TA8AKRD901050LTE / WCDMA Radio Base Station

Ericsson Internal EXHIBIT 13 1 (1) Prepared (also subject responsible if other) No. RSACGUS TA8AKRD901050 Approved Checked Date Rev Reference EAB/FJB/VA Christer Gustavsson 2013-11-18 A Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Attention: Equipment Authorization Branch TUV SUD BABT Octagon House, Concorde Way Fareham, Hampshire, PO15 5RL United Kingdom November 18, 2013 Subject: Certification for FCC ID: TA8AKRD901050 To Whom It May Concern: Ericsson AB requests a Grant of Certification (Type Acceptance) for the above mentioned FCC Identifier. This base station (RBS 6501) is designed for use in WCDMA and LTE cellular telephone system. The transmitter will operate from 2110 MHz to 2155 MHz. The receiver circuit supports 1710 MHz to 1755 MHz. It supports Channel Bandwidth of 1.4, 3, 5, 10, 15 and 20 MHz for LTE. This base station supports modulation type QPSK, 16QAM and 64QAM for WCDMA and LTE. The base station operates in the Advanced Wireless services band as per 47 CFR Part 27 subpart L. It meets the requirements of Third Generation Partnership Project (3GPP) for the Universal Mobile Telephone System (UMTS 3G) mobile standard (cellular telephone system) for operation in WCDMA and LTE cellular systems. This base station will in normal mode operates at a nominal power out of maximum 2x5 watts at the output connectors, to feed an integrated wide sector antenna or a Semi-integrated Omni directional antenna alternative external antenna (s). The Exhibit 8 user manuals submitted with this application is generic and may cover multiple products. This application is only valid for the model specified in the Exhibit 12 circuit description. Ericsson AB requests confidentiality under CFR 0.459 according to attached letter. We further certify that the applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to section 5301 of the Anti-Drug abuse Act of 1988, 21 U.S.C. Section 862. Ericsson AB accept by this request the agreement set out in the document "Bilaga SPCR 125 -Avtal om marknadskontroll för radioutrustning certifierad för USA-marknaden". If additional information is needed, please contact me on the below listed number. Christer Gustavsson Staff Engineer, Regulatory Programs Ericsson AB Isafjordsgatan 10 Kista, SE-164 80 Stockholm Sweden Telephone No.: +46 10 7175949 e-mail: [email protected]

Ericsson Internal EXHIBIT 13 1 (2) Prepared (also subject responsible if other) No. RSACGUS TA8AKRD901050 / 287AB-AS901050 Approved Checked Date Rev Reference EAB/FJB/VA Christer Gustavsson 2013-11-18 A Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Attention: Equipment Authorization Branch TUV SUD BABT FCB Octagon House, Concorde Way Fareham, Hampshire, PO15 5RL United Kingdom Industry Canada Certification and Engineering Bureau 3701 Carling Avenue, Bldg.94 P.O. Box 11490, Station “H” Ottawa, Ontario K2H 8S2 Canada November 18, 2013 Subject: Request for Confidentiality To Whom It May Concern: We, Ericsson AB, hereby request that the Exhibits/Items listed below be withheld from public inspection in accordance with Sections 0.457 and 0.459 of the Commission’s Rules. This due to the following reasons: This Base Stations (BS) are designed strictly based on the technical specifications of the international project 3GPP (the 3rd Generation Partnership Project). The competition in this field is very intense and a less advanced solution/design could get an unfair advantage by accessing the information as listed below from common domain. As we believe that we have implemented groundbreaking solutions and designs into our recent BS/Radio Unit (RU) compared to the previous BS/RU, the listed Exhibits/Items need to be protected from disclosure to our competitors in the industry. As the FCC/IC records have in-depth information and a very wide distribution, we believe that you can understand our concerns. We are strong in our belief that all vendors in the industry need to compete by their own merits. We regard these Exhibits/Items to be our intellectual property and therefore as confidential information. As our BS are generally installed in restricted places, public access is not possible thought some types of our BS under certain circumstances can be installed in an unrestricted place, but the doors on all of our BS’s are key-locked and can be opened only be by authorized personnel. It is therefore individual modules within our BS that should not be revealed to the public. There are advanced technical and design solutions/information in the Exhibits/Items, as mentioned above, that we regard as Ericsson proprietary, with actual and potential patents pending. The information can be advantageous to our competitors as well as sources seeking ways to hack past the built in security functionality. These solutions or information thereof are not accessible even for our customers or partners unless non-disclosure agreements for particular item(s) have been signed. Confidential product information can be found in, but not necessarily limited to, internal photos of the BS and the RU, block diagrams, schematics diagrams, and parts lists as well as certain documents, such as the user’s manuals. Those documents can only be accessible by the customers who purchase our BS and accept the conditions and therefore are provided with unique information access tools. Ericsson Internal EXHIBIT 13 2 (2) Prepared (also subject responsible if other) No. RSACGUS TA8AKRD901050 / 287AB-AS901050 Approved Checked Date Rev Reference EAB/FJB/VA Christer Gustavsson 2013-11-18 A EXHIBIT 9 Internal Photos of Radio Unit EXHIBIT 4 Block Diagrams EXHIBIT 5 Schematic Diagrams EXHIBIT 8 Manuals EXHIBIT 10 Parts List EXHIBIT 12 Technical Circuit Description If additional information is needed, please contact me on the below listed number. Christer Gustavsson Staff Engineer, Regulatory Programs Ericsson AB FCC Registration Number (FRN): 0013476155 Isafjordsgatan 10 Kista, SE-164 80 Stockholm Sweden Telephone No.: +46 10 7175949 e-mail: [email protected]

