TFT-RM100MaxID UHF RFID Reader Module type RM100

MAXID Corp.

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Nov 10, 2005
Application Purpose: Original Equipment
Date of Application: Nov 10, 2005
Equipment Note: MaxID UHF RFID Reader Module type RM100
Frequency Range: 902.00000000 - 928.00000000
Company: MAXID Corp.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Copyright 2005 MaxID Limited, All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior permission of MaxID. MaxID Limited, Quatro House, Lyon Way, Frimley, Surrey GU16 7ER, United Kingdom Phone: +44 (0) 1276 80 4498, Fax: +44 (0) 1276 80 4499, URL: www.MaxIDcorp.com ! " # MaxID RM100 RFID reader interface Project - RFID ID1170 Version 0.1 18 October, 2005 Page ii Change History Configuration Control Project: RFID Title: MaxID RM100 RFID reader User Manual Document ID: 1170 Created by: Riaan van den Berg Creation Date: 6 July 2005 Document History Version Date Status Who Saved as: 1.0 17 Oct. 05 revision RvdB MaxID RM100 User Manual Revision History Version Date Changes 0. 1 2005/07/06 Add unpacking and installation instruction chapters Management Authorisation Version Date Status Approval Minutes Reference MaxID RM100 RFID reader interface Project - RFID ID1170 Version 0.1 18 October, 2005 Page iii Table of Contents 1. Scope _____________________________________________________ 5 2. FCC Statement ______________________________________________ 6 WARNING ! ____________________________________________________ 6 3. Limitation of Liability_________________________________________ 7 4. Features ___________________________________________________ 8 5. Typical applications__________________________________________ 9 5.1 Automotive _______________________________________________ 9 5.2 Airline baggage ____________________________________________ 9 5.3 Consumables _____________________________________________ 9 5.4 Livestock tracking_________________________________________ 9 5.5 Hotel room Access _________________________________________ 9 5.6 Bin tracking _______________________________________________ 9 5.7 Valuable asset tracking _____________________________________ 9 5.8 Vehicle access systems _____________________________________ 9 6. Installing the RM100 RFID reader ______________________________ 10 6.1 Before You Start __________________________________________ 10 6.1.1 Overview of the RM100 module – Front ______________________ 10 6.1.2 Overview of the RM100 module – Back ______________________ 10 6.2 Hardware Requirements____________________________________ 11 6.2.1 Power supply __________________________________________ 11 6.2.2 Data Terminal Equipment (DTE) ____________________________ 11 6.3 Unpacking the RM100 KIT __________________________________ 11 6.4 Installing the software _____________________________________ 12 6.5 Installing the Patch Antennas _______________________________ 12 6.5.1 Dual Antenna set _______________________________________ 12 6.5.2 Single Antenna in handheld configuration_____________________ 13 7. Functional Block diagram ____________________________________ 14 8. Description ________________________________________________ 21 8.1 RFID Reader _____________________________________________ 21 8.2 Serial Interface ___________________________________________ 22 8.2.1 Physical: ______________________________________________ 22 8.2.2 Protocol: ______________________________________________ 22 8.2.3 Evaluation program______________________________________ 23 9. Specification_______________________________________________ 24 MaxID RM100 RFID reader interface Project - RFID ID1170 Version 0.1 18 October, 2005 Page iv 9.1 Performance _____________________________________________ 24 9.2 Physical _________________________________________________ 24 9.3 Environment _____________________________________________ 24 MaxID RM100 RFID reader interface Project - RFID ID 1170 Version 0.1 18 October, 2005 Page 5 of 24 1. Scope The RM100 from MaxID Ltd is a multi-protocol radio frequency identification (RFID) reader designed to support all electronic product code (EPC)-compliant UHF RFID tags. The RM100 is an industrial-class OEM (Original Equipment Manufacturer) reader that provides all of the RFID control functions required to power and communicates with passive RFID tags. The RM100 was designed to integrate into handheld portable data terminals, printers, label applications, mobile computers and other OEM devices. It is a high-performance reader that collects, writes, processes and communicates information from all classes of EPC RFID tags. The RM100 leverages advanced digital filter technology to deliver superior interference management and are optimized to read tags in both clean and noisy radio environments. MaxID RM100 RFID reader interface Project - RFID ID1170 Version 0.1 18 October, 2005 Page 6 of 24 2. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING ! This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Conne…

Text truncated - open the document above for the full version.

