TC2-R1011IP-STB

Roku, Inc.

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Sep 22, 2015
Application Purpose: Original Equipment
Date of Application: Sep 21, 2015
Equipment Note: IP-STB
Frequency Range: 5180.00000000 - 5240.00000000
Company: Roku, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Hi! Let’s get started. What’s in the box Roku player Remote control with in-ear headphone jack 2 x AA Alkaline batteries In-ear headphones Power adapter D Get to know your Roku B G F C Front view Back view A E Ethernet port – Connects your Roku player to a wired network with an Ethernet cable (not included). HDMI port – Connects your Roku player to an HDTV with an HDMI cable (not included). Reset button – Resets your Roku player to its original factory settings when pressed and held for 10 seconds (a feature you’ll rarely, if ever, use). Status light – Flashes slowly when the Roku player starts up. Glows when it’s on. Flashes once with each press of the remote control. Storage expansion slot – Lets you increase your storage capacity for Roku channels and games with a microSD card (optional, not included). Power port – Connects your Roku player to a 120V AC power source with the included power adapter. USB port – Plays your home videos, movies, music and photos from supported USB drives. For supported file types, visit roku.com/usb. Did you notice? Your Roku player has no on/off switch. It’s simpler that way and draws very little power—less than a nightlight! Keep it plugged in so that it can download the latest software updates automatically. What you need Roku player HDTV High-speed Internet connection (DSL or cable modem) Router HDMI cable (sold separately) Pssst! Your router can be wireless (any Wi-Fi) or wired. For wired networks, you’ll also need an Ethernet cable (not included). What to do Step 1 Ready for the step-by-step? We’ve only got four... Connect your player Use an HDMI cable (not included) to make the connection depicted in the diagram below: Did you know? Because HDMI outputs digital video and audio, you don’t need a separate audio cable. HDMI also supports up to 7.1 surround sound (where available). Got a receiver? You can also use HDMI to route video and audio directly through your receiver if it supports HDMI video pass-through. •Connect one end to the HDMI port on the back of your Roku player. •Connect the other end to an open HDMI port on your TV. What to do Step 2 Power up key components In this step, we’ll make sure all systems are GO! First, power your Roku remote by inserting the included batteries: •Turn the remote control over and locate the rectangular battery door on the rear of the unit. •Press the latch at the top of the battery door down while simultaneously removing the battery door. •Insert the batteries into their slots, making sure to match the positive (+) and negative (-) signs. •Place the battery door back over the compartment and press it gently down until the latch snaps securely into place. What to do Step 2 (continued) Next, power on your Roku player by connecting it to a wall outlet using the included power adapter, like this: Finally, power on your TV and look for a Roku message to fill the screen. Blank screen? If your TV does not display a Roku screen, make sure your TV input matches the physical connection used to connect your Roku player. Press the Input button (sometimes called Source) on your TV or TV remote to cycle through the various video inputs available until you see a Roku screen. What to do Step 3 Configure your network Step 3 establishes your network connection and brings out your inner geek. You can do it! Just choose either wireless or wired and read on for instructions: Wireless: If you use a wireless network, you can grab that Roku remote and jump right into Guided Setup. When prompted, select “Wireless” as your network connection and have your network name and password ready. Then: •Select your network from the list of available networks. •Enter your network password, if you use one. Remember, network passwords are case sensitive. Dos and don’ts on where to place your Roku player: •DO place your player within range of your wireless network. •DON’T place your player in an enclosed cabinet; it may interfere with the wireless signal. •DON’T place your player beneath anything; it may cause the player to overheat. Eeeeks. What to do Step 3 (continued) Wired: If you use a wired network, this step is a snap. Simply make the two connections depicted in the diagram below, and then use your Roku remote to select “Wired” from the on-screen network options. •Connect one end to the Ethernet port on the back of your Roku player. •Connect the other end to an open Ethernet port on your router. What to do Step 4 Complete Guided Setup It’s the final stretch and hooray—it’s a breeze! Continue following the on-screen instructions and you’ll: •Get the latest software. •Select the video output resolution. •Link the Roku player to your Roku account on your computer. And setup is done...congratulations! Continue using that Roku remote, which you can learn more about on the following pages, to personalize your channel line-up, stream movies or play games. The fun part has just begun, we promise. Your Roku account: During Guided Setup, you’ll be prompted to create your Roku account online at roku.com/link. Your Roku player will generate a unique code that links your player to your new account. Roku accounts are free and secure. And while a valid credit card number is required to create your account, rest assured you will only be charged if you authorize purchases of apps and games from the Roku Channel Store. Get to know your remote! First a couple of fun-facts about your Roku enhanced remote. •It can hush your TV. When you plug headphones into the headphone jack, the TV is automatically muted. Use the Volume UP and DOWN buttons on the side of your remote to control the volume of your headphones to your liking. •It’s sensitive and smart. The Roku 3 remote incorporates motion-sensing technology, allowing more precise and detailed control of gameplay. •It comes with an adjustable wrist strap—for good reason. Since some games make you sweat, sporting the wrist strap is a very good idea. You don’t want to crack the screen of your beautiful TV—or harm an…