Confidentiality. Each party agrees that all confidential documents, work product and information (including all computer code, internal photographs of products, block diagrams, schematic diagrams, technical and/or user manuals, related materials, and the existence of this Agreement) received or otherwise obtained from the other party pursuant to this Agreement, whether before or after the Effective Date, will be, and will be deemed to have been, received in confidence and will be used only for the purpose of carrying out the obligations of, or as otherwise contemplated by, this Agreement. In addition, each party agrees that public access to all confidential equipment supplied will be restricted either by installation of the equipment in a restricted area or by physically securing the equipment by other means, including, but not limited to, using a key-lock that can only be opened by authorized personnel. Without the other party’s prior written consent, neither party may disclose any such information to any third party or grant access to the confidential equipment to any unauthorized person, and each party will disclose such information only to such of its officers, employees and agents that have a need to know such information for the purposes contemplated hereby. However, the provisions of this Section will not apply to any such information that (i) is or becomes generally available to the public without the fault or negligence of either party, (ii) is already in the possession of the receiving party without being subject to another confidentiality obligation, (iii) is or becomes available to the receiving party on a non-confidential basis from a source other than the disclosing party; provided that such source is not bound by a confidentiality obligation of the disclosing party, (iv) is required to be disclosed pursuant to an arbitration proceeding conducted in accordance with this Agreement, or (v) is required to be disclosed pursuant to a requirement of any governmental authority or any statute, rule or regulation; provided that the party required to disclose such information of the other party provide to the other party notice of such requirement of any such disclosure and cooperates with the other party to prevent or restrict any such disclosure to the extent allowed by applicable law.

Exhibit 2 FCC authorization ‐ letter

Date Page Exhibit 3 External photos 11/28/2013 1(3) FCC ID: TA8AKRD901050 IC: 287AB-AS901050 RBS 6501 B4, KRD 901 050/1, /2, /3 and /4 Front side Rear side Date Page Exhibit 3 External photos 11/28/2013 2(3) FCC ID: TA8AKRD901050 IC: 287AB-AS901050 RBS 6501 B4, KRD 901 050/1, /2, /3 and /4 Left side Right side Date Page Exhibit 3 External photos 11/28/2013 3(3) FCC ID: TA8AKRD901050 IC: 287AB-AS901050 Top side for RBS 6501 B4, KRD 901 050/1, /2, /3 and /4 Bottom side for RBS 6501 B4, KRD 901 050/1 and /3 Bottom side for RBS 6501 B4, KRD 901 050/2 and /4

Date Page Exhibit 1 ID label and placement 11/28/2013 1( 2) FCC ID: TA8AKRD901050 IC: 287AB-AS901050 The ID label is located under the solar shield. Solar shield slide up: ID label for KRD 901 050/1 Date Page Exhibit 1 ID label and placement 11/28/2013 2( 2) FCC ID: TA8AKRD901050 IC: 287AB-AS901050 ID label for KRD 901 050/2 ID label for KRD 901 050/3 ID label for KRD 901 050/4