Block Diagram

11 22 33 44 D D C C B B A A 1 MaxID Limited Quatro House, Lyon Way FrimleySurrey GU16 7ER United Kingdom 7 MaxID_4411 Blockdiagram RM100_4411 00 7/20/2005 2:14:19 PM C:\work\ProtelProjects\MAXID_DXP\max id_4411\Documents\PROJ\BlockDiagram_4411.SCHDOC TitleSize: Number: Date:File: Revision:Sheet of Time: A3 U_BlockDiagram_4411_cpuBlockDiagram _4411_cpu.SCHDOC U_BlockDiagram_4411_fpga1BlockDiagram _4411_fpga1.SCHDOC U_BlockDiagram_4411_PABlockDiagram_4411_P A.SCHDOC U_BlockDiagram_4411_psuBlockDiagram _4411_psu.SCHDOC U_BlockDiagram_4411_synthBlockDiagram_4411_sy nth.SCHDOC U_BlockDiagram_4411_basebandBlockDiagram _4411_baseband.SCHDOC These components are located in their own RF shielded compartment Bottom compartment of enclosure houses RFD4411 Top compartment of enclosure houses RFM4410 TXRX The MaxID RFID reader consist of the following PCBs: RFD4411 - Digital section, Power supply, Digital decoder (FPGA), User Interface RFM4410 - RF synthesizer, RF power amp. , Base Band signal conditioning The Digital and RF PBCs are physically seperated from each other via an aluminium section The RF section is also further seperated from each other via aluminium compartments. 11 22 33 44 D D C C B B A A 6 MaxID Limited Quatro House, Lyon Way FrimleySurrey GU16 7ER United Kingdom 7 MaxID_4411 Blockdiagram - Base band receiver RM100_4411 00 7/20/2005 2:14:19 PM C:\work\ProtelProjects\MAXID_DXP\max id_4411\Documents\PROJ\BlockDiagram_4411_baseband.SCHDOC TitleSize: Number: Date:File: Revision:Sheet of Time: A3 RF Band Pass Filter 902-928Mhz RF IN From LO Drive I - Out Q - Out B.B Pre-amp Secondary B.B amp + LPF Single ended to Differential converter To RFD4411 ADC input Switched VRAW OpAmp_3v0 External from RFD4411 I/Q Demodulator OpAmp_1v5 From RX Antenna/ RP SMA or MMCX These components are located in their own RF shielded compartment 11 22 33 44 D D C C B B A A 2 MaxID Limited Quatro House, Lyon Way FrimleySurrey GU16 7ER United Kingdom 7 MaxID_4411 Blockdiagram - CPU and Interface RM100_4411 00 7/20/2005 2:14:20 PM C:\work\ProtelProjects\MAXID_DXP\max id_4411\Documents\SCH\BlockDiagram_4411_cpu.SCHDOC TitleSize: Number: Date:File: Revision:Sheet of Time: A3 Switched VRAW CPU_3v0 Tx_RS232 Rx_RS232 Tx_TTLRx_TTL RS232 level translation DAC output RFPA Power control Regulator/PSU filters Address/Data bus to FPGA Various Control/Interface - LEDS etc 12.288Mhz CPU programming I.F CPU MAX3232 Measure RFAMP current To PA_ADJ on RFM4410 PA power adjust buffer When RS232 translator not fitted bypass with links (TTL levels) (not user accessible) 11 22 33 44 D D C C B B A A 3 MaxID Limited Quatro House, Lyon Way FrimleySurrey GU16 7ER United