TI7ZE0800DDVD Player

8.5” TFT LCD Monitor with DVD Player ZE0800D User manual Please read it carefully before you operate this player Welcome Thank you for buying the Roof Mount LCD Monitor with DVD player. Please read this manual carefully before using the Roof Mount LCD Monitor with DVD player in order to get the most out of all the features and functions. Keep this manual in a safe place, as it can be a valuable tool in helping you to understand all the features and functions. Contents Safety information.........................................................................1 DVD player features .....................................................................3 Setting up your DVD player ..........................................................7 Using your DVD player .................................................................10 Troubleshooting ............................................................................13 Specification..................................................................................14 Maintaining ...................................................................................15 Operation flow...................................................................16 Safety information Do not operate the unit in any way other than described within this manual. Failure to follow the instructions within the manual will invalidate your warranty. SAFETY FIRST! Do not install the display where it may (i) obstruct the driver’s vision, (ii) impair the performance of any of the vehicle’s operating systems or safety features, including airbags, or (iii) impair the driver’s ability to safely operate the vehicle. When using the system, make sure you are firmly secured by your seat belt to ensure you do not accidentally hit your head on the screen during sudden braking or other incidents. If you are ever in an accident, injuries can be more severe if the seat belt is not properly buckled. Do not attempt to install or service your display by yourself. Installation 1 or servicing of the display by persons without training and experience in electronic equipment and automotive accessories may be dangerous and could expose you to the risk of electric shock or other hazards. Be careful not to drain the car battery while using the unit with the car engine stopped. To avoid draining the battery, it is suggested that the vehicle engine always is running while using the unit. Do not disassemble or alter the unit in any way. Failure to do so can cause damage to the unit and invalid the warranty. Never clean the surface of the screen with chemical solvent or corrosive detergent, which may cause permanent damage to the TFT LCD screen. Avoid installing the unit wherever is under direct sunlight or near hot air vent. Please note that the normal working temperature of the unit is between -5°C to +50°C. If the internal temperature of the vehicle is extremely high, a short cooling down period is necessary before operating the unit. W If the temperature inside the car is very low and the monitor is used soon after switching on the heater, moisture may form on the panel of the unit. Turn off the unit immediately! Failure to do so may cause the internal components to short. Allow the unit to rest for about one hour to allow the condensation to disappear before continue operation. In extremely cold temperatures, the movement of the picture may be slow and the picture may be dark. It is not a malfunction. The unit will work normally once it reaches its operating temperature. Do not drop or hit the LCD panel with a hard object, as it may cause permanent damage to the LCD panel. Should LCD panel break, avoid touching glass and fluid. If do, please clean it with plenty of water and ask for medical attention immediately. Due to different car specifications, please kindly ensue that the display monitor is properly located and not obstructing the air-conditioning vent. Avoid inserting any foreign objects into the slot of the disc Player. Failure to observe this may cause malfunction due to the precise mechanism of this unit. Protect your disc. When you leave the car, be sure to eject the disc from this unit and store it separately away from direct sun light. Heat and humidity may damage the disc and you may not be able to play it again. Use the supplied screws to fix the monitor Metal Mounting Plate. 2 FCC NOTICE: This device complies with part 15 of the FCC Rules. Operation is subject of the following two conditions: (1) this device may not cause harmful interference, and(2) this device must accept any interference received, including interference that may cause undesired operation. DOLBY: Manufactured under license from Dobly Laboratories. “Dolby” and the double-D symbol are trademarks of Dobly laboratories. DVD player features This player is a Roof Mount 8.5" TFT-LCD Color Display with DVD player that can be used as a stand-alone display, or can be integrated into a mobile multimedia system. This player has the following features: 8.5" TFT-LCD color monitor (16:9) Roof Mounting Application Pixel (dots): 234RGB(W) x 480(H) Wide Viewing angle (up/down/left/right): 45/55/65/65 NTSC and PAL Compatible Adjustable Color/Contrast/Brightness/Tint Manual Viewing Angle Adjustment Yellow LED Dome Light Automotive Startup Protection Built-in IR Transmitter for IR Wireless Headphone IR Remote Control On Screen Display 1xAV Input 1xAV Output Slot-in DVD mechanism Capability to read: DVD Format /DVD±R/DVD±RW/CD-DA/CD-RW/MP3 Audio output-FMT: The unit shall have a built in FM Transmitter and an additional Line Audio Out for FMM, with switched12volt control line FM Transmitter for listening the audio from your car audio system via FM radio receiver (setting frequency: 88.1~107.9MHz) Note: Multi-session CDs and 320kbps WMA files cannot be played on this player. 3 DVD VIDEO FEATURES This unit provides the following functions in addition to high image quali…

Text truncated - open the document above for the full version.

