Coligen Corp. Information folder No. Coligen-TXL88R07 Issuing date: April 1, 2006 Type: RF001DTX Page 1 of 10 Content DOCUMENT Content Technical description Dimension drawing Rating label drawing Circuit Diagram PCB layout Product Photo Bill of materials PAGE 1 2-3 4-5 6 7 8 9 10 Coligen Corp. Information folder No. Coligen-TXL88R07 Issuing date: April 1, 2006 Type: RF001DTX Page 2 of 10 INFORMATION DOCUMENT FOR TYPE-APPROVAL OF AN ELECTRIC/ELECTRONIC SUB- ASSEMBLY WITH RESPECT TO ELECTROMAGNETIC COMPATIBILITY ACCORDING ANNEX 2B OF ECE-R10 1 Make (trade name of the manufacturer) : Coligen 2 Type and general commercial description(s) : TXL88R07 - commercial description(s) : Parking sensor - version(s) : Version 1: TXL88R07-RF001DTX (915MHZ) 3 Name and address of the manufacturer :Coligen Corp. No. 1 bldg. ,Guantang Ind. Park, Jingding Zhuhai, Guangdong Province, P.R. China 4 In the case of components and separate technical units, location and method of affixing of the approval mark :label affixed to the housing 5 Address(es) of assembly plant(s) :Coligen Corp. No. 1 bldg. ,Guantang Ind. Park, Jingding Zhuhai, Guangdong Province, P.R. China 6 This ESA shall be approved as a :component 7 Any restrictions of use and conditions for fitting :no restrictions Coligen Corp. Information folder No. Coligen-TXL88R07 Issuing date: April 1, 2006 Type: RF001DTX Page 3 of 10 Additional information Electrical system rated voltage : DC5V, negative ground This ESA can be used on any vehicle type with the following restrictions : no restrictions Installation conditions :connected to battery and/or reversing lamp circuit This ESA can be used on the following vehicle types : not applicable Installation conditions :--- The specific test method(s) used and the frequency ranges covered to determine immunity were :not applicable frequency range : --- Remark : rating current: 50mA Coligen Corp. Information folder No. Coligen-TXL88R07 Issuing date: April 1, 2006 Type: RF001DTX DRW. RF001DTX-01 Dimension drawing Page 4 of 10 Coligen Corp. Information folder No. Coligen-TXL88R07 Issuing date: April 1, 2006 Type: RF001DTX DRW. RF001DTX-02 Dimension Drawing Page 5 of 10 Coligen Corp. Information folder No. Coligen-TXL88R07 Issuing date: April 1, 2006 Type: RF001DTX DRW. RF001DTX-03 Rating label drawing Page 6 of 10 Coligen Corp. Information folder No. Coligen-TXL88R07 Issuing date: April 1, 2006 Type: RF001DTX DRW. RF001DTX-04 Circuit Diagram Page 7 of 10 Coligen Corp. Information folder No. Coligen-TXL88R07 Issuing date: April 1, 2006 Type: RF001DTX PCB Layout Page 8 of 10 Coligen Corp. Information folder No. Coligen-TXL88R07 Issuing date: April 1, 2006 Product Photo Type: RF001DTX Page 9 of 10 Coligen Corp. Information folder No. Coligen-TXL88R07 Issuing date: April 1, 2006 Type: RF001DTX Bill of materials P/NO. DESCRIPTION QTY. Remark CC1000 Integrated circuit 1 U102 ATMEGA8L-8AI Integrated circuit 1 U1 14.745MHZ Crystal 1 XT101 8.000MHZ Crystal 1 XT1 EXRF001D-TX PCB 1 10UF/6.3V Tery Capacitor 1 C111 100UF/6.3V Tery Capacitor 1 C5 BAV99 Double Diode 1 D1 27P Ceramic Capacitor 4 C14,C15,C114,C115 102P Ceramic Capacitor 5 C103,C113, C128,C132, C210 104J Ceramic Capacitor 4 C1,C2,C3,C4 10P Ceramic Capacitor 1 C141 5P Ceramic Capacitor 3 C101,C102,C131 4P Ceramic Capacitor 1 C152 0Ω Resistor 1 R110 1K Resistor 1 R2 2K Resistor 2 R101,R1 27K Resistor 1 R109 82K Resistor 1 R131 120N Inductor 1 L142 4.7N Inductor 1 L191 1000N Inductor 1 L210 2.5N Inductor 2 L162,L141 PM2*8 PM2*8 2 M2 M2 2 DPCL-0015-4811 Power wire 1 +5,GND,RX 98-3 gumwater Omnipotent gumwater 1 ANT 502 gumwater gumwater 1 ANT Dedicated ANT RF ANT 1 ANT Page 10 of 10

Product Operation Description of RF001DTX This product is the transmitter part of a parking sensor system, which is designed with ultrasonic technology to assist the driver to park or reverse the vehicle. It would be operated with the controller part and the display part of the parking sensor system. See below picture for the installation information of the system. This product is powered by the same power source, which would be DC 5V from the vehicle lead-acid batteries, as the reverse lights. The main function of the product is to transmit the RF signal to display part of the same system. RF link is setup between this product and the display part in 2FSK half-duplex form. While in the power on handshake period, RF signal for ID confirmation would be transmitted from this product to the display part. It only happens on the first-time operation, and after ID confirmation, the signal of alarm will be transmitted from this product to the display part frequently. Integral antenna is used. The frequency range of the product is 915.11MHz and 916.58MHz. The half-duplex RF link of the system will be auto tuned to one of above channel that is available.

Produktsicherheit und –qualität Product Safety and Quality Prüfbericht - Nr.: Test Report No.: 16008030 001 Seite 8 von 15 Page 8 of 15 4 Test Set-up and Operation Mode 4.1 Principle of Configuration Selection Emission: The equipment under test (EUT) was configured to measure its highest possible radiation level. The test modes were adapted accordingly in reference to the instructions for use. 4.2 Test Operation and Test Software Refer to Test set-up in chapter 5. 4.3 Special Accessories and Auxiliary Equipment The product has been tested together with 5V DC power supply and controller part TXPCE801. 4.4 Countermeasures to achieve EMC Compliance The test sample, which has been tested, contained the noise suppression parts as described in the technical document. No additional measures were employed to achieve compliance.

Produktsicherheit und –qualität Product Safety and Quality Prüfbericht - Nr.: Test Report No.: 16008030 001 Seite 13 von 15 Page 13 of 15 6 Photographs of the Test Set-Up Photograph 1: Set-up for Radiation Measurement Below 1GHz Produktsicherheit und –qualität Product Safety and Quality Prüfbericht - Nr.: Test Report No.: 16008030 001 Seite 14 von 15 Page 14 of 15 Photograph 2: Set-up for Radiation Measurement Above 1GHz
