TA8AKRY901468-1Remote Radio Unit which supports WCDMA, LTE , NBIoT, and NR

1 (1) Prepared (also subject responsible if other) No. Denis Lalonde TA8AKRY901468-1 Approved Checked Date Rev Reference Nov. 19, 2020 A Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Attention: Equipment Authorization Branch TUV SUD BABT Octagon House Concorde Way, Segensworth North Fareham, Hampshire, PO15 5RL United Kingdom November 19, 2020 Subject: Certification for FCC ID: TA8AKRY901468-1 To Whom It May Concern: Ericsson AB requests a Grant of Certification (Type Acceptance) for the above-mentioned FCC Identifier. This Radio Unit (Dot 2274 B25B66) is designed for use in WCDMA, LTE and NR cellular telephone system. The FDD transmitter and receiver will transmit from 1930-1995 MHz and 2110-2200 MHz. It supports channel bandwidths of 5, 10, 15, and 20 MHz for LTE. It also supports channel bandwidths of 5, 10, 15, and 20 MHz for NR. The Radio Unit operates in the Broadband PCS Service as per 47 CFR Part 24 and the Advanced Wireless Service as per 47 CFR Part 27. It meets the requirements of Third Generation Partnership Project (3GPP) for operation in LTE and NR cellular systems. The Dot 2274 B25B66 product will also support NBIoT Guardband and Inband operation for LTE signals >=10MHz. The Dot 2274 B25B66 product uses the same pcb and hardware as the Dot 2284 B25B66 product (FCCID: TA8KRY901468-2). The only difference between the 2 products is the presence of internal/external antennas. All approval tests were done on the external antenna ports variant. This product includes 4 internal antennas. The Radio Unit will in normal mode operate at a nominal power output of 200mW per port. This Radio Unit (Dot 2274 B25B66) will always require a license for transmission. The Exhibit 8 user manuals submitted with this application are generic and may cover multiple products. This application is only valid for the model specified in the Exhibit 12 circuit description. Ericsson AB requests confidentiality under CFR 0.459 according to attached letter. We further certify that the applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to section 5301 of the Anti-Drug abuse Act of 1988, 21 U.S.C. Section 862. If additional information is needed, please contact me on the below listed number. Denis Lalonde Developer, Regulatory Approval, Ericsson Canada 349 Terry Fox Drive Ottawa, Ontario, Canada, K2K 2V6 Telephone No.: 613-963-6496 e-mail: [email protected]

1 (2) Prepared (also subject responsible if other) No. Denis Lalonde TA8AKRY901468-1 Approved Checked Date Rev Reference Nov. 9, 2020 PA1 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Attention: Equipment Authorization Branch TUV SUD BABT Octagon House Concorde Way, Segensworth North Fareham, Hampshire, PO15 5RL United Kingdom 9 November 2020 FCC ID: TA8AKRY901468-1 Subject: Request for Confidentiality To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission Rules, We, Ericsson Canada / Ericsson AB, hereby requests the Exhibits/Items listed below be withheld from public inspection or disclosure. This is based on the following reasons: This product is intended for use in an Ericsson Radio Base Station (BS) designed and built to state of the art technical specification and implemented with innovative solutions for a highly competitive market. Competition in this market is very intense and therefore the necessity for confidentiality is essential to protect Ericsson IP and trade secrets. Ericsson AB / Ericsson Canada confidential exhibits / documentation contains Ericsson company proprietary information (or that of our suppliers and contractors), in addition to trade secrets and proprietary information that are not intended for public disclosure. The confidential exhibits in this application are provided exclusively for the radio authorization submission and approval process and therefore need to be protected from public disclosure. Ericsson AB / Ericsson Canada has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology and solutions developed and / or implemented by Ericsson. The Confidential Exhibits listed below contain highly technical and confidential information about our product and are only available to trained and authorized service personnel. This equipment is not available to be sold to the general public, (nor is it a consumer product) and can only be accessed and installed by trained service personnel under NDA (Non-Disclosure Agreement) with Ericsson. In addition, this product is installed in restricted access areas and is only serviceable by the licensee or his designated technicians. Confidential product information can be found in, but not necessarily limited to, internal photos, block diagrams, schematics diagrams, and parts lists as well as certain documents, such as the user’s manuals. 