Text truncated - open the document above for the full version.

Cover Letter(s)

Roku Inc. Family Certification Cover Letter FCC ID: TC2-R1011 Date: 2015/09/11 Please be notified that we, the undersigned, Roku Inc. declares that the product which bears the above FCC ID Contains 6 model numbers: 4210X, 4230X, 4210X1, 4230X1, 4200X1, 4205X1 The RF specifications of six models are identical. The difference is the marketing sale. Sincerely Greg Garner / Principal Engineer Roku Inc.

Cover Letter(s)

Roku Inc. Date：2015.09.11 Federal Communications Commission Authorization and Evaluation Division FCC ID: TC2-R1011 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1 Schematics 2 Block Diagram 3 Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. Sincerely, __________________ Greg Garner / principal Engineer Roku Inc.

Cover Letter(s)

Roku Inc. Date: 2015-09-11 Federal Communications Commission Authorization and Evaluation Division FCC ID: TC2-R1011 ATTESTATION FCC ID: TC2-R1011 Product: IP-STB Model: 4210X, 4230X, 4210X1, 4230X1, 4200X1, 4205X1 We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA. Sincerely, __________________ Greg Garner / Principal Engineer Roku Inc.

Cover Letter(s)

Roku Inc. Declaration of Authorization We Name: Roku Inc. Address: 12980 Saratoga Ave, Suite D Saratoga, CA 95070 City:  CA . Country:USA . Declare that: Name Representative of agent: Dream Cao (1) Agent Company name: QuieTek Technology (Suzhou) Co., Ltd. Address: No.99 Hongye Rd., Suzhou Industrial Park , City: Suzhou Country China is authorized to apply for Certification of the following product(s): Product description: IP-STB Type designation: 4210X, 4230X, 4210X1, 4230X1, 4200X1, 4205X1 FCC ID: TC2-R1011 on our behalf. Date: 2015-09-11 Name: Greg Garner Function: Principal Engineer Signature: Notes: (1): Required for FCC application

Cover Letter(s)

Roku Inc. 12980 Saratoga Ave, Suite D Saratoga, CA 95070 Attestation for FCC Declaration of Conformity FCC ID: TC2-R1011 Date: 2015/09/11 Please be notified that we, the undersigned, Roku Inc. declares that the product which bears the above FCC ID is also compliant with the FCC requirements for DOC. The test report number supporting the DOC is 1570212R-RF-US-P01V01Testing in regards to this report was done by QuieTek Corp., located at No.5-22, Rueishu Keng, Rueiping Tsuen, Linkou Shiang, Taipei County 244, Taiwan, which has been accredited in accordance to all of the requirements of 47CFR 2.948 (d) and (e) of the FCC rules and KDB349827. Sincerely, __________________ Greg Garner / Principal Engineer Roku Inc.

