Instruction Manual of Multi-function lnduction Cooker Model: MC-C13S501 Thank you for purchasing the Midea induction cooker, please read this instructions manual carefully before using and keep it cautiously after reading for your future reference. 8 8 8 : IMPORTANT SAFEGUARDS Save These Instructions. When using electrical appliances, basic safety precautions should always be followed including the following: 1. Read all instructions before use the induction cooker. 2. Do not touch hot surfaces. Use handles or knobs. 3. To protect against electrical shock do not immerse cord, plugs in water or other liquid. 4. Close supervision is necessary when any appliance is used by or near children. 5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts. 6. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or has been damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair, or adjustment. 7. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries. 8. Do not use outdoors. 9. Do not let cord hang over edge of table or counter, or touch hot surfaces. 10. Do not place on or near a hot gas or electric burner, or in a heated oven. 11. Extreme caution must be used when moving an appliance containing hot oil or other hot liquids. 12. Do not use appliance for other than intended use. 13. WARNING – To prevent electric shock, unplug before cleaning. 14.This appliance has polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician, Do not attempt to modify the plug in any way. 15. Do Not cook on broken-Top –If cook-top should break, cleaning solution and spillovers may penetrate the broken cook-top and create a risk electric shock. 16. Clean Cook-Top with Caution – if a wet sponge or cloth is used to wipe spills on a hot cooking area, be careful to avoid steam burn, some cleaners can produce noxious fumes if applied to a hot surface. 17. Any other servicing should be performed by an authorized services representative. 1 Designations of Parts Product Introduction Control panel Midea MC-C13S501 induction cooker comes with micro-computerized control and complete functions, is able to meet various kinds of cuisine demands by electromagnetic heating. It is the optimal choice. Midea induction cooker is made from imported material and advanced process for reliable performance, making cooking an enjoyable part of your life. 6 levels of power 2 tne v ri A drocr e wo P et a lpc i mareC yrtneriA Micro-computerized control, multiple functions Simple operation interface: personalized man-machine conversation interface, easy for operation. Multiple heating power choice: 6 levels of heating power choice, making your different cuisine demands come true. Flexible timing function: the timer can be set from 1 minutes to 180 minutes. Auto alarm function: relying on its internal detecting system, it is able to identify whether a pot is put on or whether the pot material satisfies the requirement. MC-C13S501 1300W 355*302*66 120W-1300W 110-130V~50/60Hz Model Performance parameters Applied voltage/frequency 3.1 Power adjustment range Appearance dimension(mm) Weight (Kg) Performance Characteristics Rated power 2 3 3 High efficiency, saving time and electricity. Strong heating level with high heat efficiency makes cooking time-saving & convenient.Several protection functions make it safe & reliable. Over-heat protection: The induction cooker will display the protection code or shut down 1 minute later when the temperature of the pot body is too high or the temperature inside the cooker is too high. Over current or voltage abnormality protection: In case voltage is abnormal or current changes suddenly, the induction cooker will shut down automatically. Having the function of detecting small articles: When the pot is less than 80 mm in diameter or small articles (knife, fork, nipper, forceps, key, etc.) exist or non- magnetic pots (such as aluminum pot) are detected, the buzzer will give out an alarm lasting for about 1 minute. In case the user has not put a proper pot in time, the induction cooker will shut down automatically. 1 minute automatic shut down protection: when the pot is removed, the induction cooker will shut down 1 minute later. Power mode Press the "Heating" button, the buzzer sounds, the "ON/OFF" and the "Power" indicator light up, the hotplate entering the heating working state. When in heating working mode, the default power level shall be level 4, you can make a regulation by pressing the "+" or "-" key. Childproof Lock When the hotplate is in working state, to prevent children from operation, you can activate the childproof lock by pressing the childproof lock button, the buzzer will sound at the same time. In the childproof lock state, "Childproof Lock" button and "ON/OFF" button can be operated, other buttons are non effective. You can deactivate the childproof lock by holding the childproof lock button. The buzzer wiil sound. Operation Instructions 4 5 4 Free from any dangerous accidents such as leakage, explosion, flame burn that commonly happen to gas cookers. During the cooking, it does not generate any flame or smoke and facilitates the improvement of household environment and personal health, making cooking easy and safe. Advanced ceramic plate, resistant to high temperature and easy to clean and maintain. After the power supply is connected, the buzzer will sound and the cooker is in the state of "OFF". Press the "ON/OFF" button, the buzzer will sound, the "ON/OFF" indicator lights up, the LED display "-:--", indicating the cooker enters into the standby mode. If you don't press any key within 2 minutes…

Text truncated - open the document above for the full version.