2 (2) Prepared (also subject responsible if other) No. Denis Lalonde TA8AKRY901468-1 Approved Checked Date Rev Reference Nov. 9, 2020 PA1 KRY 901 468/1 Dot 2274 B25B66 - Request for confidentiality list: • Exhibit 04 Block diagram • Exhibit 05 Schematics • Exhibit 08 User Manuals • Exhibit 08 Operational and Technical Descriptions • Exhibit 09 Internal Photographs • Exhibit 10 Bill of Materials Should additional information be required, please contact the undersigned: ..................................................................... Denis Lalonde Regulatory Approvals Verification FCC Registration Number (FRN) 0024080715 Ericsson Canada Inc. 349 Terry Fox Drive Ottawa, On, K2K 2V6, Canada Phone: +1-613-963-6496 Mobile: +1-613-790-2901 Email: [email protected]

Ericsson Canada Proprietary Information Dot 2274 B25B66 Restricted Use and Duplication FCC ID: TA8AKRY901468-1 IC: 287AB-AS9014681 EMC/LB/F Regulatory Compliance 06/11/2020 Page 1 of 4 Exhibit 3: External Photographs KRY 901 468/1 Photo Submission (External) Dot 2274 B25B66 FCC ID: TA8AKRY901468-1 IC: 287AB-AS9014681 Date: 6 November 2020 Author: Ericsson EMC Ericsson Canada Proprietary Information Dot 2274 B25B66 Restricted Use and Duplication FCC ID: TA8AKRY901468-1 IC: 287AB-AS9014681 EMC/LB/F Regulatory Compliance 06/11/2020 Page 2 of 4 CONFIDENTIAL INFORMATION RESTRICTED USE AND DUPLICATION © Ericsson Canada Inc. All Rights Reserved. The information contained in this document is the property of Ericsson Canada. Except as specifically authorized in writing by Ericsson, the holder of this document shall keep all information contained herein confidential and shall protect same in whole or in part from disclosure and dissemination to all third parties. Ericsson Canada Proprietary Information Dot 2274 B25B66 Restricted Use and Duplication FCC ID: TA8AKRY901468-1 IC: 287AB-AS9014681 EMC/LB/F Regulatory Compliance 06/11/2020 Page 3 of 4 Figure 1: Dot 2274 B25B66 Top (Radome) View Figure 2: Dot 2274 B25B66 Bottom View Ericsson Canada Proprietary Information Dot 2274 B25B66 Restricted Use and Duplication FCC ID: TA8AKRY901468-1 IC: 287AB-AS9014681 EMC/LB/F Regulatory Compliance 06/11/2020 Page 4 of 4 Figure 3: Dot 2274 B25B66 Side View

Ericsson Canada Confidential Exhibit 01: Product Identification Label KRY 901 468/1 6 November 2020 Figure 1: Dot 2274 B25B66 Label Detail - The text printed shall be: - FCC ID: TA8AKRY901468-1 - IC: 287AB-AS9014681 IC MODEL NO: AS9014681

1 (9) GFTL-20:001351 Uen, Rev A, 2020-10-29 © Telefonaktiebolaget LM Ericsson AB. This report shall not be reproduced except in full, without written approval of the laboratory. EMF Test Report: Ericsson Dot 2274/2284 B25 B66 (FCC) Accred. no. 1761 Testing ISO/IEC 17025 Test report issued by an Accredited Testing Laboratory Document number: , Rev A Date of report: 2020-10-29 Testing laboratory: Ericsson EMF Research Laboratory Ericsson AB SE-164 80 Stockholm Sweden Company/Client: Denis Lalonde Ericsson Canada 349 Terry Fox Drive Ottawa ON K2K 2V6 Canada Tests performed by: Davide Colombi Dates of tests: 2020-10-28 (Rev A) Manufacturer and market name(s) of device: Ericsson Dot 2274 B25 B66 Ericsson Dot 2284 B25 B66 Testing has been performed in accordance with: FCC OET Bulletin 65 Test results: Minimum separation distance for which the RF EMF exposure complies with the limits in FCC 47 CFR 1.1310 to be included in the Customer Product Information (CPI) for Ericsson Dot 2274/2284 B25 B66. Additional information: Testing was conducted for mobile exposure conditions according to