External Photos

EUT Photograph (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo

ID Label/Location Info

REVDESCRIPTIONBYDATED.E.M.E. SHEET REV D REVISIONS DWG. NO. 8 A 7654321 B C D A B C D 8765431 SCALESHEET SIZEDRAWING NO.REV MFG.ENG. DES.ENG. DRAWN BY DATEAPPROVALS MATERIAL FINISH DO NOT SCALE DRAWING .XX .X DECIMALS ANGLES TOLERANCES ARE: DIMENSIONS ARE IN MM UNLESS OTHERWISE SPECIFIED QTY PER VERSION LIST OF MATERIALS ITEM NO.REF. DES. PART OR IDENTIFYING NO.OR DESCRIPTION NOMENCLATURE MATL/SPEC FILE 2/11 OF 1 THIRD ANGLE PROJECTION 12980 SARATOGA AVENUE, SARATOGA, CA 95070 THIS DOCUMENT CONTAINS CONFIDENTIAL AND PROPRIETARY INFORMATION OF ROKU, INC. THIS INFORMATION MAY NOT BE REPRODUCED, TRANSFERRED TO OTHER DOCUMENTS, DISCLOSED TO OTHERS, USED IN MANUFACTURING OR FOR ANY OTHER PURPOSE WITHOUT THE EXPRESS WRITTEN CONSENT OF ROKU, INC. COPYRIGHT (c) 2015 ROKU, INC. +/- 0.30 677.35 +/- 0.20 681.00 +/- 0.2035.00 +/- 0.206.00 1.50 Rubber Foot, Mustang-2, 4230X, 4 LAYER (Foxconn), US/CA WANGYI061615 SEE NOTES 0.3 0.5 0.15 6000000195-011 6000000195-0111 1PRODUCTION RELEASEWY091515 SEE NOTES NOTES: (UNLESS OTHERWISE SPECIFIED) 1. 3D DATABASE FEATURES TAKE PRECEDENCE OVER 2D DRAWINGS. 2. MATERIAL: HONGDA HD-7861 NO REGRIND ALLOWED COLOR: BLACK 1801 NOMINAL WALL:1.50 MM 3 INDICATED TEXT SURFACES TO BE HIGH POLISH 6000# 4 INDICATED SURFACES TO BE MT11520 5. ALL OTHER SURFACES TO BE SPI-B2 6 DIMENSION TO BE USED FOR CPK INSPECTION 7. ALL GATES. GATE REMOVAL, AND EJECTOR PIN LOCATIONS TO BE APPROVED BY ROKU INC. PRIOR TO TOOL CREATION. NO GATES TO BE LOCATED ON AESTHETIC SURFACES. MOLDER TO SUPPLY AND/OR CONFIRM GATE DESIGN THAT WILL YIELD AN ACCEPTABLE PART. EJECTOR MARKS TO BE FLUSH TO 0.25 BELOW SURFACE. 8. PART IDENTIFICATION: BAG AND TAG WITH PART NUMBER AND REVISION 9. THIS PART IS REQUIRED TO BE FULLY COMPLIANT WITH RoHS REQUIREMENTS FOR RESTRICTION OF HAZARDOUS SUBSTANCES. PER DIRECTIVE 2002/95/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL OF 27 JANUARY 2003 ON THE RESTRICTION OF THE USE OF CERTAIN HAZARDOUS SUBSTANCES IN ELECTRICAL AND ELECTRONIC EQUIPMENT. 10.SUPPLIER IS REQUIRED TO MANAGE AND AUDIT APPROVED SOURCES TO ASSURE RoHS COMPLIANCE IS CONTINUALLY MAINTAINED. 