Kingdom 7 MaxID_4411 Blocdiagram - FPGA/ADC interface RM100_4411 00 7/20/2005 2:14:20 PM C:\work\ProtelProjects\MAXID_DXP\max id_4411\Documents\PROJ\BlockDiagram_4411_fpga1.SCHDOC TitleSize: Number: Date:File: Revision:Sheet of Time: A3 Switched VRAW Switched VRAW ADC_3v0ADC_2v5 Switched VRAW Switched VRAW FPGA_3v0FPGA_1v5 ADCFPGA R2R Ladder I Channel In Q Channel In Differential inputs from RFM4410 Signal Conditioning/Data Modulation RFPA Modulation FPGA Programming I.F EEprom FPGA image EEprom Programming I.F To PA_MOD on RFM4410 (not user accessible) (not user accessible) Buffer 11 22 33 44 D D C C B B A A 5 MaxID Limited Quatro House, Lyon Way FrimleySurrey GU16 7ER United Kingdom 7 MaxID_4411 Blockdiagram - RF Power Amp RM100_4411 00 7/20/2005 2:14:20 PM C:\work\ProtelProjects\MAXID_DXP\max id_4411\Documents\PROJ\BlockDiagram_4411_PA.SCHDOC TitleSize: Number: Date:File: Revision:Sheet of Time: A3 Switched VRAW RF_3v0 External from RFD4411 RF_VCC High Current External from RFD4411 Regulation on RFD4411 External from RFD4411 MODULATION RF_POWER CONTROL From Splitter PI-Attenuator (If needed) Input Matching Output Matching 2nd Harmonic Suppression To Antenna/RP SMA or MMCX PA PA_MOD PA_ADJ To LO_DRIVE in b.b section LO Pre-amp PA High current filter RF output power These components are located in their own RF shielded compartment Noise Filters Noise Filters Noise Filters 11 22 33 44 D D C C B B A A 7 MaxID Limited Quatro House, Lyon Way FrimleySurrey GU16 7ER United Kingdom 7 MaxID_4411 Blockdiagram - User interface/PSU RM100_4411 00 7/20/2005 2:14:21 PM C:\work\ProtelProjects\MAXID_DXP\max id_4411\Documents\PROJ\BlockDiagram_4411_psu.SCHDOC TitleSize: Number: Date:File: Revision:Sheet of Time: A3 RS232 or TTL-3v0 level interface TxRx Ext. Power supply interface GND3v2 - 4v2 External User interface 123456789 10 -- On/Off Stat Led Tag Led CPU Load Control/Status lines 3v2 - 4v2 Switched VRAW Switched VRAW Switched VRAW Switched VRAW Switched VRAW Switched VRAW To RFM_4410 (RF_VCC) ADC_3v0ADC_2v5CPU_3v0 Switched VRAW FPGA_3v0FPGA_1v5 Regulators/PSU filters Measure RFAMP current To CPU ADC On/Off 11 22 33 44 D D C C B B A A 4 MaxID Limited Quatro House, Lyon Way FrimleySurrey GU16 7ER United Kingdom 7 MaxID_4411 Blockdiagram - RF Synth RM100_4411 00 7/20/2005 2:14:21 PM C:\work\ProtelProjects\MAXID_DXP\max id_4411\Documents\PROJ\BlockDiagram_4411_synth.SCHDOC TitleSize: Number: Date:File: Revision:Sheet of Time: A3 Switched VRAW SYNTH_3v0 10.0Mhz OSC. SYNTH PWN DATA SCLK EN External from RFD4411 External from RFD4411 RF Pre-amp 3db Splitter To PA_DRIVE These components are located in their own RF shielded compartment To LO_Pre-Drive

