TDB-FLEX-RPFLEX RP Repeater

1608 4th Street Suite 200 Berkeley CA 94710| [email protected] | P 510.548.4620 F 510.548.8264 1608 4th Street Suite 200 Berkeley CA 94710 | [email protected] | P 510.548.4620 F 510.548.8264 Quick Start Guide: FLEX-RP-B/FLEX-RP-B-LL Connect Battery Unlatch the two hinges. Open the repeater cover. Open repeater 1 a Warnings Lithium Thionyl Chloride Batteries Sensys Networks uses Lithium Thionyl Chloride batteries in the following products: • SENSORS (VSN240-F, VSN240-T, VSN240-S, VSN240-M, VSN240-F-2, VSN240-T-2) • REPEATERS (RP240-B, RP240-B-LL, RP240-BH, RP240-BH-LL, FLEX-RP-B, FLEX-RP-B-LL) Lithium batteries are widely used in electronic products because they contain more energy per unit-weight than conventional batteries. However, the same properties that deliver high energy density also contribute to potential hazards if the batteries are damaged. Improper use or handling of the batteries may result in leakage or release of battery contents, explosion, or fire. Following are the recommendations of the battery manufacturer for proper use and handling of batteries in the Sensys Networks devices mentioned above: • DO NOT CHARGE OR ATTEMPT TO RECHARGE THE BATTERIES (BATTERIES ARE NOT RECHARGEABLE) • DO NOT CRUSH OR PUNCTURE BATTERIES • DO NOT SHORT-CIRCUIT THE BATTERIES • DO NOT FORCE OVER-DISCHARGE OF THE BATTERIES • DO NOT INCINERATE OR EXPOSE BATTERIES TO EXCESSIVE HEATING • DO NOT EXPOSE BATTERY CONTENTS TO WATER • DO DISPOSE OF BATTERIES AND DEVICES CONTAINING BATTERIES IN ACCORDANCE WITH LOCAL REGULATIONS Sensys Networks sensors contain no serviceable parts and should never be disassembled. Installation and removal of sensors from pavement should only be done by trained personnel and care should be taken to insure that the sensor casing is not punctured or crushed. Additional safety information is available from the battery’s manufacturer: Sensor battery cell: http://ultralifecorporation.com/download/308/ Repeater battery cell: www.ewtbattery.com/en/DownView.asp?ID=9 Connect battery cable to circuit-board connector (a). DO NOT PINCH OR STRESS CABLES. Wait approximately five seconds for LED lights to blink. Close cover; ensure wires are not caught in edges. Latch the two hinges securely. Connect Battery 1608 4th Street Suite 200 Berkeley CA 94710| [email protected] | P 510.548.4620 F 510.548.8264 1608 4th Street Suite 200 Berkeley CA 94710 | [email protected] | P 510.548.4620 F 510.548.8264 Connect to Access Point Select an access point from the automated list and click Connect. Note: Ensure the box for Load map data is checked before clicking Connect. Select IP address Click the icon to start TrafficDOT2. Run TrafficDOT 2 The Main window displays. The map on the Main window populates and configured equipment appears on the map and in the sensor tray at the bottom of the window. Note: Before configuring or reconfiguring a repeater, ensure the correct repeater is displayed on the map by hovering over the repeater icon with the mouse to view repeater information. Main Window Quick Start Guide: FLEX-RP-B/FLEX-RP-B-LL 1608 4th Street Suite 200 Berkeley CA 94710| [email protected] | P 510.548.4620 F 510.548.8264 1608 4th Street Suite 200 Berkeley CA 94710 | [email protected] | P 510.548.4620 F 510.548.8264 Configure Repeater Select a repeater from the image map to access the Repeater Configuration window with the Position tab open. The Name field allows the repeater’s name to be user-defined. Note: Repeater’s firmware version is displayed for reference only. Repeater Configuration Window 3 Select an upstream channel by clicking the Config tab. Select an entry for the Current Upstream Ch field by clicking on the Change to drop-down list. Specifying Upstream Channel Select a entry for the Current Downstream Ch field by clicking the Change to drop-down list. Specifying Downstream Channel Quick Start Guide: FLEX-RP-B/FLEX-RP-B-LL • The default radio channel for access point to repeater communications is 0 (zero). • The default radio channel for repeater to sensor communications is 1 (one). • Never use the same channel for both access point and sensor communications. Refer to Sensys Network VDS240 Wireless Vehicle Detection System TrafficDOT v2.10 Set Up and Operating Guide for more information. Channel Notes • When an installation contains multiple repeaters with more than ten sensors, changing one or more repeaters from Current Config 0 to Current Config 1 allows the repeater to communicate with up to 20 sensors. Refer to Sensys Network VDS240 Wireless Vehicle Detection System TrafficDOT v2.10 Set Up and Operating Guide for more information. Config Notes 1608 4th Street Suite 200 Berkeley CA 94710| [email protected] | P 510.548.4620 F 510.548.8264 1608 4th Street Suite 200 Berkeley CA 94710 | [email protected] | P 510.548.4620 F 510.548.8264 Configure Repeater (cont.) Quick Start Guide: FLEX-RP-B/FLEX-RP-B-LL Click Apply to accept configuration changes. Click SAVE to save changes made to the access point. Save Configuration By default, TrafficDOT filters the contents of the drop-down list so that only available time slots are displayed. Click an entry from the Change Timeslot to drop-drop list. Note: The grayed out options can be made accessible by enabling Advanced Mode using the Advanced drop-down menu. To change the drop-down list to include all time slots in the network (both assigned and unassigned), remove the check in the Show only available slots. Set Time Slot Sensys Networks and the Sensys Networks logo are trademarks of Sensys Networks, Inc. All other trademarks are the property of their respective owners. Information contained herein is believed to be reliable, but Sensys Networks makes no warranties as to its accuracy or completeness. Copyright © 2014 Sensys Networks, Inc. • ALL RIGHTS RESERVED • P/N 152-240-020-016 Rev D Local Distributor Quick Start Guide: FLEX-RP-B/FLEX-RP-B-LL Configure Repeater (cont.) If the repeater is conn…