KDB447498 DO1. Signature: Test Engineer _____________________________ Davide Colombi Master Researcher [email protected] Tel: +46 767602089 Laboratory and Quality Manager ___________________________ Christer Törnevik Senior Expert – EMF and Health [email protected] Tel: +46 705863148 2 (9) GFTL-20:001351 Uen, Rev A, 2020-10-29 1 Summary of EMF Test Report 1 Equipment under test (EUT) Product name Ericsson Dot 2274 B25 B66 (internal antennas), Ericsson Dot 2284 B25 B66 (external antennas) Product number KRY 901 468/1 KRY 901 468/2 Supported bands, Tx frequency range (MHz), and standards B25 + B66 1930 – 1995 + 2100 – 2180 WCDMA, LTE, NR (FDD) Exposure environment General public/uncontrolled Results The minimum (test) separation distance required for the equipment under test (EUT) to comply with the mobile device exposure conditions and relevant limits applicable in the USA [1]-[3] is provided in the table below for the general public (uncontrolled exposure). RF exposure assessment results for general public (uncontrolled) exposure as obtained for Dot 2274 and Dot 2284 B25 B66 together with an assumed output power tolerance of 2 dB using procedures applicable for the US market [3]. Band Standard Nominal output power from the radio Test position Separation distance B25 + B66 WCDMA, LTE, NR 2 x 0.2 W + 2 x 0.2 W Direction of maximum gain 20 cm 1 This page contains a summary of the test results. The full report provides a complete description of all test details and results. 3 (9) GFTL-20:001351 Uen, Rev A, 2020-10-29 2 General information The test results reported in this document have been obtained by simple calculations according to plane-wave equivalent conditions [3]. The purpose of the tests was to verify that the EUT is in compliance with the appropriate RF exposure standards, recommendations and limits [1]–[3]. It should be noted that the test results presented in this test report are valid for the frequency range and for the antenna properties specified in Table 1, in addition to the power level and the power tolerance specified in Table 2. These data were supplied by the client and may affect the validity of the results. The test results were determined for Dot 2274 B25 B66 (equipped with internal antennas) and are also applicable for Dot 2284 B25 B66 which must be connected to external antennas, provided that the antenna gain is equal to or smaller than 1.3 dBi. Proposed EMF health and safety information for inclusion in the Customer Product Information (CPI) is provided in Appendices A and B. 3 Equipment under test Table 1 summarizes the technical data for the EUT. Table 1 Technical data for the EUT. Product name Ericsson Dot 2274 B25 B66 (internal antennas), Ericsson Dot 2284 B25 B66 (external antennas) Product tested KRY 901 468/1 KRY 901 468/1 Supported bands, Tx frequency range (MHz), and standards B25 + B66 1930 – 1995 + 2100 – 2180 WCDMA, LTE, NR (FDD) Dimensions, Thickness x Diameter (mm) 67 x 210 Configuration(s) covered by this report B25 + B66 Antenna(s) Two antenna branches per band Maximum antenna gain 2 : 1.3 dBi Exposure environment General public/uncontrolled In Table 2 nominal output power levels are given. The EUT related data in Table 1 and Table 2 were supplied by the client. Table 2 Nominal output power levels. Band Standard Nominal output power 3 [dBm] Power tolerance [dB] Transmission loss [dB] Maximum output power per band 4 [dBm] B25 + B66 WCDMA, LTE, NR 23 2 0 28 4 EMF exposure assessments FCC procedures [3] specify exposure assessment methods to verify compliance with EMF exposure limits [1] of mobile devices. A minimum test separation distance of at least 20 cm is required between the device and nearby persons to apply mobile device exposure limits. The minimum test separation distance for which the 2 Maximum antenna gain (per port) among all available antenna branches. 3 Nominal output power per port. 4 Conservative measure of the total maximum possible output power level per band delivered to the antennas including losses and power tolerances. 