3 4 REVDESCRIPTIONBYDATED.E.M.E. SHEET REV D REVISIONS DWG. NO. 8 A 7654321 B C D A B C D 8765431 SCALESHEET SIZEDRAWING NO.REV MFG.ENG. DES.ENG. DRAWN BY DATEAPPROVALS MATERIAL FINISH DO NOT SCALE DRAWING .XX .X DECIMALS ANGLES TOLERANCES ARE: DIMENSIONS ARE IN MM UNLESS OTHERWISE SPECIFIED QTY PER VERSION LIST OF MATERIALS ITEM NO.REF. DES. PART OR IDENTIFYING NO.OR DESCRIPTION NOMENCLATURE MATL/SPEC FILE 2/11 OF 1 THIRD ANGLE PROJECTION 12980 SARATOGA AVENUE, SARATOGA, CA 95070 THIS DOCUMENT CONTAINS CONFIDENTIAL AND PROPRIETARY INFORMATION OF ROKU, INC. THIS INFORMATION MAY NOT BE REPRODUCED, TRANSFERRED TO OTHER DOCUMENTS, DISCLOSED TO OTHERS, USED IN MANUFACTURING OR FOR ANY OTHER PURPOSE WITHOUT THE EXPRESS WRITTEN CONSENT OF ROKU, INC. COPYRIGHT (c) 2015 ROKU, INC. +/- 0.30 677.35 +/- 0.20 681.00 +/- 0.2035.00 +/- 0.206.00 1.50 Rubber Foot, Mustang 4-layer, 4210X, CA, MX (Foxconn) WANGYI061615 SEE NOTES 0.3 0.5 0.15 6000000196-011 6000000196-0111 1PRODUCTION RELEASEWY091515 SEE NOTES NOTES: (UNLESS OTHERWISE SPECIFIED) 1. 3D DATABASE FEATURES TAKE PRECEDENCE OVER 2D DRAWINGS. 2. MATERIAL: HONGDA HD-7861 NO REGRIND ALLOWED COLOR: BLACK 1801 NOMINAL WALL:1.50 MM 3 INDICATED TEXT SURFACES TO BE HIGH POLISH 6000# 4 INDICATED SURFACES TO BE MT11520 5. ALL OTHER SURFACES TO BE SPI-B2 6 DIMENSION TO BE USED FOR CPK INSPECTION 7. ALL GATES. GATE REMOVAL, AND EJECTOR PIN LOCATIONS TO BE APPROVED BY ROKU INC. PRIOR TO TOOL CREATION. NO GATES TO BE LOCATED ON AESTHETIC SURFACES. MOLDER TO SUPPLY AND/OR CONFIRM GATE DESIGN THAT WILL YIELD AN ACCEPTABLE PART. EJECTOR MARKS TO BE FLUSH TO 0.25 BELOW SURFACE. 8. PART IDENTIFICATION: BAG AND TAG WITH PART NUMBER AND REVISION 9. THIS PART IS REQUIRED TO BE FULLY COMPLIANT WITH RoHS REQUIREMENTS FOR RESTRICTION OF HAZARDOUS SUBSTANCES. PER DIRECTIVE 2002/95/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL OF 27 JANUARY 2003 ON THE RESTRICTION OF THE USE OF CERTAIN HAZARDOUS SUBSTANCES IN ELECTRICAL AND ELECTRONIC EQUIPMENT. 10.SUPPLIER IS REQUIRED TO MANAGE AND AUDIT APPROVED SOURCES TO ASSURE RoHS COMPLIANCE IS CONTINUALLY MAINTAINED. 3 4 4200EU BELLY Label define HH P/N: 7031000318-01- 1.1 Product Serial Number label(s) and format(s) 1.1.1Serial Number The serial number consists of 12 characters. Roku will provide a full list of serial numbers each month for each product. The manufacturer is WIRELESS: 000000000000 SERIAL NO: 000000000000 422 CBlack C TYPEFACE: GOTHAM MEDIUM SIZE: 6 pt STEP 1: PRINT LABEL AND INCLUDE PMS 422C BOX STEP 2: PRINT PMS BLACK C SERIAL NUMBER AND BARCODE TYPEFACE: GOTHAM MEDIUM SIZE: 4 pt MID-PLANE 1 MID-PLANE 2 6. SN & MAC Barcode format: Code 39 4205EU BELLY Label define HH P /N: 7031000315-01 1.1 Product Serial Number label(s) and format(s) 1.1.1 Serial Number The serial number consi sts of 12 characters. Roku will provide a full li st of serial numbers each mont h for each product. The manufa ct urer is WIRELESS: 000000000000 SERIAL NO: 000000000000

