TG6T433MDT2Transmitter

RCS-433MDT2 USER MANUAL Thank you for choosing a RCS transmitter. It is recommended that you read this manual carefully before using the transmitter. CONTENTS 1- TRANSMITTER INTRODUCTION 1A - General Information 1B - Technical Specifications 1C - Main Features 1D - Model Types 2- CODING 3- MEMORIZATION 4- BATTERY AND DIP-SWITCH ACCESS 5- TROUBLESHOOTING 1 - TRANSMITTER INTRODUCTION 1A - General Information • The radio control, RCS-433MDT2 has been designed for the control of automatic closing systems and anti-burglar systems. The operating frequency is 433,92 MHz. • The receiver can be used to control automatic gates, rolling shutters, awnings, anti-burglar appliances, lighting etc. • The transmitter security code is obtained by means of a 9 way three-state dip-switch, which allows up to 19683 codes combinations. All the receivers can store up to 50 different dip-switch code combinations. • Each transmitter (or its different keys)can be stored into different receivers and hence can do more functions. • In order to use the unused keys of the transmitter connect the dedicated receiver to the mechanism to drive (i.e. electro lock of a pedestrian gate, a buzzer, etc. ). • The product fully complies with Part 15 of FCC Regulations. 1B - Technical specifications Number of keys: . . . . . . . . . . . . . . . . . . . . . . . . . .2 Battery duration: . . . . . . . . . . . . . . . . . .12 - 24 months Battery type: . . . . . . . . . . . . . . . . . . . . . . . .23A (L1028) Current consumption: . . . . . . . . . . . . . . . . . . . . .25 mA Operating frequency: . . . . . . . . . . . . . . . . .433.92 MHz Security code combinations number: . . . . . . . . .19683 Modulation: . . . . . . . . . . . . . . . . . . . . . . . . . . .AM/ASK E.r.p.: . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 - 100 uW Range in open space: . . . . . . . . . . .from 100 to 200 m Operating temperature: . . . . . . .from -10 °C to +55 °C Dimensions: . . . . . . . . . . . . . . . . . . . . .1.75 x 1 x .3 in. Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..7 oz. 1C - Main Features 1D - Model Types 2 button dip-switch transmitter: Model #: RCS-433MDT2 2 - CODING Slide open the door to access to the battery and the dip-switches. The dip-position will give the security code. Warning:Each transmitter is set-in-factory with the same code on the dip-switches; it highly advisable to change this code by moving the dip-switches to any random position ( “+”, “0” , “-”). 3 - MEMORIZATION Each dip-switch setting code has to be stored into the receiver memory. The memorization can be done by self-learning. The instructions for this operation is given on the receiver installation manual. Your own installer will perform this operation during the installation or will give you the necessary explanation during installation. 4 - BATTERY AND DIP-SWITCH ACCESS To access the battery, slide the battery door down. Place the 23A alkaline battery between the 2 contacts. Respect the right polarity as indicated on the bottom of the box. NOTE:Please dispose of the batteries correctly, they are hazardous waste. 5 - TROUBLESHOOTING FAULTSOLUTION The radio signal is not verifiableReplace the transmitter battery The transmitter led doesn't switch onReplace the transmitter battery The radio signal is not verifiableCheck the power supply of the receiver The transmitter led switches onReplace the transmitter battery GUARANTEE The guarantee period of all RCS transmitters is 12 months, beginning from the manufacturer date. During this period, if the product does not work correctly, due to a defective component, the product will be repaired or substituted at the discretion of RCS. The guarantee does not cover the plastic container integrity. After-sale service is supplied at the producer's factory. REMOTE CONTROL SOLUTIONS, LLC 1-866-770-0727 www.rcsremotes.com FCC ID: ____________ This device complies with FCC Rules Part 15 Operation is subject to the following two conditions: 1) This device may not cause harmful interferences; 2) this device must accept interference that may cause undesired operation. Notice: Any changes or modification to RCS equipment not expressly approved by RCS could void the user's authority to operate the equipment. Battery Door Button Channel B Red LED Button Channel A Red LED Battery Door Dip-Switch Battery

Date: 02/20/2006 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the Taiwan office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS TW, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS TW on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS TW as our agent, we still recognize that we are responsible to: a) Comply with the relevant provisions of the certification program; b) Make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) Make claims regarding certification only in respect of the scope for which certification has been granted; d) Do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) Upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) Use certification only to indicate the products are certified as being in conformity with specified standards; g) Endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) Ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) Keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) Take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) Document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Benjaman D. Scanlan (President) Remote Control Solutions, LLC REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

February 20, 2006 Federal Communications Commission Authorization and Evaluation Division FCC ID: TG6T433MDT2 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Operational Description Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Remote Control Solutions, LLC Benjaman D. Scanlan President.

Compliance Certification Services Inc. Report No.: 60306208 Date of Issue: April 3, 2006 Page PHOTOGRAPHS OF EUT

FCC ID LABEL FORMAT AND LOCATION Applicant: Remote Control Solutions, LLC FCC ID: TG6T433MDT2 FCC ID: TG6T433MDT2 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Compliance Certification Services Inc. Report No.: 60306208 Date of Issue: April 3, 2006 Page Compliance Certification Services Inc. Report No.: 60306208 Date of Issue: April 3, 2006 Page