Text truncated - open the document above for the full version.

Attestation Letter Date: 2014.9.23 Federal Communications Commission Authorization and Evaluation Division FCC ID: TDB-FLX-RP ATTESTATION FCC ID: TDB-FLX-RP Product: FLEX RP Repeater Model: FLEX-RP-B, FLEX-RP-B-LL This is a repeater, it has software and code to ensure it’s only authorized to operate the transmitter with following FCC ID: TDB-MAG2 Sincerely, Robert Kavaler /VP Engineering SENSYS Networks Inc.

SENSYS Networks Inc. Date: 2014-09-23 Federal Communications Commission Authorization and Evaluation Division FCC ID: TDB-FLEX-RP ATTESTATION FCC ID: TDB-FLEX-RP Product: FLEX RP Repeater Model: FLEX-RP-B, FLEX-RP-B-LL We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA. Sincerely, Robert Kavaler /VP Engineering SENSYS Networks Inc.

Sensys Networks, Inc. Family Certification Cover Letter FCC ID: TDB-FLEX-RP Date: 2014/09/23 Please be notified that we, the undersigned, Sensys Networks, Inc. declares that the product which bears the above FCC ID Contains 2 model numbers: FLEX-RP-B, FLEX-RP-B-LL . Note: The difference of models as show below: model power supply mode FLEX-RP-B internal battery pack FLEX-RP-B-LL long-life battery pack The RF specifications of two models are identical. And there is no other difference. Your understanding will be highly appreciated. Robert Kavaler / VP Engineering Sensys Networks, Inc.

