TBYHPTPS-BT02Bluetooth USB Dongle

Confidential Version1.0 Released Date: 2004.10.01 1 BT Dongle-IS1002N Horus Module USB Bluetooth Adapte r Bluetooth Adapter (TPS-BT02) USER’S GUIDE Version: Rev 1.2 Nov 01, 2004 Copyright Copyright © 2004, Integrated System Solution Corp., All rights reserved. Confidential Version1.0 Released Date: 2004.10.01 2 BT Dongle-IS1002N Horus Module USB Bluetooth Adapte r Table of Contents INTRODUCTION .................................................................................................................................. 4 CHAPTER 1: INSTALLATION ........................................................................................................... 5 1.1 SYSTEM REQUIRE................................................................................................................... 5 1.2 INSTALL BLUETOOTH SOFTWARE WINDOWS 98/2000............................................................. 6 1.3 INSTALL BLUETOOTH SOFTWARE ON WINDOWS XP ............................................................. 10 1.4 HARDWARE INSTALLATION................................................................................................... 16 1.5 START THE BLUETOOTH DEVICE........................................................................................... 17 1.6 STOP THE BLUETOOTH DEVICE............................................................................................ 18 CHAPTER 2: BLUESOLEIL.............................................................................................................. 19 2.1 ABOUT BLUESOLEIL: ........................................................................................................... 19 2.2 EXPLORER BLUESOLEIL....................................................................................................... 24 2.3 FILE...................................................................................................................................... 24 2.4 VIEW.................................................................................................................................... 25 2.4.1 Local Service Status........................................................................................................ 27 2.4.2 Local Service List ........................................................................................................... 28 2.5 MY BLUETOOTH................................................................................................................... 29 2.6 MY SERVICES MENU............................................................................................................ 30 2.7 TOOLS MENU....................................................................................................................... 31 2.8 HELP MENU.......................................................................................................................... 35 CHAPTER 3: BLUETOOTH OPERATION ..................................................................................... 36 3.1 STA RT BLUETOOTH.............................................................................................................. 36 3.1.1 Establish Bluetooth Connection...................................................................................... 36 3.1.2 Terminate Bluetooth Connection .................................................................................... 37 3.2 BLUETOOTH SECURITY........................................................................................................ 37 3.3 PERSONAL AREA NETWORKING........................................................................................... 38 3.4 SERIAL PORT........................................................................................................................ 42 3.5 OBJECT PUSH....................................................................................................................... 43 3.6 FILE TRANSFER.................................................................................................................... 47 3.7 BLUETOOTH SYNCHRONIZATION.......................................................................................... 49 3.8 LAN ACCESS....................................................................................................................... 51 3.9 AV HEADPHONE................................................................................................................... 55 3.10 BASIC IMAGING.................................................................................................................... 55 3.11 HEADSET.............................................................................................................................. 57 Confidential Version1.0 Released Date: 2004.10.01 3 BT Dongle-IS1002N Horus Module USB Bluetooth Adapte r CHAPTER 4: BLUETOOTH CONNECTION MANAGEMENT................................................... 58 4.1 FIND REMOTE DEVICES................................................................................................................ 58 4.2 CONNECT AND DISCONNECT......................................................................................................... 59 4.2.1 Connect........................................................................................................................... 59 4.2.2 Disconnect ......................................................................................................................59 4.3 CONNECT VIA SHORTCUTS............................................................................................................ 60 4.4 REMOTE DEVICE STAT U S.............................................................................................................. 60 4.5 REMOTE DEVICE PROPERTIES....................................................................................................... 62 4.6 HARDWARE DEVICE CONFIGURATION.....................................................…

Text truncated - open the document above for the full version.

3. Block Diagram

Compliance Certification Services Inc. Report No: 50519204 Date of Issue: May 31, 2005 Page 1 Total Page: 3 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT

Compliance Certification Services Inc. Report No: 50519204 Date of Issue: May 31, 2005 Page 2 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: 50519204 Date of Issue: May 31, 2005 Page 3 Rev.00