4 (9) GFTL-20:001351 Uen, Rev A, 2020-10-29 equipment is shown to comply with the exposure limits must be clearly provided in the operating and installation instructions. The assessments were conducted for maximum power configurations, i.e., by assuming 100% utilization. Effects of real RBS utilization (time-averaged) is reasonably foreseeable and will significantly reduce the time- averaged power and the RF exposure. This factor was not considered in this assessment, which adds to the conservativeness of the obtained compliance boundaries. 4.1 Field strength calculations Transmit signals from the two antenna ports of the same band have been assumed to be correlated. Based on the maximum gain of the single antenna (퐺 ant = 1.3 dBi, see Table 1), the directional gain, 퐺, may be taken as 4.3 dBi according to [4] (퐺=퐺 an…

Text truncated - open the document above for the full version.

Document 7169008619 Report 01 Issue 1 November 2020 Report On FCC and ISED Testing of the Ericsson Dot 2274 B25 B66, KRY 901 468/1 and Dot 2284 B25 B66, KRY 901 468/2, LTE, NR, WCDMA, LTE + NR, LTE + WCDMA, (1900 MHz), with compatible Main Unit in a Base Station configuration in accordance with FCC CFR 47 Part 2, FCC CFR 47 Part 24, ISED RSS-GEN and Industry Canada RSS-133 COMMERCIAL-IN-CONFIDENCE FCC: TA8AKRY901468-1 and TA8AKRY901468-2 ISED: 287AB-AS9014681 and 287AB-AS9014682 PREPARED BY APPROVED BY DATED Nov 12th 2020 Glen Westwell Scott Drysdale Document 7169008619 Report 01 Issue 1 Page 1 of 107 COMMERCIAL – IN - CONFIDENCE CONTENTS Section Page No 1 REPORT INFORMATION ............................................................................................................ 2 1.1 Report Details ................................................................................................................................ 3 1.2 Brief Summary of Results .............................................................................................................. 4 1.3 Configuration Description .............................................................................................................. 5 1.4 Declaration of Build Status ............................................................................................................ 6 2 MAIN EUT ..................................................................................................................................... 6 1.5 Product Information ....................................................................................................................... 7 1.6 Test Setup ..................................................................................................................................... 8 1.7 Test Conditions .............................................................................................................................. 9 1.8 Deviation From The Standard ....................................................................................................... 9 1.9 Modification Record ....................................................................................................................... 9 1.10 Additional Information .................................................................................................................... 9 3 TEST DETAILS .......................................................................................................................... 10 2.1 Maximum Peak Output Power and Peak to Average Ratio - Conducted .................................... 11 2.2 Occupied Bandwidth .................................................................................................................... 64 2.3 Band Edge ................................................................................................................................... 65 2.4 Transceiver Spurious Emissions ................................................................................................. 86 2.5 Frequency Stability .................................................................................................................... 102 4 TEST EQUIPMENT USED ....................................................................................................... 103 3.1 Test Equipment Used ................................................................................................................ 