RF_160, Issue 02 SENSYS Networks Inc. We Name: SENSYS Networks Inc. Address: 1608 4th Street, Suite 110, Berkeley, CA 94710.USA City: Berkeley ............................................................................ Country: United States ............................................................................ Declare that: Name Representative of agent: Gene Chang (1) Agent Company name: QuieTek Corp. Address: Fl.2, No.345, Xin-hu 2 nd Rd., Nei-hu District City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: FLEX RP Repeater ............ Type designation: FLEX-RP-B, FLEX-RP-B-LL .................. Trademark: SENSYS on our behalf. Date: ...... 2014-09-23.............. City: ...... Berkeley .......................... Name: ...... Robert Kavaler ................................ Function: ...... VP Engineering ............................ Signature: ... ............................................. Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

SENSYS Networks Inc. DATE Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:___ TDB-FLEX-RP _________ Product Name:____ FLEX RP Repeater _______ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Date this 2014-09-23 By: Robert Kavaler Printed Title: VP Engineering On behalf of : SENSYS Networks Inc. (Company Name) Telephone: 5105484620

EUT Photograph (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (Antenna 1a) (8) EUT Photo (Antenna 1a) (9) EUT Photo (Antenna 1a) (10) EUT Photo (Antenna 1a) (11) EUT Photo (Antenna 1a) (12) EUT Photo (Antenna 1a) (13) EUT Photo (Antenna 1b) (14) EUT Photo (Antenna 1b) (15) EUT Photo (Antenna 1b) (16) EUT Photo (Antenna 1b) (17) EUT Photo (Antenna 1b) (18) EUT Photo (Antenna 1b)

U

U

EUT Photograph (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (Antenna 1a) (6) EUT Photo (Antenna 1a) (7) EUT Photo (Antenna 1a) (8) EUT Photo (Antenna 1a) (9) EUT Photo (10) EUT Photo (11) EUT Photo (Antenna 1b) (12) EUT Photo(Antenna 1b) (13) EUT Photo (Antenna 1b)

Test Report FCC Part15.249 Product Name : FLEX RP Repeater Model No. : FLEX-RP, FLEX-RP-B, FLEX-RP-B-LL FCC ID : TDB-FLEX-RP Applicant : Sensys Networks, Inc. Address : 1608 Fourth Street, Suite 200 Berkeley, CA 94710, U.S.A Date of Receipt : Jul. 03, 2014 Test Date : Jul. 03, 2014~Sep. 03, 2014 Issued Date : Sep. 05, 2014 Report No. : 1470114R-RF-US-P06V01 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, CNAS or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No: 1470114R-RF-US-P06V01 Page: 2 of 55 Test Report Certification Issued Date : Sep. 05, 2014 Report No. : 1470114R-RF-US-P06V01 Product Name : FLEX RP Repeater Applicant : Sensys Networks, Inc. Address : 1608 Fourth Street, Suite 200 Berkeley, CA 94710, U.S.A Manufacturer : N/A Address : N/A Model No. : FLEX-RP, FLEX-RP-B, FLEX-RP-B-LL FCC ID : TDB-FLEX-RP EUT Voltage : DC: 3.6V Applicable Standard : FCC CFR Title 47 Part 15 Subpart C: 2012 ANSI C63.4: 2009, ANSI C63.10:2009 Test Result : Complied Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392 Documented By : Reviewed By : Approved By : Report No: 1470114R-RF-US-P06V01 Page: 3 of 55 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. : BSMI, NCC, TAF Germany : TUV Rheinland Norway : Nemko, DNV USA : FCC Japan : VCCI China : CNAS Report No: 1470114R-RF-US-P06V01 Page: 4 of 55 TABLE OF CONTENTS Description Page 1. General Information.................................................................................................... 6 1.1. EUT Description ......................................................................................................... 6 1.2. Mode of Operation ..................................................................................................... 8 1.3. Tested System Details ................................................................................................ 9 1.4. Configuration of Tested System ............................................................................... 10 1.5. EUT Exercise Software ............................................................................................ 11 2. Technical Test ........................................................................................................... 12 2.1. Summary of Test Result ........................................................................................... 12 2.2. Test Environment ..................................................................................................... 13 3. Conducted Emission ................................................................................................ 14 3.1. Test Equipment ........................................................................................................ 14 3.2. Test Setup ................................................................................................................ 14 3.3. Limit .......................................................................................................................... 15 3.4. Test Procedure ......................................................................................................... 15 3.5. Uncertainty ............................................................................................................... 15 3.6. Test Result ............................................................................................................... 15 4. 20dB Bandwidth ....................................................................................................... 16 4.1. Test Equipment ........................................................................................................ 16 4.2. Test Setup ................................................................................................................ 16 4.3. Limit .......................................................................................................................... 16 4.4. Test Procedure ......................................................................................................... 17 4.5. Uncertainty ............................................................................................................... 17 4.6. Test Result ...........................…

