TIJ-BIOTOKENStarSign Bio Token

StarSign ® Bio Token 3.0 USB Token Reference Manual Edition 07.2005 ID No. 30016576 © Copyright 2005 by Giesecke & Devrient GmbH Prinzregentenstr. 159 Postfach 80 07 29 D-81607 München This document as well as the information or material contained is copyrighted. Any use not explicitly per- mitted by copyright law requires prior consent of Giesecke & Devrient GmbH. This applies to any repro- duction, revision, translation, storage on microfilm as well as its import and processing in electronical systems, in particular. Subject to technical changes. © Copyright 2005 by Giesecke & Devrient GmbH - Germany – Prinzregentenstr. 159, P.O. Box 80 07 29, D-81607 München © 2005 Giesecke & Devrient GmbH. All rights reserved The names of the other products mentioned are trademarks of their respective owners. This hardware key is in compliance with the following test specification: CEI EN 61000-4-2; CEI EN 61000-4-3; CISPR22 as required by: CEI EN 61000-6-1, CEI EN 61000-6-2, CEI EN 61000-6-3, CEI EN 61000-6-4 which are specified for the following test: • “ESD Immunity test” • “Radiated radio-frequency and electromagnetic field immunity test” • “Radiated Emission Verification” In compliance with the “Essential Requisites” for the EMC Directive 89/336/EEC. FCC ID: TIJ-BIOTOKEN Giesecke & Devrient GmbH StarSign® Bio Token 3.0 Supply: 5V DC Absorption: 150 mA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT REMARKS Due to the limited space on the product shell, all FCC certification references are on this technical manual. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Contents Reference Manual StarSign® Bio Token 3.0/Edition 07.2005 ID No. 30016576 Contents About StarSign Bio Token 3.0 .............................................................................................. 1 About the Document ........................................................................................................... 2 1Basics3 1.1General Introduction to Biometrics............................................................................. 4 1.2Biometrics, Smart Cards and Tokens .......................................................................... 5 1.3LED Status ................................................................................................................. 6 2 Command Reference9 2.1ENROLL FINGERPRINT............................................................................................... 10 2.2VERIFY FINGERPRINT ................................................................................................ 12 2.3VERSION INFO.......................................................................................................... 14 Appendix15 AOverview of Status Bytes.......................................................................................... 16 BTechnical Specifications............................................................................................ 18 CReference Literature................................................................................................. 19 DGlossary................................................................................................................... 20 Index ............................................................................................................................... 23 Contents Reference Manual StarSign® Bio Token 3.0/Edition 07.2005 ID No. 30016576 About StarSign Bio Token 3.0 Reference Manual StarSign® Bio Token 3.0/Edition 07.2005 1 of 33 ID No. 30016576 About StarSign Bio Token 3.0 Characteristics StarSign Bio Token 3.0 is a USB-PKI token based on the STARCOS 3.0 op- erating system. The token comprises a fingerprint sensor and on-token fingerprint verification functionality. The biometric data never leaves the token. StarSign Bio Token 3.0 is supported by StarSign middleware and can therefore be used for all public key applications supporting MS CAPI (CSP) or PKCS#11. Fingerprint verification can be used instead of – or in addition to – PIN verification, granting a higher user convenience and a real tie between user and token. This is particularly of interest in applications that require non-repudiation. Features Features of StarSign Bio Token 3.0 include: – Based on STARCOS 3.0 operating system – On-token sensor, image processing and biometric verification (on- card matching) – Supported by StarSign middleware; use with all public key applica- tions supporting MS CAPI (CSP) or PKCS#11 – Security system according to 7816-4; secure writing and messaging – Cryptographic authentication and key management – Encryption – Symmetric encryption: DES, 3DES – Asymmetric encryption: RSA-CRT with up to 2048 bits – Support of up to 4 logical channels – Biometric enrollment and verification functionality – LED status indication Related Standards StarSign Bio Token 3.0 adheres to the following standards: – ISO/IEC 7816-3 – ISO/IEC 7816-4 – ISO/IEC 19794-2 More information on the relevant standards may be found in the appen- dix (see ’C Reference Literature’ on page 19). About the Document 2 of 33Reference Manual StarSign® Bio Token 3.0/Edition 07.2005 ID No. 30016576 About the Document Target Group This manual addresses developers and specialists of smart card applica- tions. Required Knowledge In order to use StarSign Bio Token 3.0, you should be familiar with: – Smart card hardware/software – Related ISO/IEC standards – Experience in biometric user authentication and cryptographic ser- vices This document assumes that you have a basic understanding of Mi- crosoft Windows terminology and actions. Should you feel that this is not the case, it is suggested that you refer to yo…

Text truncated - open the document above for the full version.