104 3.2 Measurement Uncertainty ......................................................................................................... 105 5 ACCREDITATION, DISCLAIMERS AND COPYRIGHT .......................................................... 106 4.1 Accreditation, Disclaimers and Copyright .................................................................................. 107 ANNEX A Module Lists .............................................................................................................................. A.2 Document 7169008619 Report 01 Issue 1 Page 2 of 107 COMMERCIAL – IN - CONFIDENCE SECTION 1 REPORT INFORMATION Document 7169008619 Report 01 Issue 1 Page 3 of 107 COMMERCIAL – IN - CONFIDENCE 1.1 REPORT DETAILS Manufacturer Ericsson Address Torshamnsgatan 23 Kista SE-16480 Stockholm Sweden Product Name & Product Number Dot 2284 B25 B66, KRY 901 468/2 IC Model Name AS9014681 Serial Number(s) TD3W005261 Software Version CXP9013268/25-R84EF Hardware Version R1A Non-Tested Variant Dot 2274 B25B66, KRY 901 468/1 Test Specification/Issue/Date FCC CFR 47 Part 2: 2019 FCC CFR 47 Part 24: 2019 ISED RSS-GEN: Issue 5 March 2019 Amendment 1 Industry Canada RSS-133: Issue 6: January 2018 Amendment 1 Test Plan Dot 2274 B25B66_RA_testplan_NR_LTE_WCDMA Start of Test 20 October 2020 Finish of Test 23 October 2020 Name of Engineer(s) Glen Westwell Related Document(s) KDB 971168 D01 v02r02 KDB 662911 D01 v02r01 Glen Westwell ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate compliance with FCC CFR 47 Part 2: 2019, FCC CFR 47 Part 24: 2019, ISED RSS-GEN: Issue 5 March 2019 Amendment 1, Industry Canada RSS-133: Issue 6: January 2018 Amendment 1 The sample tested was found to comply with the requirements defined in the applied rules. Test Engineer(s); Document 7169008619 Report 01 Issue 1 Page 4 of 107 COMMERCIAL – IN - CONFIDENCE 1.2 BRIEF SUMMARY OF RESULTS A brief summary of results for each configuration, in accordance with FCC CFR 47 Part 2, FCC CFR 47 Part 24, ISED RSS-GEN and Industry Canada RSS-133 is shown below. Section Specification Clause Test Description Result FCC CFR 47 Part 2 FCC CFR 47 Part 24 RSS- GEN RSS- 133 - - - - - Equivalent Isotropically Radiated Power (EIRP) N/A 1 2.1 2.1046 24.232 - 6.4 Maximum Peak Output Power and Peak to Average Ratio - Conducted Pass 2.2 2.1049 24.238 (b) 6.7 6.5 Occupied B…

Text truncated - open the document above for the full version.

Document 7169008619 Report 02 Issue 1 November 2020 Report On FCC and ISED Testing of the Ericsson Dot 2274 B25 B66, KRY 901 468/1 and Dot 2284 B25 B66, KRY 901 468/2, LTE, NR, WCDMA, LTE + NR, LTE + WCDMA, (2100 MHz), with compatible Main Unit in a Base Station configuration in accordance with FCC CFR 47 Part 2, FCC CFR 47 Part 27, ISED RSS-GEN and Industry Canada RSS-139, RSS-170 COMMERCIAL-IN-CONFIDENCE FCC: TA8AKRY901468-1 and TA8AKRY901468-2 ISED: 287AB-AS9014681 and 287AB-AS9014682 PREPARED BY APPROVED BY DATED Nov 12 th 2020 Glen Westwell Scott Drysdale Document 7169008619 Report 02 Issue 1 Page 1 of 118 COMMERCIAL – IN - CONFIDENCE CONTENTS Section Page No 1 REPORT INFORMATION ............................................................................................................ 2 1.1 Report Details ................................................................................................................................ 3 1.2 Brief Summary of Results .............................................................................................................. 4 1.3 Configuration Description .............................................................................................................. 5 1.4 Declaration of Build Status ............................................................................................................ 6 2 MAIN EUT ..................................................................................................................................... 6 1.5 Product Information ....................................................................................................................... 