Document 75924587 Report 01 Issue 1 November 2013 Report On FCC and IC Testing of the Ericsson AB (1700MHz/2100 MHz) RBS 6501 B4 KRD 901 050/x* Radio Base Station In accordance with FCC CFR 47 Part 27 and Industry Canada RSS-139: Issue 2 See Note* in page 3 COMMERCIAL-IN-CONFIDENCE FCC ID: TA8AKRD901050 IC ID: 287AB-AS901050 PREPARED BY APPROVED BY DATED 29 November 2013 Guangdi Dong Simon Bennett Project Engineer Authorised Signatory Document 75924587 Report 01 Issue 1 Page 1 of 119 CONTENTS Section Page No 1 REPORT INFORMATION ............................................................................................................ 2 1.1 Report Details ................................................................................................................................ 3 1.2 Brief Summary of Results .............................................................................................................. 4 1.3 Configuration Description .............................................................................................................. 5 1.4 Declaration of Build Status ............................................................................................................ 6 1.5 Product Information ....................................................................................................................... 7 1.6 Test Setup ..................................................................................................................................... 8 1.7 Test Conditions ............................................................................................................................ 12 1.8 Deviation From The Standard ..................................................................................................... 12 1.9 Modification Record ..................................................................................................................... 12 1.10 Alternative Test Site ..................................................................................................................... 12 2 TEST DETAILS .......................................................................................................................... 13 2.1 Maximum PEAK Output Power and Peak to Average Ratio - Conducted .................................. 14 2.2 Maximum PEAK Output Power - Radiated .................................................................................. 19 2.3 Occupied Bandwidth .................................................................................................................... 24 2.4 Spurious Emission at Band Edge ................................................................................................ 38 2.5 Radiated Spurious Emissions ...................................................................................................... 73 2.6 Conducted Spurious Emissions ................................................................................................... 79 2.7 Frequency Stability .................................................................................................................... 111 3 TEST EQUIPMENT USED ....................................................................................................... 114 3.1 Test Equipment Used ................................................................................................................ 115 3.2 Measurement Uncertainty.......................................................................................................... 117 4 ACCREDITATION, DISCLAIMERS AND COPYRIGHT .......................................................... 118 4.1 Accreditation, Disclaimers and Copyright .................................................................................. 119 Document 75924587 Report 01 Issue 1 Page 2 of 119 SECTION 1 REPORT INFORMATION Document 75924587 Report 01 Issue 1 Page 3 of 119 1.1 REPORT DETAILS Manufacturer Ericsson AB Address Isafjordsgatan 10 SE-164 80 Stockholm 16480 Sweden Product Name RBS 6501 B4 Product Number KRD 901 050/x * IC Model Number AS901050x * Serial Number(s) CB4R911974 CB4R886371 Software Version CXP 902 3291 Rev R1N18 for WCDMA CXP 102 051/19 Rev R29V for LTE Hardware Version R1B Test Specification/Issue/Date FCC CFR 47 Part 27: 2012 Industry Canada RSS-139 Issue 2: 2009 Start of Test 24 October 2013 Finish of Test 16 November 2013 Name of Engineer(s) Guangdi Dong Related Document(s) ANSI C63.4: 2009 FCC CFR 47 Part 2: 2012 Industry Canada RSS-GEN Issue 3: 2010 Note * : X can be 1 to 4. RBS 6501 B4 is available in the following four variants with the listed product numbers and IC Model Numbers. The differences between them are as follows: Product Number IC Model Number Description KRD 901 050/1 AS9010501 100 - 250 VAC power feed with integrated antenna KRD 901 050/2 AS9010502 -48 VDC power feed with integrated antenna KRD 901 050/3 AS9010503 100 - 250 VAC power feed without integrated antenna KRD 901 050/4 AS9010504 -48 VDC power feed without integrated antenna Document 75924587 Report 01 Issue 1 Page 4 of 119 1.2 BRIEF SUMMARY OF RESULTS A brief summary of results for each configuration, in accordance with FCC CFR 47 Part 2, Part 27 and RSS-139 is shown below. Section Spec Clause Test Description Result Part 2 Part 27 RSS 139 2.1 2.1046 27.50 (d) 6.4 Maximum Peak Output Power and Peak to Average Ratio – Conducted Pass 2.2 - 27.50 (d) 6.4 Maximum Peak Output Power – Radiated Pass 2.3 2.1049 27.53 (h) RSS-Gen 4.6.1 Occupied Bandwidth Pass 2.4 2.1051 27.53 (h) 6.5 Spurious Emissions at Band Edge Pass 2.5 2.1053 27.53 (h) 6.5 Radiated Spurious Emissions Pass 2.6 2.1051 27.53 (h) 6.5 Conducted Spurious Emissions Pass 2.7 2.1055 27.54 6.3 Frequency Stability Pass - - - 6.6 Receiver Spurious Emissions N/A N/A – Not Applicable Document 75924587 Report 01 Issue 1 Page 5 of 119 1.3 CONFIGURATION DESCRIPTION Configuration Code Carrier(s) Configuration Description W-SC 1C WCDMA Sing…