TECNOLOGIA ELETTRONICA INGEGNERIA DI PRODOTTO pagina 1 STARSIGN BIO TOKEN SLTK-SSBIOTOKENRD-E 1 CSTK-SSBIOTOKEN>C PCB. STAR SIGN BIO TOKEN GND rev C 1 DL2 DILE-HSMG-C190 Led Verde 1.6x0.8 HSMG-C190 AGILENT SMT 1 DL4 DILE-HSMS-C190 Led Rosso 1.6x0.8 HSMS-C190 AGILENT SMT 2 DL1,DL3 DILE-HSMY-C190 Led Giallo 1.6x0.8 HSMY-C190 AGILENT SMT 1 U1 CIIN-USBUF01W6 C.I.USBUF01W 6 USB Upst.termin. SOT323 ST 1 U3 CILI-CM2830SIM23 C.I. CM2830SIM23 Volt. Reg 3.3V SOT23-3 1 FPM1 CIUP-AT77C104BSMT T C.I. AT77C104B-CB08V Atmel Finger Print 1 U6 CIUP-P5CT072SMT C.I P5CT072SMT crypto Philips SSOP20 1 U4 CIUP-STR711FR2T6 C.I. STR711FR2T6 ARM7TDMI 32 bit TQFP64 1 CN2 CMVA-IN-ELAST1 Conn. elas tom. MS-G0.1P 20x2x1.6x0.9Z 1 CN1 CNUS-4PMDIR2SMT Conn. USB 4PM Dir KUSB-SMT2-AP5S-B KYCON 1 C21 COCE-10N50V3S Chip Cap. cer. 10nF/50V X7R 10% 0603 SMT 1 C16 COCE-10U6.3V0S Chip Cap.cer. 10uF/6.3V X5R 10% 1206 SMT 12 C11,C12,C14,C15,C17,C18, C20,C25,C26,C31,C8,C9 COCE-100N25V3S Chip Cap.cer. 100nF/25V Z5U 0603 SMT 2 C22,C23 COCE-12P50V2S Chip Cap. cer. 12pF/50V NPO 5% 0603 SMT 6 C10,C13,C19,C4,C6,C7 COCE-4.7U6.3V0S Chip Cap.cer. 4.7uF/6.3V X5R10% 0805 SMT 1 C24 COCE-47N16V0S Chip Cap.cer. 47nF/16V X7R 0603 SMT Codice: SLTK-SSBIOTOKENRD-E Cliente: INFOSECURITY Documento: 1461-15-BOM-01R1 Data: 08/07/2005 Autore: MARI Verificato: Approvato: MAFFIOLI 2 2 FB1,FB2 INFE-FBM0805PT800 0 Suppr .EMI Ferr. MMZ2012D800B 0805 SMT 1 RTC1 QUAR-32.768KSMT9 32.768KHz CM415 12.5pF 20ppm SMT CITIZEN 1 X2 QUOS-FCXO-05-4M Oscillat. 4 MHz 3.3V FCXO-05 River SMT 2 R14,R15 RET5-0R16SMT Chip Res. 0 ohm 1/16W 5% 0603 SMT 1 R25 RET5-1K16SMT Chip Res. 1 kohm 1/16W 5% 0603 SMT 2 R21,R22 RET5-10K16SMT Chip Res. 10 kohm 1/16W 5% 0603 SMT 1 R26 RET5-2.2K16SMT Chip Res. 2.2 kohm 1/16W 5% 0603 SMT 2 R23,R24 RET5-47K16SMT Chip Res. 47 kohm 1/16W 5% 0603 SMT 4 R17,R18,R19,R20 RET5-470R16SMT Chip Res. 470 ohm 1/16W 5% 0603 SMT 1 Q1 TRMO-BSH205 Trans. BSH205 MO S P 12V/1A SOT23 SMT