Instruction Manual of Multi-function lnduction Cooker Model: MC-ESH13C Thank you for purchasing the Midea induction cooker, please read this instructions manual carefully before using and keep it cautiously after reading for your future reference. 8 8 8 : IMPORTANT SAFEGUARDS Save These Instructions. When using electrical appliances, basic safety precautions should always be followed including the following: 1. Read all instructions before use the induction cooker. 2. Do not touch hot surfaces. Use handles or knobs. 3. To protect against electrical shock do not immerse cord, plugs in water or other liquid. 4. Close supervision is necessary when any appliance is used by or near children. 5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts. 6. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or has been damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair, or adjustment. 7. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries. 8. Do not use outdoors. 9. Do not let cord hang over edge of table or counter, or touch hot surfaces. 10. Do not place on or near a hot gas or electric burner, or in a heated oven. 11. Extreme caution must be used when moving an appliance containing hot oil or other hot liquids. 12. Do not use appliance for other than intended use. 13. WARNING – To prevent electric shock, unplug before cleaning. 14.This appliance has polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician, Do not attempt to modify the plug in any way. 15. Do Not cook on broken-Top –If cook-top should break, cleaning solution and spillovers may penetrate the broken cook-top and create a risk electric shock. 16. Clean Cook-Top with Caution – if a wet sponge or cloth is used to wipe spills on a hot cooking area, be careful to avoid steam burn, some cleaners can produce noxious fumes if applied to a hot surface. 17. Any other servicing should be performed by an authorized services representative. 1 Designations of Parts Product Introduction Control panel Midea MC-ESH13C induction cooker comes with micro-computerized control and complete functions, is able to meet various kinds of cuisine demands by electromagnetic heating. It is the optimal choice. Midea induction cooker is made from imported material and advanced process for reliable performance, making cooking an enjoyable part of your life. 6 levels of power 2 tne v ri A drocr e wo P et a lpc i mareC yrtneriA Micro-computerized control, multiple functions Simple operation interface: personalized man-machine conversation interface, easy for operation. Multiple heating power choice: 6 levels of heating power choice, making your different cuisine demands come true. Flexible timing function: the timer can be set from 1 minutes to 180 minutes. Auto alarm function: relying on its internal detecting system, it is able to identify whether a pot is put on or whether the pot material satisfies the requirement. MC-ESH13C1300W 355*302*66 120W-1300W 110-120V~50/60Hz Model Performance parameters Applied voltage/frequency 2.98 Power adjustment range Appearance dimension(mm) Weight (Kg) Performance Characteristics Rated power 2 3 3 High efficiency, saving time and electricity. Strong heating level with high heat efficiency makes cooking time-saving & convenient.Several protection functions make it safe & reliable. Over-heat protection: The induction cooker will shut down automatically when the temperature of the pot body is too high or the temperature inside the cooker is too high. Over current or voltage abnormality protection: In case voltage is abnormal or current changes suddenly, the induction cooker will shut down automatically. Having the function of detecting small articles: When the pot is less than 80 mm in diameter or small articles (knife, fork, nipper, forceps, key, etc.) exist or non- magnetic pots (such as aluminum pot) are detected, the buzzer will give out an alarm lasting for about 1 minute. In case the user has not put a proper pot in time, the induction cooker will shut down automatically. 1 minute automatic shut down protection: when the pot is removed, the induction cooker will shut down 1 minute later. Power mode Press the "Heating" button, the buzzer sounds, the "ON/OFF" and the "Power" indicator light up, the hotplate entering the heating working state. When in heating working mode, the default power level shall be level 4, you can make a regulation by pressing the "+" or "-" key. Childproof Lock When the hotplate is in working state, to prevent children from operation, you can activate the childproof lock by pressing the childproof lock button, the buzzer will sound at the same time. In the childproof lock state, "Childproof Lock" button and "ON/OFF" button can be operated, other buttons are non effective. You can deactivate the childproof lock by holding the childproof lock button. The buzzer wiil sound. Operation Instructions 4 5 4 Free from any dangerous accidents such as leakage, explosion, flame burn that commonly happen to gas cookers. During the cooking, it does not generate any flame or smoke and facilitates the improvement of household environment and personal health, making cooking easy and safe. Advanced ceramic plate, resistant to high temperature and easy to clean and maintain. After the power supply is connected, the buzzer will sound and the cooker is in the state of "OFF". Press the "ON/OFF" button, the buzzer will sound, the "ON/OFF" indicator lights up, the LED display "-:--", indicating the cooker enters into the standby mode. If you don't press any key within 2 minutes, the cooker will shut down automat…