Internal Photos

EUT Photograph (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo

RF Exposure Info

RF Exposure Evaluation Declaration Product Name : IP-STB Model No. : 4210X,4230X,4210X1,4230X1,4200X1,4205X1 FCC ID : TC2-R1011 Applicant : Roku Inc. Address : 12980 Saratoga Ave, Suite D Saratoga, CA 95070 Date of Receipt : Jul. 07, 2015 Issued Date : Sept.18, 2015 Report No. : 1570212R-RF-US-P20V01 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No: 1570212R-RF-US-P20V01 Page: 3 of 6 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu,China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC,TAF USA :FCC Japan :VCCI China :CNAS Report No: 1570212R-RF-US-P20V01 Page: 4 of 6 History of This Test Report REPORT NO. VERSION DESCRIPTION ISSUED DATE 1570212R-RF-US-P20V01 V1.0 Initial Issued Report Sept. 18, 2015 Report No: 1570212R-RF-US-P20V01 Page: 5 of 6 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r2) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No: 1570212R-RF-US-P20V01 Page: 6 of 6 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. 1.3. Test Result of RF Exposure Evaluation Product : IP-STB Test Item : RF Exposure Evaluation Test Site : AC-6 z Antenna Gain: Antenna Gain: The maximum Gain measured in fully anechoic chamber is 2dBi for 2.4GHz and 1dBi for 5GHz in logarithm scale. z Output Power into Antenna & RF Exposure Evaluation Distance: Frequency Band (MHz) Maximum Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 2412-2462 390.84 0.0778 5150-5250 44.67 0.0112 5785-5825 145.88 0.0290 Note: The power density Pd (4th column) at a distance of 20 cm calculated from the Friis transmission formula is far below the limit of 1 mW/cm2. The End

Test Report

Test Report FCC 15 Subpart E 15.407 Product Name : IP-STB Model No. : 4210X,4230X,4210X1,4230X1,4200X1,4205X1 FCC ID : TC2-R1011 Applicant : Roku Inc. Address : 12980 Saratoga Ave, Suite D Saratoga, CA 95070 Date of Receipt : Jul.07, 2015 Test Date : Jul.09, 2015~Aug.24, 2015 Issued Date : Sept.18, 2015 Report No. : 1570212R-RF-US-P09V01 Report Version : V2.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No: 1570212R-RF-US-P09V01 Page: 3 of 200 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park, Suzhou,215006, Jiangsu,China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. : BSMI, NCC,TAF USA : FCC Japan : VCCI China : CNAS Report No: 1570212R-RF-US-P09V01 Page: 4 of 200 TABLE OF CONTENTS Description Page 1. General Information .................................................................................................................... 8 1.1. EUT Description ...................................................................................................................... 8 1.2. Mode of Operation ................................................................................................................ 10 1.3. Tested System Details ........................................................................................................... 11 1.4. Configuration of Tested System ............................................................................................ 12 1.5. EUT Exercise Software ......................................................................................................... 13 2. Technical Test ............................................................................................................................ 14 2.1. Summary of Test Result ........................................................................................................ 14 2.2. Test Environment .................................................................................................................. 15 3. Conducted Emission ................................................................................................................. 16 3.1. Test Equipment ..................................................................................................................... 16 3.2. Test Setup ............................................................................................................................. 16 3.3. Limit ....................................................................................................................................... 17 3.4. Test Procedure ...................................................................................................................... 17 3.5. Uncertainty ............................................................................................................................ 17 3.6. Test Result ............................................................................................................................ 18 4. Radiated Emission .................................................................................................................... 20 4.1. Test Equipment ..................................................................................................................... 20 4.2. Test Setup ............................................................................................................................. 21 4.3. Limit ....................................................................................................................................... 22 4.4. Test Procedure ...................................................................................................................... 22 4.5. Uncertainty ............................................................................................................................ 23 4.6. Test Result ............................................................................................................................ 24 5. Occupied Bandwidth ................................................................................................................. 33 5.1. Test Equipment ..................................................................................................................... 33 5.2. Test Setup ............................................................................................................................. 33 5.3. Limit ...........................…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Robert Curtis(VP Engineering)

[email protected]707-365-0353Fax: 1-479-446-1735

Technical Contact

QuieTek Technology (Suzhou) Co.,Ltd.Harry Zhao

[email protected]86-0512-6251-5088

No.99 Hongye RD.Suzhou Industrial Park, Loufeng · SuZhou · China

Non-Technical Contact

QuieTek Technology (Suzhou) Co.,Ltd.Yuki Li

[email protected]86-0512-6251-5088

Test Firm

DEKRA Testing and Certification (Suzhou) Co., Ltd.Jerry Pan

[email protected]86-512-62515088Fax: 86-512-62515098

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15E	5.18 GHz - 5.24 GHz	44.67 mW

Confidentiality

Long Term

Grant Notes

Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This devcie has a 20 MHz and 40 MHz bandwidth mode.