ACX Advanced Ceramic X AT3216 Series Multilayer Chip Antenna Features ™ Monolithic SMD with small, low-profile and light-weight type. ™ Wide bandwidth Applications ™Bluetooth/Wireless LAN/Home RF ™ISM band 2.4GHz applications Specifications Part Number Frequency Range (MHz) Peak Gain XZ-V Average Gain XZ-V VSWR Impedance AT3216 -B2R7HAA_ 2400 ~ 2500 0.5 dBi typ. -0.5 dBi typ. 2 max. 50 Ω Q’ty/Reel (pcs) : 3,000pcs Operating Temperature Range : -40 ~ +85 o C Storage Temperature Range : -40 ~ +85 o C Power Capacity : 3W max. Part Number AT 3216 - B 2R7 HAA ‡ ‡ i ghfe dc c Type AT : Antenna d Dimensions ( L × W ) 3.2× 1.6 mm e Material Code B f Frequency Range 2R7=2700MHz g Specification Code HAA h Packaging T: Tape & Reel B: Bulk i Soldering =lead-containing /LF=lead-free Terminal Configuration No. Terminal Name No. Terminal Name c Feeding Point d NC d c ACX Advanced Ceramic X Dimensions and Recommended PC Board Pattern Unit : mm a W T L Mark L W T a Dimensions 3.20.2 1.60.2 1.3+ 0.1/-0.2 0.50.3 (a) Without Matching Circuits (b) With Matching Circuits 1.2pF 3.3nH 2.6 4.2 1.6 1.9 2.7nH 0.4 * *Line width should be designed to match 50Ω characteristic impedance, depending on PCB material and thickness. ACX Advanced Ceramic X Typical Electrical Characteristics (T=25 o C) ™Test Board Ground 13.5mm 6.5mm 39.5mm 4mm No Ground Matching Circuit 50Ω Feed Line 19mm Antenna 6.5mm ™Return Loss (a) Without Matching Circuits (b) With Matching Circuits ACX Advanced Ceramic X Radiation Patterns .... XZ cut @2.45GHz Vertical Horizontal YZ cut @2.45GHz Vertical Horizontal XZ-V/XZ-H YZ-V/YZ-H XY cut @2.45GHz Vertical Horizontal XY-V/XY-H Z 270 o 0 o X Y XY-cut scanning direction Y 270 o 0 o X Z XZ-cut scanning direction Z X 0 o 270 Y YZ-cut scanning direction 180 180 180 o 90 o 90 o 90 o Advanced Ceramic X Corp. 16 Tzu Chiang Road, Hsinchu Industrial District Hsinchu Hsien 303, Taiwan TEL:886-3-5987008 FAX:886-3-5987001 E-mail: [email protected] http://www.acxc.com.tw

Compliance Certification Services Inc. Report No.: 50519204-RP1 FCC ID: TBYHPTPS-BT02 Date of Issue: May 31, 2005 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 46 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Bluetooth USB Dongle Model: TPS-BT02 Trade Name: N/A Issued to Hong Puu Technology Co., Ltd. 2FL.NO.49.LU HSIN ST., LU CHU SHIANG, TAOYUAN SHIEN, 338. TAIWAN.R.O.C. Issued by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No.: 50519204-RP1 FCC ID: TBYHPTPS-BT02 Date of Issue: May 31, 2005 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION.....................................................................................................................5 3.2 EUT EXERCISE.................................................................................................................................5 3.3 GENERAL TEST PROCEDURES..........................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.....................................................6 3.5 DESCRIPTION OF TEST MODES........................................................................................................6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES 8 5.2 EQUIPMENT.....................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING...............................................................................8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS....................................................................................9 6. SETUP OF EQUIPMENT UNDER TEST ................................................................................ 10 6.1 SETUP CONFIGURATION OF EUT....................................................................................................10 6.2 SUPPORT EQUIPMENT ............................................................................................................10 7. FCC PART 15.247 REQUIREMENTS...................................................................................... 11 7.1 PEAK POWER.................................................................................................................................11 7.2 BAND EDGES MEASUREMENT .............................................................................................12 7.3 PEAK POWER SPECTRAL DENSITY.................................................................................................17 7.4 FREQUENCY SEPARATION....................................................................................................20 7.5 NUMBER OF HOPPING FREQUENCY ...................................................................................22 7.6 TIME OF OCCUPANCY (DWELL TIME)................................................................................24 7.7 RADIO FREQUENCY EXPOSURE.....................................................................................................31 7.8 SPURIOUS EMISSIONS .............................................................................................................32 7.9 POWERLINE CONDUCTED EMISSIONS............................................................................................42 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ....................................................................... 45 Compliance Certification Services Inc. Report No.: 50519204-RP1 FCC ID: TBYHPTPS-BT02 Date of Issue: May 31, 2005 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: Hong Puu Technology Co., Ltd. 2FL.NO.49.LU HSIN ST., LU CHU SHIANG, TAOYUAN SHIEN, 338. TAIWAN.R.O.C. Equipment Under Test: Bluetooth USB Dongle Trade Name: N/A Model: TPS-BT02 Date of Test: May 20 ~ 27, 2005 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Harris W. Lai Gavin Lim Executive Vice President Section Manager Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No.: 50519204-RP1 FCC ID: TBYHPTPS-BT02 Date of Issue: May 31, 2005 Page 4 Rev. 00 2. EUT DESCRIPTION Product Bluetooth USB Dongle Trade Name N/A Model Number TPS-BT02 Model Discrepancy N/A Power Supply Powered from host device Frequency Range 2402 ~ 2480 MHz Transmit Power 1.36dBm Modulation Technique FHSS Transmit Data Rate 1Mbps Number of Chan…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 50519204-RP1 FCC ID: TBYHPTPS-BT02 Date of Issue: May 31, 2005 Page 45 Rev. 00 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP Radiated Emission Set up Photos Compliance Certification Services Inc. Report No.: 50519204-RP1 FCC ID: TBYHPTPS-BT02 Date of Issue: May 31, 2005 Page 46 Rev. 00 Conducted Emission Set Up Photos