Text truncated - open the document above for the full version.

Applicant letterhead AUTHORIZATION LETTER To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: FCC ID:TAPMC-C13S501 We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) to act on our behalf, as our agent, in the following matters related to the FCC approval of our product: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by SGS within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, -------------------------------------- Name & Title, Date:IAN PAN,CERTIFICATE ADMINISTRATOR ,2007-11-28 Applicant:Guangdong MD Consumer Electric Manufacturing Co.,Ltd Tel: +86-757-2633-4263 Fax: +86-757-2633-4195 Email:[email protected]

- Permanent Confidentiality Letter Example- (Date) Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mils Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: TAPMC-C13S501 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR47, the applicant requests permanent confidential treatment of the following information accompanying this application: Block Diagrams Schematics Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, 2007-11-28

Model No.: MC-C13S501 Model No.: MC-ESH13C

美的电磁炉关键元器件清单 第 1 页 共 4 页 PART LIST PRODUCT : Induction cooker MODEL :MC-ESH13C RATING :.120V/60Hz, 1300W Item Parts name Manufacturer Specification/ material Approval( 认 证 ) Remark( 备注 ) Power cord 电源线 UNIRISE ELECTRONICS CO HPN 16AWG/2C 105 °C ,300V E176069 Alternate SHUNDE HUASHENG ELECTRICAL INDUSTRIAL CO LTD HPN 16AWG/2C 105°C ,300V E230919 1 Alternate Chau’s electrical co.,ltd HPN 16AWG/2C 105 °C ,300V UL E114235 Plug 插头 UNIRISE ELECTRONICS CO 125V/15A UE-221 E206144 Alternate SHUNDE HUASHENG ELECTRICAL INDUSTRIAL CO LTD 125V/15A E230920 2 Alternate Chau’s electrical co.,ltd 125V/15A E124163 3 Enclosure 外壳（面盖） ZHONGSHAN NAPU ENGINEERING PLASTIC CO., LTD 94V-0 PBT-FR 4 Cover 底座 ZHONGSHAN NAPU ENGINEERING PLASTIC CO., LTD 94V-0 PP-FR E238086 5 Ceramic 陶瓷板 Europe EURO KERA Min 4mm thick Test with the appliance 6 Silicone adhesive 电子硅酮 胶 GUANGZHOU BAIYUN CHEMICAL INDUSTRY CO LTD SKF323 UL E252101 7 Control Panel pad 控制面 板 BAYER MATERIALSCIENCE AG DP1-9354 94V-2 80 °C UL E 41613 FLEXCON CO INC FLEXmark V-400-HW, L-156 UL MH10170 美的电磁炉关键元器件清单 第 2 页 共 4 页 LIMO LABELS AS Limo UL1 UL MH28288 7 Bushing 线扣 HEAVY POWER CO LTD 5N-4 75 °C UL E107293 8 Inductive Coil Supporting 线圈盘材料 JIANG YIN YONGTONG CHEMICAL