Cover Letter(s)

Operational Description

Copyright 2005 MaxID Limited, All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior permission of MaxID. MaxID Limited, Quatro House, Lyon Way, Frimley, Surrey GU16 7ER, United Kingdom Phone: +44 (0) 1276 80 4498, Fax: +44 (0) 1276 80 4499, URL: www.MaxIDcorp.com !" #%$ ! & " ' MaxID RM100 RFID reader interface Project - RFID ID1209 Version 0.1 21 September, 2005 Page ii Change History Configuration Control Project: RFID Title: MaxID RM100 RFID reader Technical Description Document ID: 1209 Created by: Riaan van den Berg Creation Date: 21 September 2005 Document History Version Date Status Who Saved as: Revision History Version Date Changes 0. 1 2005/0/21 Initial release. Management Authorisation Version Date Status Approval Minutes Reference MaxID RM100 RFID reader interface Project - RFID ID1209 Version 0.1 21 September, 2005 Page iii Table of Contents 1. Introduction ________________________________________________ 4 2. FCC Statement ______________________________________________ 5 WARNING ! ____________________________________________________ 5 3. Limitation of Liability_________________________________________ 6 4. Functional Block diagram _____________________________________ 7 5. Block diagram Description ___________________________________ 14 5.1 Digital Board – RFD4411 ___________________________________ 14 5.1.1 Power supply unit _______________________________________ 14 5.1.2 Micro controller _________________________________________ 14 5.1.3 Digital Signal Processing _________________________________ 15 5.2 RF board - RFM4411 _______________________________________ 16 5.2.1 Synthesizer ____________________________________________ 16 5.2.2 Power amplifier (PA) _____________________________________ 16 5.2.3 Receiver ______________________________________________ 17 5.2.4 Base band_____________________________________________ 17 6. RF Channel Management ____________________________________ 18 7. Internal frequencies_________________________________________ 19 8. Specification_______________________________________________ 20 8.1 Performance _____________________________________________ 20 8.2 Physical _________________________________________________ 20 8.3 Environment _____________________________________________ 20 MaxID RM100 RFID reader interface Project - RFID ID1209 Version 0.1 21 September, 2005 Page 4 of 20 1. Introduction The RM100 from MaxID Ltd is a multi-protocol radio frequency identification (RFID) reader designed to support all electronic product code (EPC)-compliant UHF RFID tags. The RM100 is an industrial-class OEM (Original Equipment Manufacturer) reader that provides all of the RFID control functions required to power and communicates with passive RFID tags. The RM100 was designed to integrate into handheld portable data terminals, printers, label applications, mobile computers and other OEM devices. It is a high-performance reader that collects, writes, processes and communicates information from all classes of EPC RFID tags. The RM100 leverages advanced digital filter technology to deliver superior interference management and are optimized to read tags in both clean and noisy radio environments. MaxID RM100 RFID reader interface Project - RFID ID1209 Version 0.1 21 September, 2005 Page 5 of 20 2. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING ! This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. MaxID RM100 RFID reader interface Project - RFID ID1209 Version 0.1 21 September, 2005 Page 6 of 20 3. Limitation of Liability In no event shall MaxID Ltd. or anyone else involved in the creation, production or delivery of the accompanying product (including hardware and software) be liable for any damages whatsoever (including, without limitation, consequential damages including loss of business profits, business interruption or loss of business information) arising out of the use of or the results of use of or inability to use such product, even if MaxID Ltd. has been advised of the possibility of such damages. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. MaxID RM100 RFID reader interface Project - RFID ID1209 Version 0.1 21 September, 2005 Page 7 of 20 4. Functiona…

Text truncated - open the document above for the full version.