Page 6 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Photographs Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT Page 7 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Figure 3 General Appearance of the EUT Figure 4 General Appearance of the EUT Page 8 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Figure 5 General Appearance of the EUT Figure 6 General Appearance of the EUT Label Location

ZE0800D This device complies with FCC Rules Part 15. Operation is subject to the following two conditions:(1) This device may not cause harmful interference and (2) This device must accept any interference that may be received, including interference that may cause undesired operation. FCC ID: TI7ZE0800D 50.00 mm 3 4 . 5 0 m m Page 8 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Figure 5 General Appearance of the EUT Figure 6 General Appearance of the EUT Label Location

Page 9 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Figure 7 Inside of the EUT Figure 8 Inside of the EUT Page 10 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Figure 9 Inside of the EUT Figure 10 Inside of the EUT Page 11 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Figure 11 Inside of the EUT Figure 12 Inside of the EUT Page 12 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Figure 13 Inside of the EUT Figure 14 Inside of the EUT Page 13 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Figure 15 Control board of the EUT Figure 16 Control board of the EUT Page 14 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Figure 17 Inside of the EUT Figure 18 Inside of the EUT Page 15 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Figure 19 Inside of the EUT Figure 20 Inside of the EUT Page 16 Rosen Entertainment Systems All-In-One DVD Overhead System FCC ID:TI7ZE0800D Figure 21 Inside of the EUT FM-T Module Crystal 32.768kHz Band pass filter Antenna

FCC ID:TI7ZE0800D Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F08056 APPLICATION FOR CERTIFICATION On Behalf of Rosen Entertainment Systems All-In-One DVD Overhead System Model Number: ZE0800D; ZE0800D-E1; ZE0801D; ZE0801D-E1; ZE0805D; ZE0805D-E1; ZE0806D; ZE0806D-E1 Prepared for : Rosen Entertainment Systems 1120 California Ave., Corona, CA 92881 United States Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755) 26639496 Report Number ： ACS-F08056 Date of Test ： Jan.14~15, 2008 Date of Report ： Jan.31, 2008 FCC ID:TI7ZE0800D Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F08056 TABLE OF CONTENTS Description Page Test Report Declaration 1. SUMMARY OF STANDARDS AND RESULTS .................................................................. 1-1 1.1. Description of Standards and Results.............................................................................................1-1 2. GENERAL INFORMATION .................................................................................................. 2-1 2.1. Description of Device (EUT) .........................................................................................................2-1 2.2. Test Facility....................................................................................................................................2-2 2.3. Test Uncertainty .............................................................................................................................2-2 3. POWER LINE CONDUCTED EMISSION TEST................................................................ 3-1 4. RADIATED EMISSION TEST ............................................................................................... 4-1 4.1. Test Equipment ..............................................................................................................................4-1 4.2. Block Diagram of Test Setup .........................................................................................................4-1 4.3. Radiated Emission Limit ................................................................................................................4-2 4.4. EUT Configuration on Test............................................................................................................4-2 4.5. Operating Condition of EUT..........................................................................................................4-2 4.6. Test Procedure................................................................................................................................4-2 4.7. Radiated Emission Test Results .....................................................................................................4-3 5. BANDWIDTH TEST................................................................................................................ 5-1 5.1. Test Equipment ..............................................................................................................................5-1 5.2. Test Information .............................................................................................................................5-1 5.3. Test Results ....................................................................................................................................5-1 6. DEVIATION TO TEST SPECIFICATIONS ........................................................................ 6-1 7. PHOTOGRAPHS OF TEST.................................................................................................... 7-1 FCC ID:TI7ZE0800D Page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F08056 1-1 1. SUMMARY OF STANDARDS AND RESULTS 1.1. Description of Standards and Results The EUT have been tested according to the applicable standards as referenced below. EMISSION Description of Test Item Standard Results Conducted Emission Test FCC Part 15: 15.207 ANSI C63.4: 2003 N/A Radiated Emission Test FCC Part 15: 15.209/15.239 ANSI C63.4: 2003 PASS Bandwidth Test FCC Part 15: 15.239 PASS N/A is an abbreviation for Not Applicable. FCC ID:TI7ZE0800D Page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F08056 2-1 2. GENERAL INFORMATION 2.1. Description of Device (EUT) Description : All-In-One DVD Overhead System Model Number : ZE0800D; ZE0800D-E1; ZE0801D; ZE0801D-E1; ZE0805D; ZE0805D-E1; ZE0806D; ZE0806D-E1 Difference among those model no. is appearance color. Test Model No. : ZE0800D Frequency range : 88.1MHz to 107.9MHz manually adjusted with 0.2MHz separation by press up/down buttons. Applicant : Rosen Entertainment Systems 1120 California Ave., Corona, CA 92881 United States Manufacturer : Evervictory Electronic Company Limited Chu Chi management district, Humen town, Dongguan city, Guangdong province, China Date of Test : Jan.14~15, 2008 Date of Receipt : Jan.13, 2008 Sample Type : Prototype production Note: We selected the minimum, the middle and maximum possible frequency ranges of 88.1MHz and 107.9MHz(88.1MHz, 98.1MHz and 107.9MHz) for all test. FCC ID:TI7ZE0800D Page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F08056 2-2 2.2. Test Facility Site Description Name of Firm : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park,Nantou, Shenzhen, Guangdong, China 3m Anechoic Chamber : Jun.13, 2006 File on Federal Communication Commission Registration Number: 90454 3m & 10m Anechoic Chamber : Jan.31, 2007 File on Federal Communication Commission Registration Number: 794232 EMC Lab. : Accredited by DATech, German Registration Number: DAT-P-091/99-01 Feb. 02, 2004 Accredited by NVLAP, USA NVLAP Code: 200372-0 Apr.01, 2007 2.3. Test Uncertainty No. Item Uncertainty Remark 1. Uncertainty for Radiated Emission Test 3.14dB 3m Chamber 2. Uncertainty for Bandwidth Emission Test 0.42×10 -6 dB FCC ID:TI7ZE0800D Page Audix Technology (Shenzhen) Co., Ltd. Repor…

Text truncated - open the document above for the full version.

FCC ID:TI7ZE0800D Page 7-1 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F08056 7. PHOTOGRAPHS OF TEST