CO., PBT-4308G30/94V-0 UL E139063 GUANGZHOU KINGFA SCIENCE & TECHNOLOGY CO LTD 金发 PBT-RG301 UL E171666 9 绝缘套管 SHUNDE BEIJIAO LIANDA CO LTD UL E218446 10 保护器 CHANGZHOU CITY CHANGLIAN RADIO CO LTD KW AC250V 125 °C UL E206737 Alternate DONGYANG HENGDIAN THERMAL PROTECTOR FACTORY KW AC250V 125 °C UL E213246 11 IGBT 上的热敏电阻 Thermo-resistance holder ( 硅 胶座 ) Dong Jue Fine Chemicals (Nanjing) Co., Ltd NE-Z160 94V-0, 150 °C UL E236040 12 NTC SHIBAURA ELECTRONICS CO LTD PTN-51F Tmax (C) 300 UL E225177 13 Mica sheet SHENZHEN MICA ELECTRIC MATERIAL LTD HP5 94V-0 200 °C E 129729 14 Fan 风机 SHENZHONG XU HONG ELECTRONICS CO. ， LTD TD1225MS UL E239037 Alternate YUHONG MICROMOTOR CO LTD YHWF-118 UL E254836 15 PCB 胶片 SKC Co., Ltd SH71S 94VTM-2 105 °C UL E 74359 Alternate SP PACIFIC LTD FR7 （ V-0 ） UL E141248 美的电磁炉关键元器件清单 第 3 页 共 4 页 16 PWB FOSHAN SHUNDE HAIYA PCB 2, 94V-0 UL E198946 Alternate SHUNDE JUNDA ELECTRONIC CO LTD JD-D, 94V-0 UL 173873 Alternate ZHUHAI FOREWIN FLEXTRONICS 0886Y4S0, 94V-0 UL E308304 17 Tubing 热缩套管 SHENZHEN WOER HEAT-SHRINKABLE MATERIAL CO LTD RSFR-x 600V 125 °C UL E203950 18 扎带 Cable Tie ZHEJIANG HONT ELECTRICAL CO LTD HT-2.5X100 E225994 Alternate CHANGHONG PLASTIC CO LTD CHS-30X80 E203148 19 排线线扣 ASAHI KASEI CHEMICALS CORP PA66 94V-2 1300S E48285 20 电源线端子绝缘套管 FOSHAN FANGPU PVC DIPPING CO LTD Series FP 600V 105 °C E185697 21 Switch Transformer Dongguan Dazhong Elect ric Co., Ltd MD-EE16E Test with the appliance 22 Current Transformer Dongguan Dazhong Electric Co., Ltd DZ1930006B Test with the appliance 23 Bridge rectifier RECTRON LTD VRRM 700V I=25A Tj=-55 °C to 150 °C E94233 24 Power dynatron IGBT FAIRCHILD 仙童 FGL60N100B Unlisted Component FUSE 保险管 SUN ELECTRIC CO., 15A 125V/250V E166522 25 Alternate HOLLYLAND CO LTD 15A 125V/250V UL E156471 26 Varistor 压敏电阻 CENTRA SCIENCE CORP. CNR 10D241K UL E150709 美的电磁炉关键元器件清单 第 4 页 共 4 页 27 Coil Choke ( L3) 电感 Dongguan Dazhong Electric Co., Ltd 塑料厂家： E I DUPONT DE NEMOURS & CO INC 250V 4.4 mH 塑料件材料 型号： S650FR 94V-0 130 °C UL E41938 28 Coil Choke L4 Dongguan Dazhong Electric Co., Ltd 250V 220uH FOSHAN SHUNDE FONGMING ELECTRONIC TECH CO LTD CBB61 250VAC. 5-6.8uF T90 UL E215893 SHUNDE CHUANGGE ELECTRONIC INDUSTIAL CO.,LTD CBB61 250VAC. 5-6.8uF T90 UL E228621 29 X capacitor 电容 FOSHAN SHUNDE DAHUA ELECTRIC CO.,LTD CBB6-1 250VAC. 5-6.8uF T90 UL E162459 30 电源线端子 Quick-connect Terminals GEM TERMINAL IND CO LTD 99798L UL E135745