Operational Description

Copyright 2004 MaxID Limited, All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior permission of MaxID. MaxIDLimited,QuatroHouse,LyonWay,Frimley,SurreyGU167ER,UnitedKingdom Phone:+44 (0) 1276 80 4498,Fax:+44 (0) 1276 80 4499, URL: www.maxidcorp.com MaxID RM100 Operational manual #$&' ( )* MaxID RM100 Operational manual Project - RFIDID 1147Version 1.213 September, 2005Page ii Change History Configuration Control Project:RFID Title:MaxID RM100 Operational manual Document ID:1147 Created by:Selwyn Jackson Creation Date:11 October 2004 Document History Version DateStatusWho Saved as: 0. 1 2004/10/11 Revised SJQ:\SygadeDocs\Projects\RFID_m icro50\Documentation\MaxID P100 RFID reader interface.doc 0. 2 2005/03/07 Revised SJQ:\SygadeDocs\Projects\RFID_m icro50\Documentation\MaxID P100 RFID reader interface.doc 1. 02005/03/11 Approved SJQ:\SygadeDocs\Projects\MAXid_ P100_(44xx)\Documentation\RM 100 RFID reader interface.doc 1. 1 2005/03/16 Revised SJQ:\SygadeDocs\Projects\MAXid_ P100_(44xx)\Documentation\RM 100 RFID reader interface.doc 1. 2 2005/07/06 Revised SJQ:\SygadeDocs\Projects\MAXid_ P100_(44xx)\Documentation\Max ID RM100 RFID reader interface.doc Revision History Version DateChanges 0. 1 2004/10/11 Initial release. 0. 2 2005/03/07 Added FCC statement and label. 1. 02005/03/11 Updated product name. 1. 1 2005/03/16 Updated baudrate to 38400, even parity. Added hopping and filter commands. Added repeat read (RR) command. Added debug mode. 1. 2 2005/07/06 Synchronised document. Management Authorisation Version DateStatusApproval Minutes Reference 1. 0 2005/03/11 Approved SJ, CW MaxID RM100 Operational manual Project - RFIDID 1147Version 1.213 September, 2005Page iii Table of Contents 1. Scope _____________________________________________________ 4 Introduction___________________________________________________ 4 Purpose______________________________________________________ 4 Physical interface ______________________________________________ 4 Definitions ____________________________________________________ 4 Supporting Documents __________________________________________ 5 Limitation of Liability ____________________________________________ 6 FCC compliance _______________________________________________ 7 FCC statement ________________________________________________ 7 Note ________________________________________________________ 7 Label________________________________________________________ 7 2. Simple interface _____________________________________________ 8 Introduction___________________________________________________ 8 Commands ___________________________________________________ 8 Modes_______________________________________________________ 9 IPX _________________________________________________________ 9 EPC Class 1 _________________________________________________ 10 EPC 1.19____________________________________________________ 10 3. Debug mode_______________________________________________ 11 Introduction__________________________________________________ 11 Commands __________________________________________________ 11 4. Old compatibility mode ______________________________________ 13 Introduction__________________________________________________ 13 Commands __________________________________________________ 13 Reading mode________________________________________________ 14 5. Number conversions ________________________________________ 15 Introduction__________________________________________________ 15 EAN numbers ________________________________________________ 15 EPC 1.19____________________________________________________ 16 Example 1___________________________________________________ 17 Example 2___________________________________________________ 17 MaxID RM100 RFID reader interface Project - RFIDID 1147Version 1.213 September, 2005Page 4 of 17 1. Scope Introduction The RM100 RFID reader/writer makes use of a simple interface at present. The simple interface used at present is sufficient for demonstration and evaluation purposes. The simple interface provides access to the setting up of the RFID reader as well as reading and writing various types of tags. This interface will be upgraded to the new EPCGlobal Reader interface when this specification is stabilised. Purpose This document has been provided as a reference for developers making use of the RM100 RFID reader using the simple protocol. Physical interface The RM100 reader is connected via an RS232 serial interface. The parameters for the interface are: Speed:38400 bits/sec Bits per character: 8 Parity:Even Stop bits:1 Definitions TermDefinition End-of-document marker EPCElectronic Product Code EPC 1.19Philips’ version of EPC tag based on the UCODE tag [7] EPC Class 1First generation Class 1 EPC tags based on Auto- Id Centre specification [4] EPC Gen 2EPCGlobal Class 1 Generation 2 UHF RFID [6] ETSIEuropean Telecommunications Standards Institute FCCFederal Communications Commission (USA) IPX“Tag talks first” tag [3] RFIDRadio Frequency Identification (tags) UCODEPhilips’ tags based on ISO18000-6 type B [2] 868 MHzETSI frequencies Single channel in 869.4 to 869.65 MHz [10] [11] 15 channels in 865.0 to 868.0 MHz [12] MaxID RM100 RFID reader interface Project - RFIDID 1147Version 1.213 September, 2005Page 5 of 17 TermDefinition 915 MHzFCC frequencies 50 channels from 902.75 MHz to 927.25 MHz in 500 KHz steps using frequency hopping Supporting Documents [1]EPCTM Tag Data Standards Version 1.1 Rev.1.24 – EPCglobal Standard Specification – 1 April 2004. http://www.epcglobalinc.org/standards_technology/EPCTagDataSp ecification11rev124.pdf [2]ISO/IEC FDIS 18000-6 Information technology – Radio-frequency identification for item management – Part 6: Parameters for air interface communications at 860 MHz to 960 MHz …

Text truncated - open the document above for the full version.

RF Exposure Info

MaxID RM100 RFID reader interface Project - RFID ID1170 Version 0.1 18 October, 2005 Page 12 of 24 6.4 Installing the software Insert the CD-ROM into drive. Under windows select “Run” “Browse” from the start menu Choose setup.exe from the CD-ROM and follow the easy steps displayed on the PC 6.5 Installing the Patch Antennas The RM100 Module can operate from a single antenna (combining with a circulator) or from a dual antenna set. Studies show that, in order to be exposed to RF levels that approach the safety limits adopted by the FCC, it would be necessary to remain very close to a UHF RFID antenna for a significant amount of time. For further information on this topic refer to the Web sites at www.fcc.gov/cgb www.fcc.gov/oet/rfsafety 6.5.1 Dual Antenna set For the dual antenna configuration, mount the antennas 500mm apart (centre-to- centre). Mounting the two antennas closer or further apart will have a decrease in tag read range. Never perform tests when the two antennas are facing each other with less than 50mm separation. It might cause permanent damage the module 500mm A minimum separation distance of 30cm to 60cm has been suggested as a way to minimize exposure to the human body.