7 1.6 Test Setup ..................................................................................................................................... 8 1.7 Test Conditions .............................................................................................................................. 9 1.8 Deviation From The Standard ....................................................................................................... 9 1.9 Modification Record ....................................................................................................................... 9 1.10 Additional Information .................................................................................................................... 9 3 TEST DETAILS .......................................................................................................................... 10 2.1 Maximum Peak Output Power and Peak to Average Ratio - Conducted .................................... 11 2.2 Occupied Bandwidth .................................................................................................................... 68 2.3 Band Edge ................................................................................................................................... 69 2.4 Transceiver Spurious Emissions ................................................................................................. 96 2.5 Frequency Stability .................................................................................................................... 113 4 TEST EQUIPMENT USED ....................................................................................................... 114 3.1 Test Equipment Used ................................................................................................................ 115 3.2 Measurement Uncertainty ......................................................................................................... 116 5 ACCREDITATION, DISCLAIMERS AND COPYRIGHT .......................................................... 117 4.1 Accreditation, Disclaimers and Copyright .................................................................................. 118 ANNEX A Module Lists .............................................................................................................................. A.2 Document 7169008619 Report 02 Issue 1 Page 2 of 118 COMMERCIAL – IN - CONFIDENCE SECTION 1 REPORT INFORMATION Document 7169008619 Report 02 Issue 1 Page 3 of 118 COMMERCIAL – IN - CONFIDENCE 1.1 REPORT DETAILS Manufacturer Ericsson Address Torshamnsgatan 23 Kista SE-16480 Stockholm Sweden Product Name & Product Number Dot 2284 B25 B66, KRY 901 468/2 IC Model Name AS9014681 Serial Number(s) TD3W005261 Software Version CXP9013268/25-R84EF Hardware Version R1A Non-Tested Variant Dot 2274 B25 B66, KRY 901 468/1 Test Specification/Issue/Date FCC CFR 47 Part 2: 2019 FCC CFR 47 Part 27: 2019 ISED RSS-GEN: Issue 5: March 2019 Amendment 1 Industry Canada RSS-139: Issue 3: 2015 / RSS-170 Issue 3 2020. Test Plan Dot 2274 B25B66_RA_testplan_NR_LTE_WCDMA Start of Test 20 October 2020 Finish of Test 23 October 2020 Name of Engineer(s) Glen Westwell Related Document(s) KDB 971168 D01 v02r02 KDB 662911 D01 v02r01 Glen Westwell ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate compliance with FCC CFR 47 Part 2: 2019, FCC CFR 47 Part 27: 2019, ISED RSS-GEN: Issue 5: March 2019 Amendment 1, Industry Canada RSS-139: Issue 3: 2015 The sample tested was found to comply with the requirements defined in the applied rules. Test Engineer(s); Document 7169008619 Report 02 Issue 1 Page 4 of 118 COMMERCIAL – IN - CONFIDENCE 1.2 BRIEF SUMMARY OF RESULTS A brief summary of results for each configuration, in accordance with FCC CFR 47 Part 2, FCC CFR 47 Part 27, Industry Canada RSS-GEN and Industry Canada RSS-139, & RSS-170, is shown below. Section Specification Clause Test Description Result FCC CFR 47 Part 2 RSS- GEN - FCC CFR 47 Part 27 RSS- 139 RSS- 170 Equivalent Isotopically Radiated Power (EIRP) N/A 1 2.1 2.10 46 27.50 - 6.4 5.3 Maximum Peak Output Power and Peak to Average Ratio - Conducted Pass 2.2 2.10 49 27.5…

Text truncated - open the document above for the full version.