Compliance Certification Services Inc. Report No.: 60306208-RP1 FCC ID: TG6T433MDT2 Date of Issue: April 6, 2006 Page 1 of 22 Rev. 00 FCC ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR of TRANSMITTER FCC ID Number : TG6T433MDT2 Trade Name : RCS Model Number : RCS-433MDT2 Agency Series : N/A Report Number : 60306208-RP1 Date : April 6, 2006 Prepared to Remote Control Solutions, LLC 4862 E. Baseline Rd. Suite #104 Mesa, AZ 85206, USA Prepared by Compliance Certification Services Inc. No. 165, Chung Sheng Road, Hsin Tien City, Taipei Hsien, Taiwan, R. O. C. TEL: (02)2217-0894 FAX: (02)2217-1029 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Compliance Certification Services Inc. Report No.: 60306208-RP1 FCC ID: TG6T433MDT2 Date of Issue: April 6, 2006 Page 2 Rev. 00 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE................................................3 2. PRODUCT DESCRIPTION.................................................................4 3. TEST FACILITY...................................................................................4 4. MEASUREMENT STANDARDS.........................................................4 5. TEST METHODOLOGY.....................................................................4 6. MEASUREMENT EQUIPMENT USED.............................................5 7. POWERLINE RFI LIMIT....................................................................5 8. RADIATED EMISSION LIMITS.........................................................6 9. SYSTEM TEST CONFIGURATION...................................................6 10. TEST PROCEDURE..........................................................................7 11. Equipment Modifications.....................................................................8 12. TEST RESULT....................................................................................9 12.1 Maximum Modulation Percentage (M%)..........................................9 12.2 The Emissions Bandwidth.................................................................9 APPENDIX I............................................................................................10 Compliance Certification Services Inc. Report No.: 60306208-RP1 FCC ID: TG6T433MDT2 Date of Issue: April 6, 2006 Page 3 Rev. 00 1. VERIFICATION OF COMPLIANCE COMPANY NAME : Remote Control Solutions, LLC 4862 E. Baseline Rd. Suite #104 Mesa, AZ 85206, USA CONTACT PERSON : Benjaman D. Scanlan / President TELEPHONE NO. : 1-866-770-0727 EUT DESCRIPTION : TRANSMITTER MODEL NAME/NUMBER : RCS-433MDT2 FCC ID : TG6T433MDT2 DATE TESTED : March 20, 2006 ~ March 23, 2006 REPORT NUMBER : 60306208-RP1 TYPE OF EQUIPMENT SECURITY EQUIPMENT (INTENTIONAL RADIATOR) EQUIPMENT TYPE TRANSMITTER MEASUREMENT PROCEDURE ANSI 63.4 / 2003 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 The above equipment was tested by Compliance Certification Services Inc. for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Warning: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services Inc. will constitute fraud and shall nullify the document. Approved by: Reviewed by: Compliance Certification Services Inc. Report No.: 60306208-RP1 FCC ID: TG6T433MDT2 Date of Issue: April 6, 2006 Page 4 Rev. 00 2. PRODUCT DESCRIPTION Fundamental Frequency 433.92MHz Power Source 12V Battery Transmitting Time Periodic < 5 seconds Associated Receiver RCS -433BR2 (DoC) 3. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at No. 165, Chung Sheng Road, Hsin Tien City, Taipei, Taiwan R.O.C. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 4. MEASUREMENT STANDARDS The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/2003. 5. TEST METHODOLOGY For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) Compliance Certification Services Inc. Report No.: 60306208-RP1 FCC ID: TG6T433MDT2 Date of Issue: April 6, 2006 Page 5 Rev. 00 6. MEASUREMENT EQUIPMENT USED Open Area Test Site # K Name of Equipment Manufacturer Model Serial Number Calibration Due SITE NSA CCS K Site N/A 10/01/2006 MEASURE RECEIVER R&S ESVS30 828488/004 09/26/2006 SPECTRUM ANALYZER ADVANTEST R3132 120900029 No Calibration Required ANTENNA SCHAFFNER CBL 6112B 2846 05/27/2006 PRE- AMPLIFIER SCHAFFNER CPA9231A 3639 10/08/2006 CABLE SUHNER RG 214 N-TYPE #K2 02/17/2007 THERMO- HYGRO METER TFA N/A NO.4 02/08/2007 Above 1GHz Used EMC ANALYZER (100Hz-22GHz) HP 8566B 2937A06102 06/30/2006 ANTENNA (1-18GHz) EMCO 3115 00022256 01/12/2007 AMPLIFIER (1-18GHz) HP 8449B 3008A01266 02/06/2007 CABLE (1-18GHz) JYEBAO LL142 SMA#RS1 02/06/2007 CABLE (1-18GHz) HUBER +SUHNER SUCOFLEX 104 SMA#RS3 02/06/2007 CABLE (1-18GHz) JYEBAO LL142 SMA#C1 02/06/2007 Remark: Each piece of equipment is scheduled for calibration once a year. 7. POWERLINE RFI LIMIT CONNECTED TO AC POWER LINE SECTION 15.207 CARRIER CURRENT SYSTEM IN THE FREQUENCY RANGE OF 450 KHz TO 30 MHz SECTION 15.205 AND SECTION 15.209, 15.221, 15.223, 15.225 OR 15.227, AS APPROPRIATE. BATTERY PO…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 60306208-RP1 FCC ID: TG6T433MDT2 Date of Issue: April 6, 2006 Page 6 Rev. 00 8. RADIATED EMISSION LIMITS GENERAL REQUIREMENTS SECTION 15.209 RESTRICTED BANDS OF OPERATION SECTION 15.205 PERIODIC OPERATION IN THE BAND 40.66 -40.70 MHz AND ABOVE 70 MHz. SECTION 15.231 9. SYSTEM TEST CONFIGURATION Use a block of foam and combined it with EUT wrapping rubber band around it. This way it can test X, Y and Z axis. To activate continuous transmitting & receiving, place a small plastic block between rubber band and EUT push button. Radiated Open Site Test Set-up