Text truncated - open the document above for the full version.

Test Report FCC Part15.249 Product Name : FLEX RP Repeater Model No. : FLEX-RP-B, FLEX-RP-B-LL FCC ID : TDB-FLEX-RP Applicant : Sensys Networks, Inc. Address : 1608 Fourth Street, Suite 200 Berkeley, CA 94710, U.S.A Date of Receipt : Jul. 03, 2014 Test Date : Jul. 03, 2014~Sep. 03, 2014 Issued Date : Sep. 05, 2014 Report No. : 1470114R-RF-US-P06V01 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, CNAS or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No: 1470114R-RF-US-P06V01 Page: 2 of 55 Test Report Certification Issued Date : Sep. 05, 2014 Report No. : 1470114R-RF-US-P06V01 Product Name : FLEX RP Repeater Applicant : Sensys Networks, Inc. Address : 1608 Fourth Street, Suite 200 Berkeley, CA 94710, U.S.A Manufacturer : N/A Address : N/A Model No. : FLEX-RP-B, FLEX-RP-B-LL FCC ID : TDB-FLEX-RP EUT Voltage : DC: 3.6V Applicable Standard : FCC CFR Title 47 Part 15 Subpart C: 2012 ANSI C63.4: 2009, ANSI C63.10:2009 Test Result : Complied Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392 Documented By : Reviewed By : Approved By : Report No: 1470114R-RF-US-P06V01 Page: 3 of 55 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. : BSMI, NCC, TAF Germany : TUV Rheinland Norway : Nemko, DNV USA : FCC Japan : VCCI China : CNAS Report No: 1470114R-RF-US-P06V01 Page: 4 of 55 TABLE OF CONTENTS Description Page 1. General Information.................................................................................................... 6 1.1. EUT Description ......................................................................................................... 6 1.2. Mode of Operation ..................................................................................................... 8 1.3. Tested System Details ................................................................................................ 9 1.4. Configuration of Tested System ............................................................................... 10 1.5. EUT Exercise Software ............................................................................................ 11 2. Technical Test ........................................................................................................... 12 2.1. Summary of Test Result ........................................................................................... 12 2.2. Test Environment ..................................................................................................... 13 3. Conducted Emission ................................................................................................ 14 3.1. Test Equipment ........................................................................................................ 14 3.2. Test Setup ................................................................................................................ 14 3.3. Limit .......................................................................................................................... 15 3.4. Test Procedure ......................................................................................................... 15 3.5. Uncertainty ............................................................................................................... 15 3.6. Test Result ............................................................................................................... 15 4. 20dB Bandwidth ....................................................................................................... 16 4.1. Test Equipment ........................................................................................................ 16 4.2. Test Setup ................................................................................................................ 16 4.3. Limit .......................................................................................................................... 16 4.4. Test Procedure ......................................................................................................... 17 4.5. Uncertainty ............................................................................................................... 17 4.6. Test Result .............................................…

Text truncated - open the document above for the full version.

Test Setup Photograph Description: Radiated Emission Test Setup for Below 1GHz Mode 1 Mode 2 Mode 3 Description: Radiated Emission Test Setup for Above 1GHz Mode 1 Mode 2 Mode 3