––––––––-–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– © TÜV SÜD Canada Inc This test report shall not be reproduced except in full, without written approval of TÜV SÜD Canada Inc. EMC Test Report for DOT 2274 B25B66 (KRY 901 468/1) and DOT 2284 B25B66 (KRY 901 468/2) Tested to: FCC Part 15 Subpart B / ICES 003 FCC Part 24 (Section 24.238(a)) FCC Part 27 (Section - 27.53(h)) RSS-Gen (Section 7.0) RSS-133 (Section 6.5) RSS-139 (Section 6.6) RSS-170 (Section 5.4) Test Result summury FCC/ ICES/ RSS Section Description Specification/Method Pass or Fail Results in section 15.109 / 6.2 Radiated Emissions (RE) FCC Part 15 / ICES 003 / ANSI C63.4 Pass 3.2 7.0 Receiver Emissions Limits RSS-Gen / ANSI C63.4 Pass 3.2 15.107 / 6.1 Conducted Emissions (CE) for AC Power FCC Part 15 / ICES 003 / ANSI C63.4 Not applicable 27.53(h) Transmitter Spurious Emissions (RE) FCC Part 27 / ANSI C63.26 Pass 3.2 24.238(a) Out of band Emissions (RE) FCC Part 24 / ANSI C63.26 Pass 3.2 RSS-133 / 6.5 Transmitter unwanted Emissions RSS-133 / ANSI C63.26 Pass 3.2 RSS-139 / 6.6 Transmitter unwanted Emissions RSS-139 / ANSI C63.26 Pass 3.2 RSS-170 / 5.4 Transmitter unwanted Emissions RSS-170 / ANSI C63.26 Pass 3.2 Document number: 7169008619-TR-EMC-01-01-F15 Release date: 5 November, 2020 Prepared for: Ericsson Canada EMC Test Report for DOT 2274 B25B66 (KRY 901 468/1) and DOT 2284 B25B66 (KRY 901 468/2) 7169008619-TR-EMC-01-01-F15 Prepared for: Ericsson Canada © TÜV SÜD Canada Inc This test report shall not be reproduced except in full, without written approval of TÜV SÜD Canada Inc. Release date: 5 November, 2020 Page 2 of 68 About this document This document is written and distributed by TÜV SÜD Canada Inc. Whenever TÜV SÜD is mentioned in this document it shall be taken as referring to TÜV SÜD Canada Inc. This test report does not imply product endorsement by any government, accreditation agency, or TÜV SÜD Canada Inc. Opinions or interpretations expressed in this report, if any, are outside the scope of the accreditations of TÜV SÜD Canada Inc. Any opinions expressed do not necessarily reflect the opinions of TÜV SÜD Canada Inc, unless otherwise stated. Throughout this document: • text in blue font is a clickable link • text in italics is provided as-is from the customer The release control record, document approvals, and laboratory Accreditations are as follows. Release control record This document is based on document template KG000347-TR-EMC-08-03. Issue Reason for change Date released 01 initial release 5 November, 2020 Approvals Function Name Job title Signature Technical Reviewer Scott Drysdale Canada Wireless Manager Author Kasi Sivaratnam EMC Test Engineer EMC Test Report for DOT 2274 B25B66 (KRY 901 468/1) and DOT 2284 B25B66 (KRY 901 468/2) 7169008619-TR-EMC-01-01-F15 Prepared for: Ericsson Canada © TÜV SÜD Canada Inc This test report shall not be reproduced except in full, without written approval of TÜV SÜD Canada Inc. Release date: 5 November, 2020 Page 3 of 68 Accreditations The test facilities of TÜV SÜD Canada Inc are accredited by the American Association for Laboratory Accreditation (A2LA) to ISO/IEC 17025:2017 in accordance with the scope of accreditation outlined at the website portal.a2la.org/scopepdf/2955-19.pdf. A2LA Cert. No. 2955.19 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD Canada with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD Canada. No part of this document may be reproduced without the prior written approval of TÜV SÜD Canada. © TÜV SÜD. ACCREDITATION Our A2LA Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our A2LA Accreditation. The Canadian lab registration number associated with the TÜV SÜD test facilities is 24015. Test lab information Lab name TÜV SÜD Canada Inc Company name TÜV SÜD Canada Inc Mailing or shipping address 1280 Teron Road, Ottawa, Ontario, K2K 2C1, Canada Primary technical contact Stephen Tippet Title Lab Manager Phone 613-668-5149 Customer information Company name Ericsson Canada Mailing address 349 Terry Fox Drive, Ottawa, On, K2K 2V6, Canada Primary contact Denis…

Text truncated - open the document above for the full version.
