 GHz	79.6 W	9M34W7D	0.05ppm
39	27	2.12 GHz - 2.19 GHz	96.6 W	14M1W7D	0.05ppm
4	27	2.12 GHz - 2.19 GHz	96.4 W	18M9W7D	0.05ppm
41	27	2.12 GHz - 2.19 GHz	97.7 W	23M7W7D	0.05ppm
42	27	2.13 GHz - 2.19 GHz	98.9 W	28M5W7D	0.05ppm
43	27	2.13 GHz - 2.18 GHz	100.7 W	33M6W7D	0.05ppm
44	27	2.13 GHz - 2.18 GHz	97.7 W	38M5W7D	0.05ppm
45	27	2.13 GHz - 2.18 GHz	96.8 W	43M1W7D	0.05ppm
46	27	2.11 GHz - 2.20 GHz	99.5 W	88M2W7D	0.05ppm
47	27	2.12 GHz - 2.19 GHz	81.3 W	9M34W7D	0.05ppm
48	27	2.12 GHz - 2.19 GHz	100 W	14M1W7D	0.05ppm
49	27	2.12 GHz - 2.19 GHz	99.8 W	18M9W7D	0.05ppm
5	27	2.12 GHz - 2.19 GHz	99.1 W	23M7W7D	0.05ppm
51	27	2.13 GHz - 2.19 GHz	101.4 W	28M5W7D	0.05ppm
52	27	2.13 GHz - 2.18 GHz	98.9 W	33M6W7D	0.05ppm
53	27	2.13 GHz - 2.18 GHz	98.2 W	38M5W7D	0.05ppm
54	27	2.13 GHz - 2.18 GHz	98.6 W	43M1W7D	0.05ppm

Confidentiality

Long Term

Grant Notes

The power output listed is conducted per carrier and per output port. This transmitter supports multi carrier and mixed mode operations, the nominal maximum total combined power is 100W per port, 720 W in total per unit. The antenna (s) used for this transmitter must be fixed-mounted on permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-locating requirements of 1.1307 (b)(3).