FCC.TR. TEST REPORT 05.554 Prima Ricerca & SviluppoSrl soggetta a direzione e coordinamento da parte della Giovanni Maspero & C. S.p.A. – C.I. 02634780130 Sede legale : 22100 Tavernola (CO) Via Conciliazione, 1 Cod. FISC. e N. R.I. CO 02635860139 Sede operativa : Laboratori Via Campagna, 92 22020 Faloppio fraz. Gaggino (CO) Tel. +39 03135000.11 Fax +39 031991309 Edition: 1.0 Issue date: 24/05/05 sheet 1 of 14 EQUIPMENT UNDER TEST : APPARECCHIO IN PROVA : USB ELECTRONIC KEY STARSIGN BIO TOKEN REFERENCE STANDARDS : NORME DI RIFERIMENTO : FCC 47 CFR Part 15 CUSTOMER: RICHIEDENTE: • Dept. / Firm : Ente / Società’: GIESECKE & DEVRIENT GmbH • Mr.: Sig.: Harald Gerber • Address: Indirizzo: Prinzregentenstrasse, 159- Munich Germany • Tel. : Telefono : ++49 89-41192231 • Telefax Fax : ++49 89-41192802 • E-mail: e-mail [email protected] Site of test execution: Via Campagna, 92 - 22020 Gaggino Faloppio (CO) - Italy Località esecuzione prove: Date of test samples receipt: 23/05/05 Date of start test: 24/05/05 Data ricevimento campioni: Data inizio prove: Date of end test: 24/05/05 Data fine prove: Witness to the test: Presenti alle prove: Signature of the engineers: Firma esecutore prove: Signature of the Laboratory Director: Firma Direttore Laboratori: Mr. Maffioli ......................................................... .......................................................... M.Maltempi .......................................................... R. Furfari The test results recorded in this Test Report are exclusively referred to the tested samples. I risultati del presente rapporto di prova si riferiscono esclusivamente al campione sottoposto a prova. Reproduction of this EMC-Test Report in whole or in part is prohibited without the written authorization of the Laboratory Director La riproduzione di questo Rapporto in modo parziale o totale è PROIBITO senza l’autorizzazione scritta della Direzione del Laboratorio FCC.TR. TEST REPORT 05.554 Prima Ricerca & SviluppoSrl soggetta a direzione e coordinamento da parte della Giovanni Maspero & C. S.p.A. – C.I. 02634780130 Sede legale : 22100 Tavernola (CO) Via Conciliazione, 1 Cod. FISC. e N. R.I. CO 02635860139 Sede operativa : Laboratori Via Campagna, 92 22020 Faloppio fraz. Gaggino (CO) Tel. +39 03135000.11 Fax +39 031991309 Edition: 1.0 Issue date: 24/05/05 sheet 2 of 14 0. CONTENTS Page Rev Date 0. CONTENTS .............................................................................................. 2 1. TECHNICAL INFORMATION OF EQUIPMENT UNDER TEST (EUT) ..... 3 1.1 Identification ...................................................................................... 3 1.2 Technical data ................................................................................... 3 1.3 Modifications incorporated in E.U.T................................................... 3 1.4 Ports identification ............................................................................. 4 1.5 Auxiliary equipment........................................................................... 4 2. TEST CONDITIONS ................................................................................. 5 2.1 Operating test modes and test conditions......................................... 5 2.2 Test overview .................................................................................... 5 3. REFERENCE STANDARD FOR PERFORMED TESTS .......................... 6 4. Summary of test results ............................................................................ 7 4.1 Emission tests ................................................................................... 7 5. TEST RESULTS ....................................................................................... 8 6. EUT TECHNICAL DOCUMENTATION................................................... 12 6.1 Wiring diagrams............................................................................... 12 6.2 Technical manual............................................................................ 12 6.3 Photographic documentation ........................................................... 13 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 24-05-05 FCC.TR. TEST REPORT 05.554 Prima Ricerca & SviluppoSrl soggetta a direzione e coordinamento da parte della Giovanni Maspero & C. S.p.A. – C.I. 02634780130 Sede legale : 22100 Tavernola (CO) Via Conciliazione, 1 Cod. FISC. e N. R.I. CO 02635860139 Sede operativa : Laboratori Via Campagna, 92 22020 Faloppio fraz. Gaggino (CO) Tel. +39 03135000.11 Fax +39 031991309 Edition: 1.0 Issue date: 24/05/05 sheet 3 of 14 1. TECHNICAL INFORMATION OF EQUIPMENT UNDER TEST (EUT) 1.1 Identification Brand name: GIESECKE & DEVRIENT GmbH Manufacturer: EUTRON INFOSECURITY S.r.l. Equipment : USB ELECTRONIC KEY Model name or No. : STARSIGN BIO TOKEN Serial number : Not present FCC ID : TIJ-BIOTOKEN Country of manufacturer: ITALY 1.2 Technical data FCC class: Unintentional radiators, Class B Supply voltage: +5 V dc supplied by USB PC connector Input Power / Current : 150 mA max. Maximum internal frequency generated by EUT 12MHz (max external frequencies); 48MHz (internal ARM core frequency) Typical usage : Document crypting EUT single or system: Single EUT dimensions : 10,6 x 3,2 x 1,5 cm 1.3 Modifications incorporated in E.U.T. The following items are the modifications introduced in the equipment under test : • None FCC.TR. TEST REPORT 05.554 Prima Ricerca & SviluppoSrl soggetta a direzione e coordinamento da parte della Giovanni Maspero & C. S.p.A. – C.I. 02634780130 Sede legale : 22100 Tavernola (CO) Via Conciliazione, 1 Cod. FISC. e N. R.I. CO 02635860139 Sede operativa : Laboratori Via Campagna, 92 22020 Faloppio fraz. Gaggino (CO) Tel. +39 03135000.11 Fax +39 031991309 Edition: 1.0 Issue date: 24/05/05 sheet 4 of 14 1.4 Ports identification This section con…

Text truncated - open the document above for the full version.