Test Report

TRL COMPLIANCE LTD EMC DIVISION M OSS VIEW NIPE LANE UP HOLLAND WEST LANCASHIRE WN8 9PY UNITED KINGDOM T ELEPHONE +44 (0)1695 556666 FAX +44 (0)1695 557077 E-MAIL [email protected] www.trlcompliance.com 0728 FS 21805 TEST REPORT NO: RU1178/6435 COPY NO: 2 ISSUE NO: 1 FCC ID: TFT-RM100 REPORT ON THE CERTIFICATION TESTING OF A MAXID LIMITED RM100 WITH RESPECT TO THE FCC RULES CFR 47, PART 15.209 and 15.247 INTENTIONAL RADIATOR SPECIFICATION TEST DATE: 21 st June 2005 – 25 th June 2005 TESTED BY: D WINSTANLEY APPROVED BY: P GREEN PRODUCT MANAGER DATE: 20 September 2005 Distribution: Copy Nos: 1. MAXID LIMITED 2. FCC EVALUATION LABORATORIES 3. TRL EMC THIS DOCUMENT MAY BE REPRODUCED ONLY IN ITS ENTIRETY AND WITHOUT CHANGE RU1178/6435 Page 2 of 110 CONTENTS PAGE CERTIFICATE OF CONFORMITY & COMPLIANCE 3 APPLICANT’S SUMMARY 4 EQUIPMENT TEST CONDITIONS 5 TESTS REQUIRED 6 SAMPLE CALCULATIONS 6 TEST RESULTS ANNEX PHOTOGRAPHS A APPLICANT’S SUBMISSION OF DOCUMENTATION LIST B CARRIER FREQUENCY SEPARATION C NUMBER OF HOPPING CHANNELS PLOT D 20dB BANDWIDTH PLOT E TIME OF OCCUPANCY F PEAK POWER CONDUCTED G CONDUCTED SPURIOUS EMISSIONS - TRANSMIT H RADIATED SPURIOUS EMISSIONS - TRANSMIT I BAND-EDGE EMISSIONS CONDUCTED J POWERLINE CONDUCTED EMISSIONS - TRANSMIT K CONDUCTED SPURIOUS EMISSIONS - RECEIVE L RADIATED SPURIOUS EMISSIONS - RECEIVE M POWERLINE CONDUCTED EMISSIONS - RECEIVE N Notes: 1. Component failure during test YES NO [ ] [X] 2. If Yes, details of failure: 3. The facilities used for the testing of the product contain in this report are FCC Listed. 4. The contents of the attached applicants declarations and other supplied information are not covered by the scope of this laboratory’s UKAS or FCC accreditations’ and is provided in good faith. RU1178/6435 Page 3 of 110 CERTIFICATE OF CONFORMITY & COMPLIANCE FCC IDENTITY: TFT-RM100 PURPOSE OF TEST: CERTIFICATION TEST SPECIFICATION: FCC RULES CFR 47, Part 15.247, April 2005 TEST RESULT: Compliant to Specification EQUIPMENT UNDER TEST: RM100 EQUIPMENT SERIAL No: Engineering sample EQUIPMENT TYPE: UHF RFID Tag Reader PRODUCT USE: Wireless tag reader CONDUCTED CARRIER EMISSION: 769.59mW ANTENNA TYPE: Plate Antenna ALTERNATIVE ANTENNA: Handheld Antenna CHANNEL SPACING: Not Applicable. Wideband FREQUENCY GENERATION. SAW Resonator [ ] Crystal [ ] Synthesiser [X] MODULATION METHOD: Amplitude [ ] Digital [X] Angle [ ] POWER SOURCE(s): 6Volts dc TEST DATE(s): 21 st June 2005 – 25 th June 2005 ORDER No(s): PO00009204 APPLICANT: MaxID Limited ADDRESS: Hillswood…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Steve Bowen(Mr)

[email protected]7572136863Fax: 7572136801

Technical Contact

MaxID LtdRoger Biggs

[email protected]+44 1932 895396

3000 Hillswood business Park · Surrey · United Kingdom

Test Firm

TRL Compliance LtdJohn Charters

[email protected]44-1695-556666Fax: 44-1695-557077

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Tolerance
1	15C	902 MHz - 928 MHz	1 W	10.0000000000 ppm

Confidentiality

Long Term

Grant Notes

Module for integration into RFID reader equipment. Note RF exposure distance criteria must be complied with.
